Legrand Excel Life 2014

Legrand is proud to present the Excel Life range, developed by a global team in both Australia and France over 24 months. Excel Life pushes improvements in both product design and manufacturing to bring a new level of excellence to the products you use every day. It’s what we call everyday excellence.

CONTENTS Legrand Excel Life �� 2 Dedicated Plate Series �� 4 Common Plate Series �� 5 Secure Plate Series �� 7 Switches �� 8 Illuminated Dolly Ring �� 10 Dimmers �� 12 Marking Plate Options �� 14 Multifunction Rotary Switch �� 15 Shutter Switch �� 16 Time Delay Switches �� 17 Powerpoints �� 18 LED Indicator Kits �� 21 Telephone and Data Jacks �� 22 Audio, Computing and TV Sockets �� 25 Signalling �� 26 Skirting Lights �� 28 Hotel Applications �� 29 Colour Options – Cover Plates �� 30 Catalogue �� 31

2 Legrand is proud to present the Excel Life range, developed by a global team in both Australia and France over 24 months. Excel Life pushes improvements in both product design and manufacturing to bring a new level of excellence to the products you use every day. It’s what we call everyday excellence.You trusted the Excel product for decades. A trust built on reliability. Excel Life continues the commitment to best-in-class products, the same commitment that makes Legrand the world leader in manufacturing and supply of switches and outlets. The modern design features slimmer plates and contemporary switches, to meet the needs of today’s customers. But the improvements go well beyond just looks. Excel Life also delivers greater flexibility and control through miniaturising technology and modularity, delivering a product perfect for the contractor, specifier and end-user. MINIATURISING TECHNOLOGY Gone are some of the bulky mechanisms of the past. They’ve been replaced by smaller mechanisms designed to fit into a standard switch hole, so more can now be achieved from the one switch plate. MODULARITY Make unique combinations of products onsite – powerpoints are now available with spare function holes ready for you to slot in any extra mechanism you need. Add a surge protection module to a double powerpoint, for example. ENVIRONMENTAL AWARENESS Legrand is committed to delivering environmentally responsible products. The environmental footprint of Excel Life product is smaller than any similar product on the market. Excel Life also proudly boasts an industry first by introducing Product Environmental Profiles (PEPs) for key products. The PEPs outline materials, manufacture, distribution, usage and end of life product management details. They can help you make more educated decisions and assist you with your project documentation. INNOVATION At Legrand, innovation is a constant priority—it’s an integral part of our business culture. Innovating means creating value for everyone. Fine-tuning unique solutions. Developing new functions for customised, intelligent building management. Making devices safer, easier to install, more comfortable and more ergonomic, by offering products and solutions that can function within systems EXCEL LIFE. A SWITCH FOR THE BETTER.

3 Single module Surge Protectors and Time Delay Mechanisms Programmable LED Dimmer LED Indicator Kits USB Charger Mechanism Secure Plate Series with screw lock Double powerpoint with USB charger mechanism Multi-function All-in-one Rotary Switch LED Illuminated Dolly Ring Kit HIGHLIGHTS Watch out for the new Excel Life range in stores; new products will be released regularly so to keep up-to-date go to www.excellife.com.au or www.excellife.co.nz and sign-up for ‘Newslink’, our new product newsletter. Here’s a sneak peek of some of the range:

4 THE DEDICATED PLATE SERIES This series is the progression from HPM Excel, the product you know. A slimmer look and new rockers only hint at the exciting changes. EXCEL LIFE IS AVAILABLE IN 2 FORMATS.

5 THE ALL NEW COMMON PLATE SERIES An all new offering, this series features a common coverplate that can be used across the entire range. It’s perfect for projects where easy maintenance is important.

7 SECURE PLATE SERIES There are times when you need a little extra protection, from theft and damage. Projects like schools, public areas and anywhere that precautions are needed against vandalism. The Secure Plate series now offers the peace of mind of a cover plate that can only be removed with a screwdriver. Off-the-shelf solutions are available in one to six gang switches, single and double powerpoints. But it’s also good to note any common plate series product can be fitted with a secure coverplate (ESCWPLWE). ES777WE Coverplate can only be removed with a screwdriver

8 SWITCHES Choose from a wide range of switch mechanisms, from 5A electronic push buttons to 32A rockers and ‘no-touch’ options, there is something to suit all installations, budgets and customers. STANDARD 770 ROCKER Our standard rocker has been improved to 16A with a 16AX fluoro rating. EM770WE EM770DUOWE EC914WE NO TOUCH SWITCH Perfect for any environment where hygiene is paramount or for customers who just want that extra technology. The No Touch switch activates by simply passing your hand within 50mm of the switch. DUO 770 ROCKER The Duo rocker allows you to switch two points from the one opening in a switch plate, which is great when retrofitting and you need an additional point because you can use the existing plate to reduce cost and wastage. The Duo mechanism allows you to switch more than six outputs from a standard plate, add two mechanisms and you can switch 8 outputs when installed on a 6 gang cover plate. Perfect when you’re switching loads that are normally switched together but need to be switched individually sometimes.

9 ELECTRONIC PUSH BUTTON A 3 wire switch with onboard programming that allows you to program the LED indicator to be RED or BLUE� You can also choose if the LED is completely off when the switch is not in use, or if it is on, but at a reduced brightness level� Use with ‘slave’ switch for multi-way switching. EM883WE EM800SLAVEWE

ILLUMINATED DOLLY RING A brand new innovation that allows you to add a unique LED illumination ring to any standard 16A or 20A 770 rocker. Whether your customer is looking for a stylish design touch or a way to find the switch in the dark – the new Illuminated Dolly Ring Kit is the perfect solution. 10 EM770LEDWE

12 ALL LOAD ELECTRONIC PUSH BUTTON Choose a red or blue LED indicator with the onboard programming. Onboard programming also allows you to choose if the LED indicator is completely OFF when the switch is not in use, or if it remains ON at a reduced brightness to aid in locating the switch in the dark.The all load EM400A3PWE also features a clever brightness memory, returning to the last brightness level used when the switch is activated. It can also be used with the Slave Switch (EM800SLAVEWE) for efficient multiway dimming.Suitable for use with electronic and wirewound transformers. Use with ‘slave’ switch for multi-way dimming. On board programming allows you to set the LED to be blue or red EM800SLAVEWE EM400A3PWE DIMMERS The new Excel Life range of dimmers provide whisper quiet operation and have overcome the annoying flicker caused by ripple injections in the mains supply. They are also fitted with over temperature protection, automatically dimming the lamp if it is overloaded or insufficiently derated.The range includes 250VA, 400VA, 700VA trailing edge rotary dimmers, especially designed for LED lights and a EM400A3P electronic push button dimmer.

13 EM700TRWE EM250TRWE & EM400TRWE ROTARY DIMMERS Suitable for use with electronic transformers the new rotary dimmers feature easy grip and lower profile knobs.

MARKING PLATE OPTIONS 14

MULTIFUNCTION ROTARY SWITCH An all-in-one rotary switch module that can do it all - 180°, 270° and 360°. Ideal for use with ceiling fans (ED3FCWE), but flexible enough to be used with motorised shutters and awnings. It also works with sensors, such as the Aquascan (630/9), so your customer can select lights ON, in movement sensor mode, or OFF. The rotary switch mechanism (EMRSWE) offers 6 marking plate options so you can tailor the product for the job. Current Rating: 16A, 16AX (fluoro). EMRSWE 15

16 SHUTTER SWITCH The ideal switch for controlling roller shutters or similar devices such as motorised blinds, awnings and curtains.Available in two options: Direct model (EC920) and Relay model (EC919). Both are rated 6A. EC919WE

EC923TWE EM802TDWE EM802TDWE Perfect for use in stairwells of apartment buildings and similar situations, this Time Delay Switch offers a simple 2 wire product that’s quick to program and works well with LED’s and CFL’s, delivering a flicker free result. Program one to ten minute time delays in one minute increments. The handy 770 module size means you can slot it into any normal switch hole. EC923TWE This switch allows you to program up to 8 weekly scenarios, making it the only choice for use in situations when lights need to be turned on and off at specific times such as schools, shops or sports facilities. It can also be used in conjunction with a motor such as a pool pump. Should the power go out, a working reserve will ensure the programming is maintained for 20 hours. TIME DELAY SWITCHES 17

18 EDV777WE EC787WE ECV777WE ECV777WE EC787XWE Add a surge protection module, 2OA switch or a USB charger – whatever mechanism you need! COMMON PLATE SERIES ED7774WE ED777ESWE ED777XWE DEDICATED PLATE SERIES POWERPOINTS The new Excel Life powerpoints all include internal safety shutters as a standard feature, ensuring extra peace of mind for your customers. There are plenty of innovations with you in mind as well: inline terminals on double GPOs and 4 corner fixing options simplify installation. For even greater flexibility on site, Excel Life powerpoints are available with an extra mechanism hole. Create the solution you need on the spot by adding the extra mechanism required, from a surge protection module to an oven switch. ED787WE EDV777XWE

19 EDV777WE 4 corner fixing options Inline terminals for faster installation.

21 EMPAWE EMPS1WE EMPS2WE EM803LEDWE EMPAPS1WE EMPAPS2WE LED INDICATOR KITS LED indicators that show at a glance “power available” and/or “power supplied” are ideal for hospitals and other medical facilities, factories, workshops and temporary building sites. The single 770 module mechanisms are pre-fitted with ‘quick fit’ lead ends that are ready to connect to the Excel Life sockets. Quickfit spade terminals on 777X models.

