4Seasons is an integrated system of information, technical specifications and luminaires designed specifically for parks, gardens and greenspaces. 4Seasons was created with the idea of suggesting different options for lighting engineering projects that make it possible to control and utilize shadows, in addition to respecting the natural areas.  4Seasons is not only a technical solution for lighting, it needs an emotional understanding and appreciation of the natural surrounding.

Artificially illuminating a natural object in the best way is to highlight its shape and unique characteristics, by evaluating its dimensions and possible growth and visualize its change through the seasons Successful lighting can be achieved if the equilibrium between light and shadow is re-created. 196

The wrong lighting eliminates  natural contrast  and diminishes the beauty of nature.   Light and shadows are complementary  elements in the natural environment,  only when they are combined in the  natural or artificially lit environment can  we appreciate the full richness of nature. PRISMA ARCHITECTURAL 197

Colour adds to the combination of light and dark  to interpret a season or emphasize a particular element:  nature becomes the scenography that surrounds life.  198 P R IV A T E V IL L A - T A N G S H A N  ( P E O P L E ’S R E P U B L IC  O F  C H IN A ) 4 SEASONS - GARDEN SYSTEM

The range of 4Seasons luminaires includes several light emission alternatives, with infinite possibilities for changing colours and beam intensity. 199

Natural elements and coloured lighting can produce  surprising, changing scenes.  The change can follow  and emphasize the modifications in seasonal conditions,  or create a quick, continuous visual effect, like one that  could be used for a festive evening. Seasonal variations influence the appearance of parks  and gardens. Each season coincides with a specific phase  of the life cycle of the different trees, bushes and lawns that  change colours and shapes all year long.   In this way, scenographic content becomes  an integral part of the lighting engineering project. 200 4 SEASONS - GARDEN SYSTEM

Thanks to the 4Seasons luminaires, nocturnal lighting can be planned to change the dominant colour scheme and adapt to the different seasons. 201

Luminaires from the 4Seasons system can be mounted together or stacked as desired.  Contact the Technical Service for customization requests. 202

BOX is suitable to light trees and bushes with different heights and dimensions and is offered with a wide range of light sources. The light aperture is 90º from two open sides and has the option to blank one of the openings.  CUT is also suitable to light trees and bushes with different heights and dimensions, but has a greater flexibility in application, which is distinguished by its inclined cut. The light aperture is 90º from three open sides and has the option to blank one or two of the openings. DECO is designed for the lighting of paths, patios and grazing light on ground surfaces providing decorative illumination. The light distribution can be alte-red by closing one or more of the five open sides.  All 4Seasons fittings are designed to use specific screens for an application to alter the light distribution and create shadows. They have a wide variety of light sources with options for LED colour changing. Technical descriptions, specifics on light sources, dra-wings of the screens and all the codes can be found from page 216 on. 4SEASONS SYSTEM LUMINAIRES NEW ANTI-GLARE VERSIONS 203 PRISMA ARCHITECTURAL

Here below, you’ll find a few simple guidelines that  are useful for those that want to learn more about  lighting natural elements, even if you have very little  experience.  1   Define the type of shape of the natural element  you want to spotlight 2   Define the position of the points of light necessary  for good quality lighting 3   Define the graphic personality of the natural  element and choose the most suitable screens 1 - TYPES OF SHAPES The shape and size of the natural element are determined to define the power and width of the light beam necessary for the best lighting characte-ristics.  Each shape has different requirements, both in terms of direction and in terms of the number of luminaires necessary to illumine the whole surface of the tree. 2 - POSITION OF LIGHTS It is well known that a tree’s natural develop-ment is regulated by the golden ratio, which is followed even in the fields of art and architec-ture as a perfect and harmonious proportional relationship.This same pattern also determines the optimal position of the points of light with respect to  LIGHTING TECHNIQUE 204 Picea Abies Chamaecyparis Lawsoniana Pseudotsuga Menziesii Sequoia Sempervirens X Cupressocyparis Leylandii Sequoiadendron Giganteum Cryptomeria Japonica Thuja Plicata Acer Pseudo Platanus Cedrus Deodara Carpinus Betulus Fagus Sylvatica  Salix x Chrysocoma Alnus Pendula Eucalyptus Camadulensis Fagus Pendula 4 SEASONS - GARDEN SYSTEM

