Prisma Architectural New Range Extensions 2013
PRISMA ARCHITECTURAL 1 2013 NEW PRODUCTS RANGE EXTENSIONS
PRISMA ARCHITECTURAL 2 TARGA 4 ERA 8 ALU TECH 12 SPILLO 16 New Products 2013 Wall Mount Projector Targa is a large outdoor wall-mounted luminaire designed for impressive lighting effects on facades and arcades. The choice of various emissions (wall washer, asymmetrical, concentrated) in various up/down combinations, and the available LED or metal halide light versions make Targa a highly versatile solution. With an additional frame, the painted aluminium front of the luminaire can be coated with plaster to achieve the same finish as the wall on which it is instal-led, thus reducing the visual impact of the luminaire and enhancing the light effects.Targa is ideal for outdoor architectural lighting, for public buildings, hotels and business places. Bollard ERA is a unibody unique and strong characterized design bollard made from sand cast alumi-num, usable for general and accent outdoor lighting. The light distribution allows to bring the light exactly to where it’s needed. The organic Design of ERA entirely integrates the advantages of LED. Its raw/rough character adapts well to nature’s variety of surfaces. Wall Recessed Luminaire Complete series of wall-recessed luminaires for outdoor and indoor applications entirely conceived for led sources. This complete range of luminaires goes to complete the Alu family already declined in wall inground an bollard mounting versions.Its valuable materials let this series become a good option expecially for high-end projects. Pole Top Luminaire Complete series of pole-top luminaires for outdoor applications entirely conceived for LED lighting sources. High light performances are granted thanks to the lastest LED technology available implemen-ted by the unique design of the lenses.Series of contemporary aesthetic designed energy efficient fittings completely homologate for the lastest strictes norm regarding zero upward light pollution.Spillo Mini and Spillo are innovative options for city beautification contexts such as pubblic and private parks, gardens, pathways, pedestrain and cycling areas, commercial complexes and so on.
PRISMA ARCHITECTURAL 3 SUPERBLIZ LED 22 Wall and Ceiling Luminaire Wall and ceiling mounted LED luminaire for indoor and outdoor applications. Compact design and simple clean lines combined with high quality materials and finishes makes SUPERBLIZ LED suitable for all architectural contexts.Main topics of this items are the single/double swich on and the emergency version 3 hours stand-alone packages. Range Extensions 2013
PRISMA ARCHITECTURAL 4 TARGA PRISMA ARCHITECTURAL design R. Fiorato, F. Pagliarini
PRISMA ARCHITECTURAL 5 302954 302950 302948 302946 302952 C o 140° C 90 60° C o 140° C 90 60° C o 140° C 90 60° C o 140° C 90 60° C 0°- C 180° cd/Klm 90° 105° 105° 120° 120° 90° 0° 30° 15° 45° 45° 60° 60° 75° 75° 180° 90 180 270 360 C 90° cd/Klm 90° 105° 105° 120° 120° 90° 0° 30° 15° 45° 45° 60° 60° 75° 75° 180° 90 180 270 360 C 0°- C 180° C 90° cd/Klm 90° 105° 105° 120° 120° 90° 0° 30° 15° 45° 45° 60° 60° 75° 75° 180° 90 180 270 360 C 0°- C 180° C 90° - C 270° cd/Klm 90° 105° 105° 120° 120° 90° 0° 30° 15° 