TARGA

TARGA INTERACTIVE PRINT Download the free Layar App Scan this page Discover interactive content The front finish of the luminaire can be customized to better merge into the architectural setting. Visit get.layar.com and download the application onto your smartphone or tablet. Focus on the pages with the symbol to discover interactive info. SCAN WITH

PRISMA ARCHITECTURAL Prisma Architectural Design CO 2     1150  Kg 25 40 -37,5% 10 CO 2     1840  Kg Using the LED versions, while installing the same number of luminaires, reduces CO 2  emissions by  37.5%, compared to the metal halide versions. 2 x 35 W METAL   HALIDE TREES REqUIRED   TO COMPEnSATE   fOR EMISSIOnS 3 + 3   POWER LED   46,8 W TREES REqUIRED   TO COMPEnSATE   fOR EMISSIOnS fIxTURES THAT  REMAIn SWITCHED  On fOR 1 yEAR,   12 On 24 HOURS Targa is a large outdoor wall-mounted luminaire designed for impressive lighting effects on facades and arcades. The choice of various emissions (wall washer, asymmetrical, concentrated) in various up/down combinations, and the available LED or metal halide light versions make Targa a highly versatile solution.With an additional frame, the painted aluminium front of the luminaire can be coated with plaster to achieve the same finish as the wall on which it is installed, thus reducing the visual impact of the luminaire and enhancing the light effects.Targa is ideal for outdoor architectural lighting, for public buildings, hotels and business places. SCAN WITH

F1 N F2 L2 L1 F1 N F2 L2 L1 All Targa versions with  up/down emission are designed for individual switching of light sources.

321 418 188 51 140 210 102 TARGA W  3 LED - 23,4 W W  3+1 LED - 31,2 W W  3+3 LED - 46,8 W 2  GU6,5  1x35 W MT 2  GU6,5  2x35 W MT h 4 m d 20 m p 6 m p 6 m 0 1 2 3 4 5 6 7 9 8 10 11 12 13 14 15 16 17 19 18 20 1 2 3 4 5 6 9 8 8 7 7 6 6 5 5 4 4 3 3 2 2 1 1 2 lux lux Ground isolux with 302955 1 2 1 3 4 5 6 8 7 9 4 6 3 5 8 7 3 LED - 23,4 W - 3000 K GU6,5 - 1x35 W MT 0 1 2 3 4 5 6 7 9 8 10 11 12 13 14 15 16 17 19 18 20 1 2 3 4 5 6 lux lux Ground isolux with 302948 10 lux 5 2 1 1 2 20 40 60 80 1 5 1 2 10 40 60 2 20 80 ¬  Lenses designed and engineered by  Performance in Lighting ®   ¬  AL En 44100 die-cast aluminium body  and trim with low copper content ¬  Version for GU6.5 metal halide lamp with  asymmetrical floodlights in pure anodi-zed and brushed 99.8% aluminium ¬  316 stainless steel A2 screws¬  Annealed silicon gaskets¬  LED driver included¬  Luminaires supplied with LED circuit¬  IP 66¬  IK06 1J xxx¬  Class I¬  Colour rendering index CRI 80        ¬  LED circuit designed in compliance with  the current Lumen Maintenance (LM80) regulation, with reliable quality of light for a life of 50,000 hours, corresponding to L70 Ta 25°C. Luminaire, driver and other components that differ from the LED circuit not included. ¬  Separate standard switch selectors for  each double emission model Versions available on request:for 2 x 26 W  Gx24q3 fluorescent lamps for 2 x 35 W  E27 metal halide lamps Customization ring  GR3  310402 description  colour code Double emission Targa luminaires create a decorative effect on colonnades and facades, while also lighting up the pedestrian path below, if present. Lenses that control light beams have been designed by Performance in Lighting and specially produced for Targa luminaires.