the size of the plant and the main point of view.  In fact, the points of light should always be placed along the path in a spiral, which  develops according to the golden ratio.  To avoid glare, the light beam must never be pointed towards the point of observation. MAIN POINT  OF OBSERVATION OPERATIVE AREA AREA FREE  FROM LUMINAIRES 205 Phoenix Dactilifera Cocos Nucifera Sobal Palmetto Jubae Spectabilis Acer Campestre Olea Europaea Delonix Regia Fraxinus Excelsior Quercus Suber Carya Ovata Albizzia Julibrissin Ceiba Pentandra Celtis Australis Quercus Petraea Broussonetia Papyrifera Rhizophora Mangle Sambucus Nigra Cornus Florida Arbutus Unedu Acacia Baileyana Populus X Gileadensis Platanus Occidentalis Ailanthus Altissima Talia Cordata 2 3 4 5 6 7 8 9 10 11 13 14 12 2 3 4 5 6 7 8 10 11 12 13 14 9 2 3 4 5 6 7 8 9 10 12 13 14 11 PRISMA ARCHITECTURAL

Trees with similar shapes can have different graphic personalities: dynamic, static, mobile or other.  The screens for 4Seasons luminaires (Kit Shadow) are designed according to gra-phic personality to obtain the best light and shadow effects for the specific tree.  On the following sheets, there are a few para-meters and typical personalities. DYNAMIC CONSTANT MOBILE CALM OUTGOING 3 - THE GRAPHIC PERSONALITY AND THE USE OF SCREENS Besides the shape and size, a natural element also has a graphic personality that can be emphasized with shadowing. Screens of the 4Seasons luminaires create a wide range of effects by combining light and dark, which transforms the lighting layout to tailor it to the personality of the natural element. 4Seasons has several screens designed to bring out some typical personalities.  However, the screens can be used as desired, to discover creative new effects and generate new sensations.  206 4 SEASONS - GARDEN SYSTEM

CRATAEGUS MOLLIS page  208 PODOCARPUS page  209 HIPPOCASTANUM   page 210 COCOS NUCIFERA page  211 CARPINUS BETULUS page  212 PICEA PUNGENS page  213 HEDERA HELIX page  214 SALIX TRIANDRA page  215 The technical data sheets contain  solutions for optimal lighting of the  main types of tree shapes, and for some  natural elements found frequently in gardens.  For each natural element, the sheet suggests the  best type of luminaire with the visualization of  the most correct lighting arrangement and a few  possible variations, in relation to the seasons or the  screens.  There are obviously an infinite number of variables  in the lighting project of a greenspace.  This range of basic solutions was not  intended to be all inclusive. In the pages following  the technical data sheets,  there are a few examples that allow us  to explore personalized solutions. Each icon has four tiny coloured circles near it that very concisely represent the variations of the natural element in every season.  SPRING  SUMMER AUTUMN WINTER Technical data and product codes of lumi- naires and screens are on page 220. TECHNICAL DATA SHEETS 207 PRISMA ARCHITECTURAL

Trees with similar shapes: Quercus PubescensRobinia PseudoacaciaAlnus Glutinosa SOLID PERSONALITY Infinite lighting scenes are possible by projecting chromatic variations timed with the changing seasons. Every night brings a different scene in same sophisticated atmosphere. Consumes max. 90W 208 SOLID PERSONALITY CRATAEGUS MOLLIS 2 m 2 m 2 m 2 2 3 4 5 6 7 8 9 10 11 3 4 5 6 7 8 9 10 11 Dots Stones Blind CUT  + Color 10 + 3 Dots C CUT + Color 10 + 3 Dots C BOX + Color 30 + 1 Stones + 1 Blind 4 SEASONS - GARDEN SYSTEM

Trees with similar shapes: Platanus OccidentalisAilanthus AltissimaTalia Cordata ORIENTAL PERSONALITY When talking about leaves, non-deciduous is certainly not monotonous. The scenes chan-ge with the wind and the glinting light on the leaves, if two different colour temperatures are chosen for the illumination. A dance of white light. Consumes max. 12W 209 2 m O PODOCARPUS Dots Stones Blind 2 2 3 4 5 6 7 8 9 10 11 3 4 5 6 7 8 9 10 11 CUT  + Mini W30 + 3 Stones C BOX + Mini DL30 + 1 Dots + 1 Blind PRISMA ARCHITECTURAL