45° 45° 60° 60° 75° 75° 180° 90 180 270 360 C 0°- C 180° C 90° - C 270° 302955 GR3 C o 120° C 90 30° C o 120° C 90 30° C o 120° C 90 30° C o 140° C 90 60° 0 1 2 3 4 5 6 7 9 8 10 1 2 3 4 5 6 H 4 m 9 8 8 7 7 6 6 5 5 4 4 3 3 2 2 1 1 lux meters Ground isolux with 302955 0 1 2 3 4 5 6 7 9 8 10 1 2 3 4 5 6 H 4 m 9 8 8 7 7 6 6 5 5 4 4 3 3 2 2 1 1 lux meters Ground isolux with 302955 A ++ A ++ A ++ A ++ A + A + A + A + A A A A With 3 power led in Natural White 4000 K Total Power Consumption (Fitting+Driver) 27 W Real lumen output 1587 lm Led Energy class With 2 x 3 power led in Natural White 4000 K Total Power Consumption (Fitting+Driver) 2 x 27 W Real lumen output 2 x 1587 lmLed Energy class For Nominal Power Consumption 35W Metal Halide GU6,5 Nominal Lumen Output 3300lm For Nominal Power Consumption 2 x 35W Metal Halide GU6,5Nominal Lumen Output 2 x 3300lm With 2 x 3 power led in Warm White 3000 K Total Power Consumption (Fitting+Driver) 2 x 27 W Real lumen output 2 x 1270 lm Led Energy class Die-casted copper free AL EN 44100 Body and Cover Lenses designed by Performance in Lighting® Metal Halide Versions for GU6.5 lamps with asymmetrical anodized and polished AL 99,8% pure reflector Screws A2 Inox 316 - Annealed Silicon GasketsLED Driver Included Luminaire supplied with LED circuit IP 66IK06 1J xxxCLASS IRa 80 Estimated lifetime 50.000 hours (accordingly to LM-80) With 3 power led in Warm White 3000 K Total Power Consumption (Fitting+Driver) 27 W Real lumen output 1270 lm Led Energy class Painting Finish: TARGA UP or DOWN Asymmetrical Effect CODE TARGA UP + DOWN Asymmetrical Effect
PRISMA ARCHITECTURAL 6 302951 310402 302947 302953 cd/Klm 90° 105° 105° 120° 120° 90° 0° 30° 15° 45° 45° 60° 60° 75° 75° 180° 90 180 270 360 cd/Klm 90° 105° 105° 120° 120° 90° 0° 30° 15° 45° 45° 60° 60° 75° 75° 180° 90 180 270 360 C 0°- C 180° C 90° - C 270° C 0°- C 180° C 90° - C 270° C 0°- C 180° C 90° - C 270° C o 15° C 90 5° C o 10° C 90 3° C o 140° C 90 60° C o 120° C 90 30° 0 1 2 3 4 5 6 7 9 8 10 1 2 3 4 5 6 H 4 m 9 8 8 7 7 6 6 5 5 4 4 3 3 2 2 1 1 lux meters Ground isolux with 302955 A ++ A ++ A + A + A A Dual double switching as standard for all the up + down versions. Versions available on request:2x 26W Fluorescent Lamps GX24Q3 2x 35W Metal Halide E27 With 3 +1 power led in Natural White 4000K Total Power Consumption (Fitting+Driver) 27 W + 9 W Real lumen output 1587 lm + 529 lmLed Energy class: On Request Plaster Accessory For Nominal Power Consumption 2 x 35W Metal Halide GU6,5Nominal Lumen Output 2 x 3300lm With 3 +1 power led in Warm White 3000K Total Power Consumption (Fitting+Driver) 27 W + 9 W Real lumen output 1270 lm + 424 lm Led Energy class: Take a look to the dedicated brochure downloadable from www.performanceinlighting.com Watch plaster mounting installation video on PerformanceINLighting channel on YouTube Accessories: Thanks to the accessory for plaster application the front cover of the fitting can be personalized obtaining a mimetic effect where the fitting frontally disappear in the space TARGA UP Narrow + DOWN Asymmetrical Effect CODE
PRISMA ARCHITECTURAL 7
PRISMA ARCHITECTURAL 8 ERA design by REGENT Peter Boss