22 EMRJ45C5ERD EMRJ45C5EGR EMRJ45C5EBU TELEPHONE AND DATA JACKS CAT 3, CAT 5E, CAT 6 Available in white, yellow, black, blue, green or red, Excel Life jacks are compatible with both Krone and 110 DC termination tools – your choice. Cat 3 models provide an additional slot for easy telephone looping – rather than inserting 2 cables in 1 terminal. EMRJ11C3BL EMRJ45C5EYE EMRJ11C3WE Icon makes it easier for end-users to determine if it’s a phone or data jack.

AUDIO, COMPUTING AND TV SOCKETS The world of entertainment and computing is becoming more and more demanding. The Excel Life range of audio, computing and TV sockets is designed to meet this demand, with solutions that suit homes and commercial applications such as offices, boardrooms, hotel function rooms, and computing and audio shop applications. 25 EC920MSVIDWES-video outlet ECUSBWEUSB type A female outlet EC920VGAWEVGA outlet female connection EC910J35WE3.5 female audio outlet EM910USBWE EM910HDMIWEUSB type A female outlet and HDMI socket EC920LJWELoudspeaker outlet EC920HDMIWEHDMI socket EMRCAWEWERCA outlet, white F-type on rear EMRCAYELWERCA outlet, yellow F-type on rear EMRCARDWERCA outlet, red F-type on rear EMSPWEPAL to saddle TV outlet EMFFFOXWEF to F TV outlet Foxtel approved

BULKHEAD LIGHTS Perfect for corridor navigation. Available with red, blue, green and white LEDs. SIGNALLING Good signalling can increase the efficiency of a work environment, minimise costly disruptions and most importantly, prevent accidents. Excel Life offers 2 signalling solutions. SIGNAL LIGHTS Customise and update the graphic panel with ease. Simply print the symbol required on transparency paper and slot into the window. To make it even easier a PDF of commonly used symbols is available.Ideal for operating theatres, studios, test labs and other special access rooms. Available in white, blue, and red/green LEDs. EC572WE EC573WE EC571WE EC570WE EC524WE EC520WE EC521WE EC524WE 26

SKIRTING LIGHT Create a safe environment in stairwells and low level lighting environments, or highlight other potential hazards with the Excel Life Skirting Lights. Available in two models: Permanent Light (EC510WE) and Movement Sensor (EC511WE) with optional audio function perfect for aged care facilities with high safety requirements. 28 EC511WESkirting light with PIR sensor EC510WESkirting light

HOTEL APPLICATIONS Offer a more professional alternative to cardboard swing tags for your Hotel customers.The Hotel Guest Call Control is installed inside the room giving guests the ability to simply indicate: ‘do not disturb’ or ‘clean the room’. The Hotel Corridor Indicator, installed outside the room, signals the option to staff in the corridor. The new electronic key fob switches now include a 30 second time delay giving hotel guests time to comfortably exit or collect a few last belongings before all the lights turn off. EC925WEHotel guest room call control EC798WEShaver outlet EC920USB2WEUSB charger EC924WEHotel corridor call indicator ECKFSWEElectronic keyfob switch with 30 second time delay 29

30 COLOUR OPTIONS LIQUID GLOSS DIESEL (DI)Dedicated Plate Series only LIQUID GLOSS MALT (MA)Dedicated Plate Series only LIQUID GLOSS ICE (IC)Dedicated Plate Series only WHITE (WE) MATT SILVER (MS)Dedicated Plate Series only URBAN GREY (UG) Dedicated Plate Series only

31 Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices please contact your local HPM Legrand customer service representative 10 EDA770/1WE 16AX 230 - 240V a.c.1 gang architrave switch 10 EDA770/2WE 16AX 230 - 240V a.c.2 gang architrave switch 10 EDA770/3WE 16AX 230 - 240V a.c.3 gang architrave switch Architrave dedicated plate switches Dedicated plate switches horizontal 10 ED770/1HWE 1 gang switch 16AX230 - 240V a.c. 10 ED770/2HWE 2 gang switch 16AX230 - 240V a.c. 10 ED770/3HWE 3 gang switch 16AX230 - 240V a.c. 10 ED770/4HWE 4 gang switch 16AX230 - 240V a.c. 10 ED770/5HWE 5 gang switch 16AX230 - 240V a.c. 10 ED770/6HWE 6 gang switch 16AX230 - 240V a.c. Pack Cat No. Dedicated plate switches White Urban Grey Standard rocker switch mechanisms are 16AX fluoro rated 10 ED770/1WE ED770/1UG 1 gang switch 16AX230 - 240V a.c. 10 ED770/2WE ED770/2UG 2 gang switch 16AX230 - 240V a.c. 10 ED770/3WE ED770/3UG 3 gang switch 16AX230 - 240V a.c. 10 ED770/4WE ED770/4UG 4 gang switch 16AX230 - 240V a.c. 10 ED770/5WE ED770/5UG 5 gang switch 16AX230 - 240V a.c. 10 ED770/6WE ED770/6UG 6 gang switch 16AX230 - 240V a.c. 10 ED770/40DPWE ED770/40DPUG 1 gang double-poleswitch 40A,230-240V a.c. 10 ED770/40WE ED770/40UG 1 gang switch 40A, 230-240V a.c. Pack Cat No. Common plate switches White Standard rocker switch mechanisms are 16AX fluoro rated 10 EC770/1WE 1 gang switch 16AX230 - 240V a.c. 10 EC770/2WE 2 gang switch 16AX230 - 240V a.c. 10 EC770/3WE 3 gang switch 16AX230 - 240V a.c. 10 EC770/4WE 4 gang switch 16AX230 - 240V a.c. 10 EC770/5WE 5 gang switch 16AX230 - 240V a.c. 10 EC770/6WE 6 gang switch 16AX230 - 240V a.c. 10 EC770/40DPWE 1 gang double-pole switch 40A, 230-240V a.c. 10 EC770/40WE 1 gang switch 40A, 230-240V a.c. 6 EC914WE No Touch switch, 4A230-240V a.c. EC770/1WE Excel Life TM Light switches - common plate series Excel Life TM Light switches - dedicated plate series ED770/1WE ED770/2WE EC770/3WE ED770/4WE ED770/2HWE

32 Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices please contact your local HPM Legrand customer service representative Excel Life TM Shutter, blind, curtain switches, IP66 light switches EC914WE EC919WE Excel Life TM Electronic and mechanical mechanisms EM800SLAVEWE EM883WE Pack Cat No. Shutter, blind, curtain control 10 EC919WE Push button switch (via relay) 6A230-240V a.c. Rated 500W 10 EC920WE Push button switch (direct) 6AX(fluoro rated) 230-240V a.c. Rated 500W Pack Cat No. White Urban Grey 10 EM883WE EM883UG Electronic push button 5A, 230 - 240V a.c.Fluoro rated 500VA. 10 EM800SLAVEWE EM800SLAVEUG Secondary control push button 230 - 240V a.c. Electronic push button mechanisms See p36. for wiring diagrams Dedicated plate weatherproof IP66 switches 5 ED770/1IPWE 1 gang switch 16AX, 230-240V a.c. IP66 5 ED770/2IPWE 2 gang switch 16AX, 230-240V a.c. IP66 5 ED770/3IPWE 3 gang switch 16AX, 230-240V a.c. IP66 5 ED770/4IPWE 4 gang switch 16AX, 230-240V a.c. IP66 5 ED770/1IPUG 1 gang switch 16AX, 230-240V a.c. IP66 5 ED770/2IPUG 2 gang switch 16AX, 230-240V a.c. IP66 5 ED770/1HIPWE 1 gang horizontal switch16AX, 230-240V a.c. IP66 5 ED770/2HIPWE 2 gang horizontal switch16AX, 230-240V a.c. IP66 Common plate weatherproof IP66 switches 5 EC770/1IPWE 1 gang switch 16AX230-240V a.c. IP66 5 EC770/2IPWE 2 gang switch 16AX230-240V a.c. IP66 5 EC770/1HIPWE 1 gang horizontal switch 16AX230-240V a.c. IP66 5 EC770/2HIPWE 2 gang horizontal switch 16AX230-240V a.c. IP66

