Medium Voltage YOUR ENERGY, OUR SYSTEMS, ANYWHERE

Contents Introduction  _________________________________ 3 Cable Components  __________________________ 4 Cable Handling  _______________________________ 7 Product Codes  _______________________________ 8 Health, Safety and Environment  __________ 9 Exploded Cable View  _______________________ 11 Copper 1.9/3.3kV  ______________________________   12 Aluminium 1.9/3.3kV  __________________________ 24 Copper 3.8/6.6kV  ______________________________ 36 Aluminium 3.8/6.6kV  __________________________ 48 Copper 6.35/11kV  ______________________________ 60 Aluminium 6.35/11kV  __________________________   72 Copper 12.7/22kV  ______________________________  84 Aluminium 12.7/22kV  __________________________  96 Copper 19/33kV  _______________________________  108 Aluminium 19/33kV  ___________________________   120 Technical Information  ____________________ 132 General Information  ______________________   141 Whilst every care has been taken in the preparation of this publication, the Prysmian Group take no responsibility for any errors and or omissions. This booklet is intended as a guide only and reference must be made by any person using this booklet to the appropriate Australian/New Zealand Standard and or to local electricity supply authority rulings. The company reserves the right to make changes in product without notice. All rights reserved. Subject to change without notice.

3 Introduction ONE LEADER, TWO BRANDS The world’s largest cable company, the Prysmian Group, consists of Prysmian and Draka which are two of the world’s most respected commercial brands in the industry. With subsidiaries in 50 countries, almost 100 manufacturing plants, 17 Research & Development Centres and around 22,000 employees, the Prysmian Group is truly a global company. Proudly manufacturing in Australia since 1940, Prysmian understands local standards and conditions and our products are designed and developed accordingly. Prysmian specialises in integrated, added value cabling solutions highly customised to the individual specifications of customers. Prysmian operates a Quality Management System compliant with the requirements of ISO 9001:2008 and products are fully supported by the global technical and production capabilities of the Prysmian Group. Prysmian understands local standards and conditions and our products are designed and developed accordingly.

4 THIS MANUAL CONTAINS TECHNICAL INFORMATION ON A WIDE VARIETY OF COMMONLY USED MEDIUM VOLTAGE (MV) POWER CABLES MANUFACTURED TO AUSTRALIAN STANDARD AS/NZS 1429.1.  Full constructional and technical details are given for Prysmian’s standard range of MV power cables. Other constructions and variants are available by special order. For standard industrial applications, XLPE insulation is normally recommended, but for situations where the cable may be continuously subject to wet conditions, the well proven resistance of Prysmian’s EPR compound offers additional security. Both insulation systems have been assessed for long term resistance to water under the two year UNIPEDE test regime and successfully met the criteria. Prysmian’s EPR compound has also met the requirements of more onerous long term tests. The standard oversheaths supplied are either BLACK PVC (5V-90) or a combination of layers of PVC and HDPE to AS/NZS 1429.1, AS/NZS 4026 and AS/NZS 3808. For situations where limiting the emission of smoke and corrosive gases from cables affected by fire is  desirable, the use of Prysmian’s LSOH HFS-90TP sheath to AS/NZS 3808 is recommended. These cables are constructionally and dimensionally the same as AS/NZS 1429.1 cables and employ the same insulation systems but with LSOH sheaths. The tabulated data in this technical manual is valid irrespective of the sheathing option. High-density polyethylene sheath (HDPE) can be supplied where greater impermeability to moisture and greater resistance to abrasion is required for adverse installation conditions, but such sheaths are not recommended in areas of fire risk. Where protection against termites and other invasive insects is required, cables can be supplied with a covering of Nylon 12, or with two helically applied brass or stainless steel tapes. Alternatively Prysmian offer Termitex™ covering as a protection against termites. For protection against rodents, Prysmian recommend the use of armour or steel tapes. Brass or copper tapes provide only limited protection against rodents and specifiers need to be aware of the risk for each installation. Cable Components

5 Prysmian offers a choice of two standard screen sizes for different earth fault requirements for EPR and XLPE cables. For systems with small earth fault levels a light duty screen is offered for protection based on the screens having a nominal short-circuit rating of 3 kA for one second. For systems with high fault levels, a heavy-duty screen is available with a nominal short-circuit rating of 10 kA for one second. i.) Light-duty Screened Cables are for use in circuits protected by fast acting devices such as HRC fuses or systems having low I 2 t earth fault values. ii.) Heavy-duty Screened Cables are designed to carry high earth fault currents comparable with system symmetrical fault currents. They are designed for supply systems having high I 2 t earth fault values. For three core cables, one third of the required screening is nominated for each core, the fault current being assumed to be shared by all screens. The one-second earth fault current ratings are given in the data sheets for each of the medium voltage XLPE and EPR cables. These standard screens can be varied to suit individual system fault requirements. Prysmian has many alternative solutions to meet the demanding problems  faced by Utilities and Contractors in power distribution. The company provides a cable design service capable of servicing your requirements for power cable specification. Prysmian innovation has led to new products including: • New concepts for protection of cable from termites backed by sponsored CSIRO research. • Alternative solutions to armour for protection of cables from impact damage. • EPR COMPACT medium voltage cables have been developed for cost-effective replacement of networks using existing ductwork. These cables have been designed to optimise electrical and mechanical properties in dimensionally smaller cables. This has been accomplished through use of the EPRotenax™ Premium Performance insulation system, which combines maximum current carrying capacity with a rugged outer sheath and sufficient insulation thickness to deliver the same reliable service as the paper cables being replaced. Prysmian can also advise on various tree-retardant insulations and water blocking options. CABLE COMPONENTS

6 CABLE COMPONENTS DESIGNATIONS Each cable type is identified by a reference type designation for ease of reference and a full order designation which fully identifies each cable and should be used on order documentation. Cables are metre marked for ease of installation and inventory control.  All cables are listed with the voltage rating for which the cable is designed, expressed in the form Uo/U, where Uo is the nominal voltage between conductor(s) and earth and U is the nominal voltage between phase conductors. RECOMMENDED USE The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed installations up to the indicated rated voltage at a nominal power frequency in the range 49Hz to 61Hz. Cables to AS/NZS 1429.1 and AS/NZS 4026 are  intended for use either installed in air, directly buried  in the ground or in ducts. Cables with LSOH sheath  have improved fire performance when installed in air and are primarily intended for such locations. Reasonable protection against mechanical damage should be provided. Cables in this technical manual are not specifically designed for use as self-supporting aerial cables, as submarine cables, where exposure to excessive heat  or corrosive products or solvent substances is involved. In case of any doubt concerning the suitability of a particular cable type for a particular use, guidance should be sought from Prysmian’s Customer  Service Centre.

7 Cable Handling MINIMUM BENDING RADIUS DURING INSTALLATION MINIMUM INSTALLATION TEMPERATURE INTERNAL WIRING IN FREE AIR INDUSTRIAL EQUIPMENT IN GROUND WITH  PROTECTION EXTERNAL BUILDING IN TRENCH IN GROUND IN DUCT DOMESTIC  APPLIANCES MACHINES MOBILE  EQUIPMENT IN CONDUIT SUBMERGED OUTDOOR APPLIANCES OVERHEAD AERIAL FESTOON AMBIENT TEMPERATURE Maximum operating temperatureMinimum operating temperature HALOGEN FREE AS/NZS 4507 MINIMUM BENDING RADIUS Minimum bending radius of installed cables MECHANICAL IMPACT RESISTANCE 1 Light Impact 2 Moderate Impact 3 Heavy Impact 4 Very Heavy Impact RESISTANCE TO SOLAR RADIATION AND WEATHER Excellent Permanent Very Good Frequent Good Occasional Acceptable Accidental Poor None FLEXIBILITY Rigid Flexible Semi-rigid Very flexible LOW SMOKE EMISSION AS/NZS 4507 CHEMICAL RESISTANCE Excellent Permanent Very Good Frequent Good Occasional Acceptable Accidental Poor None BEHAVIOUR IN FLAME AND FIRE Reaction To Fire Resistant To Fire C 1 Fire retardant Level 1 Ultimate fire survival C 2 Flame retardant Level 2 Two hours fire survival C 3 No fire performance Level 3 Restrained spread &   self extinguishing RESISTANCE TO WATER Negligible No humidity Water Drops Occasional condensation Spray Water run off Splashes Exposed to water splashes Heavy Sea Exposed to waves Immersion Temporarily covered by water Submersion Permanently covered by water Cable Usage Characteristics Laying Conditions

8 Product Codes Conductor Nominal Cross Sectional Area25, 35, 50, 70, 95, 120, 150, 185, 240, 300, 400, 500, 630 Insulation MaterialXLPE – X, EPR – E Single or Three core1C, 3C kV Rating3–1.9/3.3, 6–3.8/6.6, 11–6.35/11, 22–12.7/22, 33–19/33 Conductor MaterialCopper – CU, Aluminium – AL Screen TypeLight Duty – LD, Heavy Duty – HD ArmouringArmoured – A, Unarmoured – blank EXAMPLE:95mm 2  three core, copper conductor, XLPE insulated, 11kV, light duty screen, armoured. When ordering, please quote the conductor nominal cross sectional area ahead of the product code which appears on each data sheet. 95 3C CU X 11 LD A CSA PRODUCT CODE

9 PEOPLE ARE OUR GREATEST ASSET. WE BELIEVE EVERYONE HAS THE RIGHT TO WORK AND LIVE IN A HEALTHY AND SAFE ENVIRONMENT.  The Prysmian Group maintains our commitment to comply with all relevant Occupational Health, Safety and Environmental legislation, Australian and New Zealand Standards (AS/NZS 4801 and ISO 14001) Licences and Industry Codes of Practices. Our goal is an environmentally and socially sustainable business and we believe that a safe work environment is a sign of efficiency and quality. Accidents can be prevented and we commit to continually improve, to achieve zero incidents of work related injury, illness and environmental pollution. We also aim to help our customers fulfil their environmental responsibilities by providing them with cables and associated products that we believe have been manufactured as efficiently, economically sound and environmentally sustainable as possible. As our products are locally designed and manufactured we recognize the importance of risk assessment and mitigation in all mining operations.  For additional support in this area we have dedicated technical staff available to provide specific product information and guidelines for use please contact: [email protected] Health, Safety and Environment

10

Exploded Cable View SINGLE CORE Straded compacted  copper or aluminium conductor Semi-conductive conductor screen Copper wire screen PVC sheath XLPE insulation Straded compacted  copper or aluminium conductor Semi-conductive conductor screen Copper wire screen Filters PVC sheath XLPE insulation THREE CORE 11

12 MEDIUM VOLTAGE CABLES Copper 1.9/3.3kV SINGLE CORE LIGHT DUTY SCREENED UNARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Plain circular compacted copper Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conductive compound, bonded to the insulation and applied in the same operations as the insulation INSULATION OPTIONS:  Cross Linked Polyethylene (XLPE) Ethylene Propylene Rubber (EPR) INSULATION SCREEN: Extruded, semi-conductive compound Cold strippable METALLIC SCREEN: Helical plain annealed copper wire SHEATH OPTIONS: Black 5V-90 PVC Orange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer Low smoke zero halogen (LSOH) +90˚C -25˚C 3 (HDPE) Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D 15D (HDPE) 18D 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT

13 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. MEDIUM VOLTAGE CABLES Physical & Electrical Characteristics Copper 1.9/3.3kV Product Code 1CCUX3LD Nominal Conductor Area mm 2 25 35 50 70 95 120 150 185 240 300 400 500 630 Nominal Conductor Diameter mm 6.1 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 23.5 26.6 30.3 Nominal Insulation Thickness mm 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.2 2.4 Approx Cable  Diameter mm 18.6 19.6 20.7 22.3 24.0 25.4 26.8 28.6 31.0 33.5 37.2 40.9 45.2 Approx Mass kg/100m 65 75 90 110 135 160 190 225 280 340 430 535 675 Max Pulling Tension  On Conductor kN 1.8 2.5 3.5 4.9 6.7 8.4 11 13 17 21 25 25 25 Max Pulling Tension  On Stocking Grip kN 1.2 1.3 1.5 1.7 2.0 2.3 2.5 2.9 3.4 3.9 4.8 5.8 7.1 Min Bending Radius : During Installation mm 340 350 370 400 430 460 480 510 560 600 670 740 810 Min Bending Radius : Set In Position mm 220 230 250 270 290 310 320 340 370 400 450 490 540 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 0.0470 0.0366 0.0283 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 0.927 0.668 0.494 0.342 0.247 0.196 0.159 0.128 0.0983 0.0794 0.0635 0.0513 0.0419 Inductance, Trefoil Touching mH/km 0.448 0.428 0.409 0.377 0.359 0.344 0.333 0.322 0.312 0.303 0.296 0.290 0.285 Inductive Reactance,  Trefoil Touching  @ 50Hz Ohm/km 0.141 0.134 0.128 0.118 0.113 0.108 0.105 0.101 0.0981 0.0953 0.0930 0.0911 0.0896 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 1.66+  j0.0717 1.46+  j0.0669 1.32+  j0.0622 1.20+  j0.0540 1.13+  j0.0498 1.09+  j0.0461 1.06+  j0.0438 1.03+  j0.0413 1.01+  j0.0388 0.995+  j0.0367 0.982+  j0.0352 0.973+  j0.0340 0.965+ j0.0331 Capacitance, Phase  To Earth µF/km 0.318 0.350 0.390 0.448 0.507 0.556 0.605 0.666 0.742 0.824 0.943 0.962 0.994 Min Insulation  Resistance @ 20°C  MOhm.km 8,200 7,300 6,600 5,700 5,000 4,600 4,200 3,800 3,400 3,000 2,700 2,600 2,500 Electric Stress At  Conductor Screen  kV/mm 1.19 1.17 1.14 1.11 1.09 1.08 1.07 1.06 1.04 1.03 1.02 0.929 0.850 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.190 0.209 0.233 0.267 0.303 0.332 0.361 0.398 0.443 0.492 0.563 0.574 0.594 Short Circuit Rating Phase  ConductorkA, 1 sec 3.6 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 57.2 71.5 90.1 Metallic ScreenkA, 1 sec 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 Con-tinuous Current Rating In Ground,Direct Buried  A 145 175 205 250 295 335 375 425 490 550 620 695 780 In Ground,  In Singleway Ducts  A 145 170 200 240 285 320 360 400 455 510 570 640 715 In Free Air,  Unenclosed & Spaced From Wall  A 145 170 205 260 315 365 415 475 560 645 750 860 990

14 MEDIUM VOLTAGE CABLES Copper 1.9/3.3kV SINGLE CORE HEAVY DUTY SCREENED UNARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Plain circular compacted copper Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 10kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C 1 (PVC only)  3 (HDPE) Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT

15 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. MEDIUM VOLTAGE CABLES Physical & Electrical Characteristics Copper 1.9/3.3kV Product Code 1CCUX3HD Nominal Conductor Area mm 2 25 35 50 70 95 120 150 185 240 300 400 500 630 Nominal Conductor Diameter mm 6.1 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 23.5 26.6 30.3 Nominal Insulation Thickness mm 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.2 2.4 Approx Cable  Diameter mm 18.6 20.9 22.0 24.3 26.0 26.7 28.1 30.1 32.3 34.8 38.5 42.2 46.5 Approx Mass kg/100m 70 90 115 155 185 205 235 270 325 385 475 580 720 Max Pulling Tension  On Conductor kN 1.8 2.5 3.5 4.9 6.7 8.4 11 13 17 21 25 25 25 Max Pulling Tension  On Stocking Grip kN 1.2 1.5 1.7 2.1 2.4 2.5 2.8 3.2 3.6 4.2 5.2 6.2 7.6 Min Bending Radius : During Installation mm 340 380 400 440 470 480 510 540 580 630 690 760 840 Min Bending Radius : Set In Position mm 220 250 260 290 310 320 340 360 390 420 460 510 560 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 0.0470 0.0366 0.0283 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 0.927 0.668 0.494 0.342 0.247 0.196 0.159 0.128 0.0982 0.0793 0.0634 0.0511 0.0417 Inductance, Trefoil Touching mH/km 0.448 0.442 0.421 0.395 0.375 0.354 0.343 0.333 0.321 0.311 0.303 0.297 0.291 Inductive Reactance,  Trefoil Touching  @ 50Hz Ohm/km 0.141 0.139 0.132 0.124 0.118 0.111 0.108 0.105 0.101 0.0978 0.0953 0.0932 0.0914 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 1.51+  j0.0717 1.09+  j0.0696 0.783+  j0.0647 0.560+  j0.0575 0.485+  j0.0530 0.435+  j0.0481 0.406+  j0.0456 0.381+  j0.0430 0.358+  j0.0404 0.343+  j0.0381 0.330+  j0.0365 0.320+ j0.0351 0.312+  j0.0342 Capacitance, Phase  To Earth µF/km 0.318 0.350 0.390 0.448 0.507 0.556 0.605 0.666 0.742 0.824 0.943 0.962 0.994 Min Insulation  Resistance @ 20°C  MOhm.km 8,200 7,300 6,600 5,700 5,000 4,600 4,200 3,800 3,400 3,000 2,700 2,600 2,500 Electric Stress At  Conductor Screen  kV/mm 1.19 1.17 1.14 1.11 1.09 1.08 1.07 1.06 1.04 1.03 1.02 0.929 0.850 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.190 0.209 0.233 0.267 0.303 0.332 0.361 0.398 0.443 0.492 0.563 0.574 0.594 Short Circuit Rating Phase  ConductorkA, 1 sec 3.6 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 57.2 71.5 90.1 Metallic ScreenkA, 1 sec 3.5 5.0 7.1 10 10 10 10 10 10 10 10 10 10 Con-tinuous Current Rating In Ground,Direct Buried  A 145 175 205 250 295 335 370 415 475 530 595 660 735 In Ground,  In Singleway Ducts  A 145 170 195 230 270 300 325 360 405 440 490 540 595 In Free Air,  Unenclosed & Spaced From Wall  A 145 175 210 265 320 365 415 470 555 630 725 830 945

16 MEDIUM VOLTAGE CABLES Copper 1.9/3.3kV THREE CORE LIGHT DUTY SCREENED UNARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Plain circular compacted copper Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 3kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT 1 (PVC only)  3 (HDPE)

17 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. MEDIUM VOLTAGE CABLES Physical & Electrical Characteristics Copper 1.9/3.3kV Product Code 3CCUX3LD  Nominal Conductor Area mm 2 25 35 50 70 95 120 150 185 240 300 Nominal Conductor Diameter mm 6.1 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 Nominal Insulation Thickness mm 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 Approx Cable  Diameter mm 36.0 38.2 40.8 44.6 48.6 51.9 55.1 59.1 64.2 69.5 Approx Mass kg/100m 160 195 235 305 390 475 560 675 855 1050 Max Pulling Tension  On Conductors kN 5.3 7.4 11 15 20 25 25 25 25 25 Max Pulling Tension  On Stocking Grip kN 4.5 5.1 5.8 7.0 8.3 9.4 11 12 14 17 Min Bending Radius : During Installation mm 650 690 730 800 880 930 990 1060 1160 1250 Min Bending Radius : Set In Position mm 430 460 490 540 580 620 660 710 770 830 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 0.927 0.668 0.494 0.342 0.247 0.196 0.160 0.128 0.0987 0.0800 Inductance mH/km 0.380 0.364 0.348 0.321 0.307 0.295 0.287 0.278 0.270 0.262 Inductive Reactance,  @ 50Hz Ohm/km 0.119 0.114 0.109 0.101 0.0964 0.0926 0.0900 0.0874 0.0847 0.0824 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 3.46+  j0.0720 3.26+  j0.0671 3.12+  j0.0624 3.00+  j0.0542 2.93+  j0.0499 2.68+  j0.0463 2.47+  j0.0440 2.29+  j0.0415 2.13+  j0.0390 1.88  +j0.0368 Capacitance, Phase  To Earth µF/km 0.319 0.352 0.391 0.449 0.509 0.558 0.607 0.668 0.745 0.827 Min Insulation  Resistance @ 20°C  MOhm.km 8,200 7,300 6,600 5,700 5,000 4,600 4,200 3,800 3,400 3,000 Electric Stress At  Conductor Screen  kV/mm 1.19 1.17 1.14 1.11 1.09 1.08 1.07 1.06 1.04 1.03 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.190 0.210 0.234 0.268 0.304 0.333 0.362 0.399 0.445 0.494 Short Circuit Rating Phase  ConductorkA, 1 sec 3.6 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 Metallic ScreenkA, 1 sec 3.0 3.0 3.0 3.0 3.0 3.3 3.5 3.8 4.0 4.6 Con-tinuous Current Rating In Ground,Direct Buried  A 140 165 195 235 285 330 365 410 475 530 In Ground,  In Singleway Ducts  A 120 140 165 205 240 275 310 350 405 460 In Free Air,  Unenclosed & Spaced From Wall  A 135 160 190 235 280 335 375 430 495 575

18 MEDIUM VOLTAGE CABLES Copper 1.9/3.3kV THREE CORE LIGHT DUTY SCREENED ARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Plain circular compacted copper Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 3kA for nominal 1 second ARMOURING: Galvanised steel wires SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT 1 (PVC only)  3 (HDPE) 3 (Armoured)

19 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. MEDIUM VOLTAGE CABLES Physical & Electrical Characteristics Copper 1.9/3.3kV Product Code 3CCUX3LDA Nominal Conductor Area mm 2 25 35 50 70 95 120 150 185 240 Nominal Conductor Diameter mm 6.1 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 Nominal Insulation Thickness mm 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 Approx Cable  Diameter mm 43.0 45.2 49.7 53.4 57.5 61.0 64.2 68.4 73.7 Approx Mass kg/100m 320 365 460 550 660 765 870 1010 1220 Max Pulling Tension  On Conductors kN 5.3 7.4 11 15 20 25 25 25 25 Max Pulling Tension  On Stocking Grip kN 5.3 7.2 8.6 10.0 12 13 14 16 19 Max Pulling Tension  On Armour Wires kN 7.5 8.3 9.8 11 13 15 17 19 22 Min Bending Radius : During Installation mm 770 810 890 960 1040 1100 1160 1230 1330 Min Bending Radius : Set In Position mm 520 540 600 640 690 730 770 820 880 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 0.927 0.668 0.494 0.342 0.247 0.196 0.160 0.128 0.0987 Inductance mH/km 0.380 0.364 0.348 0.321 0.307 0.295 0.287 0.278 0.270 Inductive Reactance,  @ 50Hz Ohm/km 0.119 0.114 0.109 0.101 0.0964 0.0926 0.0900 0.0874 0.0847 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 3.46+  j0.0720 3.26+   j0.0671 3.12+   j0.0624 3.00+  j0.0542 2.93+  j0.0499 2.68+  j0.0463 2.47+  j0.0440 2.29+   j0.0415 2.13+   j0.0390 Capacitance, Phase  To Earth µF/km 0.319 0.352 0.391 0.449 0.509 0.558 0.607 0.668 0.745 Min Insulation  Resistance @ 20°C  MOhm.km 8,200 7,300 6,600 5,700 5,000 4,600 4,200 3,800 3,400 Electric Stress At  Conductor Screen  kV/mm 1.19 1.17 1.14 1.11 1.09 1.08 1.07 1.06 1.04 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.190 0.210 0.234 0.268 0.304 0.333 0.362 0.399 0.445 Short Circuit Rating Phase  ConductorkA, 1 sec 3.6 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 Metallic ScreenkA, 1 sec 3.0 3.0 3.0 3.0 3.0 3.3 3.5 3.8 4.0 Con-tinuous Current Rating In Ground,Direct Buried  A 140 165 195 235 285 330 365 410 475 In Ground,  In Singleway Ducts  A 120 140 165 205 240 275 310 350 405 In Free Air,  Unenclosed & Spaced From Wall  A 135 160 190 235 280 335 375 430 495

20 MEDIUM VOLTAGE CABLES Copper 1.9/3.3kV THREE CORE HEAVY DUTY SCREENED UNARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Plain circular compacted copper Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 10kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT 1 (PVC only)  3 (HDPE)

21 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. MEDIUM VOLTAGE CABLES Physical & Electrical Characteristics Copper 1.9/3.3kV Product Code 3CCUX3HD  Nominal Conductor Area mm 2 25 35 50 70 95 120 150 185 240 300 Nominal Conductor Diameter mm 6.1 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 Nominal Insulation Thickness mm 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 Approx Cable  Diameter mm 36.0 38.2 40.8 44.8 48.6 51.9 55.1 59.1 64.2 69.5 Approx Mass kg/100m 165 210 260 350 435 515 600 715 890 1080 Max Pulling Tension  On Conductors kN 5.3 7.4 11 15 20 25 25 25 25 25 Max Pulling Tension  On Stocking Grip kN 4.5 5.1 5.8 7.0 8.3 9.4 11 12 14 17 Min Bending Radius : During Installation mm 650 690 730 810 880 930 990 1060 1160 1250 Min Bending Radius : Set In Position mm 430 460 490 540 580 620 660 710 770 830 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 0.927 0.668 0.494 0.342 0.247 0.196 0.160 0.128 0.0987 0.0800 Inductance mH/km 0.380 0.364 0.348 0.321 0.307 0.295 0.287 0.278 0.270 0.262 Inductive Reactance,  @ 50Hz Ohm/km 0.119 0.114 0.109 0.101 0.0964 0.0926 0.0900 0.0874 0.0847 0.0824 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 3.07+  j0.0720 2.16+  j0.0671 1.56+  j0.0624 1.11+  j0.0542 1.03+  j0.0499 0.995+  j0.0463 0.966+  j0.0440 0.941+  j0.0415 0.917+  j0.0390 0.902+  j0.0368 Capacitance, Phase  To Earth µF/km 0.319 0.352 0.391 0.449 0.509 0.558 0.607 0.668 0.745 0.827 Min Insulation  Resistance @ 20°C  MOhm.km 8,200 7,300 6,600 5,700 5,000 4,600 4,200 3,800 3,400 3,000 Electric Stress At  Conductor Screen  kV/mm 1.19 1.17 1.14 1.11 1.09 1.08 1.07 1.06 1.04 1.03 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.190 0.210 0.234 0.268 0.304 0.333 0.362 0.399 0.445 0.494 Short Circuit Rating Phase  ConductorkA, 1 sec 3.6 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 Metallic ScreenkA, 1 sec 3.5 5.1 7.1 10 10 10 10 10 10 10 Con-tinuous Current Rating In Ground,Direct Buried  A 140 165 195 240 290 335 365 410 475 520 In Ground,  In Singleway Ducts  A 120 140 165 205 240 275 310 350 400 450 In Free Air,  Unenclosed & Spaced From Wall  A 135 160 190 240 290 340 380 435 510 590

22 MEDIUM VOLTAGE CABLES Copper 1.9/3.3kV THREE CORE HEAVY DUTY SCREENED ARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Plain circular compacted copper Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 10kA for nominal 1 second ARMOURING: Galvanised steel wires SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT 1 (PVC only)  3 (HDPE) 3 (Armoured)

