82    SPECTRA LIGHTING  OUTDOOR ARCHITECTURAL CATALOGUE   2011/2012 82 POLE MOUNT URBANSCAPE  LUMINAIRES HEDO MITIS C MITIS D MITIS P

SPECTRA LIGHTING  OUTDOOR ARCHITECTURAL CATALOGUE   2011/2012 83 HEDO

84    SPECTRA LIGHTING  OUTDOOR ARCHITECTURAL CATALOGUE   2011/2012 The Hedo is a contemporary pole-top luminaire with a distinctive disc shape. This functional luminaire uses highly-efficient light sources to offer high performance but with zero upward lighting component. The broad beam distribution coupled with good uniformity allows for additional space between fittings leading to potential total cost savings. This aesthetic design also possesses retrofit capabilities since it will easily fit many existing pole installations. For example, old inefficient light polluting spheres can be quickly and easily replaced by the Hedo. The Hedo is well suited to various recreational and residential projects as well as paths, walkways and car parks. Three versions are available featuring different lamp configurations (all come complete with integral control gear). Hedo supplied complete with integral electronic control gear Code wattage Lamp Type beam Finish 225280 22W + 55W T5 broad &  symmetrical RAL 7039 Matt Grey 225320 22W + 55W + 60W T5 broad &  symmetrical RAL 7039 Matt Grey 70 Ø500 •  Housing cover - pre-treated and die-cast aluminium•  Pole head - pre-treated and die-cast aluminium with adjustable steel anchoring device to fit 60mm - 76mm mounting poles •  Pure and polished anodised aluminium reflector•  Lens - impact resistant clear UV stabilized polycarbonate•  Distribution - broad and symmetrical•  Stainless steel fixings•  Fitted with automatic isolating terminal switch for safety when cover is open •  Capable of multi-lamp switching•  Available in stainless steel for special applications•  Suitable for separate lamp circuit switching. HEDO FEATURES PRODUCT CODES DIMENSIONS  Measurements mm INSTALLATION & SCALE

SPECTRA LIGHTING  OUTDOOR ARCHITECTURAL CATALOGUE   2011/2012 Hedo supplied complete with integral electronic control gear Code wattage Lamp Type beam Finish 225280 22W + 55W T5 broad &  symmetrical RAL 7039 Matt Grey 225320 22W + 55W + 60W T5 broad &  symmetrical RAL 7039 Matt Grey HEDO RETRO-FIT / ELIMInATE LIGHT pOLLUTIOn  TM 8.0 S S max. IP65 IK 09 17J S S 1m Class II HEDO 55w HEDO 22W + 55W + 60W 85 HEDO VISUALISATION

86    SPECTRA LIGHTING  OUTDOOR ARCHITECTURAL CATALOGUE   2011/2012 MiTis C MiTis D MiTis P The Mitis series features a range of modern pole-top luminaries which are well-suited to lighting minor roads, pathways, parks and malls. Combining aesthetic appeal and performance, the Mitis series offers a point of difference while enhancing the beauty of the surrounds. Three designs are available within the Mitis series - with different sizes, shapes and light distributions. All designs utilise metal halide technology and come with integral control gear. These luminaires are very effective where intrusive light is of concern. •  Die-cast aluminium body, pre-treated and powder   coated for durability •  Mitis C lens - clear heat tempered safety glass lens and frosted acrylic diffuser •  Mitis D lens - clear heat tempered glass lens•  Mitis P lens - impact resistant acrylic prismatic   controller - not glass •  Distribution - symmetrical, forward and side throw options available •  Pole not included. Mitis C supplied complete with lamp and integral ferromagnetic control gear Code wattage Lamp Type Distribution Finish Diameter (mm) 210705 70 MH symmetrical black 700 210725 150 MH symmetrical black 700 Mitis D supplied complete with lamp and integral ferromagnetic control gear Code wattage Lamp Type Distribution Finish Diameter (mm) 210805 70 MH symmetrical black 410 210825 150 MH symmetrical black 410 Mitis P supplied complete with lamp and integral ferromagnetic control gear Code wattage Lamp Type Distribution Finish Diameter (mm) 210855 70 MH symmetrical black 218 MITIS FEATURES PRODUCT CODES

SPECTRA LIGHTING  OUTDOOR ARCHITECTURAL CATALOGUE   2011/2012 TM max. 12.2 max. 9.7 max. 5.6 Mitis C Mitis D Mitis P IP44 0.14 0.85 1.75 3.5 7 25 50 20m 20m 20m MITIs C syMMETRICAL  0.14 0.85 1.75 3.5 7 25 50 100 20m 20m 20m MITIs D syMMETRICAL  0.140.851.75 3.5 7 25 25m 25m 25m MITIs p syMMETRICAL  MITIs D MITIs C MITIs p Class I Ø700 Ø430 Ø218 912 930 1042 Suggested pole height: 3800 Suggested pole height: 3800 MITIS C, D & P SPIGOT = Ø89.1 x 130MM Ø114.3 Ø114.3 Ø114.3 MITIS DIMENSIONS  Measurements mm INSTALLATION & SCALE VISUALISATION 87 S S