PRISMA ARCHITECTURAL 9 RB1 WH1 300099 180° C 0°- C 180° C 90° C 270° cd/Klm 90° 105° 105° 120° 120° 90° 0° 30° 15° 45° 45° 60° 60° 75° 75° 180° 50 100 150 200 ERA -4 -3 -2 -1 0 1 2 4 3 -1 0 1 2 3 4 H 1,2 m lux meters Ground isolux with 300099 1 1 1 1 1 1 2 2 5 5 5 15 15 30 30 50 50 5 100 100 A ++ A + A Die-casted copper free AL EN 44100 Body and Cover Screws A2 Inox 316 - Annealed Silicon GasketsSupplied with 1m pre-wired HORNF-5 cableFast Connector IP65 includedOn Request 3000 K LED colour temperatureLED Driver Included Luminaire supplied with LED circuit IP 65IK09 20J xxxCLASS IRa 80 Estimated lifetime 50.000 hours (accordingly to LM-80) Painting Finish: On Request: With 2 power led in Natural White 4000 KTotal Power Consumption (Fitting+Driver) 13,2 W Real lumen output 294 lm Led Energy class Watch the mounting installation video on PerformanceINLighting channel on YouTube Steel flange with stainless steel screws(to be fix in concrete) included CODE
PRISMA ARCHITECTURAL 10
PRISMA ARCHITECTURAL 11
PRISMA ARCHITECTURAL 12 ALU TECH design Prisma Architertural
PRISMA ARCHITECTURAL 13 303221 303220 C 0°- C 180° cd/Klm 90° 105° 105° 120° 120° 90° 0° 30° 15° 45° 45° 60° 60° 75° 75° 180° 200 400 600 800 ALU TECH R GR4 C o 140° C 90 60° 0 -4 -3 -2 -1 0 1 2 4 3 1 2 3 4 5 6 H 0,5 m lux meters Ground isolux with 303221 25 10 10 5 5 2 2 2 2 1 1 0.5 0.5 0.5 0.5 0.5 0.5 1 1 1 5 25 50 50 100 200 250 500 303219 303218 C 0°- C 180° cd/Klm 90° 105° 105° 120° 120° 90° 0° 30° 15° 45° 45° 60° 60° 75° 75° 180° 200 400 600 800 ALU TECH V C o 140° C 90 60° 0 -4 -3 -2 -1 0 1 2 4 3 1 2 3 4 5 6 H 0,5 m lux meters Ground isolux with 303219 25 10 10 10 5 2 2 2 2 1 0.5 0.5 0.5 0.5 0.5 1 1 5 5 25 50 50 100 200 250 A ++ A ++ A ++ A ++ A + A + A + A + A A A A With SMD power led in Natural White 4000 K Total Power Consumption (Fitting+Driver) 10,8 W Real lumen output 421 lm Led Energy class With SMD power led in Warm White 3000 K Total Power Consumption (Fitting+Driver) 10,8 W Real lumen output 396 lm Led Energy class Anodized aluminium bodyFast connector IP65 IncludedSupplied with 1m pre-wired HORNF-5 cable, or more to be confirmed at the moment of the orderLuminaire supplied with SMD LED circuitLED Driver Included IP 66IK05 0,7J xxxCLASS IRa 80 Estimated lifetime 50.000 hours (accordingly to LM-80) With SMD power led in Natural White 4000 K Total Power Consumption (Fitting+Driver) 6,6 W Real lumen output 212 lm Led Energy class With SMD power led in Warm White 3000 K Total Power Consumption (Fitting+Driver) 6,6 W Real lumen output 207 lm Led Energy class Painting Finish: CODE
PRISMA ARCHITECTURAL 14 303217 303216 1 310395 310397 310396 C o 140° C 90 60° C 0°- C 180° cd/Klm 90° 105° 105° 120° 120° 90° 0° 30° 15° 45° 45° 60° 60° 75° 75° 180° 200 400 600 800 ALU TECH S 0 -4 -3 -2 -1 0 1 2 4 3 1 2 3 4 5 6 H 0,5 m lux meters Ground isolux with 303217 25 10 10 5 5 2 2 2 2 1 1 0.5 0.5 0.5 0.5 0.5 1 1 1 5 25 50 50 100 200 250 500 A ++ A ++ A + A + A A With SMD power led in Natural White 4000 K Total Power Consumption (Fitting+Driver) 10,8 W Real lumen output 467 lm Led Energy class: With SMD power led in Warm White 3000 K Total Power Consumption (Fitting+Driver) 10,8 W Real lumen output 441 lm Led Energy class: Stainless Steel Recess Box for Alu Tech V120mmx240mmxH77mm Stainless Steel Recess Box for Alu Tech R240mmx130mmxH77mm Stainless Steel Recess Box for Alu Tech S240mmx240mmxH77mm Take a look to the dedicated brochure downloadable from www.performanceinlighting.com Accessories: CODE