23 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. MEDIUM VOLTAGE CABLES Physical & Electrical Characteristics Copper 1.9/3.3kV Product Code 3CCUX3HDA Nominal Conductor Area mm 2 25 35 50 70 95 120 150 185 240 Nominal Conductor Diameter mm 6.1 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 Nominal Insulation Thickness mm 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 Approx Cable  Diameter mm 43.0 45.2 49.7 53.6 57.5 61.0 64.4 68.6 73.7 Approx Mass kg/100m 325 380 490 600 700 805 915 1050 1250 Max Pulling Tension  On Conductors kN 5.3 7.4 11 15 20 25 25 25 25 Max Pulling Tension  On Stocking Grip kN 5.3 7.2 8.6 10 12 13 15 16 19 Max Pulling Tension  On Armour Wires kN 7.5 8.3 9.8 12 13 15 17 19 22 Min Bending Radius : During Installation mm 770 810 890 970 1040 1100 1160 1230 1330 Min Bending Radius : Set In Position mm 520 540 600 640 690 730 770 820 880 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 0.927 0.668 0.494 0.342 0.247 0.196 0.160 0.128 0.0987 Inductance mH/km 0.380 0.364 0.348 0.321 0.307 0.295 0.287 0.278 0.270 Inductive Reactance,  @ 50Hz Ohm/km 0.119 0.114 0.109 0.101 0.0964 0.0926 0.0900 0.0874 0.0847 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 3.07+  j0.0720 2.16+   j0.0671 1.56+   j0.0624 1.11+   j0.0542 1.03+  j0.0499 0.995+  j0.0463 0.966+  j0.0440 0.941+  j0.0415 0.917+  j0.0390 Capacitance, Phase  To Earth µF/km 0.319 0.352 0.391 0.449 0.509 0.558 0.607 0.668 0.745 Min Insulation  Resistance @ 20°C  MOhm.km 8,200 7,300 6,600 5,700 5,000 4,600 4,200 3,800 3,400 Electric Stress At  Conductor Screen  kV/mm 1.19 1.17 1.14 1.11 1.09 1.08 1.07 1.06 1.04 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.190 0.210 0.234 0.268 0.304 0.333 0.362 0.399 0.445 Short Circuit Rating Phase  ConductorkA, 1 sec 3.6 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 Metallic ScreenkA, 1 sec 3.5 5.1 7.1 10 10 10 10 10 10 Con-tinuous Current Rating In Ground,Direct Buried  A 140 165 195 240 290 335 365 410 475 In Ground,  In Singleway Ducts  A 120 140 165 205 240 275 310 350 400 In Free Air,  Unenclosed & Spaced From Wall  A 135 160 190 240 290 340 380 435 510

24 MEDIUM VOLTAGE CABLES Aluminium 1.9/3.3kV SINGLE CORE LIGHT DUTY SCREENED Cable Characteristics +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 1 (PVC only)  3 (HDPE) Installation Conditions Cable Design CONDUCTOR:  Circular compacted aluminium Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 3kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standard Orange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT

25 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. Physical & Electrical Characteristics Aluminium 1.9/3.3kV Product Code 1CALX3LD Nominal Conductor Area mm 2 25 35 50 70 95 120 150 185 240 300 400 500 630 Nominal Conductor Diameter mm 6.1 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 23.5 26.6 30.2 Nominal Insulation Thickness mm 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.2 2.4 Approx Cable  Diameter mm 18.6 19.6 20.6 22.3 24.0 25.4 26.7 28.5 30.8 33.5 37.2 40.9 45.1 Approx Mass kg/100m 45 55 60 70 80 90 100 110 135 155 190 225 280 Max Pulling Tension  On Conductor kN 1.3 1.8 2.5 3.5 4.8 6.0 7.5 9.3 12 15 20 25 25 Max Pulling Tension  On Stocking Grip kN 1.2 1.3 1.5 1.7 2.0 2.3 2.5 2.8 3.3 3.9 4.8 5.8 7.1 Min Bending Radius : During Installation mm 330 350 370 400 430 460 480 510 550 600 670 740 810 Min Bending Radius : Set In Position mm 220 240 250 270 290 300 320 340 370 400 450 490 540 Max Conductor  Resistance, dc @ 20°C  Ohm/km 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 0.0778 0.0605 0.0469 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 1.54 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.162 0.130 0.102 0.0805 0.0640 Inductance, Trefoil Touching mH/km 0.449 0.427 0.409 0.377 0.359 0.347 0.337 0.323 0.313 0.303 0.298 0.292 0.285 Inductive Reactance,  Trefoil Touching  @ 50Hz Ohm/km 0.141 0.134 0.129 0.118 0.113 0.109 0.106 0.101 0.0983 0.0953 0.0935 0.0916 0.0896 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 2.37+  j0.0720 1.80+  j0.0665 1.57+  j0.0623 1.38+  j0.0540 1.25+  j0.0498 1.19+  j0.0471 1.14+  j0.0448 1.10+  j0.0415 1.06+  j0.0390 1.03+  j0.0367 1.01+  j0.0357 0.996+  j0.0344 0.982+  j0.0332 Capacitance, Phase  To Earth µF/km 0.316 0.353 0.388 0.448 0.507 0.554 0.601 0.663 0.737 0.824 0.943 0.962 0.993 Min Insulation  Resistance @ 20°C  MOhm.km 8,300 7,300 6,600 5,700 5,000 4,600 4,200 3,800 3,400 3,000 2,700 2,600 2,500 Electric Stress At  Conductor Screen  kV/mm 1.19 1.16 1.14 1.11 1.09 1.08 1.07 1.06 1.05 1.03 1.02 0.929 0.850 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.189 0.211 0.232 0.267 0.303 0.331 0.359 0.395 0.440 0.492 0.563 0.574 0.593 Short Circuit Rating Phase  ConductorkA, 1 sec 2.4 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 37.8 47.2 59.5 Metallic ScreenkA, 1 sec 2.4 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 Con-tinuous Current Rating In Ground,Direct Buried  A 115 135 160 195 230 260 295 330 385 430 495 560 635 In Ground,  In Singleway Ducts  A 115 135 155 190 225 255 285 320 365 410 465 525 595 In Free Air,  Unenclosed & Spaced From Wall  A 110 135 160 200 245 285 320 370 440 505 595 695 810

26 MEDIUM VOLTAGE CABLES Aluminium 1.9/3.3kV SINGLE CORE HEAVY DUTY SCREENED UNARMOURED Cable Characteristics +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 1 (PVC only)  3 (HDPE) Installation Conditions Cable Design CONDUCTOR:  Circular compacted aluminium Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 10kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standard Orange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT

27 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. Physical & Electrical Characteristics Aluminium 1.9/3.3kV Product Code 1CALX3HD Nominal Conductor Area mm 2 25 35 50 70 95 120 150 185 240 300 400 500 630 Nominal Conductor Diameter mm 6.1 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 23.5 26.6 30.2 Nominal Insulation Thickness mm 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.2 2.4 Approx Cable  Diameter mm 18.6 19.6 21.9 23.6 25.3 26.7 28.0 30.0 32.1 34.8 38.5 42.2 46.4 Approx Mass kg/100m 45 55 70 95 120 135 145 160 180 200 235 270 325 Max Pulling Tension  On Conductor kN 1.3 1.8 2.5 3.5 4.8 6.0 7.5 9.3 12 15 20 25 25 Max Pulling Tension  On Stocking Grip kN 1.2 1.3 1.7 2.0 2.2 2.5 2.8 3.1 3.6 4.2 5.2 6.2 7.5 Min Bending Radius : During Installation mm 330 350 390 430 460 480 500 540 580 630 690 760 840 Min Bending Radius : Set In Position mm 220 240 260 280 300 320 340 360 390 420 460 510 560 Max Conductor  Resistance, dc @ 20°C  Ohm/km 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 0.0778 0.0605 0.0469 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 1.54 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.161 0.130 0.102 0.0804 0.0638 Inductance, Trefoil Touching mH/km 0.449 0.427 0.422 0.389 0.370 0.357 0.347 0.334 0.322 0.311 0.305 0.298 0.291 Inductive Reactance,  Trefoil Touching  @ 50Hz Ohm/km 0.141 0.134 0.133 0.122 0.116 0.112 0.109 0.105 0.101 0.0978 0.0958 0.0936 0.0915 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 2.37+  j0.0720 1.71+  j0.0665 1.24+  j0.0649 0.871+  j0.0563 0.635+  j0.0519 0.535+  j0.0490 0.488+  j0.0466 0.446+  j0.0432 0.407+  j0.0405 0.382+  j0.0381 0.360+  j0.0369 0.343+  j0.0356 0.330+  j0.0342 Capacitance, Phase  To Earth µF/km 0.316 0.353 0.388 0.448 0.507 0.554 0.601 0.663 0.737 0.824 0.943 0.962 0.993 Min Insulation  Resistance @ 20°C  MOhm.km 8,300 7,300 6,600 5,700 5,000 4,600 4,200 3,800 3,400 3,000 2,700 2,600 2,500 Electric Stress At  Conductor Screen  kV/mm 1.19 1.16 1.14 1.11 1.09 1.08 1.07 1.06 1.05 1.03 1.02 0.929 0.850 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.189 0.211 0.232 0.267 0.303 0.331 0.359 0.395 0.440 0.492 0.563 0.574 0.593 Short Circuit Rating Phase  ConductorkA, 1 sec 2.4 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 37.8 47.2 59.5 Metallic ScreenkA, 1 sec 2.4 3.3 4.7 6.6 8.9 10 10 10 10 10 10 10 10 Con-tinuous Current Rating In Ground,Direct Buried  A 115 135 160 195 230 260 290 330 375 425 480 545 610 In Ground,  In Singleway Ducts  A 115 135 155 190 220 245 270 300 335 375 415 465 520 In Free Air,  Unenclosed & Spaced From Wall  A 110 135 165 205 250 285 325 370 435 505 585 680 785

28 MEDIUM VOLTAGE CABLES Aluminium 1.9/3.3kV THREE CORE LIGHT DUTY SCREENED UNARMOURED Cable Characteristics +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 1 (PVC only)  3 (HDPE) Installation Conditions Cable Design CONDUCTOR:  Circular compacted aluminium Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 3kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT

29 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. Physical & Electrical Characteristics Aluminium 1.9/3.3kV Product Code 3CALX3LD Nominal Conductor Area mm 2 25 35 50 70 95 120 150 185 240 300 Nominal Conductor Diameter mm 6.1 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 Nominal Insulation Thickness mm 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 Approx Cable  Diameter mm 35.9 38.4 40.7 44.6 48.6 51.8 54.9 58.8 63.9 69.5 Approx Mass kg/100m 110 130 150 180 215 250 290 335 410 490 Max Pulling Tension  On Conductors kN 3.8 5.3 7.5 11 14 18 23 25 25 25 Max Pulling Tension  On Stocking Grip kN 3.8 5.2 5.8 7.0 8.3 9.4 11 12 14 17 Min Bending Radius : During Installation mm 650 690 730 800 880 930 990 1060 1150 1250 Min Bending Radius : Set In Position mm 430 460 490 540 580 620 660 710 770 830 Max Conductor  Resistance, dc @ 20°C  Ohm/km 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 1.54 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.162 0.130 Inductance mH/km 0.381 0.363 0.349 0.321 0.307 0.298 0.290 0.279 0.270 0.262 Inductive Reactance,  @ 50Hz Ohm/km 0.120 0.114 0.110 0.101 0.0964 0.0935 0.0910 0.0875 0.0849 0.0824 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 4.84+  j0.0722 3.60+  j0.0668 3.37+  j0.0626 3.18+  j0.0542 3.05+  j0.0499 2.78+  j0.0472 2.55+  j0.0449 2.35+  j0.0416 2.18+  j0.0391 1.92+  j0.0368 Capacitance, Phase  To Earth µF/km 0.317 0.354 0.390 0.449 0.509 0.556 0.604 0.665 0.740 0.827 Min Insulation  Resistance @ 20°C  MOhm.km 8,300 7,300 6,600 5,700 5,000 4,600 4,200 3,800 3,400 3,000 Electric Stress At  Conductor Screen  kV/mm 1.19 1.16 1.14 1.11 1.09 1.08 1.07 1.06 1.05 1.03 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.189 0.212 0.233 0.268 0.304 0.332 0.360 0.397 0.442 0.494 Short Circuit Rating Phase  ConductorkA, 1 sec 2.4 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 Metallic ScreenkA, 1 sec 2.3 3.0 3.0 3.0 3.0 3.3 3.5 3.8 4.0 4.6 Con-tinuous Current Rating In Ground,Direct Buried  A 110 125 150 185 225 255 285 320 375 420 In Ground,  In Singleway Ducts  A 90 110 130 160 185 215 245 270 315 365 In Free Air,  Unenclosed & Spaced From Wall  A 105 125 145 180 215 255 290 335 400 460

30 MEDIUM VOLTAGE CABLES THREE CORE LIGHT DUTY SCREENED ARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Circular compacted aluminium Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 3kA for nominal 1 second ARMOURING: Galvanised steel wires SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT 1 (PVC only)  3 (HDPE) 3 (Armoured) Aluminium 1.9/3.3kV

31 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. Physical & Electrical Characteristics Aluminium 1.9/3.3kV Product Code 3CALX3LDA Nominal Conductor Area mm 2 25 35 50 70 95 120 150 185 240 Nominal Conductor Diameter mm 6.1 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 Nominal Insulation Thickness mm 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 Approx Cable  Diameter mm 43.0 45.4 49.6 53.4 57.5 60.9 64.0 68.2 73.4 Approx Mass kg/100m 270 300 375 425 485 540 595 665 770 Max Pulling Tension  On Conductors kN 3.8 5.3 7.5 11 14 18 23 25 25 Max Pulling Tension  On Stocking Grip kN 3.8 5.3 7.5 10.0 12 13 14 16 19 Max Pulling Tension  On Armour Wires kN 7.4 8.3 9.8 11 13 15 17 19 22 Min Bending Radius : During Installation mm 770 820 890 960 1040 1100 1150 1230 1320 Min Bending Radius : Set In Position mm 520 550 590 640 690 730 770 820 880 Max Conductor  Resistance, dc @ 20°C  Ohm/km 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 1.54 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.162 Inductance mH/km 0.381 0.363 0.349 0.321 0.307 0.298 0.290 0.279 0.270 Inductive Reactance,  @ 50Hz Ohm/km 0.120 0.114 0.110 0.101 0.0964 0.0935 0.0910 0.0875 0.0849 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 4.84+  j0.0722 3.60+  j0.0668 3.37+  j0.0626 3.18+   j0.0542 3.05+  j0.0499 2.78+  j0.0472 2.55+  j0.0449 2.35+   j0.0416 2.18+   j0.0391 Capacitance, Phase  To Earth µF/km 0.317 0.354 0.390 0.449 0.509 0.556 0.604 0.665 0.740 Min Insulation  Resistance @ 20°C  MOhm.km 8,300 7,300 6,600 5,700 5,000 4,600 4,200 3,800 3,400 Electric Stress At  Conductor Screen  kV/mm 1.19 1.16 1.14 1.11 1.09 1.08 1.07 1.06 1.05 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.189 0.212 0.233 0.268 0.304 0.332 0.360 0.397 0.442 Short Circuit Rating Phase  ConductorkA, 1 sec 2.4 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 Metallic ScreenkA, 1 sec 2.3 3.0 3.0 3.0 3.0 3.3 3.5 3.8 4.0 Con-tinuous Current Rating In Ground,Direct Buried  A 110 125 150 185 225 255 285 320 375 In Ground,  In Singleway Ducts  A 90 110 130 160 185 215 245 270 315 In Free Air,  Unenclosed & Spaced From Wall  A 105 125 145 180 215 255 290 335 400

32 MEDIUM VOLTAGE CABLES Aluminium 1.9/3.3kV THREE CORE HEAVY DUTY SCREENED UNARMOURED Cable Characteristics +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 1 (PVC only)  3 (HDPE) Installation Conditions Cable Design CONDUCTOR:  Circular compacted aluminium Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 10kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT

33 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. Physical & Electrical Characteristics Aluminium 1.9/3.3kV Product Code 3CALX3HD Nominal Conductor Area mm 2 25 35 50 70 95 120 150 185 240 300 Nominal Conductor Diameter mm 6.1 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 Nominal Insulation Thickness mm 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 Approx Cable  Diameter mm 35.9 38.4 40.7 44.8 48.6 51.8 54.9 58.8 63.9 69.5 Approx Mass kg/100m 110 130 160 205 255 290 330 375 445 520 Max Pulling Tension  On Conductors kN 3.8 5.3 7.5 11 14 18 23 25 25 25 Max Pulling Tension  On Stocking Grip kN 3.8 5.2 5.8 7.0 8.3 9.4 11 12 14 17 Min Bending Radius : During Installation mm 650 690 730 810 880 930 990 1060 1150 1250 Min Bending Radius : Set In Position mm 430 460 490 540 580 620 660 710 770 830 Max Conductor  Resistance, dc @ 20°C  Ohm/km 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 1.54 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.162 0.130 Inductance mH/km 0.381 0.363 0.349 0.321 0.307 0.298 0.290 0.279 0.270 0.262 Inductive Reactance,  @ 50Hz Ohm/km 0.120 0.114 0.110 0.101 0.0964 0.0935 0.0910 0.0875 0.0849 0.0824 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 4.48+  j0.0722 3.39+  j0.0668 2.37+  j0.0626 1.70+  j0.0542 1.26+  j0.0499 1.09+  j0.0472 1.05+  j0.0449 1.01+  j0.0416 0.967+  j0.0391 0.942+  j0.0368 Capacitance, Phase  To Earth µF/km 0.317 0.354 0.390 0.449 0.509 0.556 0.604 0.665 0.740 0.827 Min Insulation  Resistance @ 20°C  MOhm.km 8,300 7,300 6,600 5,700 5,000 4,600 4,200 3,800 3,400 3,000 Electric Stress At  Conductor Screen  kV/mm 1.19 1.16 1.14 1.11 1.09 1.08 1.07 1.06 1.05 1.03 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.189 0.212 0.233 0.268 0.304 0.332 0.360 0.397 0.442 0.494 Short Circuit Rating Phase  ConductorkA, 1 sec 2.4 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 Metallic ScreenkA, 1 sec 2.5 3.3 4.8 6.6 8.9 10 10 10 10 10 Con-tinuous Current Rating In Ground,Direct Buried  A 110 125 150 185 225 255 285 320 375 420 In Ground,  In Singleway Ducts  A 90 110 130 160 185 215 240 270 315 360 In Free Air,  Unenclosed & Spaced From Wall  A 105 125 145 180 220 265 300 340 400 465

34 MEDIUM VOLTAGE CABLES THREE CORE HEAVY DUTY SCREENED ARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Circular compacted aluminium Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 10kA for nominal 1 second ARMOURING: Galvanised steel wires SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT 1 (PVC only)  3 (HDPE) 3 (Armoured) Aluminium 1.9/3.3kV

35 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. Physical & Electrical Characteristics Aluminium 1.9/3.3kV Product Code 3CALX3HDA Nominal Conductor Area mm 2 25 35 50 70 95 120 150 185 240 Nominal Conductor Diameter mm 6.1 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 Nominal Insulation Thickness mm 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 Approx Cable  Diameter mm 43.0 45.4 49.6 53.6 57.5 60.9 64.2 68.4 73.4 Approx Mass kg/100m 270 300 385 455 520 580 640 705 810 Max Pulling Tension  On Conductors kN 3.8 5.3 7.5 11 14 18 23 25 25 Max Pulling Tension  On Stocking Grip kN 3.8 5.3 7.5 10 12 13 14 16 19 Max Pulling Tension  On Armour Wires kN 7.4 8.3 9.8 12 13 15 17 19 22 Min Bending Radius : During Installation mm 770 820 890 970 1040 1100 1160 1230 1320 Min Bending Radius : Set In Position mm 520 550 590 640 690 730 770 820 880 Max Conductor  Resistance, dc @ 20°C  Ohm/km 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 1.54 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.162 Inductance mH/km 0.381 0.363 0.349 0.321 0.307 0.298 0.290 0.279 0.270 Inductive Reactance,  @ 50Hz Ohm/km 0.120 0.114 0.110 0.101 0.0964 0.0935 0.0910 0.0875 0.0849 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 4.48+  j0.0722 3.39+  j0.0668 2.37+  j0.0626 1.70+   j0.0542 1.26+   j0.0499 1.09+   j0.0472 1.05+  j0.0449 1.01+   j0.0416 0.967+  j0.0391 Capacitance, Phase  To Earth µF/km 0.317 0.354 0.390 0.449 0.509 0.556 0.604 0.665 0.740 Min Insulation  Resistance @ 20°C  MOhm.km 8,300 7,300 6,600 5,700 5,000 4,600 4,200 3,800 3,400 Electric Stress At  Conductor Screen  kV/mm 1.19 1.16 1.14 1.11 1.09 1.08 1.07 1.06 1.05 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.189 0.212 0.233 0.268 0.304 0.332 0.360 0.397 0.442 Short Circuit Rating Phase  ConductorkA, 1 sec 2.4 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 Metallic ScreenkA, 1 sec 2.5 3.3 4.8 6.6 8.9 10 10 10 10 Con-tinuous Current Rating In Ground,Direct Buried  A 110 125 150 185 225 255 285 320 375 In Ground,  In Singleway Ducts  A 90 110 130 160 185 215 240 270 315 In Free Air,  Unenclosed & Spaced From Wall  A 105 125 145 180 220 265 300 340 400

36 MEDIUM VOLTAGE CABLES Copper 3.8/6.6kV SINGLE CORE LIGHT DUTY SCREENED UNARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Plain circular compacted copper Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded, semi-conductive compound METALLIC SCREEN: Plain annealed copper wire: 3kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT 12D (PVC only) 15D (HDPE) 1 (PVC only)  3 (HDPE)

37 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. MEDIUM VOLTAGE CABLES Physical & Electrical Characteristics Copper 3.8/6.6kV Product Code 1CCUX6LD Nominal Conductor Area mm 2 25 35 50 70 95 120 150 185 240 300 400 500 630 Nominal Conductor Diameter mm 6.1 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 23.5 26.6 30.3 Nominal Insulation Thickness mm 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.6 2.8 3.0 3.2 3.2 Approx Cable  Diameter mm 19.6 20.6 21.7 23.3 25.0 26.4 27.8 29.8 32.2 35.1 39.2 43.1 47.0 Approx Mass kg/100m 70 80 90 115 140 165 190 230 285 350 440 550 685 Max Pulling Tension  On Conductor kN 1.8 2.5 3.5 4.9 6.7 8.4 11 13 17 21 25 25 25 Max Pulling Tension  On Stocking Grip kN 1.3 1.5 1.6 1.9 2.2 2.4 2.7 3.1 3.6 4.3 5.4 6.5 7.7 Min Bending Radius : During Installation mm 350 370 390 420 450 480 500 540 580 630 700 770 850 Min Bending Radius : Set In Position mm 240 250 260 280 300 320 330 360 390 420 470 520 560 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 0.0470 0.0366 0.0283 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 0.927 0.668 0.494 0.342 0.247 0.196 0.159 0.128 0.0982 0.0793 0.0633 0.0510 0.0416 Inductance, Trefoil Touching mH/km 0.459 0.439 0.418 0.386 0.367 0.352 0.341 0.331 0.320 0.313 0.307 0.301 0.293 Inductive Reactance,  Trefoil Touching  @ 50Hz Ohm/km 0.144 0.138 0.131 0.121 0.115 0.110 0.107 0.104 0.101 0.0984 0.0965 0.0946 0.0922 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 1.66+  j0.0761 1.46+  j0.0710 1.32+  j0.0660 1.20+  j0.0575 1.13+  j0.0530 1.09+  j0.0491 1.06+  j0.0466 1.03+  j0.0439 1.01+  j0.0417 0.995+  j0.0401 0.982+ j0.0391 0.973+  j0.0375 0.965+  j0.0356 Capacitance, Phase  To Earth µF/km 0.266 0.292 0.324 0.371 0.418 0.458 0.497 0.546 0.586 0.607 0.651 0.682 0.762 Min Insulation  Resistance @ 20°C  MOhm.km 9,700 8,800 8,000 6,900 6,100 5,500 5,100 4,600 4,300 4,100 3,800 3,700 3,300 Electric Stress At  Conductor Screen  kV/mm 2.00 1.95 1.90 1.84 1.80 1.78 1.75 1.73 1.65 1.52 1.41 1.32 1.30 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.317 0.349 0.387 0.443 0.499 0.546 0.593 0.651 0.699 0.725 0.777 0.814 0.910 Short Circuit Rating Phase  ConductorkA, 1 sec 3.6 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 57.2 71.5 90.1 Metallic ScreenkA, 1 sec 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 Con-tinuous Current Rating In Ground,Direct Buried  A 145 175 205 250 295 335 375 425 490 550 620 700 780 In Ground,  In Singleway Ducts  A 145 170 200 245 285 325 360 400 460 510 575 645 720 In Free Air,  Unenclosed & Spaced From Wall  A 145 175 210 260 320 365 415 480 565 650 755 870 995

38 MEDIUM VOLTAGE CABLES Copper 3.8/6.6kV SINGLE CORE HEAVY DUTY SCREENED UNARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Plain circular compacted copper Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 10kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C 1 (PVC only)  3 (HDPE) Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT

39 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. MEDIUM VOLTAGE CABLES Copper 3.8/6.6kV Physical & Electrical Characteristics Product Code 1CCUX6HD Nominal Conductor Area mm 2 25 35 50 70 95 120 150 185 240 300 400 500 630 Nominal Conductor Diameter mm 6.1 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 23.5 26.6 30.3 Nominal Insulation Thickness mm 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.6 2.8 3.0 3.2 3.2 Approx Cable  Diameter mm 19.6 21.9 23.0 25.3 27.0 27.7 29.1 31.1 33.7 36.6 40.7 44.4 48.3 Approx Mass kg/100m 75 95 120 160 185 210 240 275 335 395 485 595 730 Max Pulling Tension  On Conductor kN 1.8 2.5 3.5 4.9 6.7 8.4 11 13 17 21 25 25 25 Max Pulling Tension  On Stocking Grip kN 1.3 1.7 1.8 2.2 2.6 2.7 3.0 3.4 4.0 4.7 5.8 6.9 8.1 Min Bending Radius : During Installation mm 350 390 410 460 490 500 520 560 610 660 730 800 870 Min Bending Radius : Set In Position mm 240 260 280 300 320 330 350 370 400 440 490 530 580 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 0.0470 0.0366 0.0283 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 0.927 0.668 0.494 0.342 0.247 0.196 0.159 0.128 0.0981 0.0791 0.0631 0.0508 0.0414 Inductance, Trefoil Touching mH/km 0.459 0.451 0.431 0.403 0.383 0.362 0.350 0.340 0.330 0.322 0.315 0.307 0.299 Inductive Reactance,  Trefoil Touching  @ 50Hz Ohm/km 0.144 0.142 0.135 0.127 0.120 0.114 0.110 0.107 0.104 0.101 0.0990 0.0965 0.0940 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 1.51+  j0.0761 1.09+  j0.0736 0.783+  j0.0684 0.560+  j0.0608 0.485+  j0.0560 0.435+  j0.0510 0.406+  j0.0483 0.381+  j0.0456 0.358+  j0.0432 0.343+  j0.0415 0.330+  j0.0403 0.320+  j0.0385 0.312+  j0.0366 Capacitance, Phase  To Earth µF/km 0.266 0.292 0.324 0.371 0.418 0.458 0.497 0.546 0.586 0.607 0.651 0.682 0.762 Min Insulation  Resistance @ 20°C  MOhm.km 9,700 8,800 8,000 6,900 6,100 5,500 5,100 4,600 4,300 4,100 3,800 3,700 3,300 Electric Stress At  Conductor Screen  kV/mm 2.00 1.95 1.90 1.84 1.80 1.78 1.75 1.73 1.65 1.52 1.41 1.32 1.30 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.317 0.349 0.387 0.443 0.499 0.546 0.593 0.651 0.699 0.725 0.777 0.814 0.910 Short Circuit Rating Phase  ConductorkA, 1 sec 3.6 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 57.2 71.5 90.1 Metallic ScreenkA, 1 sec 3.5 5.0 7.1 10 10 10 10 10 10 10 10 10 10 Con-tinuous Current Rating In Ground,Direct Buried  A 145 175 205 250 295 335 370 415 475 530 595 665 735 In Ground,  In Singleway Ducts  A 145 170 195 235 270 300 330 360 405 445 495 545 600 In Free Air,  Unenclosed & Spaced From Wall  A 145 180 210 265 320 365 415 475 555 635 730 835 950