Trees with similar shapes: Cedrus DeodaraCarpinus BetulusFagus Sylvatica SOLID PERSONALITY Huge shapes are an advantage only when the light adds a delicate touch.  Subtle lighting accents should always be pre-ferred for large forms. Consumes max. 65W 210 HIPPOCASTANUM 2 m 2 m 2 m SOLID PERSONALITY 2 2 3 4 5 6 7 8 9 10 3 4 5 6 7 8 9 10 11 Dots Stones BOX  + Park 40 + 2 Stones BOX + Color 30 + 2 Dots 4 SEASONS - GARDEN SYSTEM

Trees with similar shapes: Phoenix DactiliferaSobal PalmettoJubae Spectabilis ORIENTAL PERSONALITY When the tree’s personality is very strong, lighting becomes a real challenge. Interpretation through lighting is a vital choice in developing nocturnal settings. Consumes max. 40W 211 COCOS NUCIFERA 2 m 2 m ORIENTAL PERSONALITY 2 2 3 4 5 6 7 8 9 10 11 3 4 5 6 7 8 9 10 11 2 2 3 4 5 6 7 8 3 4 5 6 7 8 Dots Stones Blind BOX  + Garden 12 + 1 Dots + 1 Blind BOX + Garden 12 + 1 Stones + 1 Blind BOX + Garden 40 + 1 Stones + 1 Blind PRISMA ARCHITECTURAL

Trees with similar shapes: Fraxinus ExcelsiorUlmus MinorPinus Nigra MOBILE PERSONALITY Light is able to capture the elegance of this majestic tree. Warm lighting plays up the colours of the leaves during the fall. Consumes max. 32W 212 CARPINUS BETULUS 2 m 2 m 2 m MOBILE PERSONALITY Crack Scratch 2 2 3 4 5 6 7 8 9 10 11 3 4 5 6 7 8 9 10 11 BOX  + Garden 10 + 2 Scratch CUT + Double W30 + 3 Crack C 4 SEASONS - GARDEN SYSTEM

Trees with similar shapes: Chamaecyparis LawsonianaPseudotsuga MenziesiiSequoia Sempervirens DYNAMIC PERSONALITY Composure can be emphasized by illumination only if the light finds a way to play on the branches in flickering, silvery effects.  Consumes max. 70W 213 PICEA PUNGENS 2 m 2 m 2 2 3 4 5 6 7 8 9 10 11 3 4 5 6 7 8 9 10 11 2 2 3 4 5 6 7 8 3 4 5 6 7 8 Flames Waves CUT  + Park 10 + 3 Flames C CUT + Park 40 + 3 Flames C CUT  + Garden 10 + 3 Flames C CUT + Garden 10 + 3 Waves C PRISMA ARCHITECTURAL

Trees with similar shapes: Lonicera RampicanteJasminum NudiflorumHydrangea Petiolaris The border, the edge, the perimeter:  if highlighted with colour, any climbing plant is no longer just a boundary. It becomes a poetic statement surrounding the garden. Consumes max. 15W SERPENTINE PERSONALITY 214 HEDERA HELIX SE 2 2 3 4 5 6 7 8 3 4 5 6 7 8 2 m 2 m 2 m Blind More Lines BOX  + Mini C30 + 1 More Lines + 1 Blind BOX + Mini C30 + 1 More Lines + 1 Blind 4 SEASONS - GARDEN SYSTEM

Trees with similar shapes: Osmanthus FragransLaburnum AnagyroidesSorbus Hybrida The attractiveness of this tree arises from its upward direction: if enhanced with lively colours, it transforms the garden into a magical place. Consumes max. 30W CALM PERSONALITY 215 SALIX TRIANDRA 2 m 2 m 2 m 2 2 3 4 5 6 7 8 3 4 5 6 7 8 Crack CUT + Color 30 + 3 Crack C PRISMA ARCHITECTURAL