PRISMA ARCHITECTURAL 15 xx xx
PRISMA ARCHITECTURAL 16 SPILLO design A. Pedretti
PRISMA ARCHITECTURAL 17 SPILLO MINI 6 LED SPILLO MINI 9 LED 302616 302615 DALI AN3 360° 360° DALI A ++ A ++ A + A + A A Ø 360 Ø 76 217 1200 Ø 360 Ø 76 217 1200 With 9 power Led in Natural White 4000 K Total Power Consumption (Fitting+Driver) 10 W Real lumen output TBA lm Led Energy class Dimmable DALI as standard Where the linear flex 40 led 4 W (24V) ring goes in separately in dual circuit switching Painted aluminium cylindrical pole Ø 76 mm H 1,2 m includedFixing flange included Ø 180 mm x H 11,5 mm With 6 power Led in Natural White 4000 K Total Power Consumption (Fitting+Driver) 6,5 W Real lumen output TBA lm Led Energy class Dimmable DALI as standard Where the linear flex 40 led 4 W (24V) ring goes in separately in dual circuit switching Painted aluminium pole Ø 76 mm H 1,2 m includedFixing flange included Ø 180 mm x H 11,5 mm On Request On Request Luminous flux wasted upwards 0% Luminous flux wasted upwards 0% Street optic lenses designed by Performance in Lighting® Die-casted copper free AL EN 44100 Body and Cover Screws A2 Inox 316 - Annealed Silicon GasketsSupplied with 1m pre-wired HORNF-5 cable, or more to be confirrmed at the moment of the orderLED Driver Included Luminaire supplied with LED circuit P 65IK09 20J xxxCLASS II Ra 80 Estimated lifetime 50.000 hours (accordingly to LM-80) Painting Finish: CODE DUAL CIRCUIT SWITCHING DUAL CIRCUIT SWITCHING
PRISMA ARCHITECTURAL 18 SPILLO MINI 9 LED TESTA PALO 302617 360° Ø 360 Ø 76 267 310403 A ++ A + A On Request 3000 K LED colour temperature With 9 power Led in Natural White 4000 K Total Power Consumption (Fitting+Driver) 10WReal lumen output TBA lm Led Energy class Aluminium adaptor for existing cylindrical poles Ø 60 mm spigot attachment included Luminous flux wasted upwards 0% Accessories: Aluminium adaptor for existing cylindrical poles Ø 60 mm spigot attachment On Request CODE
PRISMA ARCHITECTURAL 19 cd/Klm 90° 105° 105° 120° 120° 90° 0° 30° 15° 45° 45° 60° 60° 75° 75° 180° 100 200 300 400 SPILLO 14 LED SPILLO 28 LED 302619 302618 C 0°- C 180° C 90° - C 270° 360° 360° AN3 0 1 2 3 4 5 6 7 9 8 10 1 2 3 4 5 6 7 8 9 10 H 2,8 m lux meters Ground isolux with 302619 33 30 26 20 20 15 15 15 10 10 5 5 5 2 2 2 1 1 1 10 26 30 Ø 580 Ø 90 222 Ø 580 Ø 90 222 DALI DALI A ++ A ++ A + A + A A With 28 power Led in Natural White 4000 K Total Power Consumption (Fitting+Driver) 30 W Real lumen output TBA lm Led Energy class Dimmable DALI as standard Where the linear flex 60 led 7 W (24V) ring goes in separately in dual circuit switching It goes with 315023 or 315023 / 310405 or 310404 With 14 power Led in Natural White 4000 K Total Power Consumption (Fitting+Driver) 15 W Real lumen output TBA lm Led Energy class Dimmable DALI as standard Where the linear flex 60 led 7 W (24V) ring goes in separately in dual circuit switching It goes with 315023 or 315023 / 310405 or 310404 Street optic lenses designed by Performance in