40 MEDIUM VOLTAGE CABLES THREE CORE LIGHT DUTY SCREENED UNARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Plain circular compacted copper Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 3kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT 1 (PVC only)  3 (HDPE) Copper 3.8/6.6kV

41 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. MEDIUM VOLTAGE CABLES Physical & Electrical Characteristics Copper 3.8/6.6kV Product Code 3CCUX6LD Nominal Conductor Area mm 2 25 35 50 70 95 120 150 185 240 300 Nominal Conductor Diameter mm 6.1 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 Nominal Insulation Thickness mm 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.6 2.8 Approx Cable  Diameter mm 38.3 40.5 43.2 46.9 50.8 54.0 57.4 61.4 66.8 73.3 Approx Mass kg/100m 170 210 250 320 405 485 575 695 880 1080 Max Pulling Tension  On Conductors kN 5.3 7.4 11 15 20 25 25 25 25 25 Max Pulling Tension  On Stocking Grip kN 5.1 5.8 6.5 7.7 9.0 10 12 13 16 19 Min Bending Radius : During Installation mm 690 730 780 840 910 970 1030 1110 1200 1320 Min Bending Radius : Set In Position mm 460 490 520 560 610 650 690 740 800 880 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 0.927 0.668 0.494 0.342 0.247 0.196 0.159 0.128 0.0986 0.0797 Inductance mH/km 0.393 0.377 0.360 0.332 0.317 0.304 0.295 0.286 0.278 0.273 Inductive Reactance,  @ 50Hz Ohm/km 0.124 0.118 0.113 0.104 0.0994 0.0954 0.0927 0.0899 0.0875 0.0857 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 3.46+  j0.0764 3.26+  j0.0713 3.12+  j0.0662 3.00+  j0.0577 2.72+  j0.0531 2.50+  j0.0493 2.47+  j0.0467 2.29+  j0.0441 2.13+  j0.0418 1.88+  j0.0402 Capacitance, Phase  To Earth µF/km 0.267 0.293 0.325 0.372 0.420 0.459 0.499 0.548 0.588 0.610 Min Insulation  Resistance @ 20°C  MOhm.km 9,700 8,800 8,000 6,900 6,100 5,500 5,100 4,600 4,300 4,100 Electric Stress At  Conductor Screen  kV/mm 2.00 1.95 1.90 1.84 1.80 1.78 1.75 1.73 1.65 1.52 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.319 0.350 0.388 0.444 0.501 0.548 0.595 0.654 0.702 0.728 Short Circuit Rating Phase  ConductorkA, 1 sec 3.6 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 Metallic ScreenkA, 1 sec 3.0 3.0 3.0 3.0 3.3 3.5 3.5 3.8 4.0 4.6 Con-tinuous Current Rating In Ground,Direct Buried  A 140 170 200 245 290 325 365 410 465 530 In Ground,  In Singleway Ducts  A 125 140 170 205 240 280 310 350 405 450 In Free Air,  Unenclosed & Spaced From Wall  A 140 160 190 230 290 335 380 430 510 590

42 MEDIUM VOLTAGE CABLES THREE CORE LIGHT DUTY SCREENED ARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Plain circular compacted copper Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 3kA for nominal 1 second ARMOURING: Galvanised steel wires SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT 1 (PVC only)  3 (HDPE) 3 (Armoured) Copper 3.8/6.6kV

43 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. MEDIUM VOLTAGE CABLES Physical & Electrical Characteristics Copper 3.8/6.6kV Product Code 3CCUX6LDA Nominal Conductor Area mm 2 25 35 50 70 95 120 150 185 240 Nominal Conductor Diameter mm 6.1 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 Nominal Insulation Thickness mm 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.6 Approx Cable  Diameter mm 45.4 49.2 51.8 55.8 60.2 63.4 66.8 70.8 78.0 Approx Mass kg/100m 340 435 490 580 695 790 900 1040 1340 Max Pulling Tension  On Conductors kN 5.3 7.4 11 15 20 25 25 25 25 Max Pulling Tension  On Stocking Grip kN 5.3 7.4 9.4 11 13 14 16 18 21 Max Pulling Tension  On Amour Wires kN 8.3 9.7 11 13 15 16 18 21 25 Min Bending Radius : During Installation mm 820 890 930 1000 1080 1140 1200 1270 1400 Min Bending Radius : Set In Position mm 540 590 620 670 720 760 800 850 940 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 0.927 0.668 0.494 0.342 0.247 0.196 0.159 0.128 0.0986 Inductance mH/km 0.393 0.377 0.360 0.332 0.317 0.304 0.295 0.286 0.278 Inductive Reactance,  @ 50Hz Ohm/km 0.124 0.118 0.113 0.104 0.0994 0.0954 0.0927 0.0899 0.0875 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 3.46+  j0.0764 3.26+ j0.0713 3.12+ j0.0662 3.00+  j0.0577 2.72+ j0.0531 2.50+  j0.0493 2.47+  j0.0467 2.29+ j0.0441 2.13+ j0.0418 Capacitance, Phase  To Earth µF/km 0.267 0.293 0.325 0.372 0.420 0.459 0.499 0.548 0.588 Min Insulation  Resistance @ 20°C  MOhm.km 9,700 8,800 8,000 6,900 6,100 5,500 5,100 4,600 4,300 Electric Stress At  Conductor Screen  kV/mm 2.00 1.95 1.90 1.84 1.80 1.78 1.75 1.73 1.65 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.319 0.350 0.388 0.444 0.501 0.548 0.595 0.654 0.702 Short Circuit Rating Phase  ConductorkA, 1 sec 3.6 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 Metallic ScreenkA, 1 sec 3.0 3.0 3.0 3.0 3.3 3.5 3.5 3.8 4.0 Con-tinuous Current Rating In Ground,Direct Buried  A 140 170 200 245 290 325 365 410 465 In Ground,  In Singleway Ducts  A 125 140 170 205 240 280 310 350 405 In Free Air,  Unenclosed & Spaced From Wall  A 140 160 190 230 290 335 380 430 510

44 MEDIUM VOLTAGE CABLES THREE CORE HEAVY DUTY SCREENED UNARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Plain circular compacted copper Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 10kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT 1 (PVC only)  3 (HDPE) Copper 3.8/6.6kV

45 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. MEDIUM VOLTAGE CABLES Physical & Electrical Characteristics Copper 3.8/6.6kV Product Code 3CCUX6HD Nominal Conductor Area mm 2 25 35 50 70 95 120 150 185 240 300 Nominal Conductor Diameter mm 6.1 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 Nominal Insulation Thickness mm 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.6 2.8 Approx Cable  Diameter mm 38.3 40.5 43.2 46.9 51.0 54.2 57.4 61.4 67.0 73.3 Approx Mass kg/100m 175 220 275 360 450 530 615 735 920 1120 Max Pulling Tension  On Conductors kN 5.3 7.4 11 15 20 25 25 25 25 25 Max Pulling Tension  On Stocking Grip kN 5.1 5.8 6.5 7.7 9.1 10 12 13 16 19 Min Bending Radius : During Installation mm 690 730 780 840 920 980 1030 1110 1210 1320 Min Bending Radius : Set In Position mm 460 490 520 560 610 650 690 740 800 880 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 0.927 0.668 0.494 0.342 0.247 0.196 0.159 0.128 0.0986 0.0797 Inductance mH/km 0.393 0.377 0.360 0.332 0.317 0.304 0.295 0.286 0.278 0.273 Inductive Reactance,  @ 50Hz Ohm/km 0.124 0.118 0.113 0.104 0.0994 0.0954 0.0927 0.0899 0.0875 0.0857 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 3.07+  j0.0764 2.16+  j0.0713 1.56+  j0.0662 1.11+  j0.0577 1.03+  j0.0531 0.995+  j0.0493 0.966+  j0.0467 0.941+  j0.0441 0.917+  j0.0418 0.902+  j0.0402 Capacitance, Phase  To Earth µF/km 0.267 0.293 0.325 0.372 0.420 0.459 0.499 0.548 0.588 0.610 Min Insulation  Resistance @ 20°C  MOhm.km 9,700 8,800 8,000 6,900 6,100 5,500 5,100 4,600 4,300 4,100 Electric Stress At  Conductor Screen  kV/mm 2.00 1.95 1.90 1.84 1.80 1.78 1.75 1.73 1.65 1.52 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.319 0.350 0.388 0.444 0.501 0.548 0.595 0.654 0.702 0.728 Short Circuit Rating Phase  ConductorkA, 1 sec 3.6 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 Metallic ScreenkA, 1 sec 3.5 5.1 7.1 10 10 10 10 10 10 10 Con-tinuous Current Rating In Ground,Direct Buried  A 140 170 200 245 290 325 370 410 475 530 In Ground,  In Singleway Ducts  A 120 145 170 205 240 280 310 350 405 455 In Free Air,  Unenclosed & Spaced From Wall  A 135 165 195 245 295 340 385 435 510 590

46 MEDIUM VOLTAGE CABLES THREE CORE HEAVY DUTY SCREENED ARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Plain circular compacted copper Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 10kA for nominal 1 second ARMOURING: Galvanised steel wires SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT 1 (PVC only)  3 (HDPE) 3 (Armoured) Copper 3.8/6.6kV

47 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. MEDIUM VOLTAGE CABLES Physical & Electrical Characteristics Copper 3.8/6.6kV Product Code 3CCUX6HDA Nominal Conductor Area mm 2 25 35 50 70 95 120 150 185 240 Nominal Conductor Diameter mm 6.1 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 Nominal Insulation Thickness mm 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.6 Approx Cable  Diameter mm 45.4 49.4 52.0 56.0 60.2 63.4 66.8 71.0 78.4 Approx Mass kg/100m 345 450 515 625 735 830 940 1080 1390 Max Pulling Tension  On Conductors kN 5.3 7.4 11 15 20 25 25 25 25 Max Pulling Tension  On Stocking Grip kN 5.3 7.4 9.5 11 13 14 16 18 22 Max Pulling Tension  On Amour Wires kN 8.3 9.7 11 13 15 16 18 21 25 Min Bending Radius : During Installation mm 820 890 940 1010 1080 1140 1200 1280 1410 Min Bending Radius : Set In Position mm 540 590 620 670 720 760 800 850 940 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 0.927 0.668 0.494 0.342 0.247 0.196 0.159 0.128 0.0986 Inductance mH/km 0.393 0.377 0.360 0.332 0.317 0.304 0.295 0.286 0.278 Inductive Reactance,  @ 50Hz Ohm/km 0.124 0.118 0.113 0.104 0.0994 0.0954 0.0927 0.0899 0.0875 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 3.07+  j0.0764 2.16+ j0.0713 1.56+ j0.0662 1.11+ j0.0577 1.03+ j0.0531 0.995+  j0.0493 0.966+  j0.0467 0.941+  j0.0441 0.917+  j0.0418 Capacitance, Phase  To Earth µF/km 0.267 0.293 0.325 0.372 0.420 0.459 0.499 0.548 0.588 Min Insulation  Resistance @ 20°C  MOhm.km 9,700 8,800 8,000 6,900 6,100 5,500 5,100 4,600 4,300 Electric Stress At  Conductor Screen  kV/mm 2.00 1.95 1.90 1.84 1.80 1.78 1.75 1.73 1.65 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.319 0.350 0.388 0.444 0.501 0.548 0.595 0.654 0.702 Short Circuit Rating Phase  ConductorkA, 1 sec 3.6 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 Metallic ScreenkA, 1 sec 3.5 5.1 7.1 10 10 10 10 10 10 Con-tinuous Current Rating In Ground,Direct Buried  A 140 170 200 245 290 325 370 410 475 In Ground,  In Singleway Ducts  A 120 145 170 205 240 280 310 350 405 In Free Air,  Unenclosed & Spaced From Wall  A 135 165 195 245 295 340 385 435 510

48 MEDIUM VOLTAGE CABLES Aluminium 3.8/6.6kV SINGLE CORE LIGHT DUTY SCREENED UNARMOURED Cable Characteristics +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 1 (PVC only)  3 (HDPE) Installation Conditions Cable Design CONDUCTOR:  Circular compacted aluminium Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 3kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standard Orange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT

49 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. Physical & Electrical Characteristics Aluminium 3.8/6.6kV Product Code 1CALX6LD Nominal Conductor Area mm 2 25 35 50 70 95 120 150 185 240 300 400 500 630 Nominal Conductor Diameter mm 6.1 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 23.5 26.6 30.2 Nominal Insulation Thickness mm 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.6 2.8 3.0 3.2 3.2 Approx Cable  Diameter mm 19.6 20.6 21.6 23.3 25.0 26.4 27.7 29.7 32.0 35.1 39.2 43.1 46.9 Approx Mass kg/100m 50 60 65 70 85 90 100 120 140 165 200 240 290 Max Pulling Tension  On Conductor kN 1.3 1.8 2.5 3.5 4.8 6.0 7.5 9.3 12 15 20 25 25 Max Pulling Tension  On Stocking Grip kN 1.3 1.5 1.6 1.9 2.2 2.4 2.7 3.1 3.6 4.3 5.4 6.5 7.7 Min Bending Radius : During Installation mm 350 370 390 420 450 470 500 530 580 630 700 770 840 Min Bending Radius : Set In Position mm 230 250 260 280 300 320 330 360 380 420 470 520 560 Max Conductor  Resistance, dc @ 20°C  Ohm/km 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 0.0778 0.0605 0.0469 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 1.54 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.161 0.130 0.102 0.0803 0.0638 Inductance, Trefoil Touching mH/km 0.460 0.437 0.419 0.386 0.367 0.355 0.344 0.331 0.321 0.313 0.309 0.303 0.293 Inductive Reactance,  Trefoil Touching  @ 50Hz Ohm/km 0.144 0.137 0.132 0.121 0.115 0.111 0.108 0.104 0.101 0.0984 0.0970 0.0950 0.0922 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 2.37+  j0.0764 1.80+  j0.0706 1.57+  j0.0662 1.38+  j0.0575 1.25+  j0.0530 1.19+  j0.0500 1.14+  j0.0476 1.10+  j0.0441 1.06+  j0.0418 1.03+  j0.0401 1.01+  j0.0395 0.996+  j0.0379 0.982+  j0.0357 Capacitance, Phase  To Earth µF/km 0.265 0.295 0.323 0.371 0.418 0.456 0.494 0.543 0.582 0.607 0.651 0.682 0.761 Min Insulation  Resistance @ 20°C  MOhm.km 9,900 8,800 8,000 6,900 6,100 5,600 5,100 4,600 4,300 4,100 3,800 3,700 3,300 Electric Stress At  Conductor Screen  kV/mm 2.00 1.94 1.90 1.84 1.80 1.78 1.76 1.73 1.65 1.52 1.41 1.32 1.30 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.316 0.352 0.385 0.443 0.499 0.545 0.590 0.648 0.695 0.725 0.777 0.814 0.909 Short Circuit Rating Phase  ConductorkA, 1 sec 2.4 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 37.8 47.2 59.5 Metallic ScreenkA, 1 sec 2.4 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 Con-tinuous Current Rating In Ground,Direct Buried  A 115 135 160 195 230 260 295 330 385 435 495 560 640 In Ground,  In Singleway Ducts  A 115 135 155 190 225 255 285 320 365 410 465 530 595 In Free Air,  Unenclosed & Spaced From Wall  A 110 135 160 200 245 285 325 375 440 510 600 695 810

50 MEDIUM VOLTAGE CABLES SINGLE CORE HEAVY DUTY SCREENED UNARMOURED Cable Characteristics +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 1 (PVC only)  3 (HDPE) Installation Conditions Cable Design CONDUCTOR:  Circular compacted aluminium Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 10kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standard Orange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT Aluminium 3.8/6.6kV

51 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. Physical & Electrical Characteristics Aluminium 3.8/6.6kV Product Code 1CALX6HD Nominal Conductor Area mm 2 25 35 50 70 95 120 150 185 240 300 400 500 630 Nominal Conductor Diameter mm 6.1 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 23.5 26.6 30.2 Nominal Insulation Thickness mm 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.6 2.8 3.0 3.2 3.2 Approx Cable  Diameter mm 19.6 20.6 22.9 24.6 26.3 27.7 29.0 31.0 33.5 36.6 40.7 44.4 48.2 Approx Mass kg/100m 50 60 75 95 120 135 150 165 185 210 250 285 335 Max Pulling Tension  On Conductor kN 1.3 1.8 2.5 3.5 4.8 6.0 7.5 9.3 12 15 20 25 25 Max Pulling Tension  On Stocking Grip kN 1.3 1.5 1.8 2.1 2.4 2.7 3.0 3.4 3.9 4.7 5.8 6.9 8.1 Min Bending Radius : During Installation mm 350 370 410 440 470 500 520 560 600 660 730 800 870 Min Bending Radius : Set In Position mm 230 250 280 300 320 330 350 370 400 440 490 530 580 Max Conductor  Resistance, dc @ 20°C  Ohm/km 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 0.0778 0.0605 0.0469 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 1.54 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.161 0.130 0.102 0.0802 0.0637 Inductance, Trefoil Touching mH/km 0.460 0.437 0.432 0.397 0.378 0.365 0.354 0.340 0.330 0.322 0.317 0.309 0.299 Inductive Reactance,  Trefoil Touching  @ 50Hz Ohm/km 0.144 0.137 0.136 0.125 0.119 0.115 0.111 0.107 0.104 0.101 0.0994 0.0970 0.0940 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 2.37+  j0.0764 1.71+  j0.0706 1.24+  j0.0686 0.871+  j0.0597 0.635+  j0.0549 0.535+  j0.0519 0.488+  j0.0493 0.446+  j0.0457 0.407+  j0.0433 0.382+  j0.0415 0.360+  j0.0407 0.343+  j0.0390 0.330+  j0.0367 Capacitance, Phase  To Earth µF/km 0.265 0.295 0.323 0.371 0.418 0.456 0.494 0.543 0.582 0.607 0.651 0.682 0.761 Min Insulation  Resistance @ 20°C  MOhm.km 9,900 8,800 8,000 6,900 6,100 5,600 5,100 4,600 4,300 4,100 3,800 3,700 3,300 Electric Stress At  Conductor Screen  kV/mm 2.00 1.94 1.90 1.84 1.80 1.78 1.76 1.73 1.65 1.52 1.41 1.32 1.30 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.316 0.352 0.385 0.443 0.499 0.545 0.590 0.648 0.695 0.725 0.777 0.814 0.909 Short Circuit Rating Phase  ConductorkA, 1 sec 2.4 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 37.8 47.2 59.5 Metallic ScreenkA, 1 sec 2.4 3.3 4.7 6.6 8.9 10 10 10 10 10 10 10 10 Con-tinuous Current Rating In Ground,Direct Buried  A 115 135 160 195 230 260 290 330 380 425 480 545 610 In Ground,  In Singleway Ducts  A 115 135 155 190 220 245 270 300 340 375 420 470 520 In Free Air,  Unenclosed & Spaced From Wall  A 110 135 165 205 250 285 325 375 440 505 590 680 785

52 MEDIUM VOLTAGE CABLES THREE CORE LIGHT DUTY SCREENED UNARMOURED Cable Characteristics +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 1 (PVC only)  3 (HDPE) Installation Conditions Cable Design CONDUCTOR:  Circular compacted aluminium Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 3kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT Aluminium 3.8/6.6kV

53 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. Physical & Electrical Characteristics Aluminium 3.8/6.6kV Product Code 3CALX6LD Nominal Conductor Area mm 2 25 35 50 70 95 120 150 185 240 300 Nominal Conductor Diameter mm 6.1 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 Nominal Insulation Thickness mm 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.6 2.8 Approx Cable  Diameter mm 38.3 40.7 43.1 46.9 50.8 53.9 57.2 61.2 66.5 73.3 Approx Mass kg/100m 120 140 160 195 230 265 305 355 430 525 Max Pulling Tension  On Conductors kN 3.8 5.3 7.5 11 14 18 23 25 25 25 Max Pulling Tension  On Stocking Grip kN 3.8 5.3 6.5 7.7 9.0 10 11 13 15 19 Min Bending Radius : During Installation mm 690 730 780 840 910 970 1030 1100 1200 1320 Min Bending Radius : Set In Position mm 460 490 520 560 610 650 690 730 800 880 Max Conductor  Resistance, dc @ 20°C  Ohm/km 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 1.54 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.162 0.130 Inductance mH/km 0.394 0.375 0.360 0.332 0.317 0.307 0.298 0.287 0.279 0.273 Inductive Reactance,  @ 50Hz Ohm/km 0.124 0.118 0.113 0.104 0.0994 0.0964 0.0937 0.0901 0.0876 0.0857 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 4.84+  j0.0766 3.60+  j0.0709 3.37+  j0.0664 3.18+  j0.0577 2.84+  j0.0531 2.60+  j0.0502 2.55+  j0.0477 2.35+  j0.0442 2.18+  j0.0420 1.92+  j0.0402 Capacitance, Phase  To Earth µF/km 0.266 0.296 0.324 0.372 0.420 0.458 0.496 0.545 0.584 0.610 Min Insulation  Resistance @ 20°C  MOhm.km 9,900 8,800 8,000 6,900 6,100 5,600 5,100 4,600 4,300 4,100 Electric Stress At  Conductor Screen  kV/mm 2.00 1.94 1.90 1.84 1.80 1.78 1.76 1.73 1.65 1.52 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.317 0.353 0.387 0.444 0.501 0.547 0.592 0.650 0.697 0.728 Short Circuit Rating Phase  ConductorkA, 1 sec 2.4 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 Metallic ScreenkA, 1 sec 2.3 3.0 3.0 3.0 3.3 3.5 3.5 3.8 4.0 4.6 Con-tinuous Current Rating In Ground,Direct Buried  A 110 130 155 190 225 255 285 320 370 420 In Ground,  In Singleway Ducts  A 95 110 130 160 185 215 245 275 320 360 In Free Air,  Unenclosed & Spaced From Wall  A 105 125 145 180 220 255 290 330 395 450

54 MEDIUM VOLTAGE CABLES THREE CORE LIGHT DUTY SCREENED ARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Circular compacted aluminium Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 3kA for nominal 1 second ARMOURING: Galvanised steel wires SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT 1 (PVC only)  3 (HDPE) 3 (Armoured) Aluminium 3.8/6.6kV

55 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. Physical & Electrical Characteristics Aluminium 3.8/6.6kV Product Code 3CALX6LDA Nominal Conductor Area mm 2 25 35 50 70 95 120 150 185 240 Nominal Conductor Diameter mm 6.1 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 Nominal Insulation Thickness mm 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.6 Approx Cable  Diameter mm 45.3 49.4 51.7 55.8 60.2 63.3 66.6 70.5 77.7 Approx Mass kg/100m 290 365 400 455 520 565 630 700 895 Max Pulling Tension  On Conductors kN 3.8 5.3 7.5 11 14 18 23 25 25 Max Pulling Tension  On Stocking Grip kN 3.8 5.3 7.5 11 13 14 16 17 21 Max Pulling Tension  On Amour Wires kN 8.3 9.8 11 13 15 16 18 20 25 Min Bending Radius : During Installation mm 820 890 930 1000 1080 1140 1200 1270 1400 Min Bending Radius : Set In Position mm 540 590 620 670 720 760 800 850 930 Max Conductor  Resistance, dc @ 20°C  Ohm/km 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 1.54 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.162 Inductance mH/km 0.394 0.375 0.360 0.332 0.317 0.307 0.298 0.287 0.279 Inductive Reactance,  @ 50Hz Ohm/km 0.124 0.118 0.113 0.104 0.0994 0.0964 0.0937 0.0901 0.0876 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 4.84+  j0.0766 3.60+  j0.0709 3.37+  j0.0664 3.18+   j0.0577 2.84+   j0.0531 2.60+  j0.0502 2.55+  j0.0477 2.35+  j0.0442 2.18+   j0.0420 Capacitance, Phase  To Earth µF/km 0.266 0.296 0.324 0.372 0.420 0.458 0.496 0.545 0.584 Min Insulation  Resistance @ 20°C  MOhm.km 9,900 8,800 8,000 6,900 6,100 5,600 5,100 4,600 4,300 Electric Stress At  Conductor Screen  kV/mm 2.00 1.94 1.90 1.84 1.80 1.78 1.76 1.73 1.65 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.317 0.353 0.387 0.444 0.501 0.547 0.592 0.650 0.697 Short Circuit Rating Phase  ConductorkA, 1 sec 2.4 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 Metallic ScreenkA, 1 sec 2.3 3.0 3.0 3.0 3.3 3.5 3.5 3.8 4.0 Con-tinuous Current Rating In Ground,Direct Buried  A 110 130 155 190 225 255 285 320 370 In Ground,  In Singleway Ducts  A 95 110 130 160 185 215 245 275 320 In Free Air,  Unenclosed & Spaced From Wall  A 105 125 145 180 220 255 290 330 395

56 MEDIUM VOLTAGE CABLES THREE CORE HEAVY DUTY SCREENED UNARMOURED Cable Characteristics +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 1 (PVC only)  3 (HDPE) Installation Conditions Cable Design CONDUCTOR:  Circular compacted aluminium Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 10kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT Aluminium 3.8/6.6kV

