Legrand Switches and Sockets - Excel Life

CONTENTS New Excel Life ......................................................... 2Dedicated Plate Series ............................................ 4Common Plate Series .............................................. 5Secure Plate Series ................................................. 7Switches .................................................................. 8Illuminated Dolly Ring ........................................... 10Dimmers ................................................................ 12Multifunction Rotary Switch .................................. 15 Shutter Switch ....................................................... 16Time Delay Switches ............................................. 17Powerpoints .......................................................... 18LED Indicator Kits ................................................. 21Telephone and Data Jacks ..................................... 22Audio, Computing and TV Sockets ......................... 25Signalling .............................................................. 26Skirting Lights ....................................................... 28Hotel Applications ................................................. 29Colour Options – Cover Plates ............................... 30 Catalogue .............................................................. 31Notes ..................................................................... 48

2 Legrand is proud to present the all new Excel Life range, developed by a global team in both Australia and France over 24 months. Excel Life pushes improvements in both product design and manufacturing to bring a new level of excellence to the products you use every day. It’s what we call everyday excellence. You trusted the Excel product for decades. A trust built on reliability. The new Excel Life continues the commitment to best-in-class products, the same commitment that makes Legrand the world leader in manufacturing and supply of switches and outlets. The modern design features slimmer plates and contemporary switches, to meet the needs of today’s customers. But the improvements go well beyond just looks. The new Excel Life also delivers greater ﬂexibility and control through miniaturising technology and modularity, delivering a product perfect for the contractor, speciﬁer and end-user. MINIATURISING TECHNOLOGY Gone are some of the bulky mechanisms of the past. They’ve been replaced by smaller mechanisms designed to ﬁt into a standard switch hole, so more can now be achieved from the one switch plate. MODULARITY Make unique combinations of products onsite – powerpoints are now available with spare function holes ready for you to slot in any extra mechanism you need. Add a surge protection module to a double powerpoint, for example. ENVIRONMENTAL AWARENESS Legrand is committed to delivering environmentally responsible products. The environmental footprint of Excel Life product is smaller than any similar product on the market. Excel Life also proudly boasts an industry ﬁrst by introducing Product Environmental Proﬁles (PEPs) for key products. The PEPs outline materials, manufacture, distribution, usage and end of life product management details. They can help you make more educated decisions and assist you with your project documentation. NEW EXCEL LIFE. A SWITCH FOR THE BETTER.

3 Single module Surge Protectors and Time Delay Mechanisms LED Indicator Kits Secure Plate Series with screw lock Multi-function All-in-one Rotary Switch LED Illuminated Dolly Ring Kit Watch out for the new Excel Life range in stores; new products will be released regularly so to keep up-to-date go to www.legrand.com.au and sign-up for ‘Newslink’, our new product newsletter. Here’s a sneak peek of some of the new range: HIGHLIGHTS

4 THE DEDICATED PLATE SERIES This series is the progression from HPM Excel, the product you know. A slimmer look and new rockers only hint at the exciting changes. EXCEL LIFE IS AVAILABLE IN 2 FORMATS.

5 THE ALL NEW COMMON PLATE SERIES An all new offering, this series features a common coverplate that can be used across the entire range. It’s perfect for projects where easy maintenance is important.

7 SECURE PLATE SERIES There are times when you need a little extra protection, from theft and damage. Projects like schools, public areas and anywhere that precautions are needed against vandalism. The Secure Plate series now offers the peace of mind of a cover plate that can only be removed with a screwdriver. Off-the-shelf solutions are available in one to six gang switches, single and double powerpoints. But it’s also good to note any common plate series product can be ﬁtted with a secure coverplate (ESCWPLWE). ES777WE Coverplate can only be removed with a screwdriver

8 SWITCHES Choose from a wide range of switch mechanisms, from 5A electronic push buttons to 32A rockers and ‘no-touch’ options, there is something to suit all installations, budgets and customers. STANDARD 770 ROCKER Our standard rocker has been improved to 16A with a 16AX ﬂuoro rating. EM770WE EM770DUOWE EC914WE NO TOUCH SWITCH Perfect for any environment where hygiene is paramount or for customers who just want that extra technology. The No Touch switch activates by simply passing your hand within 50mm of the switch. DUO 770 ROCKER The Duo rocker allows you to switch two points from the one opening in a switch plate, which is great when retroﬁtting and you need an additional point because you can use the existing plate to reduce cost and wastage. The Duo mechanism allows you to switch more than six outputs from a standard plate, add two mechanisms and you can switch 8 outputs. Perfect when you’re switching loads that are normally switched together but need to be switched individually sometimes.