Lighting® Die-casted copper free AL EN 44100 Body and Cover Screws A2 Inox 316 - Annealed Silicon GasketsSupplied with 1m pre-wired HORNF-5 cable, or more to be confirrmed at the moment of the orderLED Driver Included Luminaire supplied with LED circuit P 65IK09 20J xxxCLASS IIRa 80 Estimated lifetime 50.000 hours (accordingly to LM-80) Luminous flux wasted upwards 0% Luminous flux wasted upwards 0% Painting Finish: On Request On Request DUAL CIRCUIT SWITCHING DUAL CIRCUIT SWITCHING
PRISMA ARCHITECTURAL 20 cd/Klm 90° 105° 105° 120° 120° 90° 0° 30° 15° 45° 45° 60° 60° 75° 75° 180° 100 200 300 400 C 0°- C 180° C 90° - C 270° SPILLO 28 LED TESTA PALO 310405 310404 315023 302620 360° 315024 Ø 580 Ø 90 272 0 1 2 3 4 5 6 7 9 8 10 1 2 3 4 5 6 7 8 9 10 H 2,8 m lux meters Ground isolux with 302619 33 30 26 20 20 15 15 15 10 10 5 5 5 2 2 2 1 1 1 10 26 30 A ++ A + A Accessories: Aluminium adaptor for existing cylindrical poles Ø 76 mm spigot attachment Aluminium adaptor for existing cylindrical poles Ø 60 mm spigot attachment Cylindrical poles in painted aluminium Ø 90 mm height 3,3 m - 2,8 m above ground On Request 3000 K LED colour temperature With 28 power Led in Natural White 4000 K Total Power Consumption (Fitting+Driver) 30 WReal lumen output TBA lm Led Energy class Aluminium adaptor for existing cylindrical poles Ø 76 mm spigot attachment included Luminous flux wasted upwards 0% On Request On Request On Request Cylindrical poles in painted aluminium Ø 90 mm height 2,8 m with anchor baseØ 310 mm x H 14,5 mm On Request Steel flange with stainless steel coach screws(to be fix in concrete) for 315024 On Request CODE
PRISMA ARCHITECTURAL 21
PRISMA ARCHITECTURAL 22 SUPERBLIZ LED design R. Fiorato, F. Pagliarini
PRISMA ARCHITECTURAL 23 SUPERBLIZ LED 180° 303222 303223 303228 303229 303225 303226 303230 303231 C 0°- C 180° C 90° - C 270° cd/Klm 90° 105° 105° 120° 120° 90° 0° 30° 15° 45° 45° 60° 60° 75° 75° 180° 60 120 180 240 P R R U T P R R GR3 AN3 RB1 A ++ A ++ A ++ A ++ A + A + A + A + A A A A With SMD power led in Natural White 4000K Total Power Consumption (Fitting+Driver) 27 W Real lumen output 1580 lm Led Energy classWhere 22 W + 5 W is the total power on and the 5 W goes in separately in dual circuit switching (DA) With SMD power led in Natural White 4000K Total Power Consumption (Fitting+Driver) 27 W Real lumen output 1580 lm Led Energy classWhere 5 W goes separately in emergency 3 hours (EM3h)Delivered flux after 3 hours 200 lm With SMD power led in Warm White 3000K Total Power Consumption (Fitting+Driver) 27 W Real lumen output 1508 lm Led Energy classWhere 22 W + 5 W is the total power on and the 5 W goes in separately in dual circuit switching (DA) With SMD power led in Warm White 3000K Total Power Consumption (Fitting+Driver) 27 W Real lumen output 1508 lm Led Energy classWhere 5 W goes separately in emergency 3 hours (EM3h)Delivered flux after 3 hours 191 lm Delivered with SMD self heating dissipated tiltable power LED board in MCPCB (Metal-Co-re Printed Circuit Board) Internally enlamelled pressed-glass diffuserDie-cast enamelled aluminium body and ring / grill ALL VERSIONS SUPERBLIZ LED ARE AVAILABLE WITH POLYCARBONATE DIFFUSER on request IK10 20J xx9 Luminaire supplied with SMD LED circuit IP 66CLASS IIK07 2J xx5Ra 80 Estimated lifetime 50.000 hours (accordingly to LM-80) Painting Finish: On Request: CODE EMERGENCY LUMINAIRE 3 H EMERGENCY LUMINAIRE 3 H DUAL CIRCUIT SWITCHING DUAL CIRCUIT SWITCHING