57 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. Physical & Electrical Characteristics Aluminium 3.8/6.6kV Product Code 3CALX6HD  Nominal Conductor Area mm 2 25 35 50 70 95 120 150 185 240 300 Nominal Conductor Diameter mm 6.1 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 Nominal Insulation Thickness mm 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.6 2.8 Approx Cable  Diameter mm 38.3 40.7 43.1 46.9 51.0 54.1 57.2 61.2 66.7 73.3 Approx Mass kg/100m 120 145 170 215 270 305 345 395 470 560 Max Pulling Tension  On Conductors kN 3.8 5.3 7.5 11 14 18 23 25 25 25 Max Pulling Tension  On Stocking Grip kN 3.8 5.3 6.5 7.7 9.1 10 11 13 16 19 Min Bending Radius : During Installation mm 690 730 780 840 920 970 1030 1100 1200 1320 Min Bending Radius : Set In Position mm 460 490 520 560 610 650 690 730 800 880 Max Conductor  Resistance, dc @ 20°C  Ohm/km 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 1.54 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.162 0.130 Inductance mH/km 0.394 0.375 0.360 0.332 0.317 0.307 0.298 0.287 0.279 0.273 Inductive Reactance,  @ 50Hz Ohm/km 0.124 0.118 0.113 0.104 0.0994 0.0964 0.0937 0.0901 0.0876 0.0857 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 4.48+  j0.0766 3.39+  j0.0709 2.46+  j0.0664 1.70+  j0.0577 1.26+  j0.0531 1.09+  j0.0502 1.05+  j0.0477 1.01+  j0.0442 0.967+  j0.0420 0.942+  j0.0402 Capacitance, Phase  To Earth µF/km 0.266 0.296 0.324 0.372 0.420 0.458 0.496 0.545 0.584 0.610 Min Insulation  Resistance @ 20°C  MOhm.km 9,900 8,800 8,000 6,900 6,100 5,600 5,100 4,600 4,300 4,100 Electric Stress At  Conductor Screen  kV/mm 2.00 1.94 1.90 1.84 1.80 1.78 1.76 1.73 1.65 1.52 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.317 0.353 0.387 0.444 0.501 0.547 0.592 0.650 0.697 0.728 Short Circuit Rating Phase  ConductorkA, 1 sec 2.4 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 Metallic ScreenkA, 1 sec 2.5 3.3 4.6 6.6 8.9 10 10 10 10 10 Con-tinuous Current Rating In Ground,Direct Buried  A 110 130 155 190 225 255 285 325 375 420 In Ground,  In Singleway Ducts  A 95 110 130 160 190 215 240 275 320 365 In Free Air,  Unenclosed & Spaced From Wall  A 105 125 145 180 225 260 300 340 405 460

58 MEDIUM VOLTAGE CABLES THREE CORE HEAVY DUTY SCREENED ARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Circular compacted aluminium Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 10kA for nominal 1 second ARMOURING: Galvanised steel wires SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT 1 (PVC only)  3 (HDPE) 3 (Armoured) Aluminium 3.8/6.6kV

59 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. Physical & Electrical Characteristics Aluminium 3.8/6.6kV Product Code 3CALX6HDA Nominal Conductor Area mm 2 25 35 50 70 95 120 150 185 240 Nominal Conductor Diameter mm 6.1 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 Nominal Insulation Thickness mm 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.6 Approx Cable  Diameter mm 45.3 49.4 51.9 56.0 60.2 63.3 66.6 70.7 78.1 Approx Mass kg/100m 290 370 415 480 555 605 670 740 940 Max Pulling Tension  On Conductors kN 3.8 5.3 7.5 11 14 18 23 25 25 Max Pulling Tension  On Stocking Grip kN 3.8 5.3 7.5 11 13 14 16 18 21 Max Pulling Tension  On Amour Wires kN 8.3 9.8 11 13 15 16 18 21 25 Min Bending Radius : During Installation mm 820 890 930 1010 1080 1140 1200 1270 1410 Min Bending Radius : Set In Position mm 540 590 620 670 720 760 800 850 940 Max Conductor  Resistance, dc @ 20°C  Ohm/km 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 1.54 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.162 Inductance mH/km 0.394 0.375 0.360 0.332 0.317 0.307 0.298 0.287 0.279 Inductive Reactance,  @ 50Hz Ohm/km 0.124 0.118 0.113 0.104 0.0994 0.0964 0.0937 0.0901 0.0876 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 4.48+  j0.0766 3.39+  j0.0709 2.46+  j0.0664 1.70+   j0.0577 1.26+   j0.0531 1.09+  j0.0502 1.05+   j0.0477 1.01+   j0.0442 0.967+  j0.0420 Capacitance, Phase  To Earth µF/km 0.266 0.296 0.324 0.372 0.420 0.458 0.496 0.545 0.584 Min Insulation  Resistance @ 20°C  MOhm.km 9,900 8,800 8,000 6,900 6,100 5,600 5,100 4,600 4,300 Electric Stress At  Conductor Screen  kV/mm 2.00 1.94 1.90 1.84 1.80 1.78 1.76 1.73 1.65 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.317 0.353 0.387 0.444 0.501 0.547 0.592 0.650 0.697 Short Circuit Rating Phase  ConductorkA, 1 sec 2.4 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 Metallic ScreenkA, 1 sec 2.5 3.3 4.6 6.6 8.9 10 10 10 10 Con-tinuous Current Rating In Ground,Direct Buried  A 110 130 155 190 225 255 285 325 375 In Ground,  In Singleway Ducts  A 95 110 130 160 190 215 240 275 320 In Free Air,  Unenclosed & Spaced From Wall  A 105 125 145 180 225 260 300 340 405

60 MEDIUM VOLTAGE CABLES Copper 6.35/11kV SINGLE CORE LIGHT DUTY SCREENED UNARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Plain circular compacted copper Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded, semi-conductive compound METALLIC SCREEN: Plain annealed copper wire: 3kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT 12D (PVC only) 15D (HDPE) 1 (PVC only)  3 (HDPE)

61 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. MEDIUM VOLTAGE CABLES Physical & Electrical Characteristics Copper 6.35/11kV Product Code 1CCUX11LD Nominal Conductor Area mm 2 25 35 50 70 95 120 150 185 240 300 400 500 630 Nominal Conductor Diameter mm 6.1 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 23.5 26.6 30.3 Nominal Insulation Thickness mm 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 Approx Cable  Diameter mm 21.4 22.4 23.5 25.1 26.8 28.2 29.8 31.6 34.0 36.7 40.4 43.7 47.6 Approx Mass kg/100m 75 85 100 120 150 175 200 240 295 360 445 555 690 Max Pulling Tension  On Conductor kN 1.8 2.5 3.5 4.9 6.7 8.4 11 13 17 21 25 25 25 Max Pulling Tension  On Stocking Grip kN 1.6 1.7 1.9 2.2 2.5 2.8 3.1 3.5 4.0 4.7 5.7 6.7 7.9 Min Bending Radius : During Installation mm 390 400 420 450 480 510 540 570 610 660 730 790 860 Min Bending Radius : Set In Position mm 260 270 280 300 320 340 360 380 410 440 480 520 570 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 0.0470 0.0366 0.0283 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 0.927 0.668 0.494 0.342 0.247 0.196 0.159 0.128 0.0981 0.0791 0.0632 0.0509 0.0415 Inductance, Trefoil Touching mH/km 0.477 0.456 0.435 0.402 0.382 0.365 0.355 0.343 0.332 0.322 0.314 0.304 0.296 Inductive Reactance,  Trefoil Touching  @ 50Hz Ohm/km 0.150 0.143 0.137 0.126 0.120 0.115 0.112 0.108 0.104 0.101 0.0985 0.0955 0.0930 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 1.66+  j0.0833 1.46+  j0.0778 1.32+  j0.0724 1.20+  j0.0633 1.13+  j0.0583 1.09+  j0.0541 1.06+  j0.0513 1.03+  j0.0483 1.01+  j0.0453 0.995+  j0.0430 0.982+  j0.0409 0.973+  j0.0385 0.965+  j0.0366 Capacitance, Phase  To Earth µF/km 0.211 0.230 0.254 0.289 0.324 0.353 0.382 0.418 0.463 0.516 0.586 0.650 0.725 Min Insulation  Resistance @ 20°C  MOhm.km 12,000 11,000 10,000 8,900 7,900 7,200 6,600 6,000 5,400 4,900 4,300 3,900 3,400 Electric Stress At  Conductor Screen  kV/mm 2.64 2.56 2.49 2.40 2.33 2.29 2.25 2.22 2.18 2.14 2.11 2.08 2.06 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.420 0.460 0.507 0.576 0.646 0.704 0.762 0.834 0.924 1.03 1.17 1.30 1.45 Short Circuit Rating Phase  ConductorkA, 1 sec 3.6 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 57.2 71.5 90.1 Metallic ScreenkA, 1 sec 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 Con-tinuous Current Rating In Ground,Direct Buried  A 145 175 205 250 300 335 375 425 490 550 620 700 780 In Ground,  In Singleway Ducts  A 145 170 200 245 285 325 360 400 460 515 575 645 720 In Free Air,  Unenclosed & Spaced From Wall  A 145 175 210 265 320 370 420 480 570 650 755 870 995

62 MEDIUM VOLTAGE CABLES SINGLE CORE HEAVY DUTY SCREENED UNARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Plain circular compacted copper Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 10kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C 1 (PVC only)  3 (HDPE) Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT Copper 6.35/11kV

63 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. MEDIUM VOLTAGE CABLES Physical & Electrical Characteristics Copper 6.35/11kV Product Code 1CCUX11HD  Nominal Conductor Area mm 2 25 35 50 70 95 120 150 185 240 300 400 500 630 Nominal Conductor Diameter mm 6.1 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 23.5 26.6 30.3 Nominal Insulation Thickness mm 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 Approx Cable  Diameter mm 21.4 23.7 24.8 27.1 28.1 29.5 31.1 32.9 35.3 38.0 41.7 45.0 48.9 Approx Mass kg/100m 80 100 125 165 195 220 245 285 340 405 495 600 735 Max Pulling Tension  On Conductor kN 1.8 2.5 3.5 4.9 6.7 8.4 11 13 17 21 25 25 25 Max Pulling Tension  On Stocking Grip kN 1.6 2.0 2.1 2.6 2.8 3.1 3.4 3.8 4.4 5.1 6.1 7.1 8.4 Min Bending Radius : During Installation mm 390 430 450 490 510 530 560 590 630 680 750 810 880 Min Bending Radius : Set In Position mm 260 280 300 330 340 350 370 390 420 460 500 540 590 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 0.0470 0.0366 0.0283 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 0.927 0.668 0.494 0.342 0.247 0.196 0.159 0.128 0.0980 0.0790 0.0630 0.0507 0.0413 Inductance, Trefoil Touching mH/km 0.477 0.468 0.447 0.418 0.392 0.375 0.364 0.352 0.339 0.330 0.320 0.310 0.302 Inductive Reactance,  Trefoil Touching  @ 50Hz Ohm/km 0.150 0.147 0.140 0.131 0.123 0.118 0.114 0.110 0.107 0.104 0.101 0.0974 0.0948 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 1.51+  j0.0833 1.09+  j0.0801 0.783+  j0.0745 0.560+  j0.0663 0.475+  j0.0601 0.435+  j0.0559 0.406+  j0.0529 0.381+  j0.0498 0.358+  j0.0467 0.343+  j0.0443 0.330+  j0.0421 0.320+  j0.0395 0.312+  j0.0375 Capacitance, Phase  To Earth µF/km 0.211 0.230 0.254 0.289 0.324 0.353 0.382 0.418 0.463 0.516 0.586 0.650 0.725 Min Insulation  Resistance @ 20°C  MOhm.km 12,000 11,000 10,000 8,900 7,900 7,200 6,600 6,000 5,400 4,900 4,300 3,900 3,400 Electric Stress At  Conductor Screen  kV/mm 2.64 2.56 2.49 2.40 2.33 2.29 2.25 2.22 2.18 2.14 2.11 2.08 2.06 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.420 0.460 0.507 0.576 0.646 0.704 0.762 0.834 0.924 1.03 1.17 1.30 1.45 Short Circuit Rating Phase  ConductorkA, 1 sec 3.6 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 57.2 71.5 90.1 Metallic ScreenkA, 1 sec 3.5 5.0 7.1 10 10 10 10 10 10 10 10 10 10 Con-tinuous Current Rating In Ground,Direct Buried  A 145 175 205 250 295 335 370 415 475 530 595 665 735 In Ground,  In Singleway Ducts  A 145 170 195 235 270 300 330 365 410 450 495 545 600 In Free Air,  Unenclosed & Spaced From Wall  A 145 180 215 270 320 370 420 480 560 640 735 835 950

64 MEDIUM VOLTAGE CABLES THREE CORE LIGHT DUTY SCREENED UNARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Plain circular compacted copper Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 3kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT 1 (PVC only)  3 (HDPE) Copper 6.35/11kV

65 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. MEDIUM VOLTAGE CABLES Physical & Electrical Characteristics Copper 6.35/11kV Product Code 3CCUX11LD  Nominal Conductor Area mm 2 25 35 50 70 95 120 150 185 240 300 Nominal Conductor Diameter mm 6.1 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 Nominal Insulation Thickness mm 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 Approx Cable  Diameter mm 42.6 44.6 47.3 51.2 55.1 58.3 61.5 65.5 70.6 76.3 Approx Mass kg/100m 195 230 270 345 440 520 610 730 915 1110 Max Pulling Tension  On Conductors kN 5.3 7.4 11 15 20 25 25 25 25 25 Max Pulling Tension  On Stocking Grip kN 5.3 7.0 7.8 9.2 11 12 13 15 17 20 Min Bending Radius : During Installation mm 770 800 850 920 990 1050 1110 1180 1270 1370 Min Bending Radius : Set In Position mm 510 540 570 610 660 700 740 790 850 920 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 0.927 0.668 0.494 0.342 0.247 0.196 0.159 0.128 0.0984 0.0796 Inductance mH/km 0.415 0.397 0.379 0.350 0.333 0.319 0.310 0.300 0.290 0.282 Inductive Reactance,  @ 50Hz Ohm/km 0.130 0.125 0.119 0.110 0.105 0.100 0.0973 0.0942 0.0910 0.0885 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 3.46+  j0.0836 3.26+  j0.0781 3.12+  j0.0726 2.79+  j0.0635 2.54+  j0.0585 2.34+  j0.0543 2.17+  j0.0515 2.03+  j0.0485 1.90+  j0.0454 1.70+  j0.0431 Capacitance, Phase  To Earth µF/km 0.212 0.231 0.255 0.290 0.325 0.354 0.383 0.419 0.465 0.518 Min Insulation  Resistance @ 20°C  MOhm.km 12,000 11,000 10,000 8,900 7,900 7,200 6,600 6,000 5,400 4,900 Electric Stress At  Conductor Screen  kV/mm 2.64 2.56 2.49 2.40 2.33 2.29 2.25 2.22 2.18 2.14 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.422 0.461 0.509 0.578 0.648 0.706 0.764 0.837 0.927 1.03 Short Circuit Rating Phase  ConductorkA, 1 sec 3.6 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 Metallic ScreenkA, 1 sec 3.0 3.0 3.0 3.3 3.5 3.8 4.0 4.3 4.6 5.1 Con-tinuous Current Rating In Ground,Direct Buried  A 140 165 195 235 280 325 365 410 475 530 In Ground,  In Singleway Ducts  A 120 145 170 205 240 280 310 350 405 455 In Free Air,  Unenclosed & Spaced From Wall  A 135 160 190 235 285 330 380 435 510 580

66 MEDIUM VOLTAGE CABLES THREE CORE LIGHT DUTY SCREENED ARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Plain circular compacted copper Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 3kA for nominal 1 second ARMOURING: Galvanised steel wires SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT 1 (PVC only)  3 (HDPE) 3 (Armoured) Copper 6.35/11kV

67 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. MEDIUM VOLTAGE CABLES Physical & Electrical Characteristics Copper 6.35/11kV Product Code 3CCUX11LDA Nominal Conductor Area mm 2 25 35 50 70 95 120 150 185 240 Nominal Conductor Diameter mm 6.1 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 Nominal Insulation Thickness mm 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 Approx Cable  Diameter mm 51.3 53.5 56.3 60.4 64.2 67.7 71.1 75.2 82.1 Approx Mass kg/100m 430 475 535 630 745 850 955 1100 1400 Max Pulling Tension  On Conductors kN 5.3 7.4 11 15 20 25 25 25 25 Max Pulling Tension  On Stocking Grip kN 5.3 7.4 11 13 14 16 18 20 24 Max Pulling Tension  On Amour Wires kN 11 12 13 15 17 19 21 23 25 Min Bending Radius : During Installation mm 920 960 1010 1090 1160 1220 1280 1350 1480 Min Bending Radius : Set In Position mm 620 640 680 720 770 810 850 900 980 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 0.927 0.668 0.494 0.342 0.247 0.196 0.159 0.128 0.0984 Inductance mH/km 0.415 0.397 0.379 0.350 0.333 0.319 0.310 0.300 0.290 Inductive Reactance,  @ 50Hz Ohm/km 0.130 0.125 0.119 0.110 0.105 0.100 0.0973 0.0942 0.0910 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 3.46+  j0.0836 3.26+ j0.0781 3.12+ j0.0726 2.79+  j0.0635 2.54+  j0.0585 2.34+  j0.0543 2.17+ j0.0515 2.03+  j0.0485 1.90+  j0.0454 Capacitance, Phase  To Earth µF/km 0.212 0.231 0.255 0.290 0.325 0.354 0.383 0.419 0.465 Min Insulation  Resistance @ 20°C  MOhm.km 12,000 11,000 10,000 8,900 7,900 7,200 6,600 6,000 5,400 Electric Stress At  Conductor Screen  kV/mm 2.64 2.56 2.49 2.40 2.33 2.29 2.25 2.22 2.18 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.422 0.461 0.509 0.578 0.648 0.706 0.764 0.837 0.927 Short Circuit Rating Phase  ConductorkA, 1 sec 3.6 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 Metallic ScreenkA, 1 sec 3.0 3.0 3.0 3.3 3.5 3.8 4.0 4.3 4.6 Con-tinuous Current Rating In Ground,Direct Buried  A 140 165 195 235 280 325 365 410 475 In Ground,  In Singleway Ducts  A 120 145 170 205 240 280 310 350 405 In Free Air,  Unenclosed & Spaced From Wall  A 135 160 190 235 285 330 380 435 510

68 MEDIUM VOLTAGE CABLES THREE CORE HEAVY DUTY SCREENED UNARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Plain circular compacted copper Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 10kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT 1 (PVC only)  3 (HDPE) Copper 6.35/11kV

69 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. MEDIUM VOLTAGE CABLES Physical & Electrical Characteristics Copper 6.35/11kV Product Code 3CCUX11HD Nominal Conductor Area mm 2 25 35 50 70 95 120 150 185 240 300 Nominal Conductor Diameter mm 6.1 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 Nominal Insulation Thickness mm 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 Approx Cable  Diameter mm 42.6 44.8 47.5 51.2 55.1 58.3 61.5 65.5 70.6 76.3 Approx Mass kg/100m 195 245 300 390 480 560 645 765 945 1140 Max Pulling Tension  On Conductors kN 5.3 7.4 11 15 20 25 25 25 25 25 Max Pulling Tension  On Stocking Grip kN 5.3 7.0 7.9 9.2 11 12 13 15 17 20 Min Bending Radius : During Installation mm 770 810 850 920 990 1050 1110 1180 1270 1370 Min Bending Radius : Set In Position mm 510 540 570 610 660 700 740 790 850 920 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 0.927 0.668 0.494 0.342 0.247 0.196 0.159 0.128 0.0984 0.0796 Inductance mH/km 0.415 0.397 0.379 0.350 0.333 0.319 0.310 0.300 0.290 0.282 Inductive Reactance,  @ 50Hz Ohm/km 0.130 0.125 0.119 0.110 0.105 0.100 0.0973 0.0942 0.0910 0.0885 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 3.07+  j0.0836 2.16+  j0.0781 1.56+  j0.0726 1.11+  j0.0635 1.03+  j0.0585 0.995+  j0.0543 0.966+ j0.0515 0.941+  j0.0485 0.917+  j0.0454 0.902+  j0.0431 Capacitance, Phase  To Earth µF/km 0.212 0.231 0.255 0.290 0.325 0.354 0.383 0.419 0.465 0.518 Min Insulation  Resistance @ 20°C  MOhm.km 12,000 11,000 10,000 8,900 7,900 7,200 6,600 6,000 5,400 4,900 Electric Stress At  Conductor Screen  kV/mm 2.64 2.56 2.49 2.40 2.33 2.29 2.25 2.22 2.18 2.14 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.422 0.461 0.509 0.578 0.648 0.706 0.764 0.837 0.927 1.03 Short Circuit Rating Phase  ConductorkA, 1 sec 3.6 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 Metallic ScreenkA, 1 sec 3.5 5.1 7.1 10 10 10 10 10 10 10 Con-tinuous Current Rating In Ground,Direct Buried  A 135 165 195 245 290 330 370 410 475 530 In Ground,  In Singleway Ducts  A 120 145 170 205 245 280 310 350 410 460 In Free Air,  Unenclosed & Spaced From Wall  A 135 165 195 245 295 345 385 440 520 290

70 MEDIUM VOLTAGE CABLES THREE CORE HEAVY DUTY SCREENED ARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Plain circular compacted copper Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 10kA for nominal 1 second ARMOURING: Galvanised steel wires SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT 1 (PVC only)  3 (HDPE) 3 (Armoured) Copper 6.35/11kV

71 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. MEDIUM VOLTAGE CABLES Physical & Electrical Characteristics Copper 6.35/11kV Product Code 3CCUX11HDA Nominal Conductor Area mm 2 25 35 50 70 95 120 150 185 240 Nominal Conductor Diameter mm 6.1 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 Nominal Insulation Thickness mm 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 Approx Cable  Diameter mm 51.3 53.7 56.3 60.4 64.4 67.9 71.3 76.7 82.1 Approx Mass kg/100m 430 495 560 675 795 890 995 1220 1440 Max Pulling Tension  On Conductors kN 5.3 7.4 11 15 20 25 25 25 25 Max Pulling Tension  On Stocking Grip kN 5.3 7.4 11 13 15 16 18 21 24 Max Pulling Tension  On Amour Wires kN 11 12 13 15 17 19 21 24 25 Min Bending Radius : During Installation mm 920 970 1010 1090 1160 1220 1280 1380 1480 Min Bending Radius : Set In Position mm 620 640 680 720 770 810 860 920 980 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 0.927 0.668 0.494 0.342 0.247 0.196 0.159 0.128 0.0984 Inductance mH/km 0.415 0.397 0.379 0.350 0.333 0.319 0.310 0.300 0.290 Inductive Reactance,  @ 50Hz Ohm/km 0.130 0.125 0.119 0.110 0.105 0.100 0.0973 0.0942 0.0910 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 3.07+  j0.0836 2.16+ j0.0781 1.56+ j0.0726 1.11+ j0.0635 1.03+  j0.0585 0.995+  j0.0543 0.966+ j0.0515 0.941+  j0.0485 0.917+  j0.0454 Capacitance, Phase  To Earth µF/km 0.212 0.231 0.255 0.290 0.325 0.354 0.383 0.419 0.465 Min Insulation  Resistance @ 20°C  MOhm.km 12,000 11,000 10,000 8,900 7,900 7,200 6,600 6,000 5,400 Electric Stress At  Conductor Screen  kV/mm 2.64 2.56 2.49 2.40 2.33 2.29 2.25 2.22 2.18 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.422 0.461 0.509 0.578 0.648 0.706 0.764 0.837 0.927 Short Circuit Rating Phase  ConductorkA, 1 sec 3.6 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 Metallic ScreenkA, 1 sec 3.5 5.1 7.1 10 10 10 10 10 10 Con-tinuous Current Rating In Ground,Direct Buried  A 135 165 195 245 290 330 370 410 475 In Ground,  In Singleway Ducts  A 120 145 170 205 245 280 310 350 410 In Free Air,  Unenclosed & Spaced From Wall  A 135 165 195 245 295 345 385 440 520

72 MEDIUM VOLTAGE CABLES Aluminium 6.35/11kV SINGLE CORE LIGHT DUTY SCREENED UNARMOURED Cable Characteristics +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 1 (PVC only)  3 (HDPE) Installation Conditions Cable Design CONDUCTOR:  Circular compacted aluminium Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 3kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standard Orange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT

73 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. Physical & Electrical Characteristics Aluminium 6.35/11kV Product Code 1CALX11LD  Nominal Conductor Area mm 2 25 35 50 70 95 120 150 185 240 300 400 500 630 Nominal Conductor Diameter mm 6.1 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 23.5 26.6 30.2 Nominal Insulation Thickness mm 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 Approx Cable  Diameter mm 21.4 22.4 23.4 25.1 26.8 28.2 29.7 31.5 33.8 36.7 40.4 43.7 47.5 Approx Mass kg/100m 55 65 70 80 90 100 110 125 150 175 210 245 295 Max Pulling Tension  On Conductor kN 1.3 1.8 2.5 3.5 4.8 6.0 7.5 9.3 12 15 20 25 25 Max Pulling Tension  On Stocking Grip kN 1.3 1.8 1.9 2.2 2.5 2.8 3.1 3.5 4.0 4.7 5.7 6.7 7.9 Min Bending Radius : During Installation mm 380 400 420 450 480 510 540 570 610 660 730 790 860 Min Bending Radius : Set In Position mm 260 270 280 300 320 340 360 380 410 440 480 520 570 Max Conductor  Resistance, dc @ 20°C  Ohm/km 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 0.0778 0.0605 0.0469 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 1.54 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.161 0.130 0.102 0.0803 0.0637 Inductance, Trefoil Touching mH/km 0.478 0.455 0.436 0.402 0.382 0.369 0.359 0.344 0.332 0.322 0.315 0.305 0.296 Inductive Reactance,  Trefoil Touching  @ 50Hz Ohm/km 0.150 0.143 0.137 0.126 0.120 0.116 0.113 0.108 0.104 0.101 0.0990 0.0960 0.0930 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 2.37+  j0.0836 1.80+  j0.0774 1.57+  j0.0726 1.38+  j0.0633 1.25+  j0.0583 1.19+  j0.0551 1.14+  j0.0523 1.10+  j0.0485 1.06+  j0.0454 1.03+  j0.0430 1.01+  j0.0413 0.996+  j0.0389 0.982+  j0.0366 Capacitance, Phase  To Earth µF/km 0.210 0.232 0.253 0.289 0.324 0.352 0.380 0.416 0.460 0.516 0.586 0.650 0.724 Min Insulation  Resistance @ 20°C  MOhm.km 12,000 11,000 10,000 8,900 7,900 7,200 6,600 6,000 5,400 4,900 4,300 3,900 3,400 Electric Stress At  Conductor Screen  kV/mm 2.65 2.56 2.49 2.40 2.33 2.29 2.25 2.22 2.18 2.14 2.11 2.08 2.06 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.419 0.463 0.505 0.576 0.646 0.702 0.758 0.830 0.918 1.03 1.17 1.30 1.44 Short Circuit Rating Phase  ConductorkA, 1 sec 2.4 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 37.8 47.2 59.5 Metallic ScreenkA, 1 sec 2.4 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 Con-tinuous Current Rating In Ground,Direct Buried  A 115 135 160 195 230 260 295 330 385 435 495 560 640 In Ground,  In Singleway Ducts  A 115 135 155 190 225 255 285 320 365 410 465 530 595 In Free Air,  Unenclosed & Spaced From Wall  A 115 135 165 205 250 285 325 375 445 510 600 700 810

74 MEDIUM VOLTAGE CABLES SINGLE CORE HEAVY DUTY SCREENED UNARMOURED Cable Characteristics +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 1 (PVC only)  3 (HDPE) Installation Conditions Cable Design CONDUCTOR:  Circular compacted aluminium Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 10kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standard Orange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT Aluminium 6.35/11kV