9 ELECTRONIC PUSH BUTTON A 3 wire switch with onboard programming that allows you to program the LED indicator to be RED or BLUE. You can also choose if the LED is completely off when the switch is not in use, or if it is on, but at a reduced brightness level. Use with ‘slave’ switch for multi-way switching. EM883WE EM800SLAVEWE

ILLUMINATED DOLLY RING A brand new innovation that allows you to add a unique LED illumination ring to any standard 16A or 20A 770 rocker. Whether your customer is looking for a stylish design touch or a way to ﬁnd the switch in the dark – the new Illuminated Dolly Ring Kit is the perfect solution. 10 EM770LEDWE

12 UNIVERSAL ELECTRONIC PUSH BUTTON Choose a red or blue LED indicator with the onboard programming. Onboard programming also allows you to choose if the LED indicator is completely OFF when the switch is not in use, or if it remains ON at a reduced brightness to aid in locating the switch in the dark. The universal 450UP also features a clever brightness memory, returning to the last brightness level used when the switch is activated. It can also be used with the Slave Switch (EM800SLAVEWE) for efﬁcient multiway dimming. Suitable for use with electronic and wirewound transformers. Use with ‘slave’ switch for multi-way dimming. On board programming allows you to set the LED to be blue or red EM800SLAVEWE EM450UPWE DIMMERS The new Excel Life range of dimmers provide whisper quiet operation and have overcome the annoying ﬂicker caused by ripple injections in the mains supply. They are also ﬁtted with over temperature protection, automatically dimming the lamp if it is overloaded or insufﬁciently derated. The range includes 250VA, 400VA, 700VA trailing edge rotary dimmers and a 450VA universal electronic push button dimmer.

13 EM700TRWE EM250TRWE & EM400TRWE ROTARY DIMMERS Suitable for use with electronic transformers the new rotary dimmers feature easy grip and lower proﬁle knobs.

MARKING PLATE OPTIONS 14

MULTIFUNCTION ROTARY SWITCH An all-in-one rotary switch module that can do it all - 180°, 270° and 360°. Ideal for use with ceiling fans, but ﬂexible enough to be used with motorised shutters and awnings. It also works with sensors, such as the Aquascan (630/9), so your customer can select lights ON, in movement sensor mode, or OFF. The rotary switch offers 6 marking plate options so you can tailor the product for the job. Current Rating: 16A, 16AX (ﬂuoro). EMRSWE 15

16 SHUTTER SWITCH The ideal switch for controlling roller shutters or similar devices such as motorised blinds, awnings and curtains. Available in two options: Direct model (EC920) and Relay model (EC919). Both are rated 6A. EC919WE

EC923TWE TIME DELAY SWITCHES EM802TDWE Perfect for use in stairwells of apartment buildings and similar situations, this Time Delay Switch offers a simple 2 wire product that’s quick to program and works well with CFLs, delivering a ﬂicker free result. Program one to ten minute time delays in one minute increments. The handy 770 module size means you can slot it into any normal switch hole. EC923TWE This switch allows you to program up to 8 weekly scenarios, making it the only choice for use in situations when lights need to be turned on and off at speciﬁc times such as schools, shops or sports facilities. It can also be used in conjunction with a motor such as a pool pump. Should the power go out, a working reserve will ensure the programming is maintained for 20 hours. EM802TDWE 17

18 EC787WE EC777WE EC787XWE ED7774WE Add a surge protection module, 2OA switch – whatever mechanism you need! COMMON PLATE SERIES ED787WE ED777WE ED777XWE DEDICATED PLATE SERIES POWERPOINTS The new Excel Life powerpoints all include internal safety shutters as a standard feature, ensuring extra peace of mind for your customers. There are plenty of innovations with you in mind as well: inline terminals on double GPOs and 4 corner ﬁxing options simplify installation. For even greater ﬂexibility on site, Excel Life powerpoints are available with an extra mechanism hole. Create the solution you need on the spot by adding the extra mechanism required, from a surge protection module to an oven switch.

19 4 corner ﬁxing options Inline terminals for faster installation.

21 EMPAWE EMPS1WE EMPS2WE EM803LEDWE EMPAPS1WE EMPAPS2WE LED INDICATORS KITS LED indicators that show at a glance “power available” and/or “power supplied” are ideal for hospitals and other medical facilities, factories, workshops and temporary building sites. The single 770 module mechanisms are pre-ﬁtted with ‘quick ﬁt’ lead ends that are ready to connect to the Excel Life sockets. Quickﬁt spade terminals on 777X models.

22 EMRJ45C5ERD EMRJ45C5EGR EMRJ45C5EBU TELEPHONE AND DATA JACKS CAT 3, CAT 5E, CAT 6 Available in white, yellow, black, blue, green or red, Excel Life jacks are compatible with both Krone and 110 DC termination tools – your choice. Cat 3 models provide an additional slot for easy telephone looping – rather than inserting 2 cables in 1 terminal. EMRJ11C3BL EMRJ45C5EYE EMRJ11C3WE Icon makes it easier for end-users to determine if it’s a phone or data jack.