GR3 66 328 425 140° 60° 120° 30° 140° 5° 60° 15° 120° 10° 30° 30° 120° 120° 30° 30° 140° 140° 60° 60° C 0°-  C 180° cd/Klm 90° 105° 105° 120° 120° 90° 0° 30° 15° 45° 45° 60° 60° 75° 75° 180° 90 180 270 360 C 90° cd/Klm 90° 105° 105° 120° 120° 90° 0° 30° 15° 45° 45° 60° 60° 75° 75° 180° 90 180 270 360 C 0°-  C 180° C 90° cd/Klm 90° 105° 105° 120° 120° 90° 0° 30° 15° 45° 45° 60° 60° 75° 75° 180° 90 180 270 360 C 0°-  C 180° C 90° -  C 270° cd/Klm 90° 105° 105° 120° 120° 90° 0° 30° 15° 45° 45° 60° 60° 75° 75° 180° 90 180 270 360 C 0°-  C 180° C 90° -  C 270° cd/Klm 90° 105° 105° 120° 120° 90° 0° 30° 15° 45° 45° 60° 60° 75° 75° 180° 90 180 270 360 cd/Klm 90° 105° 105° 120° 120° 90° 0° 30° 15° 45° 45° 60° 60° 75° 75° 180° 90 180 270 360 TARGA A MDischarge - electronic ballast GU6,5  1x35 W  MT  GR3  I  66    •   IK06 1J  •   302948  TARGA WW MPower LED 3 LED - 23,4 W  GR3  I  66    • 3000 IK06 1J  •   302955  3 LED - 23,4 W  GR3  I  66    • 4000 IK06 1J  •   302954  TARGA C/WW BPower LED 3+1 LED - 31,2 W  GR3  I  66    • 3000 IK06 1J  •   302953  3+1 LED - 31,2 W  GR3  I  66    • 4000 IK06 1J  •   302951  TARGA C/A BDischarge - electronic ballast  GU6,5  2x35 W  MT  GR3  I  66    •   IK06 1J  •   302947  TARGA WW BPower LED 3+3 LED - 46,8 W  GR3  I  66    • 3000 IK06 1J  •   302952  3+3 LED - 46,8 W  GR3  I  66    • 4000 IK06 1J  •   302950  TARGA A BDischarge - electronic ballast GU6,5  2x35 W  MT  GR3  I  66    •   IK06 1J  •   302946                   Cos  φ  lampholder w  ILCOS  colour  class  IP  ß  X  Kelvin  F  ≥ 0,9  EEI  code  notes Powder polyester painting process optimized against UV rays in 13 different steps.Mat/glossy finish. LED Energy class: LED Energy class: LED Energy class:

PRISMA ARCHITECTURAL The frame, which is available as an accessory, allows panel installation on the luminaire front, which can be plastered with the same finish as the wall on which it will be installed. Installation of the luminaire is facilitated by a plate designed to be fitted to the wall.Bulbs can be easily replaced. SCAN WITH

PRISMA ARCHITECTURAL ®  is a brand of  PERFORMANCE IN LIGHTING S.p.A.9/11, viale del Lavoro - 37030 Colognola ai Colli (VR) - Italytel +39.045.61.59.211  fax export +39.045.61.59.393www.performanceinlighting.com All informations presented in this catalogue may be subject to  modifications. The company reserves the right to make any   changes if necessary without prior notice.   Partial or complete reproduction of this catalogue is prohibited.  This document includes interactive contents PRISMA ARCHITECTURAL supply and manufacture technically designed products, suitable for various types of outdoor lighting installations, combining design with high quality materials and lighting performance. Wall-mounted, pole-mounted  and recessed fittings with a high IP  are just some of the solutions  offered by this brand. 1.  Private chalet   Val ferret - Courmayeur - Italy 2.  Head Office of Stone Italiana  Verona - Italy 3.  Olympic Park - Beijing   Chinese People’s Republic En G 09-2013 INTERACTIVE PRINT 1 2 3