75 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. Physical & Electrical Characteristics Aluminium 6.35/11kV Product Code 1CALX11HD  Nominal Conductor Area mm 2 25 35 50 70 95 120 150 185 240 300 400 500 630 Nominal Conductor Diameter mm 6.1 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 23.5 26.6 30.2 Nominal Insulation Thickness mm 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 Approx Cable  Diameter mm 21.4 22.4 24.7 26.4 28.1 29.5 31.0 32.8 35.1 38.0 41.7 45.0 48.8 Approx Mass kg/100m 55 65 80 100 130 145 155 170 195 220 255 290 340 Max Pulling Tension  On Conductor kN 1.3 1.8 2.5 3.5 4.8 6.0 7.5 9.3 12 15 20 25 25 Max Pulling Tension  On Stocking Grip kN 1.3 1.8 2.1 2.4 2.8 3.0 3.4 3.8 4.3 5.1 6.1 7.1 8.3 Min Bending Radius : During Installation mm 380 400 450 480 510 530 560 590 630 680 750 810 880 Min Bending Radius : Set In Position mm 260 270 300 320 340 350 370 390 420 460 500 540 590 Max Conductor  Resistance, dc @ 20°C  Ohm/km 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 0.0778 0.0605 0.0469 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 1.54 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.161 0.130 0.102 0.0802 0.0636 Inductance, Trefoil Touching mH/km 0.478 0.455 0.447 0.412 0.392 0.378 0.368 0.352 0.340 0.330 0.322 0.312 0.302 Inductive Reactance,  Trefoil Touching  @ 50Hz Ohm/km 0.150 0.143 0.141 0.129 0.123 0.119 0.116 0.111 0.107 0.104 0.101 0.0979 0.0948 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 2.37+  j0.0836 1.71+  j0.0774 1.24+  j0.0747 0.871+  j0.0653 0.635+  j0.0601 0.535+  j0.0568 0.488+  j0.0539 0.446+  j0.0500 0.407+  j0.0469 0.382+  j0.0443 0.360+  j0.0425 0.343+  j0.0400 0.330+  j0.0376 Capacitance, Phase  To Earth µF/km 0.210 0.232 0.253 0.289 0.324 0.352 0.380 0.416 0.460 0.516 0.586 0.650 0.724 Min Insulation  Resistance @ 20°C  MOhm.km 12,000 11,000 10,000 8,900 7,900 7,200 6,600 6,000 5,400 4,900 4,300 3,900 3,400 Electric Stress At  Conductor Screen  kV/mm 2.65 2.56 2.49 2.40 2.33 2.29 2.25 2.22 2.18 2.14 2.11 2.08 2.06 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.419 0.463 0.505 0.576 0.646 0.702 0.758 0.830 0.918 1.03 1.17 1.30 1.44 Short Circuit Rating Phase  ConductorkA, 1 sec 2.4 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 37.8 47.2 59.5 Metallic ScreenkA, 1 sec 2.4 3.3 4.7 6.6 8.9 10 10 10 10 10 10 10 10 Con-tinuous Current Rating In Ground,Direct Buried  A 115 135 160 195 230 260 290 330 380 425 480 545 615 In Ground,  In Singleway Ducts  A 115 135 155 190 220 245 270 300 340 375 420 470 525 In Free Air,  Unenclosed & Spaced From Wall  A 115 135 165 210 250 290 330 375 440 510 590 685 790

76 MEDIUM VOLTAGE CABLES THREE CORE LIGHT DUTY SCREENED UNARMOURED Cable Characteristics +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 1 (PVC only)  3 (HDPE) Installation Conditions Cable Design CONDUCTOR:  Circular compacted aluminium Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 3kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT Aluminium 6.35/11kV

77 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. Physical & Electrical Characteristics Aluminium 6.35/11kV Product Code 3CALX11LD Nominal Conductor Area mm 2 25 35 50 70 95 120 150 185 240 300 Nominal Conductor Diameter mm 6.1 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 Nominal Insulation Thickness mm 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 Approx Cable  Diameter mm 42.3 44.8 47.2 51.2 55.1 58.2 61.3 65.3 70.3 76.3 Approx Mass kg/100m 140 160 185 220 265 295 340 390 465 550 Max Pulling Tension  On Conductors kN 3.8 5.3 7.5 11 14 18 23 25 25 25 Max Pulling Tension  On Stocking Grip kN 3.8 5.3 7.5 9.2 11 12 13 15 17 20 Min Bending Radius : During Installation mm 760 810 850 920 990 1050 1100 1170 1270 1370 Min Bending Radius : Set In Position mm 510 540 570 610 660 700 740 780 840 920 Max Conductor  Resistance, dc @ 20°C  Ohm/km 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 1.54 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.162 0.130 Inductance mH/km 0.416 0.396 0.380 0.350 0.333 0.322 0.313 0.300 0.290 0.282 Inductive Reactance,  @ 50Hz Ohm/km 0.131 0.124 0.119 0.110 0.105 0.101 0.0983 0.0944 0.0912 0.0885 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 4.48+  j0.0839 3.60+  j0.0777 3.37+  j0.0728 2.97+  j0.0635 2.66+  j0.0585 2.44+  j0.0553 2.26+  j0.0525 2.09+  j0.0487 1.95+  j0.0456 1.74+  j0.0431 Capacitance, Phase  To Earth µF/km 0.211 0.233 0.254 0.290 0.325 0.353 0.381 0.417 0.462 0.518 Min Insulation  Resistance @ 20°C  MOhm.km 12,000 11,000 10,000 8,900 7,900 7,200 6,600 6,000 5,400 4,900 Electric Stress At  Conductor Screen  kV/mm 2.65 2.56 2.49 2.40 2.33 2.29 2.25 2.22 2.18 2.14 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.420 0.465 0.507 0.578 0.648 0.704 0.760 0.833 0.921 1.03 Short Circuit Rating Phase  ConductorkA, 1 sec 2.4 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 Metallic ScreenkA, 1 sec 2.5 3.0 3.0 3.3 3.5 3.8 4.0 4.3 4.6 5.1 Con-tinuous Current Rating In Ground,Direct Buried  A 110 130 155 185 220 250 285 325 370 420 In Ground,  In Singleway Ducts  A 95 110 130 160 185 215 245 275 320 360 In Free Air,  Unenclosed & Spaced From Wall  A 105 125 145 180 220 255 290 340 400 460

78 MEDIUM VOLTAGE CABLES THREE CORE LIGHT DUTY SCREENED ARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Circular compacted aluminium Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 3kA for nominal 1 second ARMOURING: Galvanised steel wires SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT 1 (PVC only)  3 (HDPE) 3 (Armoured) Aluminium 6.35/11kV

79 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. Physical & Electrical Characteristics Aluminium 6.35/11kV Product Code 3CALX11LDA Nominal Conductor Area mm 2 25 35 50 70 95 120 150 185 240 Nominal Conductor Diameter mm 6.1 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 Nominal Insulation Thickness mm 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 Approx Cable  Diameter mm 51.2 53.7 56.2 60.4 64.2 67.5 70.9 75.0 81.8 Approx Mass kg/100m 375 415 450 505 570 625 685 760 960 Max Pulling Tension  On Conductors kN 3.8 5.3 7.5 11 14 18 23 25 25 Max Pulling Tension  On Stocking Grip kN 3.8 5.3 7.5 11 14 16 18 20 23 Max Pulling Tension  On Amour Wires kN 11 12 13 15 17 19 21 23 25 Min Bending Radius : During Installation mm 920 970 1010 1090 1160 1220 1280 1350 1470 Min Bending Radius : Set In Position mm 610 640 670 720 770 810 850 900 980 Max Conductor  Resistance, dc @ 20°C  Ohm/km 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 1.54 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.162 Inductance mH/km 0.416 0.396 0.380 0.350 0.333 0.322 0.313 0.300 0.290 Inductive Reactance,  @ 50Hz Ohm/km 0.131 0.124 0.119 0.110 0.105 0.101 0.0983 0.0944 0.0912 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 4.48+  j0.0839 3.60+ j0.0777 3.37+ j0.0728 2.97+  j0.0635 2.66+  j0.0585 2.44+  j0.0553 2.26+  j0.0525 2.09+  j0.0487 1.95+ j0.0456 Capacitance, Phase  To Earth µF/km 0.211 0.233 0.254 0.290 0.325 0.353 0.381 0.417 0.462 Min Insulation  Resistance @ 20°C  MOhm.km 12,000 11,000 10,000 8,900 7,900 7,200 6,600 6,000 5,400 Electric Stress At  Conductor Screen  kV/mm 2.65 2.56 2.49 2.40 2.33 2.29 2.25 2.22 2.18 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.420 0.465 0.507 0.578 0.648 0.704 0.760 0.833 0.921 Short Circuit Rating Phase  ConductorkA, 1 sec 2.4 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 Metallic ScreenkA, 1 sec 2.5 3.0 3.0 3.3 3.5 3.8 4.0 4.3 4.6 Con-tinuous Current Rating In Ground,Direct Buried  A 110 130 155 185 220 250 285 325 370 In Ground,  In Singleway Ducts  A 95 110 130 160 185 215 245 275 320 In Free Air,  Unenclosed & Spaced From Wall  A 105 125 145 180 220 255 290 340 400

80 MEDIUM VOLTAGE CABLES THREE CORE HEAVY DUTY SCREENED UNARMOURED Cable Characteristics +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 1 (PVC only)  3 (HDPE) Installation Conditions Cable Design CONDUCTOR:  Circular compacted aluminium Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 10kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT Aluminium 6.35/11kV

81 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. Physical & Electrical Characteristics Aluminium 6.35/11kV Product Code 3CALX11HD Nominal Conductor Area mm 2 25 35 50 70 95 120 150 185 240 300 Nominal Conductor Diameter mm 6.1 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 Nominal Insulation Thickness mm 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 Approx Cable  Diameter mm 42.5 44.8 47.4 51.2 55.1 58.2 61.3 65.3 70.3 76.3 Approx Mass kg/100m 145 165 195 240 300 335 375 425 500 585 Max Pulling Tension  On Conductors kN 3.8 5.3 7.5 11 14 18 23 25 25 25 Max Pulling Tension  On Stocking Grip kN 3.8 5.3 7.5 9.2 11 12 13 15 17 20 Min Bending Radius : During Installation mm 770 810 850 920 990 1050 1100 1170 1270 1370 Min Bending Radius : Set In Position mm 510 540 570 610 660 700 740 780 840 920 Max Conductor  Resistance, dc @ 20°C  Ohm/km 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 1.54 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.162 0.130 Inductance mH/km 0.416 0.396 0.380 0.350 0.333 0.322 0.313 0.300 0.290 0.282 Inductive Reactance,  @ 50Hz Ohm/km 0.131 0.124 0.119 0.110 0.105 0.101 0.0983 0.0944 0.0912 0.0885 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 4.18+  j0.0839 3.39+  j0.0777 2.46+  j0.0728 1.70+  j0.0635 1.26+  j0.0585 1.09+  j0.0553 1.05+  j0.0525 1.01+  j0.0487 0.967+  j0.0456 0.942+  j0.0431 Capacitance, Phase  To Earth µF/km 0.211 0.233 0.254 0.290 0.325 0.353 0.381 0.417 0.462 0.518 Min Insulation  Resistance @ 20°C  MOhm.km 12,000 11,000 10,000 8,900 7,900 7,200 6,600 6,000 5,400 4,900 Electric Stress At  Conductor Screen  kV/mm 2.65 2.56 2.49 2.40 2.33 2.29 2.25 2.22 2.18 2.14 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.420 0.465 0.507 0.578 0.648 0.704 0.760 0.833 0.921 1.03 Short Circuit Rating Phase  ConductorkA, 1 sec 2.4 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 Metallic ScreenkA, 1 sec 2.8 3.3 4.6 6.6 8.9 10 10 10 10 10 Con-tinuous Current Rating In Ground,Direct Buried  A 110 130 155 190 225 255 285 325 370 420 In Ground,  In Singleway Ducts  A 95 110 130 160 185 215 245 275 320 360 In Free Air,  Unenclosed & Spaced From Wall  A 105 130 150 190 230 265 300 345 405 465

82 MEDIUM VOLTAGE CABLES THREE CORE HEAVY DUTY SCREENED ARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Circular compacted aluminium Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 10kA for nominal 1 second ARMOURING: Galvanised steel wires SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT 1 (PVC only)  3 (HDPE) 3 (Armoured) Aluminium 6.35/11kV

83 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. Physical & Electrical Characteristics Aluminium 6.35/11kV Product Code 3CALX11HDA Nominal Conductor Area mm 2 25 35 50 70 95 120 150 185 240 Nominal Conductor Diameter mm 6.1 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 Nominal Insulation Thickness mm 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 Approx Cable  Diameter mm 51.2 53.7 56.2 60.4 64.4 67.7 71.1 76.5 81.8 Approx Mass kg/100m 380 415 460 525 610 665 725 880 990 Max Pulling Tension  On Conductors kN 3.8 5.3 7.5 11 14 18 23 25 25 Max Pulling Tension  On Stocking Grip kN 3.8 5.3 7.5 11 14 16 18 20 23 Max Pulling Tension  On Amour Wires kN 11 12 13 15 17 19 21 24 25 Min Bending Radius : During Installation mm 920 970 1010 1090 1160 1220 1280 1380 1470 Min Bending Radius : Set In Position mm 610 640 670 720 770 810 850 920 980 Max Conductor  Resistance, dc @ 20°C  Ohm/km 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 1.54 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.162 Inductance mH/km 0.416 0.396 0.380 0.350 0.333 0.322 0.313 0.300 0.290 Inductive Reactance,  @ 50Hz Ohm/km 0.131 0.124 0.119 0.110 0.105 0.101 0.0983 0.0944 0.0912 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 4.18+ j0.0839 3.39+ j0.0777 2.46+  j0.0728 1.70+ j0.0635 1.26+ j0.0585 1.09+ j0.0553 1.05+ j0.0525 1.01+ j0.0487 0.967+  j0.0456 Capacitance, Phase  To Earth µF/km 0.211 0.233 0.254 0.290 0.325 0.353 0.381 0.417 0.462 Min Insulation  Resistance @ 20°C  MOhm.km 12,000 11,000 10,000 8,900 7,900 7,200 6,600 6,000 5,400 Electric Stress At  Conductor Screen  kV/mm 2.65 2.56 2.49 2.40 2.33 2.29 2.25 2.22 2.18 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.420 0.465 0.507 0.578 0.648 0.704 0.760 0.833 0.921 Short Circuit Rating Phase  ConductorkA, 1 sec 2.4 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 Metallic ScreenkA, 1 sec 2.8 3.3 4.6 6.6 8.9 10 10 10 10 Con-tinuous Current Rating In Ground,Direct Buried  A 110 130 155 190 225 255 285 325 370 In Ground,  In Singleway Ducts  A 95 110 130 160 185 215 245 275 320 In Free Air,  Unenclosed & Spaced From Wall  A 105 130 150 190 230 265 300 345 405

84 MEDIUM VOLTAGE CABLES Copper 12.7/22kV SINGLE CORE LIGHT DUTY SCREENED UNARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Plain circular compacted copper Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded, semi-conductive compound METALLIC SCREEN: Plain annealed copper wire: 3kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT 12D (PVC only) 15D (HDPE) 1 (PVC only)  3 (HDPE)

85 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. MEDIUM VOLTAGE CABLES Physical & Electrical Characteristics Copper 12.7/22kV Product Code 1CCUX22LD Nominal Conductor Area mm 2 35 50 70 95 120 150 185 240 300 400 500 630 Nominal Conductor Diameter mm 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 23.5 26.6 30.3 Nominal Insulation Thickness mm 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 Approx Cable  Diameter mm 26.6 27.7 29.5 31.2 32.8 34.2 36.2 38.4 41.1 44.8 48.1 52.0 Approx Mass kg/100m 100 115 140 165 195 225 265 320 385 475 585 725 Max Pulling Tension  On Conductor kN 2.5 3.5 4.9 6.7 8.4 11 13 17 21 25 25 25 Max Pulling Tension  On Stocking Grip kN 2.5 2.7 3.1 3.4 3.8 4.1 4.6 5.2 5.9 7.0 8.1 9.4 Min Bending Radius : During Installation mm 480 500 530 560 590 620 650 690 740 810 860 940 Min Bending Radius : Set In Position mm 320 330 350 370 390 410 430 460 490 540 580 620 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 0.0470 0.0366 0.0283 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 0.668 0.494 0.342 0.247 0.196 0.159 0.128 0.0978 0.0788 0.0628 0.0504 0.0410 Inductance, Trefoil Touching mH/km 0.492 0.470 0.435 0.414 0.397 0.384 0.372 0.357 0.346 0.335 0.324 0.315 Inductive Reactance,  Trefoil Touching  @ 50Hz Ohm/km 0.155 0.148 0.137 0.130 0.125 0.121 0.117 0.112 0.109 0.105 0.102 0.0988 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 1.46+  j0.0913 1.32+  j0.0851 1.20+  j0.0751 1.13+  j0.0693 1.09+  j0.0645 1.06+  j0.0611 1.03+  j0.0575 1.01+  j0.0538 0.995+  j0.0509 0.982+  j0.0481 0.973+  j0.0451 0.965+  j0.0426 Capacitance, Phase  To Earth µF/km 0.164 0.179 0.200 0.223 0.241 0.259 0.282 0.310 0.343 0.386 0.426 0.473 Min Insulation  Resistance @ 20°C  MOhm.km 16,000 14,000 13,000 11,000 10,000 9,700 8,900 8,100 7,300 6,500 5,900 5,300 Electric Stress At  Conductor Screen  kV/mm 3.64 3.49 3.33 3.21 3.12 3.06 2.99 2.91 2.85 2.78 2.73 2.68 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.652 0.713 0.799 0.888 0.961 1.03 1.12 1.24 1.37 1.54 1.70 1.89 Short Circuit Rating Phase  ConductorkA, 1 sec 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 57.2 71.5 90.1 Metallic ScreenkA, 1 sec 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 Con-tinuous Current Rating In Ground,Direct Buried  A 175 205 250 300 335 375 425 490 550 625 705 790 In Ground,  In Singleway Ducts  A 170 200 245 290 325 360 405 460 515 580 650 730 In Free Air,  Unenclosed & Spaced From Wall  A 180 215 270 325 375 425 490 575 660 765 880 1005

86 MEDIUM VOLTAGE CABLES SINGLE CORE HEAVY DUTY SCREENED UNARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Plain circular compacted copper Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 10kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C 1 (PVC only)  3 (HDPE) Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT Copper 12.7/22kV

87 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. MEDIUM VOLTAGE CABLES Physical & Electrical Characteristics Copper 12.7/22kV Product Code 1CCUX22HD  Nominal Conductor Area mm 2 35 50 70 95 120 150 185 240 300 400 500 630 Nominal Conductor Diameter mm 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 23.5 26.6 30.3 Nominal Insulation Thickness mm 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 Approx Cable  Diameter mm 27.9 29.0 30.8 32.5 34.1 35.5 37.5 39.9 42.4 46.3 49.4 53.5 Approx Mass kg/100m 115 140 185 215 240 270 310 370 430 525 630 770 Max Pulling Tension  On Conductor kN 2.5 3.5 4.9 6.7 8.4 11 13 17 21 25 25 25 Max Pulling Tension  On Stocking Grip kN 2.5 2.9 3.3 3.7 4.1 4.4 4.9 5.6 6.3 7.5 8.5 10 Min Bending Radius : During Installation mm 500 520 550 590 610 640 670 720 760 830 890 960 Min Bending Radius : Set In Position mm 330 350 370 390 410 430 450 480 510 560 590 640 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 0.0470 0.0366 0.0283 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 0.668 0.494 0.342 0.247 0.196 0.159 0.128 0.0978 0.0788 0.0627 0.0503 0.0408 Inductance, Trefoil Touching mH/km 0.502 0.479 0.444 0.422 0.405 0.392 0.379 0.365 0.353 0.342 0.330 0.321 Inductive Reactance,  Trefoil Touching  @ 50Hz Ohm/km 0.158 0.151 0.140 0.133 0.127 0.123 0.119 0.115 0.111 0.108 0.104 0.101 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 1.09+  j0.0931 0.783+  j0.0868 0.550+  j0.0767 0.475+  j0.0708 0.435+  j0.0660 0.406+  j0.0625 0.381+  j0.0589 0.358+  j0.0550 0.343+  j0.0520 0.330+  j0.0491 0.320+  j0.0460 0.312+  j0.0435 Capacitance, Phase  To Earth µF/km 0.164 0.179 0.200 0.223 0.241 0.259 0.282 0.310 0.343 0.386 0.426 0.473 Min Insulation  Resistance @ 20°C  MOhm.km 16,000 14,000 13,000 11,000 10,000 9,700 8,900 8,100 7,300 6,500 5,900 5,300 Electric Stress At  Conductor Screen  kV/mm 3.64 3.49 3.33 3.21 3.12 3.06 2.99 2.91 2.85 2.78 2.73 2.68 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.652 0.713 0.799 0.888 0.961 1.03 1.12 1.24 1.37 1.54 1.70 1.89 Short Circuit Rating Phase  ConductorkA, 1 sec 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 57.2 71.5 90.1 Metallic ScreenkA, 1 sec 5.0 7.1 10 10 10 10 10 10 10 10 10 10 Con-tinuous Current Rating In Ground,Direct Buried  A 175 205 250 295 335 370 415 480 535 600 670 740 In Ground,  In Singleway Ducts  A 170 195 235 275 305 335 370 415 460 510 560 615 In Free Air,  Unenclosed & Spaced From Wall  A 185 220 270 330 375 425 485 565 645 740 845 960

88 MEDIUM VOLTAGE CABLES THREE CORE LIGHT DUTY SCREENED UNARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Plain circular compacted copper Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 3kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT 1 (PVC only)  3 (HDPE) Copper 12.7/22kV

89 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. MEDIUM VOLTAGE CABLES Physical & Electrical Characteristics Copper 12.7/22kV Product Code 3CCUX22LD Nominal Conductor Area mm 2 35 50 70 95 120 150 185 240 300 Nominal Conductor Diameter mm 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 Nominal Insulation Thickness mm 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 Approx Cable  Diameter mm 54.5 57.1 60.9 64.7 68.0 71.2 75.1 80.3 86.2 Approx Mass kg/100m 300 340 420 515 605 690 820 1010 1220 Max Pulling Tension  On Conductors kN 7.4 11 15 20 25 25 25 25 25 Max Pulling Tension  On Stocking Grip kN 7.4 11 13 15 16 18 20 23 25 Min Bending Radius : During Installation mm 980 1030 1100 1170 1220 1280 1350 1440 1550 Min Bending Radius : Set In Position mm 650 690 730 780 820 850 900 960 1030 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 0.668 0.494 0.342 0.247 0.196 0.159 0.128 0.0981 0.0791 Inductance mH/km 0.438 0.418 0.386 0.367 0.351 0.340 0.328 0.316 0.306 Inductive Reactance,  @ 50Hz Ohm/km 0.138 0.131 0.121 0.115 0.110 0.107 0.103 0.0993 0.0962 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 2.87+ j0.0916 2.73+  j0.0854 2.45+  j0.0754 2.24+  j0.0695 2.08+  j0.0647 1.95+ j0.0613 1.83+ j0.0577 1.64+  j0.0540 1.55+ j0.0511 Capacitance, Phase  To Earth µF/km 0.164 0.179 0.201 0.223 0.242 0.260 0.283 0.311 0.344 Min Insulation  Resistance @ 20°C  MOhm.km 16,000 14,000 13,000 11,000 10,000 9,700 8,900 8,100 7,300 Electric Stress At  Conductor Screen  kV/mm 3.64 3.49 3.33 3.21 3.12 3.06 2.99 2.91 2.85 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.655 0.715 0.802 0.891 0.964 1.04 1.13 1.24 1.37 Short Circuit Rating Phase  ConductorkA, 1 sec 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 Metallic ScreenkA, 1 sec 3.5 3.5 3.8 4.0 4.3 4.6 4.8 5.3 5.6 Con-tinuous Current Rating In Ground,Direct Buried  A 165 190 235 275 325 360 410 475 530 In Ground,  In Singleway Ducts  A 145 170 205 245 280 315 360 410 460 In Free Air,  Unenclosed & Spaced From Wall  A 160 190 240 290 335 380 430 515 585

90 MEDIUM VOLTAGE CABLES THREE CORE LIGHT DUTY SCREENED ARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Plain circular compacted copper Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 3kA for nominal 1 second ARMOURING: Galvanised steel wires SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT 1 (PVC only)  3 (HDPE) 3 (Armoured) Copper 12.7/22kV

91 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. MEDIUM VOLTAGE CABLES Physical & Electrical Characteristics Copper 12.7/22kV Product Code 3CCUX22LDA Nominal Conductor Area mm 2 35 50 70 95 120 150 185 Nominal Conductor Diameter mm 7.0 8.2 9.8 11.5 12.9 14.3 16.1 Nominal Insulation Thickness mm 5.5 5.5 5.5 5.5 5.5 5.5 5.5 Approx Cable  Diameter mm 63.6 66.5 70.2 74.3 79.4 82.6 87.0 Approx Mass kg/100m 605 660 760 875 1080 1190 1350 Max Pulling Tension  On Conductors kN 7.4 11 15 20 25 25 25 Max Pulling Tension  On Stocking Grip kN 7.4 11 15 19 22 24 25 Max Pulling Tension  On Amour Wires kN 17 18 20 23 25 25 25 Min Bending Radius : During Installation mm 1150 1200 1260 1340 1430 1490 1570 Min Bending Radius : Set In Position mm 760 800 840 890 950 990 1040 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 0.668 0.494 0.342 0.247 0.196 0.159 0.128 Inductance mH/km 0.438 0.418 0.386 0.367 0.351 0.340 0.328 Inductive Reactance,  @ 50Hz Ohm/km 0.138 0.131 0.121 0.115 0.110 0.107 0.103 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 2.87+j0.0916 2.73+j0.0854 2.45+j0.0754 2.24+j0.0695 2.08+j0.0647 1.95+j0.0613 1.83+j0.0577 Capacitance, Phase  To Earth µF/km 0.164 0.179 0.201 0.223 0.242 0.260 0.283 Min Insulation  Resistance @ 20°C  MOhm.km 16,000 14,000 13,000 11,000 10,000 9,700 8,900 Electric Stress At  Conductor Screen  kV/mm 3.64 3.49 3.33 3.21 3.12 3.06 2.99 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.655 0.715 0.802 0.891 0.964 1.04 1.13 Short Circuit Rating Phase  ConductorkA, 1 sec 5.0 7.2 10.0 13.6 17.2 21.5 26.5 Metallic ScreenkA, 1 sec 3.5 3.5 3.8 4.0 4.3 4.6 4.8 Con-tinuous Current Rating In Ground,Direct Buried  A 165 190 235 275 325 360 410 In Ground,  In Singleway Ducts  A 145 170 205 245 280 315 360 In Free Air,  Unenclosed & Spaced From Wall  A 160 190 240 290 335 380 430

92 MEDIUM VOLTAGE CABLES THREE CORE HEAVY DUTY SCREENED UNARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Plain circular compacted copper Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 10kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT 1 (PVC only)  3 (HDPE) Copper 12.7/22kV