AUDIO, COMPUTING AND TV SOCKETS The world of entertainment and computing is becoming more and more demanding. The Excel Life range of audio, computing and TV sockets is designed meet this demand, with solutions that suit homes and commercial applications such as ofﬁces, boardrooms, hotel function rooms, and computing and audio shop applications. 25 EC920MSVIDWES-video outlet ECUSBWEUSB type A female outlet EC920VGAWEVGA outlet female connection EC910J35WE3.5 female audio outlet EC920LJWELoudspeaker outlet EC920HDMIWEHDMI socket EMRCAWEWERCA outlet, white F-type on rear EMRCAYELWERCA outlet, yellow F-type on rear EMRCARDWERCA outlet, red F-type on rear EMSPWEPAL to saddle TV outlet EMFFFOXWEF to F TV outlet Foxtel approved

BULKHEAD LIGHTS Perfect for corridor navigation. Available with red, blue, green and white LEDs. SIGNALLING Good signalling can increase the efﬁciency of a work environment, minimise costly disruptions and most importantly, prevent accidents. Excel Life offers 2 signalling solutions. SIGNAL LIGHTS Customise and update the graphic panel with ease. Simply print the symbol required on transparency paper and slot into the window. To make it even easier a PDF of commonly used symbols is available. Ideal for operating theatres, studios, test labs and other special access rooms. Available in white, blue, and red/green LEDs. EC572WE EC573WE EC571WE EC570WE EC524WE EC520WE EC521WE EC524WE 26

SKIRTING LIGHT Create a safe environment in stairwells and low level lighting environments, or highlight other potential hazards with the Excel Life Skirting Lights. Available in two models: Permanent Light (EC510WE) and Movement Sensor (EC511WE) with optional audio function perfect for aged care facilities with high safety requirements. 28 EC511WESkirting light with PIR sensor EC510WESkirting light

HOTEL APPLICATIONS Offer a more professional alternative to cardboard swing tags for your Hotel customers. The Hotel Guest Call Control is installed inside the room giving guests the ability to simply indicate: ‘do not disturb’ or ‘clean the room’. The Hotel Corridor Indicator, installed outside the room, signals the option to staff in the corridor. The new electronic key fob switches now include a 30 second time delay giving hotel guests time to comfortably exit or collect a few last belongings before all the lights turn off. EC925WEHotel guest room call control EC924WEHotel corridor call indicator ECKFSWEElectronic keyfob switch with 30 second time delay 29

COLOUR OPTIONS The Excel Life Dedicated Plate series is available in White and Urban Grey (Available late 2011). The Excel Life Common Plate series is only available in White. Matt Silver cover plates are available for a stylish upgrade to Dedicated Plate products. Check the catalogue pages for details. WHITE (WE) MATT SILVER (MS)Dedicated Plate Series only URBAN GREY (UG) Dedicated Plate Series only – Available late 2011 30

31 Some items sold seperately For trade price, please see your local HPM Legrand representative for the current price list. Pack Cat No. Dedicated plate switches White Urban Grey Standard rocker switch mechanisms are 16AX 10 ED770/1WE ED770/1UG 1 gang switch 16A230 - 240V a.c. 10 ED770/2WE ED770/2UG 2 gang switch 16A230 - 240V a.c. 10 ED770/3WE ED770/3UG 3 gang switch 16A230 - 240V a.c. 10 ED770/4WE ED770/4UG 4 gang switch 16A230 - 240V a.c. 10 ED770/5WE ED770/5UG 5 gang switch 16A230 - 240V a.c. 10 ED770/6WE ED770/6UG 6 gang switch 16A230 - 240V a.c. Pack Cat No. Common plate switches White Standard rocker switch mechanisms 10 EC770/1WE 1 gang switch 16A230 - 240V a.c. 10 EC770/2WE 2 gang switch 16A230 - 240V a.c. 10 EC770/3WE 3 gang switch 16A230 - 240V a.c. 10 EC770/4WE 4 gang switch 16A230 - 240V a.c. 10 EC770/5WE 5 gang switch 16A230 - 240V a.c. 10 EC770/6WE 6 gang switch 16A230 - 240V a.c. 6 EC914WE No Touch switch, 4A230-240V a.c. EC770/1WE Excel Life TM light switches - common plate seriesshutter, blind, curtain control Excel Life TM light switches - dedicated plate series ED770/1WE ED770/2WE EC770/3WE 10 EC919WE Push button switch (via relay) 6A230-240V a.c. 10 EC920WE Push button switch (direct) 6AX Any 16 or 20A standard rocker (EM770LEDWE) for a Any common plate (ESCWPLWE) for environments where the prevention of petty EC914WE EC919WE ED770/4WE ED770/6WE