PARK Suitable for situations in which the distance from the light source to the spotlighted element is greater than 5 metres. Controlled light diffusion, with beam of 10° or 40°. Adjustable rotating light source. MARK Designed for illuminating pedestrian walkways, bushes and hedges. Non adjustable light source. COLOR Suitable for situations in which the distance from the light source to the spotlighted element is greater than 5 metres. Light colour can be programmed and modified. Controlled light diffusion, with beam of 10°, 30° or 45°.Adjustable rotating light source.  GARDEN Suitable for situations in which the dis-tance from the light source to the spot-lighted element is less than 5 metres.Controlled light diffusion, with beam of 10° or 40°. Adjustable rotating light source.  DOUBLE Suitable for situations in which the distance from the light source to the spotlighted element is less than 3 metres. White light that can be either cool (DL) or warm (W). Light colour can be pro-grammed and modified (C).  Controlled light diffusion, with beam of 30°. Two independently adjustable rotating light sources. MINI Suitable for situations in which the distance from the light source to the spotlighted element is less than 3 metres. White light that can be either cool (DL) or warm (W). Light colour can be programmed and modified (C).  Controlled light diffusion, with beam of 30°. Adjustable rotating light source.  THE LIGHT SOURCES The range of light sources available for  the 4Seasons luminaires makes it possible  to satisfy any lighting requirement.  These brief descriptions define the characteristi- cs of each single source.  216 Park 10 Park 40 Mark 61 Color 10 Color 45 Color 30 Mini W180 Mini DL180 Mini W30 Mini DL30 Mini C180 Mini C30 Garden 40 Garden 10 Double W180 Double DL180 Double W30 Double DL30 Double C180 Double C30 4 SEASONS - GARDEN SYSTEM

217

218

DYNAMIC PERSONALITY CONSTANT PERSONALITY MOBILE PERSONALITY CALM PERSONALITY OUTGOING PERSONALITY RESERVED PERSONALITY ORIENTAL PERSONALITY SOLID PERSONALITY SERPENTINE PERSONALITY ARCHITECTURAL PERSONALITY FUTURE PERSONALITY THE SCREENS This table suggests the most suitable screens to draw attention to each graphic personality.  The Dots, Waves, Scales, Stones and Crack screens are available in anti-glare versions. The reduced hole surface avoids unwanted glare effects in particular conditions of use. 219 Scales Flames Waves Scratch Lines More lines Stones Scratch Crack Waves Scratch Crack More lines Crack Dots Scales Stones Leaves Dots Mini dots Stones Dots Stones Dots Scratch Waves More lines Dots Mini dots Waves More lines Crack Stones Waves Crack Crack Anti Glare PRISMA ARCHITECTURAL

Luminaires To order a complete product it is necessary to choose a luminaire, a light source and the number of screens necessary for each lumi-naire: 5 for Deco, 2 for Box and 3 for Cut. One or more screens can be blind. An anti-vandalism grate, Grill, can be mounted in place of the screens. The code to order a complete product is formed by indicating the codes for each element selected in sequence. The order in which the screens are listed in the order code determines their position, using the order code method described beside. The luminaires, screens and accessories of the 4Seasons systems are made with high quality materials with high resistance to wear and tear and to corrosion (aluminium, glass, stainless steel). SUMMARY TABLE OF AVAILABLE LIGHT SOURCES Luminaires DECO BOX  CUT 5 open sides   2 open sides   3 open sides Lig h t sou rc e s description colour  reference  code 220 Mark 61 • Park 10 • • Park 40 • • Garden 10 • • Garden 40 • • Color 10 • • Color 30 • • Color 45 • • Double W180 • • Double W30 • • Double DL180 • • Double DL30 • • Double C180 • • Double C30 • • Mini W180 • • Mini W30 • • Mini DL180 • • Mini DL30 • • Mini C180 • • Mini C30 • • DECO, BOX, CUT  Deco RB1  318001   DECO Box RB1  318002   BOX Cut RB1  318003   CUT GR GRC BL BLC CUT BOX DECO 4 SEASONS - GARDEN SYSTEM