33 Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices please contact your local HPM Legrand customer service representative EM770BPASSWE EM770KITCHENWE EM770/20HWSWE EM770DAYNIGHTWE Excel Life TM Mechanical mechanisms Excel Life TM Mechanical mechanisms Mechanical mechanisms engraved Cat. No. Amp Rating Legend Pack White Urban Grey MARKED AS AIR CON 16AX SPDT 10 EM770AIRCONWE EM770AIRCONUG AIR CON 20A SPDT 10 EM770/20ACWE EM770/20ACUG AUTO/MAN 16AX SPDT 10 EM770AUTOMANWE EM770AUTOMANUG BED 1 16AX SPDT 10 EM770BED1WE EM770BED1UG BED 2 16AX SPDT 10 EM770BED2WE EM770BED2UG BED 3 16AX SPDT 10 EM770BED3WE EM770BED3UG BED 4 16AX SPDT 10 EM770BED4WE EM770BED4UG BYPASS 16AX SPDT 10 EM770BYPASSWE EM770BYPASSUG COOKTOP 32A SPST 10 EM770/32CTOPWE EM770/32CTOPUG DAY/NIGHT 16AX SPDT 10 EM770DAYNIGHTWE EM770DAYNIGHTUG DINING 16AX SPDT 10 EM770DININGWE EM770DININGUG D/WASH 16AX SPDT 10 EM770DWASHWE EM770DWASHUG EXHAUST 16AX SPDT 10 EM770EXHWE EM770EXHUG FAN 16AX SPDT 10 EM770FANWE EM770FANUG FRIDGE 16AX SPDT 10 EM770FRIDGEWE EM770FRIDGEUG GAMES 16AX SPDT 10 EM770GAMESWE EM770GAMESUG HEAT 16AX SPDT 10 EM770HEATWE EM770HEATUG HOB 16AX SPDT 10 EM770/32HOBWE EM770HOODUG HOB 32A SPST 10 EM770/32HOBWE EM770/32HOBUG HOOD 16AX SPDT 10 EM770HOODWE EM770HOODUG HOT PLATE 32A SPST 10 EM770/32HOTPWE EM770/32HOTPUG HWS 16AX SPDT 10 EM770/20HWSWE EM770/20HWSUG HWS 20A SPDT 10 EM770/20HWSWE EM770/20HWSUG KITCHEN 16AX SPDT 10 EM770KITCHENWE EM770KITCHENUG LIGHT 16AX SPDT 10 EM770LIGHTWE EM770LIGHTUG LIVING 16AX SPDT 10 EM770LIVINGWE EM770LIVINGUG LOUNGE 16AX SPDT 10 EM770LOUNGEWE EM770LOUNGEUG MICROWAVE 16AX SPDT 10 EM770MICROWAVWE EM770MICROWAVUG OFFICE 16AX SPDT 10 EM770OFFICEWE EM770OFFICEUG OVEN 32A SPST 10 EM770/32OVENWE EM770/32OVENUG RANGE 16AX SPDT 10 EM770/32RANGEWE EM770/32RANGEUG RANGE 32A SPST 10 EM770/32RANGEWE EM770/32RANGEUG RUMPUS 16AX SPDT 10 EM770RUMPUSWE EM770RUMPUSUG SENSOR 16AX SPDT 10 EM770SENSORWE EM770SENSORUG WASH 16AX SPDT 10 EM770DWASHWE EM770DWASHUG WASTE 16AX SPDT 10 EM770WASTEWE EM770WASTEUG ZONE 1 16AX SPDT 10 EM770ZONE1WE EM770ZONE1UG ZONE 2 16AX SPDT 10 EM770ZONE2WE EM770ZONE2UG ZONE 3 16AX SPDT 10 EM770ZONE3WE EM770ZONE3UG ZONE 4 16AX SPDT 10 EM770ZONE4WE EM770ZONE4UG NEW

34 Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices please contact your local HPM Legrand customer service representative White Urban Grey 10 EM770IMWE EM770IMUG Intermediate switch16A 230 - 240V a.c. 10 EM770IMLEDWE — Intermediate switchwith illuminatedBlue LED ring16A 230 - 240V a.c. 10 EM770RDWE EM770RDUG Single pole double throw with Red indicator16A flouro rated 16AX 230 - 240V a.c. 10 EM770DPWE EM770DPUG Double pole single throw 16A fluoro rated 10AX, 230 - 240V a.c. 10 EM770DPRDWE EM770DPRDUG Double pole single throwwith Red indicator16A flouro rated10AX 230 - 240V a.c. 10 EM770/20WE EM770/20UG Single pole single throw 20A fluoro rated 20AX, 230 - 240V a.c. 10 EM770/20RDWE EM770/20RDUG Single pole double throw with Red indicator dot20A fluoro rated 20AX230 - 240V a.c. 10 EM770/20DPWE EM770DPUG Double pole singlethrow 20A fluoro rated10AX, 230 - 240V a.c. 10 EM770/25WE EM770/25UG Single pole single throw 25A fluoro rated20AX, 230 - 240V a.c. 10 EM770/32WE EM770/32UG Single pole single throw 32A, fluoro rated 20AX, 230 - 240V a.c. 10 EM770/32RDWE EM770/32RDUG Single pole single throwwith Red indicator dot flouro 32A rated 20AX 10 EM770DUOWE EM770DUOUG 2 x single pole single throw 16Afluoro rated 10AX 230 - 240V a.c. EM770/32UGHEAT EM770/32OVEN White Urban Grey 10 EM770WE EM770UG Single pole double throw 16A fluoro rated 16AX, 230 - 240V a.c. 10 EM770/20ACWE EM770/20ACUG Single pole double throw 20A fluro rated 20AX, 230 - 240V a.c. Marked air con 10 EM770/ 32HOTPWE EM770/ 32HOTPUG Single pole single throw 32A fluro rated 20AX, 230 - 240V a.c. Marked hot plate 10 EM770/ 32CTOPWE EM770/ 32CTOPUG Single pole single throw 32A fluro rated 20AX, 230 - 240V a.c. Marked cook top 10 EM770/ 32OVENWE EM770/ 32OVENUG Single pole single throw 32A fluro rated 20AX 230 - 240V a.c. Marked oven 10 EM770- DUOHTWE EM770- DUOHTUG 2 x single pole single throw 16A fluro rated 10AX, 230 - 240V a.c. Marked heat Spring Return 10 EM770X- DOORWE EM770X- DOORUG Single pole double throw spring return 16A 230 - 240V a.c. Marked door 10 EM770X- PRESSWE EM770X- PRESSUG Single pole double throw spring return 16A 230 - 240V a.c. Marked press 10 EM770X- RESETWE EM770X- RESETUG Single pole double throw spring return 16A 230 - 240V a.c. Marked reset 10 EM770XWE EM770XUG Single pole double throw spring return 16A 230 - 240V a.c. Excel Life TM Mechanical mechanisms Pack Cat. No. Mechanical mechanisms Pack Cat. No. Mechanical mechanisms Excel Life TM Mechanical mechanisms EM770DUOWE EM770WE

35 Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices please contact your local HPM Legrand customer service representative White Urban Grey 10 EMRSWE EMRSUG Rotary switch mechanism - (all-in-one solution), comes with 6 marking plate options and 180°, 270° and 360° rings. 16A fluoro rated 16AX 230-240V a.c. Excel Life TM Mechanical mechanisms Keylock mechanisms Excel Life TM Plate installation dimensions Keylock mechanisms 10 EM820KLIOWE EM820KLIOUG Switch mechanism 1 gang keylock switch removable OFF or ON position 20A fluoro rated 20AX, 230 - 240V a.c. 10 EM820KLIWE EM820KLIUG Switch mechanism 1 gang keylock switch removable ON only 20A fluoro rated 20AX, 230 - 240V a.c. 10 EM820KLOWE EM820KLOUG Switch mechanism 1 gang keylock switch removable OFF only 20A fluoro rated 20AX, 230-240V a.c. BiLock ™ switch mechanism Suitable for high security applications. Can be installed on 1 gang plate or single powerpoint with 2 extra function holes blanking insert. 10 EM820BL1WE 1 Gang BiLock ™ switch Key removeable ‘ON’ only position 20A flouro rated 20AX 230 - 240V a.c. 10 EM820BL0WE 1 Gang BiLock ™ switch Key removeable ‘OFF’ only position 20A flouro rated 20AX 230 - 240V a.c. 10 EM820BL10WE 1 Gang BiLock ™ switch Key removeable ‘ON or OFF’ position 20A flouro rated 20AX 230 - 240V a.c. Mechanical keytag switch 1 EM770/20KT Single pole, single throw20A flouro rated 20AX230-240V a.c. EMRSWE EM770/20KT EM820KLIOWE EM820BLIWE Pack Cat. No. Rotory switch mechanisms Common plate series installation dimensions Dedicated plate series installation dimensions 74mm 118mm 10mm 96mm 56mm 74mm 118mm 10mm 96mm 56mm 77mm 121mm 10mm 96mm 56mm 77mm 121mm 10mm 96mm 56mm Glass and tile cut-out size Glass and tile cut-out size Key not supplied and must be sourced from approved BiLock™ locksmiths