32 Some items sold seperately For trade price, please see your local HPM Legrand representative for the current price list. 10 EM770DU0WE EM770DU0UG 2 x single pole single throw 16A 230 - 240V a.c. 10 EMRSWE EMRSUG Rotary switch mechanism - (all-in-one solution), comes with 6 marking plate options and 180°, 270° and 360° rings.16A fluoro rated 16AX 230-240V a.c. Keylock mechanisms 10 EM820- KLIOWE EM820- KLIOUG Switch mechanism1 gang keylock switch removable OFF or ON 20AX, 230 - 240V a.c. 10 EM820KLIWE EM820KLIUG Switch mechanism1 gang keylock switchremovable ON only 230 - 240V a.c. 10 EM820KLOWE EM820KLOUG Switch mechanism1 gang keylock switchremovable OFF only 230-240V a.c. Mechanicalmechanisms 10 EM770WE EM770UG Single pole double 16AX, 230 - 240V a.c. 10 EM770IMWE EM770IMUG Intermediate 16A 230 - 240V a.c. 10 EM770DPWE EM770DPUG Double pole double 10AX, 230 - 240V a.c. 10 EM770/- 20DPWE EM770/-20DPUG Double pole double 10AX, 230 - 240V a.c. 10 EM770/20WE EM770/20UG Single pole single 20AX, 230 - 240V a.c. 10 EM770/- 20RDWE EM770/- 20RDUG Single pole double throw with red indicator 230 - 240V a.c. 10 EM770/25WE EM770/25UG Single pole single 20AX, 230 - 240V a.c. 10 EM770/32WE EM770/32UG Single pole single 20AX, 230 - 240V a.c. Pack Cat No. mechanisms White Urban Grey 10 EM883WE EM883UG Electronic push button 5A, 230 - 240V a.c.Fluoro rated 500VA. 10 EM800- SLAVEWE EM800- SLAVEUG Secondary control push button 230 - 240V a.c. Excel Life TM electronic and mechanical mechanisms Excel Life TM mechanical mechanismskeylock mechanisms EM770WE EM883WE EMRSWE EM800SLAVEWE EM820KLIOWE EM770DUOWE

33 Some items sold seperately For trade price, please see your local HPM Legrand representative for the current price list. Excel Life TM switch mechanisms 2 1 C L LOOP 2 1 1 2 1 2 C L LOOP EM770EM770/20 EM770DPEM770/20DP MULTIWAY SWITCHING 2 SWITCHES 2 1 L LOOP EM770/25EM770/32 2 1 C L EM770IM EM770IM EM770IM 2 1 C L 4 2 1 3 4 2 1 3 4 2 1 3 MULTIWAY SWITCHING MORE THAN 2 SWITCHES(Any quantity of intermediate switches may be used). UP POSITION EM770IM 4 2 1 3 DOWN POSITION EM770IM 1 2 1 2 EM770DUO EM770EM770/20 EM770EM770/20

34 Some items sold seperately For trade price, please see your local HPM Legrand representative for the current price list. Excel Life TM switch mechanisms EM883WE LED Indicator The colour of the LED indicator can be either red or blue. In addition, when the switch is off the LED indicator can either glow faintly or be off completely. The four possible modes are as follows: To change between modes, press and hold the push button for at least 10 seconds. This will select the next mode in the sequence above. Mode Status of LED indicator Switch on Switch off 1 Bright red Faint red 2 Bright blue Faint blue 3 Bright red Off 4 Bright blue Off EM883 EM800SLAVE LOAD ACTIVE NEUTRAL REMOTE ACTIVE REMOTE LOOP LOAD ACTIVE NEUTRAL EM800SLAVE Connect optional Secondary Control Buttons (EM800SLAVE) to enable switching from multiple locations. Minimum load = 10VA for all load types Incandescent 1200W 1200W Max load + 50°C + 0°C 230 - 240V a.c. 50Hz 1 x 2.5 mm² 2 x 1.5 mm² transformer Electronic transformer Compact LED Fan motor 500VA 500VA 500VA 500VA 500VA 500VA Important:An unlimited number of EM800SLAVE can be connected to an EM883. However, the total length of the remote wire used to interconnect all of the EM800SLAVE should not exceed 50 metres. Important:Power factor correction capacitors must be either removed or placed on the line side of the Electronic Push Switch. Technical characteristics

35 Some items sold seperately For trade price, please see your local HPM Legrand representative for the current price list. Excel Life TM Rotary switch - EMRSWE Installation Step 1 Step 2 Step 3 Step 4 not supplied Marking plate Locating ring 1 1 3 2 C Front View Rear View Output 1 Input ACTIVE Output 3 Output 2 3 2 0 Select one of the following wiring options: POSITION WIRING 0 1 2 3 OFF ON ON ON Connect All Terminals OFF ON OFF ON Do Not Connect Terminal 2 1 1 3 2 C Front View Rear View Output 1 3 2 0 Input ACTIVE Output 3 Output 2 Select one of the following wiring options: POSITION WIRING 0 1 2 3 OFF ON ON ON Connect All Terminals 1 Front View Rear View 3 2 1 3 2 C Output 1 Input ACTIVE Output 3 Output 2 Select one of the following wiring options: POSITION WIRING 1 2 3 ON ON ON Connect All Terminals ON OFF ON Do Not Connect Terminal 2 OFF ON ON Do Not Connect Terminal 1 ON ON OFF Do Not Connect Terminal 3 Flat side facing up facing up