93 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. MEDIUM VOLTAGE CABLES Physical & Electrical Characteristics Copper 12.7/22kV Product Code 3CCUX22HD Nominal Conductor Area mm 2 35 50 70 95 120 150 185 240 300 Nominal Conductor Diameter mm 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 Nominal Insulation Thickness mm 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 Approx Cable  Diameter mm 54.5 57.1 60.9 64.7 68.0 71.2 75.1 80.3 86.2 Approx Mass kg/100m 310 360 455 550 640 725 850 1040 1240 Max Pulling Tension  On Conductors kN 7.4 11 15 20 25 25 25 25 25 Max Pulling Tension  On Stocking Grip kN 7.4 11 13 15 16 18 20 23 25 Min Bending Radius : During Installation mm 980 1030 1100 1170 1220 1280 1350 1440 1550 Min Bending Radius : Set In Position mm 650 690 730 780 820 850 900 960 1030 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 0.668 0.494 0.342 0.247 0.196 0.159 0.128 0.0981 0.0791 Inductance mH/km 0.438 0.418 0.386 0.367 0.351 0.340 0.328 0.316 0.306 Inductive Reactance,  @ 50Hz Ohm/km 0.138 0.131 0.121 0.115 0.110 0.107 0.103 0.0993 0.0962 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 2.16+j0.0916 1.56+j0.0854 1.11+j0.0754 1.03+j0.0695 0.995+j0.0647 0.966+j0.0613 0.941+j0.0577 0.917+j0.0540 0.902+j0.0511 Capacitance, Phase  To Earth µF/km 0.164 0.179 0.201 0.223 0.242 0.260 0.283 0.311 0.344 Min Insulation  Resistance @ 20°C  MOhm.km 16,000 14,000 13,000 11,000 10,000 9,700 8,900 8,100 7,300 Electric Stress At  Conductor Screen  kV/mm 3.64 3.49 3.33 3.21 3.12 3.06 2.99 2.91 2.85 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.655 0.715 0.802 0.891 0.964 1.04 1.13 1.24 1.37 Short Circuit Rating Phase  ConductorkA, 1 sec 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 Metallic ScreenkA, 1 sec 5.1 7.1 10 10 10 10 10 10 10 Con-tinuous Current Rating In Ground,Direct Buried  A 170 200 240 290 330 365 410 475 530 In Ground,  In Singleway Ducts  A 145 170 210 245 285 320 360 415 465 In Free Air,  Unenclosed & Spaced From Wall  A 170 200 250 305 350 390 445 520 590

94 MEDIUM VOLTAGE CABLES THREE CORE HEAVY DUTY SCREENED ARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Plain circular compacted copper Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 10kA for nominal 1 second ARMOURING: Galvanised steel wires SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT 1 (PVC only)  3 (HDPE) 3 (Armoured) Copper 12.7/22kV

95 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. MEDIUM VOLTAGE CABLES Physical & Electrical Characteristics Copper 12.7/22kV Product Code 3CCUX22HDA Nominal Conductor Area mm 2 35 50 70 95 120 150 185 Nominal Conductor Diameter mm 7.0 8.2 9.8 11.5 12.9 14.3 16.1 Nominal Insulation Thickness mm 5.5 5.5 5.5 5.5 5.5 5.5 5.5 Approx Cable  Diameter mm 63.6 66.5 70.6 74.5 79.4 82.8 87.0 Approx Mass kg/100m 615 680 805 915 1110 1230 1380 Max Pulling Tension  On Conductors kN 7.4 11 15 20 25 25 25 Max Pulling Tension  On Stocking Grip kN 7.4 11 15 19 22 24 25 Max Pulling Tension  On Amour Wires kN 17 18 20 23 25 25 25 Min Bending Radius : During Installation mm 1150 1200 1270 1340 1430 1490 1570 Min Bending Radius : Set In Position mm 760 800 850 890 950 990 1040 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 0.668 0.494 0.342 0.247 0.196 0.159 0.128 Inductance mH/km 0.438 0.418 0.386 0.367 0.351 0.340 0.328 Inductive Reactance,  @ 50Hz Ohm/km 0.138 0.131 0.121 0.115 0.110 0.107 0.103 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 2.16+j0.0916 1.56+j0.0854 1.11+j0.0754 1.03+j0.0695 0.995+j0.0647 0.966+j0.0613 0.941+j0.0577 Capacitance, Phase  To Earth µF/km 0.164 0.179 0.201 0.223 0.242 0.260 0.283 Min Insulation  Resistance @ 20°C  MOhm.km 16,000 14,000 13,000 11,000 10,000 9,700 8,900 Electric Stress At  Conductor Screen  kV/mm 3.64 3.49 3.33 3.21 3.12 3.06 2.99 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.655 0.715 0.802 0.891 0.964 1.04 1.13 Short Circuit Rating Phase  ConductorkA, 1 sec 5.0 7.2 10.0 13.6 17.2 21.5 26.5 Metallic ScreenkA, 1 sec 5.1 7.1 10 10 10 10 10 Con-tinuous Current Rating In Ground,Direct Buried  A 170 200 240 290 330 365 410 In Ground,  In Singleway Ducts  A 145 170 210 245 285 320 360 In Free Air,  Unenclosed & Spaced From Wall  A 170 200 250 305 350 390 445

96 MEDIUM VOLTAGE CABLES SINGLE CORE LIGHT DUTY SCREENED UNARMOURED Cable Characteristics +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 1 (PVC only)  3 (HDPE) Installation Conditions Cable Design CONDUCTOR:  Circular compacted aluminium Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 3kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standard Orange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT Aluminium 12.7/22kV

97 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. Physical & Electrical Characteristics Aluminium 12.7/22kV Product Code 1CALX22LD Nominal Conductor Area mm 2 35 50 70 95 120 150 185 240 300 400 500 630 Nominal Conductor Diameter mm 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 23.5 26.6 30.2 Nominal Insulation Thickness mm 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 Approx Cable  Diameter mm 26.6 27.6 29.5 31.2 32.8 34.1 36.1 38.2 41.1 44.8 48.1 51.9 Approx Mass kg/100m 80 85 95 110 120 130 150 170 200 235 275 330 Max Pulling Tension  On Conductor kN 1.8 2.5 3.5 4.8 6.0 7.5 9.3 12 15 20 25 25 Max Pulling Tension  On Stocking Grip kN 1.8 2.5 3.1 3.4 3.8 4.1 4.6 5.1 5.9 7.0 8.1 9.4 Min Bending Radius : During Installation mm 480 500 530 560 590 610 650 690 740 810 860 930 Min Bending Radius : Set In Position mm 320 330 350 370 390 410 430 460 490 540 580 620 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 0.0778 0.0605 0.0469 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.161 0.130 0.102 0.0800 0.0634 Inductance, Trefoil Touching mH/km 0.491 0.471 0.435 0.414 0.400 0.388 0.372 0.358 0.346 0.337 0.326 0.315 Inductive Reactance,  Trefoil Touching  @ 50Hz Ohm/km 0.154 0.148 0.137 0.130 0.126 0.122 0.117 0.112 0.109 0.106 0.102 0.0989 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 1.80+  j0.0908 1.57+  j0.0853 1.38+  j0.0751 1.25+  j0.0693 1.19+  j0.0654 1.14+  j0.0622 1.10+  j0.0577 1.06+  j0.0540 1.03+  j0.0509 1.01+  j0.0485 0.996+  j0.0455 0.982+  j0.0426 Capacitance, Phase  To Earth µF/km 0.165 0.178 0.200 0.223 0.240 0.258 0.280 0.308 0.343 0.386 0.426 0.472 Min Insulation  Resistance @ 20°C  MOhm.km 16,000 14,000 13,000 11,000 10,000 9,700 8,900 8,100 7,300 6,500 5,900 5,300 Electric Stress At  Conductor Screen  kV/mm 3.63 3.50 3.33 3.21 3.13 3.06 2.99 2.92 2.85 2.78 2.73 2.68 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.657 0.710 0.799 0.888 0.958 1.03 1.12 1.23 1.37 1.54 1.70 1.88 Short Circuit Rating Phase  ConductorkA, 1 sec 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 37.8 47.2 59.5 Metallic ScreenkA, 1 sec 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 Con-tinuous Current Rating In Ground,Direct Buried  A 135 160 195 230 260 295 330 385 435 495 565 640 In Ground,  In Singleway Ducts  A 135 155 190 225 255 285 320 370 415 470 530 600 In Free Air,  Unenclosed & Spaced From Wall  A 140 170 210 255 295 330 380 450 520 605 705 815

98 MEDIUM VOLTAGE CABLES SINGLE CORE HEAVY DUTY SCREENED UNARMOURED Cable Characteristics +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 1 (PVC only)  3 (HDPE) Installation Conditions Cable Design CONDUCTOR:  Circular compacted aluminium Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 10kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standard Orange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT Aluminium 12.7/22kV

99 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. Physical & Electrical Characteristics Aluminium 12.7/22kV Product Code 1CALX22HD Nominal Conductor Area mm 2 35 50 70 95 120 150 185 240 300 400 500 630 Nominal Conductor Diameter mm 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 23.5 26.6 30.2 Nominal Insulation Thickness mm 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 Approx Cable  Diameter mm 26.6 28.9 30.8 32.5 34.1 35.4 37.4 39.7 42.4 46.3 49.4 53.4 Approx Mass kg/100m 80 95 120 150 165 180 195 220 245 285 320 375 Max Pulling Tension  On Conductor kN 1.8 2.5 3.5 4.8 6.0 7.5 9.3 12 15 20 25 25 Max Pulling Tension  On Stocking Grip kN 1.8 2.5 3.3 3.7 4.1 4.4 4.9 5.5 6.3 7.5 8.5 10 Min Bending Radius : During Installation mm 480 520 550 590 610 640 670 720 760 830 890 960 Min Bending Radius : Set In Position mm 320 350 370 390 410 430 450 480 510 560 590 640 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 0.0778 0.0605 0.0469 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.161 0.130 0.101 0.0799 0.0633 Inductance, Trefoil Touching mH/km 0.491 0.480 0.444 0.422 0.409 0.396 0.380 0.366 0.353 0.344 0.331 0.321 Inductive Reactance,  Trefoil Touching  @ 50Hz Ohm/km 0.154 0.151 0.140 0.133 0.128 0.124 0.119 0.115 0.111 0.108 0.104 0.101 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 1.71+  j0.0908 1.24+  j0.0871 0.871+  j0.0767 0.635+  j0.0708 0.535+  j0.0669 0.488+  j0.0636 0.446+  j0.0590 0.407+  j0.0553 0.382+  j0.0520 0.360+  j0.0495 0.343+  j0.0465 0.330+  j0.0435 Capacitance, Phase  To Earth µF/km 0.165 0.178 0.200 0.223 0.240 0.258 0.280 0.308 0.343 0.386 0.426 0.472 Min Insulation  Resistance @ 20°C  MOhm.km 16,000 14,000 13,000 11,000 10,000 9,700 8,900 8,100 7,300 6,500 5,900 5,300 Electric Stress At  Conductor Screen  kV/mm 3.63 3.50 3.33 3.21 3.13 3.06 2.99 2.92 2.85 2.78 2.73 2.68 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.657 0.710 0.799 0.888 0.958 1.03 1.12 1.23 1.37 1.54 1.70 1.88 Short Circuit Rating Phase  ConductorkA, 1 sec 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 37.8 47.2 59.5 Metallic ScreenkA, 1 sec 3.3 4.7 6.6 8.9 10 10 10 10 10 10 10 10 Con-tinuous Current Rating In Ground,Direct Buried  A 135 160 195 230 260 290 330 380 425 485 545 615 In Ground,  In Singleway Ducts  A 135 155 190 220 245 270 305 345 380 430 480 530 In Free Air,  Unenclosed & Spaced From Wall  A 140 170 210 255 295 330 380 445 515 595 690 795

100 MEDIUM VOLTAGE CABLES THREE CORE LIGHT DUTY SCREENED UNARMOURED Cable Characteristics +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 1 (PVC only)  3 (HDPE) Installation Conditions Cable Design CONDUCTOR:  Circular compacted aluminium Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 3kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT Aluminium 12.7/22kV

101 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. Physical & Electrical Characteristics Aluminium 12.7/22kV Product Code 3CALX22LD Nominal Conductor Area mm 2 35 50 70 95 120 150 185 240 300 Nominal Conductor Diameter mm 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 Nominal Insulation Thickness mm 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 Approx Cable  Diameter mm 54.7 57.0 60.9 64.7 67.8 71.0 74.9 80.0 86.2 Approx Mass kg/100m 230 255 295 340 380 420 480 565 660 Max Pulling Tension  On Conductors kN 5.3 7.5 11 14 18 23 25 25 25 Max Pulling Tension  On Stocking Grip kN 5.3 7.5 11 14 16 18 20 22 25 Min Bending Radius : During Installation mm 980 1030 1100 1170 1220 1280 1350 1440 1550 Min Bending Radius : Set In Position mm 660 680 730 780 810 850 900 960 1030 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.161 0.130 Inductance mH/km 0.437 0.419 0.386 0.367 0.354 0.343 0.329 0.317 0.306 Inductive Reactance,  @ 50Hz Ohm/km 0.137 0.132 0.121 0.115 0.111 0.108 0.103 0.0995 0.0962 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 3.21+j0.0911 2.98+j0.0856 2.63+j0.0754 2.37+j0.0695 2.18+j0.0657 2.03+j0.0624 1.89+j0.0579 1.69+j0.0542 1.59+j0.0511 Capacitance, Phase  To Earth µF/km 0.165 0.179 0.201 0.223 0.241 0.259 0.281 0.309 0.344 Min Insulation  Resistance @ 20°C  MOhm.km 16,000 14,000 13,000 11,000 10,000 9,700 8,900 8,100 7,300 Electric Stress At  Conductor Screen  kV/mm 3.63 3.50 3.33 3.21 3.13 3.06 2.99 2.92 2.85 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.659 0.712 0.802 0.891 0.962 1.03 1.12 1.23 1.37 Short Circuit Rating Phase  ConductorkA, 1 sec 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 Metallic ScreenkA, 1 sec 3.5 3.5 3.8 4.0 4.3 4.6 4.8 5.3 5.6 Con-tinuous Current Rating In Ground,Direct Buried  A 125 145 190 235 255 285 320 370 420 In Ground,  In Singleway Ducts  A 110 130 160 190 220 245 275 320 360 In Free Air,  Unenclosed & Spaced From Wall  A 125 145 190 230 265 300 345 405 465

102 MEDIUM VOLTAGE CABLES THREE CORE LIGHT DUTY SCREENED ARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Circular compacted aluminium Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 3kA for nominal 1 second ARMOURING: Galvanised steel wires SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT 1 (PVC only)  3 (HDPE) 3 (Armoured) Aluminium 12.7/22kV

103 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. Physical & Electrical Characteristics Aluminium 12.7/22kV Product Code 3CALX22LDA Nominal Conductor Area mm 2 35 50 70 95 120 150 185 Nominal Conductor Diameter mm 7.1 8.1 9.8 11.5 12.9 14.2 16.0 Nominal Insulation Thickness mm 5.5 5.5 5.5 5.5 5.5 5.5 5.5 Approx Cable  Diameter mm 63.8 66.4 70.2 74.3 79.3 82.4 86.8 Approx Mass kg/100m 535 570 630 700 855 920 1010 Max Pulling Tension  On Conductors kN 5.3 7.5 11 14 18 23 25 Max Pulling Tension  On Stocking Grip kN 5.3 7.5 11 14 18 23 25 Max Pulling Tension  On Amour Wires kN 17 18 20 23 25 25 25 Min Bending Radius : During Installation mm 1150 1190 1260 1340 1430 1480 1560 Min Bending Radius : Set In Position mm 770 800 840 890 950 990 1040 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.868 0.641 0.443 0.320 0.253 0.206 0.164 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 1.11 0.822 0.568 0.411 0.325 0.265 0.211 Inductance mH/km 0.437 0.419 0.386 0.367 0.354 0.343 0.329 Inductive Reactance,  @ 50Hz Ohm/km 0.137 0.132 0.121 0.115 0.111 0.108 0.103 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 3.21+j0.0911 2.98+j0.0856 2.63+j0.0754 2.37+j0.0695 2.18+j0.0657 2.03+j0.0624 1.89+j0.0579 Capacitance, Phase  To Earth µF/km 0.165 0.179 0.201 0.223 0.241 0.259 0.281 Min Insulation  Resistance @ 20°C  MOhm.km 16,000 14,000 13,000 11,000 10,000 9,700 8,900 Electric Stress At  Conductor Screen  kV/mm 3.63 3.50 3.33 3.21 3.13 3.06 2.99 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.659 0.712 0.802 0.891 0.962 1.03 1.12 Short Circuit Rating Phase  ConductorkA, 1 sec 3.3 4.7 6.6 9.0 11.3 14.2 17.5 Metallic ScreenkA, 1 sec 3.5 3.5 3.8 4.0 4.3 4.6 4.8 Con-tinuous Current Rating In Ground,Direct Buried  A 125 145 190 235 255 285 320 In Ground,  In Singleway Ducts  A 110 130 160 190 220 245 275 In Free Air,  Unenclosed & Spaced From Wall  A 125 145 190 230 265 300 345

104 MEDIUM VOLTAGE CABLES THREE CORE HEAVY DUTY SCREENED UNARMOURED Cable Characteristics +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 1 (PVC only)  3 (HDPE) Installation Conditions Cable Design CONDUCTOR:  Circular compacted aluminium Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 10kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT Aluminium 12.7/22kV

105 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. Physical & Electrical Characteristics Aluminium 12.7/22kV Product Code 3CALX22HD Nominal Conductor Area mm 2 35 50 70 95 120 150 185 240 300 Nominal Conductor Diameter mm 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 Nominal Insulation Thickness mm 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 Approx Cable  Diameter mm 54.7 57.0 60.9 64.7 67.8 71.0 74.9 80.0 86.2 Approx Mass kg/100m 230 260 310 370 415 455 510 590 685 Max Pulling Tension  On Conductors kN 5.3 7.5 11 14 18 23 25 25 25 Max Pulling Tension  On Stocking Grip kN 5.3 7.5 11 14 16 18 20 22 25 Min Bending Radius : During Installation mm 980 1030 1100 1170 1220 1280 1350 1440 1550 Min Bending Radius : Set In Position mm 660 680 730 780 810 850 900 960 1030 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.161 0.130 Inductance mH/km 0.437 0.419 0.386 0.367 0.354 0.343 0.329 0.317 0.306 Inductive Reactance,  @ 50Hz Ohm/km 0.137 0.132 0.121 0.115 0.111 0.108 0.103 0.0995 0.0962 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 3.21+j0.0911 2.46+j0.0856 1.76+j0.0754 1.26+j0.0695 1.09+j0.0657 1.05+j0.0624 1.01+j0.0579 0.967+j0.0542 0.942+j0.0511 Capacitance, Phase  To Earth µF/km 0.165 0.179 0.201 0.223 0.241 0.259 0.281 0.309 0.344 Min Insulation  Resistance @ 20°C  MOhm.km 16,000 14,000 13,000 11,000 10,000 9,700 8,900 8,100 7,300 Electric Stress At  Conductor Screen  kV/mm 3.63 3.50 3.33 3.21 3.13 3.06 2.99 2.92 2.85 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.659 0.712 0.802 0.891 0.962 1.03 1.12 1.23 1.37 Short Circuit Rating Phase  ConductorkA, 1 sec 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 Metallic ScreenkA, 1 sec 3.5 4.6 6.3 8.9 10 10 10 10 10 Con-tinuous Current Rating In Ground,Direct Buried  A 125 145 190 225 250 285 325 375 420 In Ground,  In Singleway Ducts  A 110 130 160 190 225 250 280 325 365 In Free Air,  Unenclosed & Spaced From Wall  A 125 145 190 230 265 305 350 410 470

106 MEDIUM VOLTAGE CABLES THREE CORE HEAVY DUTY SCREENED ARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Circular compacted aluminium Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 10kA for nominal 1 second ARMOURING: Galvanised steel wires SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT 1 (PVC only)  3 (HDPE) 3 (Armoured) Aluminium 12.7/22kV

107 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. Physical & Electrical Characteristics Aluminium 12.7/22kV Product Code 3CALX22HDA Nominal Conductor Area mm 2 35 50 70 95 120 150 185 Nominal Conductor Diameter mm 7.1 8.1 9.8 11.5 12.9 14.2 16.0 Nominal Insulation Thickness mm 5.5 5.5 5.5 5.5 5.5 5.5 5.5 Approx Cable  Diameter mm 63.8 66.4 70.4 74.5 79.3 82.6 86.8 Approx Mass kg/100m 535 580 655 735 890 955 1040 Max Pulling Tension  On Conductors kN 5.3 7.5 11 14 18 23 25 Max Pulling Tension  On Stocking Grip kN 5.3 7.5 11 14 18 23 25 Max Pulling Tension  On Amour Wires kN 17 18 20 23 25 25 25 Min Bending Radius : During Installation mm 1150 1190 1270 1340 1430 1490 1560 Min Bending Radius : Set In Position mm 770 800 850 890 950 990 1040 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.868 0.641 0.443 0.320 0.253 0.206 0.164 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 1.11 0.822 0.568 0.411 0.325 0.265 0.211 Inductance mH/km 0.437 0.419 0.386 0.367 0.354 0.343 0.329 Inductive Reactance,  @ 50Hz Ohm/km 0.137 0.132 0.121 0.115 0.111 0.108 0.103 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 3.21+j0.0911 2.46+j0.0856 1.76+j0.0754 1.26+j0.0695 1.09+j0.0657 1.05+j0.0624 1.01+j0.0579 Capacitance, Phase  To Earth µF/km 0.165 0.179 0.201 0.223 0.241 0.259 0.281 Min Insulation  Resistance @ 20°C  MOhm.km 16,000 14,000 13,000 11,000 10,000 9,700 8,900 Electric Stress At  Conductor Screen  kV/mm 3.63 3.50 3.33 3.21 3.13 3.06 2.99 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.659 0.712 0.802 0.891 0.962 1.03 1.12 Short Circuit Rating Phase  ConductorkA, 1 sec 3.3 4.7 6.6 9.0 11.3 14.2 17.5 Metallic ScreenkA, 1 sec 3.5 4.6 6.3 8.9 10 10 10 Con-tinuous Current Rating In Ground,Direct Buried  A 125 145 190 225 250 285 325 In Ground,  In Singleway Ducts  A 110 130 160 190 225 250 280 In Free Air,  Unenclosed & Spaced From Wall  A 125 145 190 230 265 305 350

108 MEDIUM VOLTAGE CABLES Copper 19/33kV SINGLE CORE LIGHT DUTY SCREENED UNARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Plain circular compacted copper Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded, semi-conductive compound METALLIC SCREEN: Plain annealed copper wire: 3kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT 12D (PVC only) 15D (HDPE) 1 (PVC only)  3 (HDPE)

109 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. MEDIUM VOLTAGE CABLES Physical & Electrical Characteristics Copper 19/33kV Product Code 1CCUX33LD Nominal Conductor Area mm 2 50 70 95 120 150 185 240 300 400 500 630 Nominal Conductor Diameter mm 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 23.5 26.6 30.3 Nominal Insulation Thickness mm 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 Approx Cable  Diameter mm 33.1 34.7 36.6 38.0 39.6 41.4 43.8 46.5 50.2 53.5 57.4 Approx Mass kg/100m 140 165 195 225 255 295 355 420 515 625 770 Max Pulling Tension  On Conductor kN 3.5 4.9 6.7 8.4 11 13 17 21 25 25 25 Max Pulling Tension  On Stocking Grip kN 3.5 4.2 4.7 5.1 5.5 6.0 6.7 7.6 8.8 10 12 Min Bending Radius : During Installation mm 600 630 660 680 710 740 790 840 900 960 1030 Min Bending Radius : Set In Position mm 400 420 440 460 480 500 530 560 600 640 690 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 0.0470 0.0366 0.0283 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 0.494 0.342 0.247 0.196 0.159 0.127 0.0976 0.0786 0.0625 0.0500 0.0405 Inductance, Trefoil Touching mH/km 0.507 0.469 0.447 0.428 0.415 0.400 0.385 0.372 0.359 0.346 0.335 Inductive Reactance,  Trefoil Touching  @ 50Hz Ohm/km 0.159 0.147 0.140 0.134 0.130 0.126 0.121 0.117 0.113 0.109 0.105 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 1.32+  j0.0975 1.20+  j0.0868 1.13+  j0.0802 1.09+  j0.0749 1.06+  j0.0711 1.03+  j0.0670 1.01+  j0.0627 0.995+  j0.0591 0.982+  j0.0556 0.973+  j0.0521 0.965+  j0.0491 Capacitance, Phase  To Earth µF/km 0.139 0.155 0.170 0.183 0.196 0.212 0.231 0.254 0.284 0.312 0.344 Min Insulation  Resistance @ 20°C  MOhm.km 18,000 16,000 15,000 14,000 13,000 12,000 11,000 9,900 8,800 8,000 7,200 Electric Stress At  Conductor Screen  kV/mm 4.07 3.85 3.67 3.55 3.46 3.36 3.26 3.16 3.06 2.99 2.93 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.831 0.923 1.02 1.09 1.17 1.26 1.38 1.52 1.70 1.86 2.06 Short Circuit Rating Phase  ConductorkA, 1 sec 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 57.2 71.5 90.1 Metallic ScreenkA, 1 sec 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 Con-tinuous Current Rating In Ground,Direct Buried  A 205 250 300 335 380 425 490 555 625 705 795 In Ground,  In Singleway Ducts  A 200 245 290 325 360 405 465 520 585 655 735 In Free Air,  Unenclosed & Spaced From Wall  A 220 275 330 380 435 495 580 665 770 885 1015

110 MEDIUM VOLTAGE CABLES SINGLE CORE HEAVY DUTY SCREENED UNARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Plain circular compacted copper Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 10kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C 1 (PVC only)  3 (HDPE) Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT Copper 19/33kV

111 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. MEDIUM VOLTAGE CABLES Physical & Electrical Characteristics Copper 19/33kV Product Code 1CCUX33HD Nominal Conductor Area mm 2 50 70 95 120 150 185 240 300 400 500 630 Nominal Conductor Diameter mm 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 23.5 26.6 30.3 Nominal Insulation Thickness mm 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 Approx Cable  Diameter mm 34.4 36.2 37.9 39.5 40.9 42.9 45.1 47.8 51.5 54.8 58.7 Approx Mass kg/100m 165 210 240 270 300 340 400 465 560 675 815 Max Pulling Tension  On Conductor kN 3.5 4.9 6.7 8.4 11 13 17 21 25 25 25 Max Pulling Tension  On Stocking Grip kN 3.5 4.6 5.0 5.5 5.9 6.4 7.1 8.0 9.3 10 12 Min Bending Radius : During Installation mm 620 650 680 710 740 770 810 860 930 990 1060 Min Bending Radius : Set In Position mm 410 430 460 470 490 510 540 570 620 660 700 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 0.0470 0.0366 0.0283 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 0.494 0.342 0.247 0.196 0.159 0.127 0.0976 0.0785 0.0624 0.0500 0.0404 Inductance, Trefoil Touching mH/km 0.515 0.478 0.454 0.436 0.422 0.407 0.391 0.378 0.365 0.352 0.340 Inductive Reactance,  Trefoil Touching  @ 50Hz Ohm/km 0.162 0.150 0.143 0.137 0.133 0.128 0.123 0.119 0.115 0.110 0.107 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 0.783+  j0.0989 0.550+  j0.0881 0.475+  j0.0815 0.435+  j0.0762 0.406+  j0.0723 0.381+  j0.0681 0.358+  j0.0638 0.343+  j0.0601 0.330+  j0.0566 0.320+  j0.0530 0.312+  j0.0499 Capacitance, Phase  To Earth µF/km 0.139 0.155 0.170 0.183 0.196 0.212 0.231 0.254 0.284 0.312 0.344 Min Insulation  Resistance @ 20°C  MOhm.km 18,000 16,000 15,000 14,000 13,000 12,000 11,000 9,900 8,800 8,000 7,200 Electric Stress At  Conductor Screen  kV/mm 4.07 3.85 3.67 3.55 3.46 3.36 3.26 3.16 3.06 2.99 2.93 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.831 0.923 1.02 1.09 1.17 1.26 1.38 1.52 1.70 1.86 2.06 Short Circuit Rating Phase  ConductorkA, 1 sec 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 57.2 71.5 90.1 Metallic ScreenkA, 1 sec 7.1 10 10 10 10 10 10 10 10 10 10 Con-tinuous Current Rating In Ground,Direct Buried  A 205 250 295 335 370 420 480 535 605 675 750 In Ground,  In Singleway Ducts  A 200 235 275 310 340 375 425 470 520 575 630 In Free Air,  Unenclosed & Spaced From Wall  A 220 275 335 380 430 490 575 655 750 855 970