36 Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices please contact your local HPM Legrand customer service representative Excel Life TM Switch Mechanisms Mechanical switch mechanism wiring diagrams 1 & 2 way (SPDT) EM770 Series 240V a.c. Cat. No. Legend Loop Amp Rating Body Colour EM770 SPDT 1L 16A/16AX Black EM770/20 SPDT 1L 20A/20AX Black Double Pole (DPST, DPDT) EM770DP Series 240V a.c. Cat. No. Legend Loop Amp Rating Body Colour EM770DP DPST 0L 16A/10AX Blue EM770/20DP DPST 0L 20A/10AX Blue Duo Series 2 x 1 Way (2 x SPST) 240Va.c. Cat. No. Legend Loop Amp Rating Body Colour EM770DUO 2xSPST 0L 16A/10AX White 1 way (SPST) EM770 Series 240V a.c. Cat. No. Legend Loop Amp Rating Body Colour EM770/32 SPST 1L 32A/20AX Grey Intermediate (DPXT - Crossover) EM770I Series 240V a.c. Cat. No. Legend Loop Amp Rating Body Colour EM770IM DPXT 0L 16A Red 2 1 3 4 2 1 C 2 1 1 1 2 2 1 1 2 2 1 1 2 2 Rear view Rear view Rear view Rear view Rear view Rear view 1 4 2 3 Rear view 2 1 C L LOOP 2 1 1 2 1 2 C L LOOP EM770 EM770/20 EM770DP EM770/20DP 2 WAY SWITCHING 2 1 L LOOP EM770/32 2 1 C L EM770IM EM770IM EM770IM 2 1 C L 4 2 1 3 4 2 1 3 4 2 1 3 MULTIWAY SWITCHING MORE THAN 2 SWITCHES (Any quantity of intermediate switches may be used). UP POSITION EM770IM 4 2 1 3 DOWN POSITION EM770IM 1 2 1 2 EM770DUO EM770 EM770/20 EM770 EM770/20 2 1 3 4 2 1 C 2 1 1 1 2 2 1 1 2 2 1 1 2 2 Rear view Rear view Rear view Rear view Rear view Rear view 1 4 2 3 Rear view 2 1 3 4 2 1 C 2 1 1 1 2 2 1 1 2 2 1 1 2 2 Rear view Rear view Rear view Rear view Rear view Rear view 1 4 2 3 Rear view 2 1 C L LOOP 2 1 1 2 1 2 C L LOOP EM770 EM770/20 EM770DP EM770/20DP 2 WAY SWITCHING 2 1 L LOOP EM770/32 2 1 C L EM770IM EM770IM EM770IM 2 1 C L 4 2 1 3 4 2 1 3 4 2 1 3 MULTIWAY SWITCHING MORE THAN 2 SWITCHES (Any quantity of intermediate switches may be used). UP POSITION EM770IM 4 2 1 3 DOWN POSITION EM770IM 1 2 1 2 EM770DUO EM770 EM770/20 EM770 EM770/20 2 1 C L LOOP 2 1 1 2 1 2 C L LOOP EM770 EM770/20 EM770DP EM770/20DP 2 WAY SWITCHING 2 1 L LOOP EM770/32 2 1 C L EM770IM EM770IM EM770IM 2 1 C L 4 2 1 3 4 2 1 3 4 2 1 3 MULTIWAY SWITCHING MORE THAN 2 SWITCHES (Any quantity of intermediate switches may be used). UP POSITION EM770IM 4 2 1 3 DOWN POSITION EM770IM 1 2 1 2 EM770DUO EM770 EM770/20 EM770 EM770/20 2 1 3 4 2 1 C 2 1 1 1 2 2 1 1 2 2 1 1 2 2 Rear view Rear view Rear view Rear view Rear view Rear view 1 4 2 3 Rear view 2 1 3 4 2 1 C 2 1 1 1 2 2 1 1 2 2 1 1 2 2 Rear view Rear view Rear view Rear view Rear view Rear view 1 4 2 3 Rear view 2 1 C L LOOP 2 1 1 2 1 2 C L LOOP EM770 EM770/20 EM770DP EM770/20DP 2 WAY SWITCHING 2 1 L LOOP EM770/32 2 1 C L EM770IM EM770IM EM770IM 2 1 C L 4 2 1 3 4 2 1 3 4 2 1 3 MULTIWAY SWITCHING MORE THAN 2 SWITCHES (Any quantity of intermediate switches may be used). UP POSITION EM770IM 4 2 1 3 DOWN POSITION EM770IM 1 2 1 2 EM770DUO EM770 EM770/20 EM770 EM770/20 2 1 C L LOOP 2 1 1 2 1 2 C L LOOP EM770 EM770/20 EM770DP EM770/20DP 2 WAY SWITCHING 2 1 L LOOP EM770/32 2 1 C L EM770IM EM770IM EM770IM 2 1 C L 4 2 1 3 4 2 1 3 4 2 1 3 MULTIWAY SWITCHING MORE THAN 2 SWITCHES (Any quantity of intermediate switches may be used). UP POSITION EM770IM 4 2 1 3 DOWN POSITION EM770IM 1 2 1 2 EM770DUO EM770 EM770/20 EM770 EM770/20

37 Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices please contact your local HPM Legrand customer service representative Excel Life TM Switch mechanisms Electronic push button switch wiring diagram EM883WE LOAD ACTIVE NEUTRAL REMOTE (optional) LED Indicator■ The colour of the LED indicator can be either red or blue. In addition, when the switch is off the LED indicator can either glow faintly or be off completely. The four possible modes are as follows: ■ To change between modes, press and hold the push button for at least 10 seconds. This will select the next mode in the sequence above. Mode Status of LED indicator Switch on Switch off 1 Bright red Faint red 2 Bright blue Faint blue 3 Bright red Off 4 Bright blue Off EM883 EM800SLAVE LOAD ACTIVE NEUTRAL REMOTE ACTIVE REMOTE LOOP LOAD ACTIVE NEUTRAL EM800SLAVE ■ Connect optional Secondary Control Buttons (EM800SLAVE) to enable switching from multiple locations. Minimum load = 10VA for all load types Incandescent Halogen 1200W 1200W Max load + 50°C + 0°C 230 - 240V a.c. 50Hz 1 x 2.5 mm² 2 x 1.5 mm² Fluorescent tube Wirewound transformer Electronic transformer Compact fluorescent LED Fan motor 500VA 500VA 500VA 500VA 500VA 500VA Important:An unlimited number of EM800SLAVE can be connected to an EM883. However, the total length of the remote wire used to interconnect all of the EM800SLAVE should not exceed 50 metres. Important:Power factor correction capacitors must be either removed or placed on the line side of the Electronic Push Switch. Technical characteristics

38 Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices please contact your local HPM Legrand customer service representative Excel Life TM Rotary switch - EMRSWE Installation Step 1 Step 2 Step 3 Step 4 not supplied Marking plate Locating ring 180 270 360 Rotation ring options Marking plate options 1 1 3 2 C Front View Rear View Output 1 Input ACTIVE Output 3 Output 2 3 2 0 1 1 3 2 C Front View Rear View Output 1 3 2 1 Front View Rear View 3 2 0 Input ACTIVE Output 3 Output 2 1 3 2 C Output 1 Input ACTIVE Output 3 Output 2 Select one of the following wiring options: POSITION WIRING 0 1 2 3 OFF ON ON ON Connect All Terminals OFF ON OFF ON Do Not Connect Terminal 2 Wiring for 360º rotation Wiring for 270º rotation 1 1 3 2 C Front View Rear View Output 1 Input ACTIVE Output 3 Output 2 3 2 0 1 1 3 2 C Front View Rear View Output 1 3 2 1 Front View Rear View 3 2 0 Input ACTIVE Output 3 Output 2 1 3 2 C Output 1 Input ACTIVE Output 3 Output 2 Select one of the following wiring options: POSITION WIRING 0 1 2 3 OFF ON ON ON Connect All Terminals Wiring for 180º rotation 1 1 3 2 C Front View Rear View Output 1 Input ACTIVE Output 3 Output 2 3 2 0 1 1 3 2 C Front View Rear View Output 1 3 2 1 Front View Rear View 3 2 0 Input ACTIVE Output 3 Output 2 1 3 2 C Output 1 Input ACTIVE Output 3 Output 2 Select one of the following wiring options: POSITION WIRING 1 2 3 ON ON ON Connect All Terminals ON OFF ON Do Not Connect Terminal 2 OFF ON ON Do Not Connect Terminal 1 ON ON OFF Do Not Connect Terminal 3 Flat side facing up Shaft flat facing up TYPE 1 TYPE 2 TYPE 3 TYPE 4 TYPE 5 TYPE 6