36 Some items sold seperately For trade price, please see your local HPM Legrand representative for the current price list. Pack Cat No. Dimmers White Urban Grey - 10 EM450UPWE EM450UPUG Electronic push button450VA universal load230 - 240V a.c. Rotary if dimmer is overloaded or 10 EM250TRWE EM250TRUG 250VA Trailing edge230 - 240V a.c. 10 EM400TRWE EM400TRUG 400VA Trailing edge230 - 240V a.c. 10 EM700TRWE EM700TRUG 700VA Trailing edge230 - 240V a.c. Excel Life TM dimmers EM250TRWE EM700TRWE EM450UPWE Excel Life TM electronic push button dimmer - EM450UP 25 30 35 40 45 50 50 60 70 80 90 100 % Rating Installation air temperature (ºC) Important:When used in ambient temperatures greater than 25°C, the dimmer must be de-rated according to the following chart. EM450UP Technical characteristics Minimum load = 10VA for all load types Incandescent + 50°C + 0°C 230 - 240V a.c. 50Hz 1 x 2.5 mm² 2 x 1.5 mm² Maxload transformer Electronic transformer Compact LED Fan motor 1 dimmer per plate 2 dimmers per plate 3 or more dimmers per plate 450W 450W 400W 400W 350W 350W 270VA 450VA 400VA 350VA 240VA 210VA Connect optional Secondary Control Buttons (EM800SLAVE) to enable dimming from multiple locations. EM450UP ACTIVE REMOTE ACTIVE LOAD NEUTRAL TO ADDITIONAL EM800SLAVE EM800SLAVE ACTIVE REMOTE Important:An unlimited number of EM800SLAVE can be connected to an EM450UP. However, the total length of the remote wire used to interconnect all of the EM800SLAVE should not exceed 50 metres.

37 Some items sold seperately For trade price, please see your local HPM Legrand representative for the current price list. Excel Life TM Rotary dimmers - EM250TR/EM400TR/EM700TR Technical characteristics Minimum load = 10VA for all load types 1 dimmer per plate + 50°C + 0°C 230 - 240V a.c. 50Hz 1 x 2.5 mm² 2 x 1.5 mm² 250W 250W Incandescent transformer Electronic transformer compact LED Fan motor 1 dimmer per plate 2 dimmers per plate Maxload EM250TR Maxload EM400TR Maxload EM700TR 3 dimmers per plate 1 dimmer per plate 2 dimmers per plate 3 dimmers per plate 225W 225W 200W 200W 400W 400W 350W 350W 300W 300W 700W 700W 250VA 250VA see note 225VA 225VA see note 200VA 200VA see note 400VA 400VA see note 350VA 350VA see note 300VA 300VA see note 700VA 700VA see note Note: - EM770 EM770 EM770 Important:When used in ambient temperatures greater than 25°C, the dimmer must be de-rated according to the following chart. 25 30 35 40 45 50 50 60 70 80 90 100 % Rating Installation air temperature (ºC)

38 Some items sold seperately For trade price, please see your local HPM Legrand representative for the current price list. Pack Cat No. Time delay mechanisms White Urban Grey 10 EM802TDWE EM802TDUG Programmable time delay switch, 2 wire all load 400VA, 230 - 240V a.c.Can be programmed from 1-10 minutes in steps of 1 minute. 6 EC923TWE - Programmable time delay switch, 16A 230 - 240V a.c.Up to 8 weekly programmes, 20hrs working reserve Excel Life TM time delay switches Excel Life TM EM802TD ACTIVE LOAD ACTIVE LOOP LOAD EM802TD MOMENTARY PUSH SWITCHEM870X NEUTRAL Important:An unlimited number of EM870X can be connected to an EM802TD. However, the total length of the load wire used to interconnect all of the EM870X should not exceed 50 metres. Connect optional Momentary Push Switches (EM870X) to enable switching from multiple locations. Minimum load = 10VA for all load types Electronic ballast only Technical characteristicsEM802TD + 50°C + 0°C 230 - 240V a.c. 50Hz 1 x 2.5 mm² 2 x 1.5 mm² Incandescent transformer Electronic transformer Compact LED Fan motor Max load 400W 400W 400VA 400VA 400VA 400VA Note:EM870X available 2012 EM802TDWE EC923TWE