112 MEDIUM VOLTAGE CABLES THREE CORE LIGHT DUTY SCREENED UNARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Plain circular compacted copper Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 3kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT 1 (PVC only)  3 (HDPE) Copper 19/33kV

113 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. MEDIUM VOLTAGE CABLES Physical & Electrical Characteristics Copper 19/33kV Product Code 3CCUX33LD Nominal Conductor Area mm 2 50 70 95 120 150 185 240 300 Nominal Conductor Diameter mm 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 Nominal Insulation Thickness mm 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 Approx Cable  Diameter mm 68.5 72.4 76.3 79.5 82.7 86.7 91.8 97.6 Approx Mass kg/100m 435 525 620 715 810 940 1140 1350 Max Pulling Tension  On Conductors kN 11 15 20 25 25 25 25 25 Max Pulling Tension  On Stocking Grip kN 11 15 20 22 24 25 25 25 Min Bending Radius : During Installation mm 1230 1300 1370 1430 1490 1560 1650 1760 Min Bending Radius : Set In Position mm 820 870 920 950 990 1040 1100 1170 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 0.494 0.342 0.247 0.196 0.159 0.128 0.0978 0.0788 Inductance mH/km 0.457 0.422 0.401 0.384 0.371 0.358 0.344 0.332 Inductive Reactance,  @ 50Hz Ohm/km 0.143 0.133 0.126 0.121 0.117 0.112 0.108 0.104 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 2.32+j0.0978 2.09+j0.0871 1.92+j0.0805 1.79+j0.0752 1.69+j0.0714 1.59+j0.0672 1.44+j0.0629 1.37+j0.0593 Capacitance, Phase  To Earth µF/km 0.140 0.155 0.171 0.184 0.197 0.212 0.232 0.255 Min Insulation  Resistance @ 20°C  MOhm.km 18,000 16,000 15,000 14,000 13,000 12,000 11,000 9,900 Electric Stress At  Conductor Screen  kV/mm 4.07 3.85 3.67 3.55 3.46 3.36 3.26 3.16 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.834 0.927 1.02 1.10 1.17 1.27 1.39 1.52 Short Circuit Rating Phase  ConductorkA, 1 sec 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 Metallic ScreenkA, 1 sec 4.3 4.6 4.8 5.1 5.3 5.6 6.1 6.3 Con-tinuous Current Rating In Ground,Direct Buried  A 190 235 280 320 365 410 484 545 In Ground,  In Singleway Ducts  A 170 210 245 280 310 355 401 452 In Free Air,  Unenclosed & Spaced From Wall  A 195 245 295 340 390 440 544 620

114 MEDIUM VOLTAGE CABLES THREE CORE LIGHT DUTY SCREENED ARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Plain circular compacted copper Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 3kA for nominal 1 second ARMOURING: Galvanised steel wires SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT 1 (PVC only)  3 (HDPE) 3 (Armoured) Copper 19/33kV

115 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. MEDIUM VOLTAGE CABLES Physical & Electrical Characteristics Copper 19/33kV Product Code 3CCUX33LDA Nominal Conductor Area mm 2 50 70 95 120 150 Nominal Conductor Diameter mm 8.2 9.8 11.5 12.9 14.3 Nominal Insulation Thickness mm 8.0 8.0 8.0 8.0 8.0 Approx Cable  Diameter mm 79.9 84.1 88.0 91.4 94.8 Approx Mass kg/100m 920 1040 1160 1280 1400 Max Pulling Tension  On Conductors kN 11 15 20 25 25 Max Pulling Tension  On Stocking Grip kN 11 15 20 25 25 Max Pulling Tension  On Amour Wires kN 25 25 25 25 25 Min Bending Radius : During Installation mm 1440 1510 1580 1640 1710 Min Bending Radius : Set In Position mm 960 1010 1060 1100 1140 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.387 0.268 0.193 0.153 0.124 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 0.494 0.342 0.247 0.196 0.159 Inductance mH/km 0.457 0.422 0.401 0.384 0.371 Inductive Reactance,  @ 50Hz Ohm/km 0.143 0.133 0.126 0.121 0.117 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 2.32+j0.0978 2.09+j0.0871 1.92+j0.0805 1.79+j0.0752 1.69+j0.0714 Capacitance, Phase  To Earth µF/km 0.140 0.155 0.171 0.184 0.197 Min Insulation  Resistance @ 20°C  MOhm.km 18,000 16,000 15,000 14,000 13,000 Electric Stress At  Conductor Screen  kV/mm 4.07 3.85 3.67 3.55 3.46 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.834 0.927 1.02 1.10 1.17 Short Circuit Rating Phase  ConductorkA, 1 sec 7.2 10.0 13.6 17.2 21.5 Metallic ScreenkA, 1 sec 4.3 4.6 4.8 5.1 5.3 Con-tinuous Current Rating In Ground,Direct Buried  A 190 235 280 320 365 In Ground,  In Singleway Ducts  A 170 210 245 280 310 In Free Air,  Unenclosed & Spaced From Wall  A 195 245 295 340 390

116 MEDIUM VOLTAGE CABLES THREE CORE HEAVY DUTY SCREENED UNARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Plain circular compacted copper Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 10kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT 1 (PVC only)  3 (HDPE) Copper 19/33kV

117 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. MEDIUM VOLTAGE CABLES Physical & Electrical Characteristics Copper 19/33kV Product Code 3CCUX33HD Nominal Conductor Area mm 2 50 70 95 120 150 185 240 300 Nominal Conductor Diameter mm 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 Nominal Insulation Thickness mm 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 Approx Cable  Diameter mm 68.7 72.4 76.3 79.5 82.7 86.7 91.8 97.6 Approx Mass kg/100m 455 560 655 745 840 970 1160 1380 Max Pulling Tension  On Conductors kN 11 15 20 25 25 25 25 25 Max Pulling Tension  On Stocking Grip kN 11 15 20 22 24 25 25 25 Min Bending Radius : During Installation mm 1240 1300 1370 1430 1490 1560 1650 1760 Min Bending Radius : Set In Position mm 820 870 920 950 990 1040 1100 1170 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 0.494 0.342 0.247 0.196 0.159 0.128 0.0978 0.0788 Inductance mH/km 0.457 0.422 0.401 0.384 0.371 0.358 0.344 0.332 Inductive Reactance,  @ 50Hz Ohm/km 0.143 0.133 0.126 0.121 0.117 0.112 0.108 0.104 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 1.56+j0.0978 1.11+j0.0871 1.03+j0.0805 0.995+j0.0752 0.966+j0.0714 0.941+j0.0672 0.917+j0.0629 0.902+j0.0593 Capacitance, Phase  To Earth µF/km 0.140 0.155 0.171 0.184 0.197 0.212 0.232 0.255 Min Insulation  Resistance @ 20°C  MOhm.km 18,000 16,000 15,000 14,000 13,000 12,000 11,000 9,900 Electric Stress At  Conductor Screen  kV/mm 4.07 3.85 3.67 3.55 3.46 3.36 3.26 3.16 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.834 0.927 1.02 1.10 1.17 1.27 1.39 1.52 Short Circuit Rating Phase  ConductorkA, 1 sec 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 Metallic ScreenkA, 1 sec 7.1 10 10 10 10 10 10 10 Con-tinuous Current Rating In Ground,Direct Buried  A 195 240 285 330 370 410 486 547 In Ground,  In Singleway Ducts  A 170 210 250 280 320 360 402 452 In Free Air,  Unenclosed & Spaced From Wall  A 195 250 305 350 395 450 550 627

118 MEDIUM VOLTAGE CABLES THREE CORE HEAVY DUTY SCREENED ARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Plain circular compacted copper Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 10kA for nominal 1 second ARMOURING: Galvanised steel wires SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT 1 (PVC only)  3 (HDPE) 3 (Armoured) Copper 19/33kV

119 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. MEDIUM VOLTAGE CABLES Physical & Electrical Characteristics Copper 19/33kV Product Code 3CCUX33HDA Nominal Conductor Area mm 2 50 70 95 120 150 Nominal Conductor Diameter mm 8.2 9.8 11.5 12.9 14.3 Nominal Insulation Thickness mm 8.0 8.0 8.0 8.0 8.0 Approx Cable  Diameter mm 80.1 84.1 88.0 91.4 94.8 Approx Mass kg/100m 940 1070 1190 1310 1430 Max Pulling Tension  On Conductors kN 11 15 20 25 25 Max Pulling Tension  On Stocking Grip kN 11 15 20 25 25 Max Pulling Tension  On Amour Wires kN 25 25 25 25 25 Min Bending Radius : During Installation mm 1440 1510 1580 1640 1710 Min Bending Radius : Set In Position mm 960 1010 1060 1100 1140 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.387 0.268 0.193 0.153 0.124 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 0.494 0.342 0.247 0.196 0.159 Inductance mH/km 0.457 0.422 0.401 0.384 0.371 Inductive Reactance,  @ 50Hz Ohm/km 0.143 0.133 0.126 0.121 0.117 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 1.56+j0.0978 1.11+j0.0871 1.03+j0.0805 0.995+j0.0752 0.966+j0.0714 Capacitance, Phase  To Earth µF/km 0.140 0.155 0.171 0.184 0.197 Min Insulation  Resistance @ 20°C  MOhm.km 18,000 16,000 15,000 14,000 13,000 Electric Stress At  Conductor Screen  kV/mm 4.07 3.85 3.67 3.55 3.46 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.834 0.927 1.02 1.10 1.17 Short Circuit Rating Phase  ConductorkA, 1 sec 7.2 10.0 13.6 17.2 21.5 Metallic ScreenkA, 1 sec 7.1 10 10 10 10 Con-tinuous Current Rating In Ground,Direct Buried  A 195 240 285 330 370 In Ground,  In Singleway Ducts  A 170 210 250 280 320 In Free Air,  Unenclosed & Spaced From Wall  A 195 250 305 350 395

120 MEDIUM VOLTAGE CABLES SINGLE CORE LIGHT DUTY SCREENED UNARMOURED Cable Characteristics +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 1 (PVC only)  3 (HDPE) Installation Conditions Cable Design CONDUCTOR:  Circular compacted aluminium Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 3kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standard Orange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT Aluminium 19/33kV

121 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. Physical & Electrical Characteristics Aluminium 19/33kV Product Code 1CALX33LD Nominal Conductor Area mm 2 50 70 95 120 150 185 240 300 400 500 630 Nominal Conductor Diameter mm 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 23.5 26.6 30.2 Nominal Insulation Thickness mm 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 Approx Cable  Diameter mm 33.0 34.7 36.6 38.0 39.5 41.3 43.6 46.5 50.2 53.5 57.3 Approx Mass kg/100m 110 120 135 150 165 180 205 235 275 320 375 Max Pulling Tension  On Conductor kN 2.5 3.5 4.8 6.0 7.5 9.3 12 15 20 25 25 Max Pulling Tension  On Stocking Grip kN 2.5 3.5 4.7 5.0 5.5 6.0 6.7 7.6 8.8 10 11 Min Bending Radius : During Installation mm 590 630 660 680 710 740 790 840 900 960 1030 Min Bending Radius : Set In Position mm 400 420 440 460 470 500 520 560 600 640 690 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 0.0778 0.0605 0.0469 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 0.822 0.568 0.411 0.325 0.265 0.211 0.161 0.129 0.101 0.0797 0.0630 Inductance, Trefoil Touching mH/km 0.508 0.469 0.447 0.431 0.419 0.401 0.386 0.372 0.361 0.348 0.336 Inductive Reactance,  Trefoil Touching  @ 50Hz Ohm/km 0.160 0.147 0.140 0.136 0.132 0.126 0.121 0.117 0.113 0.109 0.105 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 1.57+  j0.0978 1.38+  j0.0868 1.25+  j0.0802 1.19+  j0.0759 1.14+  j0.0722 1.10+  j0.0672 1.06+  j0.0629 1.03+  j0.0591 1.01+  j0.0561 0.996+  j0.0526 0.982+  j0.0492 Capacitance, Phase  To Earth µF/km 0.139 0.155 0.170 0.183 0.195 0.211 0.230 0.254 0.284 0.312 0.344 Min Insulation  Resistance @ 20°C  MOhm.km 18,000 16,000 15,000 14,000 13,000 12,000 11,000 9,900 8,800 8,000 7,200 Electric Stress At  Conductor Screen  kV/mm 4.08 3.85 3.67 3.56 3.46 3.36 3.26 3.16 3.06 2.99 2.93 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.828 0.923 1.02 1.09 1.16 1.26 1.37 1.52 1.70 1.86 2.05 Short Circuit Rating Phase  ConductorkA, 1 sec 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 37.8 47.2 59.5 Metallic ScreenkA, 1 sec 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 Con-tinuous Current Rating In Ground,Direct Buried  A 160 195 230 265 295 330 385 435 495 565 645 In Ground,  In Singleway Ducts  A 155 190 225 255 285 320 370 415 470 535 605 In Free Air,  Unenclosed & Spaced From Wall  A 170 215 260 295 335 385 455 520 610 705 820

122 MEDIUM VOLTAGE CABLES SINGLE CORE HEAVY DUTY SCREENED UNARMOURED Cable Characteristics +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 1 (PVC only)  3 (HDPE) Installation Conditions Cable Design CONDUCTOR:  Circular compacted aluminium Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 10kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standard Orange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT Aluminium 19/33kV

123 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. Physical & Electrical Characteristics Aluminium 19/33kV Product Code 1CALX33HD Nominal Conductor Area mm 2 50 70 95 120 150 185 240 300 400 500 630 Nominal Conductor Diameter mm 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 23.5 26.6 30.2 Nominal Insulation Thickness mm 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 Approx Cable  Diameter mm 34.3 36.2 37.9 39.5 40.8 42.8 44.9 47.8 51.5 54.8 58.6 Approx Mass kg/100m 125 150 175 195 210 230 250 280 320 365 420 Max Pulling Tension  On Conductor kN 2.5 3.5 4.8 6.0 7.5 9.3 12 15 20 25 25 Max Pulling Tension  On Stocking Grip kN 2.5 3.5 4.8 5.5 5.8 6.4 7.1 8.0 9.3 10 12 Min Bending Radius : During Installation mm 620 650 680 710 730 770 810 860 930 990 1050 Min Bending Radius : Set In Position mm 410 430 460 470 490 510 540 570 620 660 700 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 0.0778 0.0605 0.0469 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 0.822 0.568 0.411 0.325 0.265 0.211 0.161 0.129 0.101 0.0797 0.0629 Inductance, Trefoil Touching mH/km 0.516 0.478 0.454 0.439 0.426 0.408 0.392 0.378 0.366 0.353 0.340 Inductive Reactance,  Trefoil Touching  @ 50Hz Ohm/km 0.162 0.150 0.143 0.138 0.134 0.128 0.123 0.119 0.115 0.111 0.107 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 1.24+  j0.0992 0.871+  j0.0881 0.635+  j0.0815 0.535+ j0.0771 0.488+  j0.0734 0.446+  j0.0683 0.407+  j0.0640 0.382+  j0.0601 0.360+  j0.0570 0.343+  j0.0534 0.330+  j0.0500 Capacitance, Phase  To Earth µF/km 0.139 0.155 0.170 0.183 0.195 0.211 0.230 0.254 0.284 0.312 0.344 Min Insulation  Resistance @ 20°C  MOhm.km 18,000 16,000 15,000 14,000 13,000 12,000 11,000 9,900 8,800 8,000 7,200 Electric Stress At  Conductor Screen  kV/mm 4.08 3.85 3.67 3.56 3.46 3.36 3.26 3.16 3.06 2.99 2.93 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.828 0.923 1.02 1.09 1.16 1.26 1.37 1.52 1.70 1.86 2.05 Short Circuit Rating Phase  ConductorkA, 1 sec 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 37.8 47.2 59.5 Metallic ScreenkA, 1 sec 4.7 6.6 8.9 10 10 10 10 10 10 10 10 Con-tinuous Current Rating In Ground,Direct Buried  A 160 195 230 260 290 330 380 425 485 550 620 In Ground,  In Singleway Ducts  A 155 190 220 245 275 305 345 385 435 485 540 In Free Air,  Unenclosed & Spaced From Wall  A 175 215 260 295 335 385 450 515 600 690 800

124 MEDIUM VOLTAGE CABLES THREE CORE LIGHT DUTY SCREENED UNARMOURED Cable Characteristics +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 1 (PVC only)  3 (HDPE) Installation Conditions Cable Design CONDUCTOR:  Circular compacted aluminium Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 3kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT Aluminium 19/33kV

125 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. Physical & Electrical Characteristics Aluminium 19/33kV Product Code 3CALX33LD Nominal Conductor Area mm 2 50 70 95 120 150 185 240 300 Nominal Conductor Diameter mm 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 Nominal Insulation Thickness mm 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 Approx Cable  Diameter mm 68.4 72.4 76.3 79.4 82.5 86.5 91.5 97.6 Approx Mass kg/100m 350 400 445 490 535 600 690 795 Max Pulling Tension  On Conductors kN 7.5 11 14 18 23 25 25 25 Max Pulling Tension  On Stocking Grip kN 7.5 11 14 18 23 25 25 25 Min Bending Radius : During Installation mm 1230 1300 1370 1430 1490 1560 1650 1760 Min Bending Radius : Set In Position mm 820 870 920 950 990 1040 1100 1170 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 0.822 0.568 0.411 0.325 0.265 0.211 0.161 0.130 Inductance mH/km 0.457 0.422 0.401 0.387 0.375 0.359 0.345 0.332 Inductive Reactance,  @ 50Hz Ohm/km 0.144 0.133 0.126 0.121 0.118 0.113 0.108 0.104 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 2.57+j0.0981 2.27+j0.0871 2.05+j0.0805 1.89+j0.0762 1.77+j0.0724 1.66+j0.0674 1.49+j0.0632 1.41+j0.0593 Capacitance, Phase  To Earth µF/km 0.139 0.155 0.171 0.183 0.196 0.211 0.231 0.255 Min Insulation  Resistance @ 20°C  MOhm.km 18,000 16,000 15,000 14,000 13,000 12,000 11,000 9,900 Electric Stress At  Conductor Screen  kV/mm 4.08 3.85 3.67 3.56 3.46 3.36 3.26 3.16 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.831 0.927 1.02 1.09 1.17 1.26 1.38 1.52 Short Circuit Rating Phase  ConductorkA, 1 sec 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 Metallic ScreenkA, 1 sec 4.3 4.6 4.8 5.1 5.3 5.6 6.1 6.3 Con-tinuous Current Rating In Ground,Direct Buried  A 150 180 220 250 280 315 377 426 In Ground,  In Singleway Ducts  A 130 160 190 225 250 275 313 353 In Free Air,  Unenclosed & Spaced From Wall  A 155 190 230 270 300 340 424 484

126 MEDIUM VOLTAGE CABLES THREE CORE LIGHT DUTY SCREENED ARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Circular compacted aluminium Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 3kA for nominal 1 second ARMOURING: Galvanised steel wires SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT 1 (PVC only)  3 (HDPE) 3 (Armoured) Aluminium 19/33kV

127 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. Physical & Electrical Characteristics Aluminium 19/33kV Product Code 3CALX33LDA Nominal Conductor Area mm 2 50 70 95 120 150 Nominal Conductor Diameter mm 8.1 9.8 11.5 12.9 14.2 Nominal Insulation Thickness mm 8.0 8.0 8.0 8.0 8.0 Approx Cable  Diameter mm 79.8 84.1 88.0 91.3 94.6 Approx Mass kg/100m 830 910 980 1050 1120 Max Pulling Tension  On Conductors kN 7.5 11 14 18 23 Max Pulling Tension  On Stocking Grip kN 7.5 11 14 18 23 Max Pulling Tension  On Amour Wires kN 25 25 25 25 25 Min Bending Radius : During Installation mm 1440 1510 1580 1640 1700 Min Bending Radius : Set In Position mm 960 1010 1060 1100 1140 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.641 0.443 0.320 0.253 0.206 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 0.822 0.568 0.411 0.325 0.265 Inductance mH/km 0.457 0.422 0.401 0.387 0.375 Inductive Reactance,  @ 50Hz Ohm/km 0.144 0.133 0.126 0.121 0.118 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 2.57+j0.0981 2.27+j0.0871 2.05+j0.0805 1.89+j0.0762 1.77+j0.0724 Capacitance, Phase  To Earth µF/km 0.139 0.155 0.171 0.183 0.196 Min Insulation  Resistance @ 20°C  MOhm.km 18,000 16,000 15,000 14,000 13,000 Electric Stress At  Conductor Screen  kV/mm 4.08 3.85 3.67 3.56 3.46 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.831 0.927 1.02 1.09 1.17 Short Circuit Rating Phase  ConductorkA, 1 sec 4.7 6.6 9.0 11.3 14.2 Metallic ScreenkA, 1 sec 4.3 4.6 4.8 5.1 5.3 Con-tinuous Current Rating In Ground,Direct Buried  A 150 180 220 250 280 In Ground,  In Singleway Ducts  A 130 160 190 225 250 In Free Air,  Unenclosed & Spaced From Wall  A 155 190 230 270 300

128 MEDIUM VOLTAGE CABLES THREE CORE HEAVY DUTY SCREENED UNARMOURED Cable Characteristics +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 1 (PVC only)  3 (HDPE) Installation Conditions Cable Design CONDUCTOR:  Circular compacted aluminium Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 10kA for nominal 1 second SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT Aluminium 19/33kV

129 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. Physical & Electrical Characteristics Aluminium 19/33kV Product Code 3CALX33HD Nominal Conductor Area mm 2 50 70 95 120 150 185 240 300 Nominal Conductor Diameter mm 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 Nominal Insulation Thickness mm 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 Approx Cable  Diameter mm 68.6 72.4 76.3 79.4 82.5 86.5 91.5 97.6 Approx Mass kg/100m 355 410 470 520 565 630 715 820 Max Pulling Tension  On Conductors kN 7.5 11 14 18 23 25 25 25 Max Pulling Tension  On Stocking Grip kN 7.5 11 14 18 23 25 25 25 Min Bending Radius : During Installation mm 1230 1300 1370 1430 1490 1560 1650 1760 Min Bending Radius : Set In Position mm 820 870 920 950 990 1040 1100 1170 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 0.822 0.568 0.411 0.325 0.265 0.211 0.161 0.130 Inductance mH/km 0.457 0.422 0.401 0.387 0.375 0.359 0.345 0.332 Inductive Reactance,  @ 50Hz Ohm/km 0.144 0.133 0.126 0.121 0.118 0.113 0.108 0.104 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 2.46+j0.0981 1.76+j0.0871 1.28+j0.0805 1.09+j0.0762 1.05+j0.0724 1.01+j0.0674 0.967+j0.0632 0.942+j0.0593 Capacitance, Phase  To Earth µF/km 0.139 0.155 0.171 0.183 0.196 0.211 0.231 0.255 Min Insulation  Resistance @ 20°C  MOhm.km 18,000 16,000 15,000 14,000 13,000 12,000 11,000 9,900 Electric Stress At  Conductor Screen  kV/mm 4.08 3.85 3.67 3.56 3.46 3.36 3.26 3.16 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.831 0.927 1.02 1.09 1.17 1.26 1.38 1.52 Short Circuit Rating Phase  ConductorkA, 1 sec 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 Metallic ScreenkA, 1 sec 4.6 6.3 8.6 10 10 10 10 10 Con-tinuous Current Rating In Ground,Direct Buried  A 145 190 225 255 285 320 380 428 In Ground,  In Singleway Ducts  A 130 160 195 225 250 280 314 354 In Free Air,  Unenclosed & Spaced From Wall  A 150 185 235 270 305 350 430 491

130 MEDIUM VOLTAGE CABLES THREE CORE HEAVY DUTY SCREENED ARMOURED Cable Characteristics Installation Conditions Cable Design CONDUCTOR:  Circular compacted aluminium Maximum Continuous Operating Temperature:   90°C CONDUCTOR SCREEN:  Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation INSULATION:  Cross Linked Polyethylene (XLPE) – standard Ethylene Propylene Rubber (EPR) – alternative INSULATION SCREEN: Extruded semi-conducting compound METALLIC SCREEN: Plain annealed copper wire: 10kA for nominal 1 second ARMOURING: Galvanised steel wires SHEATH: Black 5V-90 polyvinyl chloride (PVC) – standardOrange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer – alternativeLow smoke zero halogen (LSOH) – alternative +90˚C -25˚C Good Spray (XPLE) Immersion (EPR) Acceptable C3 Semi-rigid 12D (PVC only) 15D (HDPE) 18D (PVC only) 25D (HDPE) IN FREE AIR IN GROUND WITH  PROTECTION IN TRENCH IN GROUND IN DUCT 1 (PVC only)  3 (HDPE) 3 (Armoured) Aluminium 19/33kV

131 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. Increased radius required for HDPE and nylon incorporating designs. Physical & Electrical Characteristics Aluminium 19/33kV Product Code 3CALX33HDA Nominal Conductor Area mm 2 50 70 95 120 150 Nominal Conductor Diameter mm 8.1 9.8 11.5 12.9 14.2 Nominal Insulation Thickness mm 8.0 8.0 8.0 8.0 8.0 Approx Cable  Diameter mm 80.0 84.1 88.0 91.3 94.6 Approx Mass kg/100m 835 920 1010 1080 1150 Max Pulling Tension  On Conductors kN 7.5 11 14 18 23 Max Pulling Tension  On Stocking Grip kN 7.5 11 14 18 23 Max Pulling Tension  On Amour Wires kN 25 25 25 25 25 Min Bending Radius : During Installation mm 1440 1510 1580 1640 1700 Min Bending Radius : Set In Position mm 960 1010 1060 1100 1140 Max Conductor  Resistance, dc @ 20°C  Ohm/km 0.641 0.443 0.320 0.253 0.206 Conductor Resistance,  ac @ 90°C & 50 Hz  Ohm/km 0.822 0.568 0.411 0.325 0.265 Inductance mH/km 0.457 0.422 0.401 0.387 0.375 Inductive Reactance,  @ 50Hz Ohm/km 0.144 0.133 0.126 0.121 0.118 Zero Seq. Impedance@ 20°C & 50 Hz Ohm/km 2.46+j0.0981 1.76+j0.0871 1.28+j0.0805 1.09+j0.0762 1.05+j0.0724 Capacitance, Phase  To Earth µF/km 0.139 0.155 0.171 0.183 0.196 Min Insulation  Resistance @ 20°C  MOhm.km 18,000 16,000 15,000 14,000 13,000 Electric Stress At  Conductor Screen  kV/mm 4.08 3.85 3.67 3.56 3.46 Charging Current @ Rated Voltage & 50 Hz  A/phase/km 0.831 0.927 1.02 1.09 1.17 Short Circuit Rating Phase  ConductorkA, 1 sec 4.7 6.6 9.0 11.3 14.2 Metallic ScreenkA, 1 sec 4.6 6.3 8.6 10 10 Con-tinuous Current Rating In Ground,Direct Buried  A 145 190 225 255 285 In Ground,  In Singleway Ducts  A 130 160 195 225 250 In Free Air,  Unenclosed & Spaced From Wall  A 150 185 235 270 305