39 Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices please contact your local HPM Legrand customer service representative Pack Cat No. Push Button White Urban Grey Onboard programming allows the LED to be blue or red. 10 EM450UPWE EM450UPUG Electronic push button450VA universal load230 - 240V a.c. 10 EM400A3PWE EM400A3PUG Electronic push button 400VA all-load (neutral required) 230-240V a.c. Rotary New easy grip lower profile knob. Automatically dims if dimmer is overloaded or insufficiently derated 10 EM250TRWE EM250TRUG 250VA Trailing edge230 - 240V a.c. 10 EM400TRWE EM400TRUG 400VA Trailing edge230 - 240V a.c. 10 EM700TRWE EM700TRUG 700VA Trailing edge230 - 240V a.c. 5 EMDIMKNOBWE EMDIMKNOBUG Spare dimmer knobs kits of 5 10 EM2000ERC 2000VA leading-edge remote dimmer Excel Life TM Dimmers EM250TRWE EM700TRWE EM2000ERC EM450UPWE Excel Life TM Electronic push button dimmer - EM450UP 25 30 35 40 45 50 50 60 70 80 90 100 % Rating Installation air temperature (ºC) Important:When used in ambient temperatures greater than 25°C, the dimmer must be de-rated according to the following chart. Wiring ■ Connect optional Secondary Control Buttons (EM800SLAVE) to enable dimming from multiple locations. EM450UP ACTIVE REMOTE LOAD ACTIVE LOAD NEUTRAL TO ADDITIONAL EM800SLAVE EM800SLAVE ACTIVE REMOTE LOAD Important:An unlimited number of EM800SLAVE can be connected to an EM450UP. However, the total length of the remote wire used to interconnect all of the EM800SLAVE should not exceed 50 metres. Electronic push button dimmer EM450UP Technical characteristics Minimum load = 10VA for all load types Incandescent + 50°C + 0°C 230 - 240V a.c. 50Hz 1 x 2.5 mm² 2 x 1.5 mm² Halogen Max load Fluorescent tube Wirewound transformer Electronic transformer Compact fluorescent LED Fan motor 1 dimmer per plate 2 dimmers per plate 3 or more dimmers per plate 450W 450W 400W 400W 350W 350W 270VA 450VA 400VA 350VA 240VA 210VA

40 Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices please contact your local HPM Legrand customer service representative Excel Life TM Electronic push button dimmers EM400A3P Rotary dimmers - EM250TR/EM400TR/EM700TR Note: Compact Fluorescent Lamps (CFLs) and LCDs, also known as Energy Saving Lamps, can only be dimmed if they are specifically marked as "dimmable". Dimmable CFLs may have different characteristics from brand to brand, and so each brand may require a specific type of dimmer to operate correctly. Using the incorrect dimmer may cause the CFL to flicker. Please read the documentation that comes with each CFL carefully to ensure that the CFL and dimmer are compatible. For more information, please contact HPM Legrand. In some cases, the dimmable CFL may turn off or flicker when dimmed to a very low brightness. This can be overcome by ensuring that the dimmer brightness is not set too low. See "Setting minimum brightness" for instructions on how to achieve this. EM770 EM770 EM770 Wiring for rotary dimmers One-way wiring diagram Two-way wiring diagram Important:When used in ambient temperatures greater than 25°C, the dimmer must be de-rated according to the following chart. 25 30 35 40 45 50 50 60 70 80 90 100 % Rating Installation air temperature (ºC) Electronic push button dimmer EM400A3P Technical characteristics Minimum load = 3VA for all load types Rotary dimmers - EM250TR/EM400TR/EM700TR Technical characteristics ■ Incandescent ■ Halogen ■ Halogen or dimmable LED with electronic transformer ■ Dimmable compact fluorescent ■ Dimmable LED without transformer ■ Halogen or dimmable LED with wirewound transformer 2 Fluorescent tube Fan motor Max Power Max number of transformers 1 Max Power Max number of transformers Max load 1 dimmer per plate 400W 400VA 8 300VA 6 X X 2 dimmers per plate 350W 350VA 8 250VA 6 X X 3 or more dimmers per plate 300W 300VA 8 200VA 6 X X Max load EM250TR 1 dimmer per plate 250W 250W X X 250VA 250VA see note X X 2 dimmers per plate 225W 225W X X 225VA 225VA see note X X 3 or more dimmers per plate 200W 200W X X 200VA 200VA see note X X Max load EM400TR 1 dimmer per plate 400W 400W X X 400VA 400VA see note X X 2 dimmers per plate 350W 350W X X 350VA 350VA see note X X 3 dimmers per plate 300W 300W X X 300VA 300VA see note X X Max load EM700TR 1 dimmer per plate 700W 700W X X 700VA 700VA see note X X + 50 o C 230-240V a.c. 50Hz 1 x 2.5mm 2 2 x 1.5mm 2 + 0 o C Minimum load = 10VA for all load types

41 Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices please contact your local HPM Legrand customer service representative Pack Cat No. Time delay mechanisms White Urban Grey 10 EM802TDWE EM802TDUG Programmable time delay switch, 2 wire all load 400VA, 230 - 240V a.c.Can be programmed from 1-10 minutes in steps of 1 minute. 6 EC923TWE — Programmable time delay switch, 16A 230 - 240V a.c.Up to 8 weekly programmes, 20hrs working reserve 10 EM3FCWE EM3FCUG Fan controller, 3 speed, 100VA mechanism 10 ED3FCWE ED3FCUG Fan controller, dedicated plate, 3 speed, 100VA plate Excel Life TM Time delay switches Excel Life TM Time delay switches Wiring EM802TD ACTIVE LOAD ACTIVE LOOP LOAD EM802TD MOMENTARY PUSH SWITCH NEUTRAL Important:An unlimited number of EM770XWE can be connected to an EM802TD. However, the total length of the load wire used to interconnect all of the EM770XWE should not exceed 50 metres. ■ Connect optional Momentary Push Switches (EM870X) to enable switching from multiple locations. Minimum load = 10VA for all load types Electronic ballast only Technical characteristics EM802TD + 50°C + 0°C 230 - 240V a.c. 50Hz 1 x 2.5 mm² 2 x 1.5 mm² Incandescent Halogen Fluorescent tube Wirewound transformer Electronic transformer Compact fluorescent LED Fan motor Max load 400W 400W 400VA 400VA 400VA 400VA EM802TDWE EC923TWE

42 Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices please contact your local HPM Legrand customer service representative Pack Cat No. Dedicated plate powerpoints Internal safety shutters on all powerpoints. Powerpoints with extra hole ready to be equipped with 240V 770 module mechanisms such as EM803SURGEWE and EMPAPS1WE White Urban Grey 10 ED787WE ED787UG Single powerpoint 10A, 230 - 240V a.c. 10 ED787XWE ED787XUG Single powerpoint withextra function hole, 10A, 230 - 240V a.c. 10 ED787/2XWE ED787/2XUG Single powerpoint with 2 extra function holes, 10A, 230 - 240V a.c. 10 ED787/15WE ED787/15UG Single powerpoint 15A, 230 - 240V a.c. 10 ED787/20WE ED787/20UG Single powerpoint20A, 230 - 240V a.c. 10 ED787/25WE ED787/25UG Single powerpoint25A, 230 - 240V a.c. 10 ED787/32WE ED787/32UG Single powerpoint 32A, 230 - 240V a.c. 10 ED787A/15WE ED787A/15UG Single autoswitchpowerpoint15A, 230 - 240V a.c. 10 ED787/ARWE ED787/ARUG Single round-earth autoswitch powerpoint10A, 230 - 240V a.c. 10 ED787RWE ED787RUG Single round-earth powerpoint10A, 230 - 240V a.c. 10 ED787AWE ED787AUG Single autoswitch powerpoint 10A,230 - 240V a.c. 10 ED787DPWE ED787DPUG Single double-pole powerpoint 10A, 230 - 240V a.c. Pack Cat No. Dedicated plate powerpoints White Urban Grey 10 ED777WE ED777UG Double powerpoint 10A, 230 - 240V a.c. 10 ED777AWE ED777AUG Double autoswitch powerpoint 10A, 230 – 24V a.c. 10 ED777DPWE ED777DPUG Double powerpoint, double pole 10A, 230 – 24V a.c. 10 ED777XWE ED777XUG Double powerpoint with extra function hole, 10A, 230 - 240V a.c. 10 ED777/15WE ED777/15UG Double powerpoint 15A 230 - 240V a.c. 10 ED7774WE ED7774UG 4 gang powerpoint20A, 230 - 240V a.c. 10 ED777RWE ED777RUG Double round-earth powerpoint 10A, 230 - 240V a.c. 10 ED777ESWE ED777ESUG Double extra-safe powerpoint 10A, 230 - 240V a.c. ED777ASWE ED777ASUG Double extra-safe autoswitch powerpoint 10A, 230 – 24V a.c. Excel Life TM Powerpoints - dedicated plate series Excel Life TM Powerpoints - dedicated plate series ED777WE ED787XWE ED787/15WE ED787/2XWE ED7774WE ED777ESWE