39 Some items sold seperately For trade price, please see your local HPM Legrand representative for the current price list. 10 ES777WE Double powerpoint 10A 230 - 240V a.c. 10 ES787WE Single powerpoint 10A 230 - 240V a.c. Pack Cat No. Common plate powerpoints White 10 EC777WE Double powerpoint 10A, 230 - 240V a.c. 10 EC777XWE Double powerpoint with extra function hole, 10A, 230 - 240V a.c. 10 EC777/15WE Double powerpoint 15A, 230 - 240V a.c. 10 EC777/15XWE Double powerpoint with extra function hole, 15A, 230 - 240V a.c. 10 EC787WE Single powerpoint 10A, 230 - 240V a.c. 10 EC787/15WE Single powerpoint 15A, 230 - 240V a.c. 10 EC787XWE Single powerpoint with extra function hole, 10A, 230 - 240V a.c. 10 EC787/2XWE Single powerpoint with 2 extra function holes, 10A, 230 - 240V a.c. 10 EM787WE Single powerpoint 10A 230 - 240V a.c.mechanism only Pack Cat No. Dedicated platepowerpoints White Urban Grey 10 ED777WE ED777UG Double powerpoint 10A 230 - 240V a.c. 10 ED777XWE ED777XUG Double powerpoint with extra function hole, 10A 230 - 240V a.c. 10 ED777/15WE ED777/15UG Double powerpoint 15A 230 - 240V a.c. 10 ED787WE ED787UG Single powerpoint 10A 230 - 240V a.c. 10 ED787XWE ED787XUG Single powerpoint with extra function hole, 10A 230 - 240V a.c. 10 ED787/2XWE ED787/2XUG Single powerpoint with 2 extra function holes, 10A 230 - 240V a.c. 10 ED787/15WE ED787/15UG Single powerpoint 15A 230 - 240V a.c. 10 ED7774WE ED7774UG 4 gang powerpoint 10A 230 - 240V a.c. Excel Life TM powerpoints - common plate series Excel Life TM powerpoints - dedicated and secure plate seriessurge protection module ED777WE ED7774WE EC777WE EC787WE ES777WE EM803SURGEWE 10 EM803- SURGEWE EM803- SURGEUG Mechanism surge protection module500J, 230-240V a.c.

40 Some items sold seperately For trade price, please see your local HPM Legrand representative for the current price list. Excel Life TM indicator kits Excel Life TM EM803LEDWE EM770LEDWE Pack Cat No. White Urban Grey 10 EM770LEDWE EM770LEDUG EM770 illumination kit blue LED 230 - 240V a.c. 10 EM803LEDWE EM803LEDUG White LED and coloured lenses kit 230 - 240V a.c. 10 EMPAPS1WE EMPAPS1UG Power available and 1 gang power supplied indicator kit 230 - 240V a.c. 10 EMPAPS2WE EMPAPS2UG Power available and 2 gang power supplied indicator kit 230 - 240V a.c. 10 EMPAWE EMPAUG Power available indicator kit 230 - 240V a.c. 10 EMPS1WE EMPS1UG Power supplied to 1 outlet indicator kit 230 - 240V a.c. 10 EMPS2WE EMPS2UG Power supplied to 2 outlets indicator kit 230 - 240V a.c. Click 1. Standard switch 2. Remove ring 3. Insert new ring 4. Screws must be fully screwed in 5. Align the slot and push 6. Engage in slot Installation LOAD LOAD LOAD LED on when “OFF” LED on when “ON” LED on “ALWAYS” N N N A A A Voltage: 240V~ Frequency: 50Hz Current: 1.2mA per indicator Operating temperature: -5°C to +50°C Storage temperature: -10°C to +70°C Resistant to the following agents: Hexane, methylated spirits, soapy water, diluted ammonia, diluted pure bleach (10%), glass cleaning sustance, pre-impregnated wipes, diluted hydrogen peroxide Not resistant to the following agents: Acetone, tar remover, trichloroethylene EMPAEMPS1EM803LED EMPAPS1EMPS2 EMPAPS2 Connector leads MUST be fully inserted Example of afully inserted connector leads not supplied Click into this area Installation EMPAPS1WE EMPS2WE Connector leads

41 Some items sold seperately For trade price, please see your local HPM Legrand representative for the current price list. Excel Life TM LED power supplied/power available indicator kits Wire/leadmarking EMPAPS2 EMPAPS1 EMPA EMPS2 EMPS1 EM803LED EM803LED EM803LED LED N Neutral Neutral Neutral Neutral Neutral Neutral Neutral Switched active LED L Switched Active (LHS) Switched Active (LHS) LED R Switched Active (RHS) Switched Active (RHS) LED Switched active Switched active A Active Active Active Active Switched active Active ++ = In this mode the LED indicator will be ON whenever there is power available to the product. = In this mode the LED indicator will only be ON whenever the associated switch/socket is OFF. The current required to light the indicator when the switch is ON will be bled through the load. Active Terminal LED N LED L LED R Example:EMPAPS2 '~' = Power available' ' = Power supplied