Light sources Screens Accessories The Grill accessory is a protective, anti-vandalism grate that can be mounted in place of a screen to protect the underlying glass.  The Blind accessory is a blind screen that blocks the light beam.  The USB interface for the DMX card is a module that contains a software interface between the PC and the DMX communication protocol, used in the control system of the lights.  The IR multi-function remote makes it possible to manage and change the light emission of the light sources Color, Double C and Mini C by sending signals to a infra-red sensor.  The IR sensor receives the commands and sends them to the light source management driver. description   class  IP  reference  code description colour  reference  code description colour  code Screens and accessories with the C suffix are rectangular in shape and may be mounted only on the Cut luminaires.The screens with a G suffix can be mounted only on Deco luminaires with Mark 61 light sources. Anti glare screens: the reduced hole surface avoids unwanted glare effects in particular conditions of use. Ground plate/Fixing rods    318036 USB interface for DMX card    318037 IR multi-function remote control unit    318038 IR sensor    318039 IP67 driver kit with voltage 24V DC 70W    310309 Examples of compositions of order codes: DECO - COMPLETE UNIT Luminaire + Light source + 5 screens KIT4S DECO MK6118    GR  GR  GR  GR  GR KIT4S DECO MK6135    BL   GR  GR  GR  GR    BOX - COMPLETE UNIT Luminaire + Light source + 2 screens KIT4S BOX DDL180    MDT  BL   KIT4S BOX GN40    GR     GR   CUT - COMPLETE UNIT Luminaire + Light source + 3 screens KIT4S CUT DDL30    DTC  DTC  DTC KIT4S CUT PK10    SCC  SCC  BLC 221 Mark 61  Gx24q-2  18w  I  66  308021  MK6118 Mark 61  G12  35w  I  66  308024  MK6135 Mark 61  E27  60w  I  66  308025  MK6160 Park 10  GX8,5  35w  I  66  308002  PK10 Park 40  GX8,5  35w  I  66  308003  PK40 Garden 10  GX10  20w  I  66  308004  GN10 Garden 40  GX10  20w  I  66  308005  GN40 Color 10  LED RGB 30w  III  66  308006  CO10 Color 30  LED RGB 30w III  66  308007  CO30 Color 45  LED RGB 30w III  66  308008  CO45 Double W180  2 LED 5,3w III  66  308015  DW180 Double W30  2 LED 5,3w III  66  308016  DW30 Double DL180  2 LED 5,3w III  66  308017  DDL180 Double DL30  2 LED 5,3w III  66  308018  DDL30 Double C180  LED RGB 6,8w III  66  308019  DC180 Double C30  LED RGB 6,8w III  66  308020  DC30 Mini W180  LED 5,3w  III  66  308009  MW180 Mini W30  LED 5,3w  III  66  308010  MW30 Mini DL180  LED 5,3w  III  66  308011  MDL180 Mini DL30  LED 5,3w  III  66  308012  MDL30 Mini C180  LED RGB 6,8w III  66  308013  MC180 Mini C30  LED RGB 6,8w III  66  308014  MC30 Dots     RB1  318010  DT Mini dots      RB1  318012  MDT Waves     RB1  318014  WA Scales     RB1  318016  SC Lines     RB1  318018  LI Stones     RB1  318020  ST Scratch     RB1  318022  SCH Leaves     RB1  318024  LE Flames     RB1  318026  FL Crack     RB1  318028  CR More lines      RB1  318030  ML Grill     RB1  318032  GR Blind     RB1  318034  BL Dots C      RB1  318011  DTC Mini dots C      RB1  318013  MDTC Waves C      RB1  318015  WAC Scales C      RB1  318017  SCC Lines C      RB1  318019  LIC Stones C      RB1  318021  STC Scratch C      RB1  318023  SCHC Leaves C      RB1  318025  LEC Flames C      RB1  318027  FLC Crack C      RB1  318029  CRC More lines C      RB1  318031  MLC Grill C      RB1  318033  GRC Blind C      RB1  318035  BLC Dots Anti glare      RB1  318044  DTG Waves Anti glare      RB1  318043  WAG Scales Anti glare      RB1  318045  SCG Stones Anti glare      RB1  318046  STG Crack Anti glare      RB1  318047  CRG A B C A B A B C D E     A    B    C    D    E     A       B         A      B     C    318037 318038 318039 318036 PRISMA ARCHITECTURAL

222

For more information on the 4seasons system, visit: http://www.architectural-pil.com/4seasons. In addition to many technical charts and animations, you will also find an interactive application that simulates a great variety of light effects that may be obtained with the screens of the 4seasons system. 223