132 CABLE SELECTION  Cables should be selected and used such that the product does not present an unacceptable risk or danger to life or property when used in its intended manner. Cables should also be selected so that they are suitable for the operating environment conditions e.g. use in petrochemical works, need for fire performance, the need for protection against attack by rodents, termites, etc, equipment classification and any other external influences which may exist. They should also be selected according to the appropriate rated voltage and the cross-sectional area of every conductor such that its current carrying capacity is not less than the maximum sustained current which would normally flow through it, and the short circuit current rating of conductor and screen is adequate for the prospective short circuit and time for which it persists. In addition, consideration should be given to other relevant factors, such as: •  voltage drop requirements •  operating characteristics of connected equipment •  economics ENVIRONMENTAL PROTECTION The standard cable finishes are adequate for normal environmental conditions. However, there are many installations where conditions are much more onerous than normal and some brief notes for protection of cables against hostile environments are given below. Once the type of protective covering to meet environmental conditions has been decided, it is generally possible taking voltage and current ratings into account, to arrive at the type of cable insulation to be used. OIL REFINERIES AND CHEMICAL PLANTS Polymeric and elastomeric cables are not compatible with hydrocarbon oils and organic solvents. Such oils and solvents particularly at elevated temperatures are absorbed by the insulation and sheathing materials leading to swelling and resultant damage. Semi-conductive components on high voltage cables may lose their conductive properties. It follows that where polymeric and elastomeric cables are used in locations where exposure to hydrocarbon oils and organic solvents is likely, a lead sheath is required. The most satisfactory protection for the lead sheath would be a high density polyethylene sheath with steel wire armour. For casual contact with oil spills, a Nitrile or CSP rubber sheath can be used. PVC sheaths offer good protection against chemical attack. Specifiers should contact Prysmian for recommendations regarding the protection of cables against harsh chemical environments. TERMITES, TEREDOES & RODENTS Special constructions are necessary to resist insects such as termites, as all cables with normal finishes are susceptible to their attack. If cables are installed in locations where termite attack is likely, protection may take the form of one of the following: •  Two helically applied brass tapes, the upper one  overlapping the gap in the lower one, may be incorporated into the cable design. In the case of armoured cable the brass tapes may be applied under the bedding of the armour. For unarmoured cable the brass tapes can be applied over the normal PVC or other extruded sheath followed by a PVC sheath over the brass tapes. •  A nylon jacket may be applied over the PVC or other  extruded sheath followed by a sacrificial layer of extruded PVC over the nylon to protect it from damage during installation. •  Termitex™ technology incorporated into the cable  design, for long term protection. Chemical treatment of the backfill is no longer recommended because of damage to the environment and the risk to health. The teredo worm is prevalent in tropical, subtropical and temperate oceans and estuaries. Protection is usually attained by incorporating two brass tapes under the armour of all submarine cables. In areas liable to attack by rodents, galvanised steel wire armour provides an effective barrier. A layer of nylon covering under the armour provides additional protection from insects. Prysmian have expertise in designing cables to resist boring insect and rodent attack. Please call the Customer Service Team for advice. Technical Information

133 EXPOSURE TO MECHANICAL DAMAGE  1.  Slight exposure to impact and to tensile stresses.  The application of a high density polyethylene sheath can give appreciable added mechanical protection to cables with the normal PVC sheath. This method is suitable for single and multi-core cables. 2.  Moderate exposure to impact and to tensile  stresses. Single core cables can be armoured with non-ferrous armour wire, usually hard drawn aluminium. For Multicore cables a single layer of galvanised steel wire armour is recommended. The steel wire is necessary if there is likely to be a moderate tensile stress applied to the cable during pulling in or during service. Steel wire armoured cables offer good protection against rugged installation conditions. 3.  Severe exposure to impact and tensile stresses.   The double wire armour finish offers a very high level of protection against mechanical damage whether it be impact or longitudinal tensile stress such as in subsidence areas and submarine installations on an uneven sea floor. 4. Polymeric protection against impact.   Prysmian developed AIRBAG™, which provides enhanced mechanical/impact protection keeping the handling and installation characteristics of unprotected cables. EXPOSURE TO ULTRA VIOLET RADIATION Prysmian has special materials designed to prevent UV degradation when exposed to sunlight. To be sure the correct material is used it is necessary to state at the time of enquiry and ordering that the cable will be exposed to sunlight. FIRE SITUATIONS The performance of a cable in a fire situation can be a major factor in the choice of cable type. When correctly selected, located and installed cables do not present a fire hazard but in the case of fire initiated elsewhere, cables provide a source of fuel and a possible means of propagation along its length.  Additionally cables can contribute to the emission of smoke and noxious gases injurious to equipment and human health. Evolution of smoke can reduce visibility, which can cause panic and create serious problems in evacuating personnel. The presence of acid gas in the smoke can result in corrosion, damage of electronic and other equipment and can cause intense irritation to the eyes and lungs. Cables manufactured from PVC and some other traditional materials when exposed to fire will produce dense black smoke and harmful fumes and may propagate fire when installed in bundles. Where these factors are of concern, the use of LSOH sheathed cables is recommended.  On the basis of standards in current use, cables can be divided into the following categories in relation to their behaviour in the presence of fire: Flame propagation (single cable) – when tested singly, the cable should self-extinguish within a short period of time and within a short distance from the point of application of a Bunsen burner flame. Such cables meet AS/NZS 1660.5.6 and IEC 60332 Part 1 and are often called flame retardant. Such cables will not necessarily prevent propagation along bunches of cables installed together on vertical racks and exposed to a large-scale fire source. Flame propagation (cable bunches) – when tested installed in defined bunches on a vertical ladder, the cables should not propagate flame more than a limited distance from the point of application of a ribbon burner flame front. Such cables meet AS/NZS 1660.5.1 and IEC 60332 Part 3 and are often called reduced propagation. Three categories exist in AS/NZS 1660.5.1 according to the volume of combustible material tested, Category A (7 l/m), Category B (3.5 l/m) and Category C (1.5 l/m). It should however be noted that propagation of fire is often a function of installation conditions and appropriate care should be taken to ensure that the test category chosen is representative of the actual installed condition. Low smoke zero halogen cables – have controlled limits on smoke evolution when cable samples are burnt in a closed 3m cube smoke chamber and controlled limits on acidic and corrosive gases when subject to material pyrolysis in a tube furnace. Such cables meet AS/NZS 1660.5.2 (IEC 61034) for smoke emission and AS/NZS 1660.5.4 (IEC 754-2) for determination of degree of acidity by measurement of pH and conductivity and are often called LSOH. By nature of their typical intended use the MV power cables of this type may be used where the performance of the cable in case of fire is important, either for limitation of the propagation of flame along cable bunches or the limitation of smoke and corrosive gas emissions. Reduced flame propagation variants of all cables in this technical manual can be supplied LSOH sheaths for situations where limiting the emission of smoke and corrosive gas from the cables if affected by fire is desirable. TECHNICAL INFORMATION

134 It is important to know whether the system to which the cable is connected is classified as earthed or unearthed. Supply authority systems are generally, though not always, earthed design. Mining systems are usually the unearthed design. Prysmian products are suitable for voltages that are commonly used in Australia. Voltage is usually expressed in the form Uo/U and Um.   Uo is the rms power frequency voltage between phase and earth.  U is the rms power frequency voltage between phases.  Um is the maximum continuous rms power frequency voltage between any two phases for which the cable is designed. It excludes momentary variations due to fault conditions or sudden disconnection of large loads. CABLE VOLTAGES  CABLE SELECTION VOLTAGE RATING The selection of standard cables for particular supply systems depends on the system voltage and earthing arrangements. Category A – system in which any phase conductor that comes in contact with earth or an earth conductor is disconnected from the system within 1 minute. Category B – system which, under fault conditions, is operated for a short time with one phase earthed, not exceeding 8 hours on any occasion and total duration of earth faults in any year not exceeding 125 hours. Category C – system which does not fall into Categories A and B. Note: If an earth fault is not automatically and promptly isolated, the extra stresses on the cable insulation during the fault reduce the life of the cable to a certain degree. If the system is expected to be operated fairly often with a permanent earth fault, it may be advisable to classify the system in Category C. TECHNICAL INFORMATION  Rated Voltages of Cables Max Continuous Operating Voltage Um kV General Cables  Uo/U kV Mining Cables Uo/U kV  1.9/3.3 3.3/3.3 3.6 3.8/6.6 6.6/6.6 7.2 6.35/11 11/11 12 12.7/22 22/22 24 19/33 33/33 36 38/66 72 Max System Voltage (Um) kV Min Rated (Phase to Earth) Voltage of Cable (Uo) kV Category A & B Category C 3.6 1.9 3.8 7.2 3.8 6.35 12.0 6.35 12.7 24.0 12.7 19 36.0 19 -

135 CURRENT RATINGS  The current ratings indicated in this manual have been based on the calculation procedures as recommended in IEC 60287 and the following assumptions. Rating factors should be applied to cover any variation. •  Max. continuous conductor temp. = 90°C •  Ambient air temperature = 40°C •  Ambient ground temperature = 25°C •  Depth of laying = 0.8m •  Thermal resistivity of soil = 1.2°C.m/W •  Balanced load, comprising either a single three core  cable or three single core cables, in trefoil formation touching throughout, with the screens bonded at both ends of the route. •  Installation conditions: 1.  Direct Buried:  Cables are installed direct in the ground, with suitable compacted backfill 2.  Buried Singleway Ducts:  Cables are installed with one cable per duct 3.  In Free Air:  Cables installed shielded from direct sunlight and with a minimum clearance from any vertical wall of 0.3xCable Dia. and 0.5xCable Dia. for single and three core cables respectively to ensure free air circulation. In order to select the appropriate cable for a given application, consideration must be given to the nature of the installation. It is not possible to provide a definitive guide to specifying the correct cable type for every situation, this choice must be made by the specifier and/or installer based upon a knowledge of the installation, applicable regulations and the characteristics of available cable designs. General guidance on the use of cable types included has been given above, but for further information and guidance it is recommended to make reference to the appropriate cable standard (e.g. AS/NZS 1429.1 or AS/NZS 4026). TEMPERATURE LIMITS In respect of thermal effects the temperature limit given for each cable type is the maximum temperature due to any combination of the heating effect of current in the conductors and ambient conditions. All insulation and sheathing materials become stiffer as their temperature is lowered and due regard has been taken of this factor in the guidance on minimum installation temperature. The materials used for these cables are compatible with temperatures of 90ºC for continuous operation and 250ºC for short circuit conditions of up to 5 seconds. The fault ratings for the conductors and the metallic screens are provided for a time period of 1 second. When other times (t) between 0.2 and 5 seconds are required, the appropriate rating may be obtained by multiplying the 1 second rating by the factor: 1/√t. The ratings for the screens are based upon the traditional adiabatic method, which provides a substantial safety margin when account is taken of the heat loss occurring in practice. The non-adiabatic method to IEC standards can be used according to  AS/NZS 1429.1 when agreed between the purchaser and supplier. This can provide substantial systems savings. Short circuit capacity that is related to the energy expended during a short circuit. It is equated to the mass x specified heat capacity x temperature change in the conductor. Two types of conditions have to be considered – symmetrical and earth short circuit currents. Various cable designs have different nominated maximum temperatures after short circuit, depending usually on the type of insulation and sheathing, and these temperatures should not be exceeded.  Economics important criteria related to cable economics are the initial system cost and annual cost of losses. Economics are generally considered on a present value calculation based on initial cost and discounted cost of losses. Data provided in the tables assists specifiers to estimate purchase and running costs. TECHNICAL INFORMATION

136 It is recommended that all cables described in this manual be installed in accordance with the Electricity supply authority Specifications or Regulations, the Wiring Rules and any other appropriate national regulations or legislation. In installing cables, care should be taken to ensure that the ambient and cable temperature has been above 0ºC for the previous 24 hours to avoid the risk of cracking of the oversheath. For groups of parallel single core circuits, the cables should be installed in trefoil touching formation as hereunder: i) Two conductors per phase. ii) Three conductors per phase. It is good practice when planning ducts or trenches to prescribe a bending radius of 3 metres for 11kV, 22kV and 33kV cables and 2 metres for cables below 11kV.  The following tables set out the recommended minimum bending radii for single or multicore polymeric insulated cables greater than 1.1/1.1kV: – Recommended duct sizes are given in the following table: – Where: D = Overall diameter of cable in mm. D = Diameter over Nylon jacket component in mm. The radius is related to the inner surface of the cable and not the axis. The recommendation for installation allows for the cable to be pulled under tension. Where cables are placed in position adjacent to joints and terminations and the bending is carefully controlled, the controlled bending radius as given in the data tables may be used. Sidewall Bearing Pressures need to be considered also. Using a pulling eye on the conductor: Copper       – 0.07 kN/mm 2  of conductor  Aluminium, Stranded   – 0.05 kN/mm 2  of conductor Using a pulling eye on the Steel Wire Armour: P = 0.005 D 2 Using a Stocking grip: P = 0.0035 D 2   Where:   P = Tension in kN   D = Cable diameter in mm Notes:1.  When considering the use of a stocking grip the  tension should not exceed the values given for a pulling eye on the conductor(s). 2.  Refer also to Maximum Sidewall Bearing Pressure. Using bond pulling: By this method the cable is tied at intervals to a steel hawser which is coiled onto a take-up winch in the normal manner. The hawser would be twice the length of the cable being pulled. In this way the pulling load on the cable is kept to a low value and risk of damage to the cable is minimised. CABLE INSTALLATION RECOMMENDED MINIMUM BENDING RADII DUCT SIZES MAXIMUM RECOMMENDED PULLING TENSIONS TECHNICAL INFORMATION  Cable Description During Installation Setting at Final Position or Location Nylon Jacketed 30D 20D HDPE Sheathed 25D 15D PVC Sheathed and LSOH Sheathed 18D 12D Nominal Internal Duct Diameter (mm) Cable Diameter (mm) 100 Up to 65 125 Over 65, up to 90 150 Over 90, up to 115 A A A A A B B C C B C C B B C

137 TECHNICAL INFORMATION  MAXIMUM SIDEWALL BEARING PRESSURE Another factor which can limit the maximum tension that a cable can withstand is the sidewall bearing pressure exerted on a cable in duct bends and elbows. The sidewall bearing pressure formula is expressed as: SWBP = [W 2  + (T/(0.0098 x R)) 2 ]     (equation 1)   as most of the time, [T/(0.0098 x R)] 2   W 2    equation 1 can therefore be simplified as follows: SWBP ≈ T/(0.0098 x R)       (equation 2)  From eqn. 2 = T = 0.0098 x R x SWBP   (equation 3)  From eqn. 2 = R = T / (0.0098 x SWBP)   (equation 4) Where:   SWBP = sidewall bearing pressure (kg/m)   W = weight of cable per unit length (kg/m)    T = cable pulling tension (kN)    R = radius of the bend or elbow (m) The recommended maximum SWBP for sheathed cables shall be 1450kg/m. Examples: 1. To find out the maximum pulling tension of a  12.7/22kV 240mm 2  copper single core PVC sheathed  cable based on its minimum recommended bending radius: First calculate the minimum recommended bending radius without considering SWBP: = 18 x Cable Diameter = 18 x 40.5mm = 729mm Then calculate the maximum pulling tensions:a) Maximum pulling tension for straight pull:  T = 0.07 kN/mm 2  x 240 mm 2     = 16.8 kN b) Maximum pulling tension when taking maximum  SWBP into consideration. From Equation 3: T   = 0.0098 x 0.729 x 1450   = 10.4 kN We have to select the lesser of the two pulling tensions, i.e. 10.4kN. In this example, the maximum SWBP dictates the maximum pulling tension. 2. To find out the minimum bending radius for the same cable if we do need a pulling tension of 16.8kN: From Equation 4: R  = 16.8 / (0.0098 x 1450)   = 1.2m JOINTS AND TERMINATIONS Whilst jointing and terminating of Medium Voltage Polymeric Cables is routine, care is needed to maintain clean working conditions and in ensuring that the insulation semiconducting screen is completely removed and properly connected at the stress control areas. Reference should be made to literature for suitable systems available from Prysmian. TESTS AFTER INSTALLATION High Voltage d.c. testing of primary insulation is not recommended and can be detrimental to the cable and accessories. AS/NZS 1429.1 describes an a.c. voltage test at power frequency that should be applied for 24 hours at the normal operating voltage of the system. A sheath integrity test (e.g. with a 1000 Volt minimum rated insulation resistance tester) may be applied between the outer-most metallic layer and the earth to identify post-installation damage, provided the metallic layer is isolated from earth at the joints, terminations, etc. SHORT CIRCUIT FORCES When single core cables are installed touching, special attention should be given to cleating and strapping arrangements to contain the repulsive forces under short circuit conditions. Longitudinal thrust and tensions in cable conductors may be considerable and may cause buckling of conductors and other damage in a joint or termination. When cables are installed, provision should be made to accommodate the resulting longitudinal forces on terminations and joints. Sharp bends and fixings at a bend should be avoided. PREVENTION OF MOISTURE INGRESS Care should be exercised during installation to avoid any damage to cable coverings. This is important in wet or other aggressive environments. The protective cap should not be removed from the ends of the cable until immediately prior to termination or jointing. When the caps have been removed the unprotected ends of the cable should not be exposed to moisture. The possibility of damage to moisture seals during handling and installation or during storage of the cable should be considered and where such damage may have occurred, the seals should be inspected and remade if necessary.

138 CABLE DESIGN SERVICE Prysmian offer their customers a full cable design service, either to give advice on the selection of the most appropriate cable from this technical manual for a particular application or to design a specific cable for any particular installation condition. This service is backed by an experienced team of design engineers working under a Quality Management System approved to AS/NZS ISO 9001. The Prysmian commitment to new product introduction and development ensures effective and reliable designs are developed and assessed in our own research laboratories. Prysmian is also able to offer aerial cables including OPGW, water blocked designs and high voltage cables to 400kV. Cable termination and identification systems are also available as part of the Prysmian systems approach. QUALITY ASSURANCE All Prysmian MV power cables are manufactured under the Prysmian Quality Management System. This system has received certification by Quality Assurance Services that it meets the requirements of AS/NZS ISO 9001. TECHNICAL INFORMATION

139 Technical Information - Ratings Information TECHNICAL INFORMATION  1. Cables buried direct in the ground:  Variation in ground temperature Ground Temperature °C 10 15 20 25 30 35 40 Rating Factor 1.11 1.07 1.03 1.00 0.97 0.93 0.89 Group Rating Factors for circuits of three single core cables, in Trefoil touching, horizontal formation Circuit Spacing – Metres Voltage Range of Cables No. Of Circuits Touching 0.15 0.30 0.45 0.60 From 1.9/3.3kV to 12.7/22kV 2 0.78 0.81 0.85 0.88 0.90 3 0.66 0.71 0.76 0.80 0.83 4 0.60 0.65 0.72 0.76 0.80 19/33kV 2 0.79 0.81 0.85 0.88 0.90 3 0.67 0.71 0.76 0.80 0.83 4 0.62 0.65 0.72 0.76 0.80 Group Rating Factors for three core cables, in horizontal formation Circuit Spacing – Metres Voltage Range of Cables No. Of Circuits in Group Touching 0.15 0.30 0.45 0.60 From 1.9/3.3kV to 12.7/22kV 2 0.80 0.85 0.89 0.90 0.92 3 0.69 0.75 0.80 0.84 0.86 4 0.63 0.70 0.77 0.80 0.84 19/33kV 2 0.80 0.83 0.87 0.89 0.91 3 0.70 0.73 0.78 0.82 0.85 4 0.64 0.68 0.74 0.78 0.82 Variation in depth of laying Depth of Laying m Up to 300 mm 2 Above 300 mm 2 0.8 1 1 1 0.98 0.97 1.25 0.96 0.95 1.5 0.95 0.94 1.75 0.94 0.92 2 0.92 0.90 2.5 0.91 0.89 3.0 or more 0.90 0.88 RATING FACTORS – 1.9/3.3KV TO 19/33KV, SINGLE AND THREE CORE CABLES, ARMOURED OR UNARMOURED Variation in thermal resistivity of soil Values of ‘g’ °C m/W Nominal Area Of Conductor mm 2 0.8 0.9 1.0 1.2 1.5 2.0 2.5 3.0 Single Core Cables Rating Factors Up to 150 1.16 1.11 1.07 1.00 0.91 0.81 0.73 0.67 From 185 - 400 1.17 1.12 1.07 1.00 0.90 0.80 0.72 0.66 Above 400 1.18 1.13 1.08 1.00 0.90 0.79 0.71 0.65 Three Core Cables Up to 16 1.09 1.06 1.04 1.00 0.95 0.87 0.79 0.74 From 25 - 150 1.14 1.10 1.07 1.00 0.93 0.84 0.76 0.70 From 185 - 400 1.16 1.11 1.07 1.00 0.92 0.82 0.74 0.68 Measured to centre of cable or trefoil group of cables. These spacings may not be possible for some of the larger diameter cables. These spacings may not be possible for some of the larger diameter cables. spacing spacing

140 2. Cables in singleway ducts, buried direct in the ground:  Variation in ground temperature Ground Temperature °C 10 15 20 25 30 35 40 Rating Factor 1.11 1.07 1.03 1.00 0.97 0.93 0.89 Group Rating Factors for single core cables in single way ducts, laid in Trefoil touching, horizontal formation Circuit Spacing – Metres Voltage Range of Cables No. Of Circuits Touching 0.45 0.60 From 1.9/3.3kV to 12.7/22kV 2 0.85 0.88 0.90 3 0.75 0.80 0.83 4 0.70 0.76 0.80 19/33kV 2 0.85 0.88 0.90 3 0.76 0.80 0.83 4 0.71 0.76 0.80 Group Rating Factors for three core cables in singleway ducts, in horizontal formation Circuit Spacing – Metres Voltage Range of Cables No. Of Ducts   in Group Touching 0.30 0.45 0.60 From 1.9/3.3kV to 12.7/22kV 2 0.88 0.91 0.93 0.90 3 0.80 0.84 0.87 0.84 4 0.75 0.81 0.84 0.80 19/33kV 2 0.87 0.89 0.92 0.93 3 0.78 0.82 0.85 0.87 4 0.73 0.78 0.82 0.85 Variation in depth of laying Rating Factors Depth of Laying m Single Core Multicore 0.8 1 1 1 0.98 0.99 1.25 0.95 0.97 1.5 0.93 0.96 1.75 0.92 0.95 2 0.90 0.94 2.5 0.89 0.93 3.0 or more 0.88 0.92 Variation in thermal resistivity of soil Values of ‘g’ °C m/W Nominal Area Of Conductor mm 2 0.8 0.9 1.0 1.2 1.5 2.0 2.5 3.0 Single Core Cables Rating Factors Up to 150 1.10 1.07 1.05 1.00 0.94 0.87 0.81 0.75 From 185 - 400 1.11 1.08 1.06 1.00 0.94 0.86 0.79 0.73 Above 400 1.13 1.09 1.06 1.00 0.93 0.84 0.77 0.70 Three Core Cables Up to 16 1.05 1.04 1.03 1.00 0.97 0.92 0.87 0.83 From 25 - 150 1.07 1.05 1.03 1.00 0.96 0.90 0.85 0.78 From 185 - 400 1.09 1.06 1.04 1.00 0.95 0.87 0.82 0.76 Measured to centre of cable or trefoil group of cables. These spacings may not be possible for some of the larger diameter cables. These spacings may not be possible for some of the larger diameter cables. spacing spacing TECHNICAL INFORMATION

141 Grouping of cables in air:Derating is not necessary if the following minimum clearance between adjacent circuits can be maintained    1  The horizontal clearance is not less than twice the diameter of an individual cable.          2  The vertical clearance is not less than four times the diameter of an individual cable.         3  Where the number of circuits is more than three, they are installed in a horizontal plane.    AS 1018   Partial discharge measurements AS/NZS 1026   Electric cables – Impregnated paper insulated for working voltages up to and including 19/33 (36)kV AS/NZS 1125   Conductors in insulated electric cables and flexible cords AS/NZS 1429.1   Electric cables – Polymeric insulated Part 1: electric cables for working voltages 1.9/3.3 (3.6)kV    up to and including 19/33 (36)kV AS/NZS 1660   Test methods for electric cables, cords and conductors AS 1931   High-voltage testing techniques AS/NZS 2857   Timber drums for insulated electric cables and bare conductors AS/NZS 2893   Electric cables – lead and lead alloy sheaths – composition AS/NZS 3008   Electrical installations – selection of cables AS/NZS 3808   Insulating and sheathing materials for electric cables AS/NZS 3863   Galvanized mild steel wire for armouring cables AS 3983   Metal drums for insulated electric cables and bare conductors AS/NZS 4026   Electric cables – for underground residential distribution systems IEC 754-2  Test on gases evolved during combustion of electric cables, Part 2: Determination of degree of acidity     of gases evolved during the combustion of materials taken from electric cables by measuring pH     and conductivity IEC 60287  Electric cables – calculation of the current rating IEC 60332-1  Tests on electric and optical fibre cables under fire conditions, Part 1: Test for vertical flame     propagation for a single insulated wire or cable IEC 60332-3  Tests on electric cables under fire conditions, Part 3: Test for vertical flame spread of vertically-mounted     bunched wires or cables  IEC 60502-2  Power cables with extruded insulation and their accessories for rated voltages from 1kV (Um = 1.2kV)     up to 30kV (Um = 36kV) - Part 2: Cables for rated voltages from 6kV (Um = 7.2kV) up to 30kV (Um = 36kV) IEC 60949  Calculation of thermally permissible short-circuit currents, taking into account non-adiabatic       heating effects IEC 60986  Short-circuit temperature limits of electric cables with a rated voltages from 6kV (Um = 7.2kV)     up to 30kV (Um = 36kV) IEC 61034  Measurement of smoke density of cables burning under defined conditions 3. Cables installed in free air:  Variation in ambient air temperature Ambient Air Temperature °C 15 20 25 30 35 40 45 50 Rating Factor 1.26 1.20 1.15 1.10 1.05 1.00 0.94 0.88 TECHNICAL INFORMATION  General Information

142 Notes

143 Notes