42 Some items sold seperately For trade price, please see your local HPM Legrand representative for the current price list. White Urban Grey 10 EMFFFOXWE EMFFFOXUG F to F TV outlet 75 ohm 2.4 GHz(Foxtel approved) 10 EMFFWE EMFFUG F to F TV outlet75 ohm 10 EMPFWE EMPFUG PAL to F TV outlet, white 10 EMSPWE EMSPUG PAL to saddle TV outlet white Pack Cat No. RJ45 data sockets CAT 6 termination tools 10 EMRJ45C6WE CAT 6, RJ45 data socketwhite 10 EMRJ45C6BL CAT 6, RJ45 data socketblack 10 EMRJ45C6BU CAT 6, RJ45 data socketblue 10 EMRJ45C6GR CAT 6, RJ45 data socketgreen 10 EMRJ45C6RD CAT 6, RJ45 data socketred 10 EMRJ45C6YE CAT 6, RJ45 data socketyellow Excel Life TM RJ11 Cat 3 voice socketsRJ45 Cat 5e sockets Pack Cat No. RJ11 voice sockets termination tools 10 EMRJ11C3WE CAT 3 RJ11 voice socketwhite 10 EMRJ11C3BL CAT 3 RJ11 voice socketblack 10 EMRJ11C3BU CAT 3 RJ11 voice socketblue 10 EMRJ11C3GR CAT 3 RJ11 voice socketgreen 10 EMRJ11C3RD CAT 3 RJ11 voice socketred 10 EMRJ11C3YE CAT 3 RJ11 voice socketyellow Excel Life TM RJ45 Cat 6 data socketsTV outlets EMRJ11C3WE EMRJ11C3BL RJ45 data sockets CAT 5E and IDC termination tools 10 EMRJ45C5EWE CAT 5E RJ45 data socketwhite 10 EMRJ45C5EBL CAT 5E RJ45 data socketblack 10 EMRJ45C5EBU CAT 5E RJ45 data socketblue 10 EMRJ45C5EGR CAT 5E RJ45 data socketgreen 10 EMRJ45C5ERD CAT 5E RJ45 data socketred 10 EMRJ45C5EYE CAT 5E RJ45 data socketyellow EMRJ45C6RD EMFFWE EMSPWE EMRJ45C5EBU EMRJ45C5EGR EMRJ45C6YE

43 Some items sold seperately For trade price, please see your local HPM Legrand representative for the current price list. 6 EC520WE Signal lightwhite LED 1.0W max230 - 240V a.c. 6 EC521WE Signal lightblue LED 1.0W max230 - 240V a.c. 6 EC524WE Signal lightred/green LED 1.0W max230 - 240V a.c. 4 EC570WE Bulkhead lightred LED230 - 240V a.c. 4 EC571WE Bulkhead lightwhite LED230 - 240V a.c. 4 EC572WE Bulkhead lightgreen LED230-240V a.c. 4 EC573WE Bulkhead lightblue LED230 - 240V a.c. Pack Cat No. White 4 EC511WE Skirting light withPIR sensor 1.3W max230 - 240V a.c. 6 EC510WE Permanent skirting light230 - 240V a.c. Pack Cat No. White Urban Grey 10 EMRCARDWE EMRCARDUG RCA outlet white F-type on rearred 10 EMRCAWEWE EMRCAWEUG RCA outlet white F-type on rearwhite 10 EMRCAYEWE EMRCAYEUG RCA outlet white F-type on rearyellow 10 ECUSBWE - USB type A female outlet 6 EC910J35WE - 3.5mm female audio outlet 4 EC920- HDMIWE - HDMI socketrear pluggable 8 EC920LJWE - Loudspeaker outletIP41, 6mm terminal capacity 10 EC920- MSVIDWE - S-Video outletmini din 10 EC920- VGAWE - VGA outletfemale connection Excel Life TM data, audio and video sockets Excel Life TM sensor lights and signalling EMRCARDWE EC920HDMIWE EC920LJWE EC511WE EC524WE ED571WE EC510WE EC920VGAWE

44 Some items sold seperately For trade price, please see your local HPM Legrand representative for the current price list. Pack Cat No. Hospitality and commercial White 4 EC915WE Emergency stop push button1/4 turn 3AX230 - 240V a.c. 6 EC918WE Electronic bell 10 EAKEYFOB Key fob230 - 240V a.c. 10 ECKFSWE Common plate serieselectronic key fob switch with30 second time delay230 - 240V a.c. 10 EDKFSWE Dedicated plate serieselectronic key fob switch with30 second time delay230 - 240V a.c. 6 EC924WE Hotel corridor call indicator 6A, 230 - 240V a.c. 8 EC925WE Hotel guest room call control 230 - 240V a.c. Excel Life TM hospitality and commercial EC918WE C EC919WE C EC924WE C ECKFSWE C SWE 8 EC919WE Push button switch (via relay) 6A230-240V a.c. 8 EC920WE Push button switch (direct control) Pack Cat No. Dedicated White Urban Grey 10 ED770/0GPLWE ED770/0GPLUG Blank grid andcoverplate only 10 ED770/1GPLWE ED770/1GPLUG Dedicated plate1 gang grid and coverplate only 10 ED770/2GPLWE ED770/2GPLUG Dedicated plate2 gang grid and coverplate only 10 ED770/3GPLWE ED770/3GPLUG Dedicated plate3 gang grid and coverplate only 10 ED770/4GPLWE ED770/4GPLUG Dedicated plate4 gang grid and coverplate only 10 ED770/5GPLWE ED770/5GPLUG Dedicated plate5 gang grid and coverplate only 10 ED770/6GPLWE ED770/6GPLUG Dedicated plate6 gang grid and coverplate only Excel Life TM grid and plate - dedicated plate and common plate series Common 10 EC770/0GPLWE Common plategrid and cover only 10 EC770/1GPLWE Common plate1 gang grid and coverplate only 10 EC770/2GPLWE Common plate2 gang grid and coverplate only 10 EC770/3GPLWE Common plate3 gang grid and coverplate only 10 EC770/4GPLWE Common plate4 gang grid and coverplate only EC770/3GPLWE ED770/4GPLWE EC770/0GPLWE