PRISMA ARCHITECTURAL 24 303234 303235 303240 303241 303237 303238 303243 303244 SUPERBLIZ/G LED U T N M N P R R P R R 180° C 0°- C 180° C 90° - C 270° cd/Klm 90° 105° 105° 120° 120° 90° 0° 30° 15° 45° 45° 60° 60° 75° 75° 180° 60 120 180 240 A ++ A ++ A ++ A ++ A + A + A + A + A A A A With SMD power led in Natural White 4000K Total Power Consumption (Fitting+Driver) 27 W Real lumen output 1127 lm Led Energy classWhere 22 W + 5 W is the total power on and the 5 W goes in separately in dual circuit switching (DA) With SMD power led in Natural White 4000K Total Power Consumption (Fitting+Driver) 27 W Real lumen output 1127 lm Led Energy classWhere 5 W goes separately in emergency 3 hours (EM3h)Delivered flux after 3 hours 145 lm With SMD power led in Warm White 3000K Total Power Consumption (Fitting+Driver) 27 W Real lumen output 1076 lm Led Energy classWhere 22 W + 5 W is the total power on and the 5 W goes in separately in dual circuit switching (DA) With SMD power led in Warm White 3000K Total Power Consumption (Fitting+Driver) 27 W Real lumen output 1076 lm Led Energy classWhere 5 W goes separately in emergency 3 hours (EM3h)Delivered flux after 3 hours 138 lm Delivered with SMD self heating dissipation tiltable power LED board in MCPCB (Metal-Co-re Printed Circuit Board) CODE DUAL CIRCUIT SWITCHING DUAL CIRCUIT SWITCHING EMERGENCY LUMINAIRE 3 H EMERGENCY LUMINAIRE 3 H
PRISMA ARCHITECTURAL 25
PRISMA ARCHITECTURAL 26 GR3 WH1 AN3 RB1 GR4 SS1 PA1 Powder polyester painting process optimized against UV rays in 13 different stepsMat/glossy finishSimilar to RAL 9006 colour Powder polyester painting process optimized against UV rays in 13 different steps. Mat/glossy finish. Similar to RAL 9003 colour Powder polyester painting process optimized against UV rays in 13 different stepsMat/glossy finishSimilar to RAL 7011 colour Powder polyester painting process optimized against UV rays in 13 different stepsMat/glossy finishSimilar to RAL 8016 colour Anodized aluminiumMat/glossy finishSimilar to RAL 7047 colour Brushed Stainless Steel Anodized Stainless Steel Painting Finishes Please verify colours with commercial departments Every RAL coulor on aluminium can be done on express purpose with extra cost
PRISMA ARCHITECTURAL 27 Datas contained in the catalogue are for exclusive reference purpose and they not involve any commitment by Perfor-mance In Lighting S.p.A which reserves the right to make all necessary changes without prior notice.Partial or complete reproduction of this catalogue is strictly forbitten.
PRISMA ARCHITECTURAL 28 PRISMA ARCHITECTURAL ® is a brand of PERFORMANCE IN LIGHTING S.p.A. Viale Del Lavoro, 9/11 37030 Colognola Ai Colli (Vr) – Italy Tel. +39 045 6159 211 Fax. +39 045 6159 292 [email protected] www.performanceinlighting.com PERFORMANCE IN LIGHTING UK Ltd. Office 31 - Imex Spaces Business Centre OXleasow Road - East Moons Moat - Redditch Worcs. B98 ORE - England Tel. +44/1527.830.439 Fax. +44/1527.830.440 www.pil-uk.com