43 Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices please contact your local HPM Legrand customer service representative Pack Cat No. Common plate vertical powerpoints 10 ECV777AWE Vertical doubleautoswitch powerpoint10A, 230 - 240V a.c. 10 ECV777WE Vertical double powerpoint 10A, 230 - 240V a.c. 10 ECV777XWE Vertical double powerpoint with extra function hole 10A, 230 - 240V a.c. 10 ECV787ARWE Vertical single autoswitchround-earth powerpoint10A, 230 - 240V a.c. 10 ECV787WE Vertical single powerpoint 10A, 230 - 240V a.c. 10 ECV787RWE Vertical singleround-earth powerpoint10A, 230 - 240V a.c. 10 ECV787XWE Vertical single powerpointwith extra function hole 10 ECV787/2XWE Vertical single powerpoint with 2 extra function holes 10A, 230 – 24V a.c. 10 ECV787/15WE Vertical single powerpoint 15A, 230 - 240V a.c. 10 ECV787A/15WE Vertical singleautoswitch powerpoint15A, 230 - 240V a.c. Excel Life TM Vertical Powerpoints ECV777WE ECV777AWE EDV777XWE Pack Cat No. Common plate powerpoints White Internal safety shutters on all powerpoints. Powerpoints with extra hole ready to be equipped with 240V 770 module mechanisms 10 EC777WE Double powerpoint 10A, 230 - 240V a.c. 10 EC777AWE Double autoswitch powerpoint 10A, 230 – 24V a.c. 10 EC777DPWE Double powerpoint, double pole 10A, 230 – 24V a.c. 10 EC777XWE Double powerpoint with extra function hole, 10A, 230 - 240V a.c. 10 EC777/15WE Double powerpoint 15A, 230 - 240V a.c. 10 EC777/15DPWE Double powerpoint double pole 15A, 230 – 24V a.c. 10 EC777/15XWE Double powerpoint with extra function hole, 15A, 230 - 240V a.c. 10 EC777RWE Double round-earth powerpoint 10A, 230 - 240V a.c. 10 EC787WE Single powerpoint 10A, 230 - 240V a.c. 10 EC787/15WE Single powerpoint 15A, 230 - 240V a.c. 10 EC787XWE Single powerpoint with extra function hole, 10A, 230 - 240V a.c. 10 EC787/2XWE Single powerpoint with 2 extra function holes 10A, 230 - 240V a.c. 10 EC787DPWE Single outlet double-pole powerpoint 10A, 230 - 240V a.c. 10 EC787/15DPWE Single outlet double-pole powerpoint 15A, 230 - 240V a.c. 10 EC787/15XWE Single powerpoint with extra function hole15A, 230 - 240V a.c. 10 EC787/20WE Single powerpoint 20A, 230 - 240V a.c. 10 EC787/25WE Single powerpoint25A, 230 - 240V a.c. 10 EC787/32WE Single powerpoint 32A, 230 - 240V a.c. 10 EC787AWE Single autoswitch powerpoint 10A 230-240V a.c. 10 EC787ARWE Single autoswitch round-earth powerpoint 10A, 230 – 24V a.c. 10 EC787A/15WE Single powerpoint 15A 230-240V a.c. 10 EC787RWE Single round-earth powerpoint10A, 23-240V a.c. Excel Life TM Powerpoints - common plate series White Urban Grey Dedicated plate vertical powerpoints 10 EDV777WE EDV777UG Vertical double powerpoint 10A, 230 - 240V a.c. 10 EDV777AWE EDV777AUG Vertical double autoswitch powerpoint 10A, 230 - 240V a.c. 10 EDV777XWE EDV777XUG Vertical double powerpoint with extra function 10A, 230 - 240V a.c. 10 EDV787WE EDV787UG Vertical single powerpoint 10A, 230 - 240V a.c. 10 EDV787RWE EDV787RUG Vertical single round-earth powerpoint 10A, 230 – 24V a.c. 10 EDV787ARWE EDV787ARUG Vertical single autoswitch round-earth powerpoint 10A, 230 - 240V a.c. 10 EDV787XWE EDV787XUG Vertical single powerpoint with 1 extra function hole 10 EDV787/15WE EDV787/15UG Vertical single powerpoint 15A, 230 - 240V a.c. 10 EDV787/2XWE EDV787/2XUG Vertical single powerpoint with 2 extra function holes 10 ED787A/15WE ED787A/15UG Vertical single autoswitch powerpoint 15A, 230 - 240V a.c. EC777WE EC787WE ES777WE Secure plate powerpoints 10 ES777WE Double powerpoint 10A, 230 - 240V a.c. 10 ES787WE Single powerpoint 10A, 230 - 240V a.c.

44 Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices please contact your local HPM Legrand customer service representative White Used in conjunction with Common Frame (ECFRAME), suitable cover plates and 1 module inserts. Also suitable for 2 module panel mount adaptor. Mech dim 57mm x 50mm 10 EM787WE Single powerpoint 10A, 230 - 240V a.c.mechanism only 10 EM787ARWE Single round-earth autoswitch powerpoint 10A, 230-240V a.c. 10 EM787A/15WE Single autoswitch powerpoint mechanism only15A, 230-240V a.c. 10 EM787U/20WE Single unswitched powerpoint 20A, 230-240V a.c. 10 EM787U/25WE Single gangunswitched powerpoint mechanism only25A, 230-240V a.c. 10 EM787U/32WE Single unswitched powerpoint mechanism only32A, 230-240V a.c. 10 EMV787WE Vertical single powerpoint mechanism only10A, 230-240V a.c. 10 EMV787AWE Vertical single autoswitch powerpoint mechanism only 10A, 230-240V a.c. 10 EMV787A/15WE Vertical single autoswitch powerpoint mechanism only 15A, 230-240V a.c. White Electresafe wall mount safety switch 4 ECEL10N2WE Electresafe 10mA wall mounted safety switch with 2 LED indicators Pack Cat No. Illumination kits White Urban Grey 10 EM770LEDWE EM770LEDUG EM770 illumination blue LED kit 230 - 240V a.c. 10 EM803LEDWE EM803LEDUG White LED and coloured lenses kit 230 - 240V a.c. 10 EMPAPS1WE EMPAPS1UG Power available and 1 gang power supplied indicator kit 230 - 240V a.c. 10 EMPAPS2WE EMPAPS2UG Power available and 2 gang power supplied indicator kit 230 - 240V a.c. 10 EMPAWE EMPAUG Power available indicator kit (Amber) 230 - 240V a.c. 10 EMPS1WE EMPS1UG Power supplied to 1 outlet indicator kit (Red) 230 - 240V a.c. 10 EMPS2WE EMPS2UG Power supplied to 2 outlets indicator kit 230 - 240V a.c. Excel Life TM Indicator kits Surge protection EM803LEDWE EM770LEDWE EMPAPS1WE EMPS2WE Excel Life TM Powerpoints - secure plate series Powerpoint mechanisms EM787AWE EM803SURGEWE White Urban Grey Surge protection 10 EM803- SURGEWE EM803- SURGEUG Mechanism surge protection module 500J, 230-240V a.c. White Urban Grey 10 EM787AWE EM787AUG Single autoswitch powerpointmechanism only10A, 230-240V a.c. Pack Cat. No. Powerpoint mechanisms