45 Some items sold seperately For trade price, please see your local HPM Legrand representative for the current price list. Common 10 EC770/5GPLWE Common plate5 gang grid and coverplate only 10 EC770/6GPLWE Common plate6 gang grid and coverplate only 10 ECCWPLWE Coverplate 10 ES770/0GPLWE Grid and coverplate only 10 ES770/1GPLWE 1 gang grid and coverplate only 10 ES770/2GPLWE 2 gang grid and coverplate only 10 ES770/3GPLWE 3 gang grid and coverplate only 10 ES770/4GPLWE 4 gang grid and coverplate only 10 ES770/5GPLWE 5 gang grid and coverplate only 10 ES770/6GPLWE 6 gang grid and coverplate only Excel Life TM coverplates - common plate and secure series ED770/6GPLWE ES770/1GPLWE ES770/3GPLWE ES770/6GPLWE

46 Some items sold seperately For trade price, please see your local HPM Legrand representative for the current price list. Pack Cat No. Dedicated plate seriescoverplates Matt Silver 10 ED770/1PLMS 1 gang coverplatematt silver 10 ED770/2PLMS 2 gang coverplatematt silver 10 ED770/3PLMS 3 gang coverplatematt silver 10 ED770/4PLMS 4 gang coverplatematt silver 10 ED770/5PLMS 5 gang coverplatematt silver 10 ED770/6PLMS 6 gang coverplatematt silver 10 ED777PLMS Double powerpoint coverplate, matt silver 10 ED777XPLMS Double powerpoint with extra function hole coverplate, matt silver 10 ED787PLMS Single powerpoint coverplatematt silver 10 EDCWPLMS 75 x 57 windowmatt silver 10 ED920PLMS 45 x 45 windowmatt silver Excel Life TM coverplates - dedicated, common and secure series ED770/4PLWE ED770/6PLWE Dedicated plate seriescoverplates White Urban Grey 10 ED770/1PLWE ED770/1PLUG Dedicated plate1 gang coverplate 10 ED770/2PLWE ED770/2PLUG Dedicated plate2 gang coverplate 10 ED770/3PLWE ED770/3PLUG Dedicated plate3 gang coverplate 10 ED770/4PLWE ED770/4PLUG Dedicated plate4 gang coverplate 10 ED770/5PLWE ED770/5PLUG Dedicated plate5 gang coverplate 10 ED770/6PLWE ED770/6PLUG Dedicated plate6 gang coverplate 10 ED920PLWE ED920PLUG Dedicated plate920 coverplatewhite White Common plate series coverplate 10 ECCWPLWE Coverplate Pack Cat No. coverplate White 10 ESCWPLWE Coverplate Excel Life TM coverplates - dedicated seriesmatt silver ED920PLWE ESCWPLWE ED770/1PLMS ED777PLMS ED787PLMS

47 Some items sold seperately For trade price, please see your local HPM Legrand representative for the current price list. Pack Cat No. Accessories White Urban Grey 10 ECFRAME - Common plate series frame 50 EAPP - Transparent paint and damageprotection shell 1 EAPWDSCREW - Public works department 1-4 gang mechanism retention kit 10 EMCCWE EMCCUG Cord clamp 10 EMCLIDWE EMCLIDUG Blank with clear cap suits 800 module 10 EMIDWE EMIDUG Blank, suits 800 module Excel Life TM accessories EMCCWE EMIDWE ECFRAME Excel Life TM plate sizes Common plate seriesinstallation dimensions Dedicated plate seriesinstallation dimensions 74mm 118mm 10mm 96mm 56mm 77mm 121mm 10mm 96mm 56mm Glass and tile cut-out size Glass and tile cut-out size

48 NOTES

HPM Legrand – Australia Unit 99/79-99 St Hilliers Road Auburn NSW 2144 Tel: 1300 369 777 www.legrand.com.au