45 Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices please contact your local HPM Legrand customer service representative Excel Life TM Illuminated LED ring kits Click 1. Standard switch 2. Remove ring 3. Insert new ring 4. Screws must be fully screwed in 5. Align the slot and push 6. Engage in slot Installation EM770LED - LED 770 illumination kit Wiring LED Power Available/Power Supplied Indicator Kits EMPAPS2, EMPAPS1, EMPA, EMPS1, EMPS2, EM803LED Features ■ Voltage: 240V ~ ■ Frequency: 50Hz ■ Current: 1.2mA per indicator ■ Operating temperature: -5°C to +50°C ■ Storage temperature: -10°C to +70°C ■ Resistant to the following agents: Hexane, methylated spirits, soapy water, diluted ammonia, diluted pure bleach (10%), glass cleaning sustance, pre-impregnated wipes, diluted hydrogen peroxide ■ Not resistant to the following agents: Acetone, tar remover, trichloroethylene EMPA EMPS1 EM803LED EMPAPS1 EMPS2 EMPAPS2 Note: Low Impedance Load examples include incandescent, halogen, resistive loads High Impedance Load examples include CFL’s, LED globes LOAD LOAD LOAD LED on when “OFF” (Low Impedance Load) LED on when “ON” LED on “ALWAYS” N N N A A A LOAD LED on when “OFF” (High Impedance Load) N A Connector leads MUST be fully inserted Example of a fully inserted connector leads not supplied Click into this area Connector leads Installation EMPAPS2, EMPAPS1, EMPA, EMPS1, EMPS2, EM803LED LED Power Available/Power Supplied Indicator Kits Excel Life TM LED power supplied/power available indicator kits Wire/lead marking LED N LED L LED R LED A EMPAPS2 Neutral Switched Active (LHS) Switched Active (RHS) Active EMPAPS1 Neutral Switched active Active EMPA Neutral Active EMPS2 Neutral Switched Active (LHS) Switched Active (RHS) EMPS1 Neutral Switched active EM803LED (power available) ++ Neutral Active EM803LED (power supplied) Neutral Switched active EM803LED (power available without neutral) Switched active Active ++ = In this mode the LED indicator will be ON whenever there is power available to the product. = In this mode the LED indicator will only be ON whenever the associated switch/socket is OFF. The current required to light the indicator when the switch is ON will be bled through the load. LED N LED L LED R Active Terminal Wiring '~' = Power available (Amber) ' ' = Power supplied (Red) Example: EMPAPS2

46 Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices please contact your local HPM Legrand customer service representative Pack Cat No. RJ45 data sockets CAT 6 Compatible with both Krone and IDC termination tools 10 EMRJ45C6WE CAT 6, RJ45 data socketwhite 10 EMRJ45C6BL CAT 6, RJ45 data socketblack 10 EMRJ45C6BU CAT 6, RJ45 data socketblue 10 EMRJ45C6GR CAT 6, RJ45 data socketgreen 10 EMRJ45C6RD CAT 6, RJ45 data socketred 10 EMRJ45C6YE CAT 6, RJ45 data socketyellow Excel Life TM RJ11 Cat 3 voice sockets RJ45 Cat 5e sockets Pack Cat No. RJ11 voice sockets Additional slot available for looping. Compatible with both Krone and IDC termination tools 10 EMRJ11C3WE CAT 3 RJ11 voice socket white 10 EMRJ11C3BL CAT 3 RJ11 voice socket black 10 EMRJ11C3BU CAT 3 RJ11 voice socket blue 10 EMRJ11C3GR CAT 3 RJ11 voice socket green 10 EMRJ11C3RD CAT 3 RJ11 voice socket red 10 EMRJ11C3YE CAT 3 RJ11 voice socket yellow Excel Life TM RJ45 Cat 6 data sockets EMRJ11C3WE EMRJ11C3BL RJ45 data sockets CAT 5E Compatible with both Krone and IDC termination tools 10 EMRJ45C5EWE CAT 5E RJ45 data socket white 10 EMRJ45C5EBL CAT 5E RJ45 data socket black 10 EMRJ45C5EBU CAT 5E RJ45 data socket blue 10 EMRJ45C5EGR CAT 5E RJ45 data socket green 10 EMRJ45C5ERD CAT 5E RJ45 data socket red 10 EMRJ45C5EYE CAT 5E RJ45 data socket yellow EMRJ45C6RD EMRJ45C5EBU EMRJ45C5EGR EMRJ45C6YE

47 Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices please contact your local HPM Legrand customer service representative Excel Life TM TV outlets Keystone adapters EMFFFOXWE EMSPWE White Urban Grey 10 EMFFFOXWE EMFFFOXUG F to F TV outlet 75 ohm 3.0GHz (Foxtel approved) F30583 10 EMPFWE EMPFUG PAL to F TV outlet white 10 EMSPWE EMSPUG PAL to saddle TV outlet white White Urban Grey Keystone adapters 10 EMKEYSTONEAWE EMKEYSTONEAUG Suits Clipsal, Levtion, Hubbel, Siemens & Krone keystone jacks 10 EMKEYSTONEBWE EMKEYSTONEBUG Suits Panduit keystone jacks 10 EMKEYSTONECWE EMKEYSTONECUG Suits Systimax keystone jacks 10 EMKEYSTONEDWE EMKEYSTONEDUG Suits Tyco/AMP keystone jacks 10 EMKEYSTONEEWE EMKEYSTONEEUG Suits Molex keystone jacks Pack Cat. No. TV outlets EMKEYSTONEAWE EMKEYSTONEBWE Pack Cat No. Data, audio and video White Urban Grey 10 EMRCARDWE EMRCARDUG RCA outlet - red 10 EMRCAWEWE EMRCAWEUG RCA outlet - white 10 EMRCAYELWE EMRCAYELUG RCA outlet - yellow 10 ECUSBWE - USB type A female outlet 6 EC910J35WE - 3.5mm female audio outlet 4 EC920- HDMIWE - HDMI socket rear pluggable 8 EC920LJWE - Loudspeaker outlet IP41, 6mm terminal capacity 10 EC920- MSVIDWE - S-Video outlet mini din 10 EC920- VGAWE - VGA outlet female connection Excel Life TM Data, audio, video sockets and USB chargers EMRCARDWE EC920HDMIWE EC920LJWE EMUSB2PSWE HDMI and USB Inserts White Urban Grey Suitable for all custom AV applications. Used in conjunction with Common Frame (ECFRAME), or EC910GPLWE. Also can be used with Panel Mount adaptors. Insert dimension 57mm x 25mm 12 EMUSB2PSWE - Dual USB Charger Mechanism 12 EM910USBWE - USB insert with extension lead 150mm 12 EM910HDMIWE - HDMI insert with extension lead 150mm

48 Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices please contact your local HPM Legrand customer service representative Signalling 6 EC520WE Signal light white LED 1.0W max 230 - 240V a.c. 6 EC521WE Signal light blue LED 1.0W max 230 - 240V a.c. 6 EC524WE Signal light red/green LED 1.0W max 230 - 240V a.c. 4 EC570WE Bulkhead light red LED 230 - 240V a.c. 4 EC571WE Bulkhead light white LED 230 - 240V a.c. 4 EC572WE Bulkhead light green LED 230-240V a.c. 4 EC573WE Bulkhead light blue LED 230 - 240V a.c. USB chargers 3 EC920USB2WE Common plate dual socket USB charger 1500mA 3 ED920USB2WE Dedicated plate dual socket USB charger 1500mA Shaver outlet 2 EC798WE Common plate shaver outlet 22VA 230 - 240V a.c. Pack Cat No. Sensor lights White 4 EC511WE Skirting light with PIR sensor 1.3W max 230 - 240V a.c. 6 EC510WE Permanent skirting light 230 - 240V a.c. Excel Life TM Sensor lights and signalling USB charger Shaver outlet EC524WE ED571WE EC920USB2WE EC510WE Pack Cat No. Hospitality and commercial White 4 EC915WE Emergency stop push button1/4 turn 3AX 230 - 240V a.c. 10 EC917WE Buzzer 240V a.c. 6 EC918WE Electronic bell12-48V 10 EAKEYFOB Key fob 10 ECKFSWE Common plate series electronic key fob switch with 30 second time delay230 - 240V a.c. 10 EDKFSWE Dedicated plate series electronic key fob switch with 30 second time delay230 - 240V a.c. 10 EC20A/4KTWE Common plate series mechanical keycard 85mm x54mm switch white 4 x 20A 230-240V a.c. 10 ED20A/4KTWE ED20A/4KTUG Dedicated plate series mechanical keycard 85mm x54mm switch white 4 x 20A 230-240V a.c. 6 EC924WE Hotel corridor call indicator 6A, 230 - 240V a.c. 8 EC925WE Hotel guest room call control 10AX (fluoro rated) 230 - 240V a.c. 10 EM20A/4KTWE 20A 4 gang mechanical keycard switch mechanism Excel Life TM Hospitality and commercial EC918WE EC919WE EC924WE ECKFSWE Shutter, blind, curtain control 8 EC919WE Push button switch (via relay) 6A230-240V a.c. 8 EC920WE Push button switch (direct control) 6AX (fluoro rated) 230-240V a.c.

49 Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices please contact your local HPM Legrand customer service representative Pack Cat No. Dedicated plate series grids and plates White Urban Grey 10 ED770/0GPLWE ED770/0GPLUG Dedicated plate series blank grid and coverplate only 10 ED770/1GPLWE ED770/1GPLUG Dedicated plate series 1 gang grid and coverplate only 10 ED770/2GPLWE ED770/2GPLUG Dedicated plate series 2 gang grid and coverplate only 10 ED770/3GPLWE ED770/3GPLUG Dedicated plate series 3 gang grid and coverplate only 10 ED770/4GPLWE ED770/4GPLUG Dedicated plate series 4 gang grid and coverplate only 10 ED770/5GPLWE ED770/5GPLUG Dedicated plate series 5 gang grid and coverplate only 10 ED770/6GPLWE ED770/6GPLUG Dedicatedplate series 6 gang grid and coverplate only Excel Life TM Grids and plates Excel Life TM Grids and plates Pack Cat No. Common plate series grids and plates White 10 EC770/0GPLWE Common plate seriesgrid and cover only 10 EC770/1GPLWE Common plate series1 gang grid and coverplate only 10 EC770/2GPLWE Common plate series2 gang grid and coverplate only 10 EC770/3GPLWE Common plate series3 gang grid and coverplate only 10 EC770/4GPLWE Common plate series4 gang grid and coverplate only 10 EC770/5GPLWE Common plate series5 gang grid and coverplate only 10 EC770/6GPLWE Common plate series6 gang grid and coverplate only 10 ECCWGPLWE Deep mounting block and cover plate common series only ED770/1GPLWE ED770/4GPLWE ED770/6GPLWE EC770/0GPLWE EC770/2GPLWE EC770/3GPLWE EC770/1GPLWE

50 Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices please contact your local HPM Legrand customer service representative 10 EC910GPLWE 1 module grid and coverplate only57x25mm inserts 10 EC920GPLWE 2 module grid and coverplate only45x45mm inserts 10 ED920GPLWE 2 module grid and coverplate only45x45mm inserts White Excel Life TM Grids and coverplates Module and architrave Excel Life TM Grids and plates Pack Cat No. ES770/1GPLWE ES770/3GPLWE ES770/6GPLWE EC910GPLWE EC920GPLWE ED920GPLWE White Urban Grey Architrave dedicated plate series grid and plate 10 EDA771GPLWE EDA771GPLUG Dedicated plate series architrave 1 gang grid and coverplate only 10 EDA772GPLWE EDA772GPLUG Dedicated plate series architrave 2 gang grid and coverplate only 10 EDA773GPLWE EDA773GPLUG Dedicated plate series architrave 3 gang grid and coverplate only 10 EDA774GPLWE EDA774GPLUG Dedicated plate series architrave 4 gang grid and coverplate only Pack Cat No. Module grid and coverplate only Secure plate series grids and plates 10 ES770/0GPLWE Secure plate series grid and coverplate only 10 ES770/1GPLWE Secure plate series 1 gang grid and coverplate only 10 ES770/2GPLWE Secure plate series 2 gang grid and coverplate only 10 ES770/3GPLWE Secure plate series 3 gang grid and coverplate only 10 ES770/4GPLWE Secure plate series 4 gang grid and coverplate only 10 ES770/5GPLWE Secure plate series 5 gang grid and coverplate only 10 ES770/6GPLWE Secure plate series 6 gang grid and coverplate only White

51 Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices please contact your local HPM Legrand customer service representative Finish White ED787PLWE ED777PLWE ED777XPLWE ED777APLWE EDV787PLWE EDV777PLWE EDV777XPLWE EDV777APLWE Urban Grey ED787PLUG ED777PLUG ED777XPLUG EDV787PLUG EDV777PLUG EDV777XPLUG EDV777APLUG Matt Silver ED787PLMS ED777PLMS ED777XPLMS EDV787PLMS EDV777PLMS EDV777XPLMS Ice ED787PLIC ED777PLIC ED777XPLIC EDV787PLIC EDV777PLIC EDV777XPLIC Malt ED787PLMA ED777PLMA ED777XPLMA EDV787PLMA EDV777PLMA EDV777XPLMA Diesel ED787PLDI ED777PLDI ED777XPLDI EDV787PLDI EDV777PLDI EDV777XPLDI Finish White ED770/1PLWE ED770/2PLWE ED770/3PLWE ED770/4PLWE ED770/5PLWE ED770/6PLWE ED920PLWE EDCWPLWE Urban Grey ED770/1PLUG ED770/2PLUG ED770/3PLUG ED770/4PLUG ED770/5PLUG ED770/6PLUG ED920PLUG EDCWPLUG Matt Silver ED770/1PLMS ED770/2PLMS ED770/3PLMS ED770/4PLMS ED770/5PLMS ED770/6PLMS ED920PLMS EDCWPLMS Ice ED770/1PLIC ED770/2PLIC ED770/3PLIC ED770/4PLIC ED770/5PLIC ED770/6PLIC ED920PLIC EDCWPLIC Malt ED770/1PLMA ED770/2PLMA ED770/3PLMA ED770/4PLMA ED770/5PLMA ED770/6PLMA ED920PLMA EDCWPLMA Diesel ED770/1PLDI ED770/2PLDI ED770/3PLDI ED770/4PLDI ED770/5PLDI ED770/6PLDI ED920PLDI EDCWPLDI Excel Life TM Cover plates Liquid Gl os s Dedicated Plate Switches - cover plate only Dedicated Plate Powerpoints - cover plate only ED770/4PLWE ED920PLWE ESCWPLWE ED770/1PLMS ED787PLMS ED770/1PLDI ED777PLWE ED770/1PLIC ECCW2HPLWE ECCW4HPLWE Finish White ESCWPLWE Finish White ECCW- PLWE ECCW- 2WPLWE ECCW- 3WPLWE ECCW- 2HPLWE ECCW- 3HPLWE ECCW- 4HPLWE Common Plate Series - cover plate only Secure Plate Series - cover plate only

52 Whilst most items are stock lines some products are made to order. For delivery dates and latest prices please contact your local HPM Legrand customer service representative For pack quantity, please refer to numerical index pages. White Urban Grey 10 EMCCWE EMCCUG Cord clamp 10 EMCLIDWE EMCLIDUG Blank with clearcap suits 800 moduleUsed for circuit identification 10 EMIDWE EMIDUG Blank, suits 800 module Circuit identification labels to be used with EMCLIDWE/UG 10 10 10 10 EACIDLABELWE EACIDLABELBU EACIDLABELRED EACIDLABELYE White Blue Red Yellow 10 sheets (96 labels per sheet) 10 sheets (96 labels per sheet) 10 sheets (96 labels per sheet) 10 sheets (96 labels per sheet) Pack Cat No. Accessories 10 ECFRAME Common plate series frame 50 EAPP Transparent paint and damageprotection shell 1 EA751 Insulation shroud 1 EAPWDSCREW Public works department 1-4 gang mechanism retention kit 10 EAPWD5GKIT Public works department 5 gang mechanism retention kit 10 EAPWD6GKIT Public works department 6 gang mechanism retention kit 10 EM910RPWE Plug & cable retainer module white Excel Life TM Accessories EMCCWE EA751 ECFRAME Excel Life TM Panel mount adaptors Common frame inserts Pack Cat No. Panel Mount Adaptors White Suitable for panel mount installations From 0.3 to 3mm thick Used in conjunction with 1 module inserts and/or powerpoint mechanisms EA910PMAWE Single module panel mount adaptor EA920PMAWE Two module panel mount adaptor Common Frame Inserts White Urban Grey One module inserts for custom made applications. Insert dimension 57mm x 25mm 10 EA910/0WE EA910/0UG Single module blank insert 10 EA910/1WE EA910/1UG Single module insert with one function hole EA910/2WE EA910/2UG Single module insert with two function holes

53 10 EA143/2W 2 gang horizontal stud-bracket 10 EA143/3W 3 gang horizontal stud-bracket 10 EA143/2H 2 gang vertical stud-bracket 10 EA143/3H 3 gang vertical stud-bracket 10 EA143/4H 4 gang vertical stud-bracket 10 EA503/2W 2 gang horizontal render-bracket 10 EA503/3W 3 gang horizontal render-bracket 10 EA503/2H 2 gang vertical render-bracket 10 EA503/3H 3 gang vertical render-bracket 10 EA503/4H 4 gang vertical render-bracket Whilst most items are stock lines some products are made to order. For delivery dates and latest prices please contact your local HPM Legrand customer service representative For pack quantity, please refer to numerical index pages. Excel Life TM Accessories Brackets Pack Cat No. Accessories - multi-gang brackets

HPM Legrand Australia Building 4, Nexus Industry Park 43-47 Lyn Parade, Prestons NSW 2170 % : 1300 369 777 www.excellife.com.au www.legrand.com.au HPM Legrand - New Zealand 106-124 Target Road Glenfield, Auckland 0627 % : 0800 476 009 www.excellife.co.nz www.legrand.co.nz 05/14

Published: 16 December 2014 Category: Product Catalogues
