S 8 94 Pack Cat No. Plug bases, surface, 240V a.c.Mounting centres: 50mm. Size 65mm dia x 48mm high.Standard colour is clear. 10 37 10A plug base, 3 pin flat, includes Cat. No. 37B snap-on base plate. 10 37/15 15A plug base, 3 pin flat 10 37R 10A plug base, 3 pin, round earth, flat active & neutral 10 37B Snap-on base plate for Cat. No. 37 range.  Also fits Cat. No. 366, 80 & 33 Section 8 Pack Cat No. Colour codes:BL (Black), CL (Clear), GY (Grey), WE (White)Large finger-grip, rigid, impact-resistant moulding, 240V a.c. 10 90 10A plug top, 3 pin flat (BL,WE) 10 90/15 15A plug top, 3 pin flat (BL, GY, WE) 10 90/20 20A plug top, 3 pin flat (GY,WE) 10 90/25 25A plug top, 3 pin, L-shaped earth, flat active and neutral (WE) 10 90R 10A plug top, 3 pin, round earth, flat active and neutral (WE) 10 94 10A plug top, 4 pin plug for use with Cat. No 33 and 34 series. Available in white only (WE) Pack Cat No. Flexible PVC cover with cord locking nut, and screwed clamp terminals, 240V a.c. 10 100L 10A plug top, 3 pin flat, locking nut, 8mm entry hole (BL, CL, GY, WE) 10 100LHD 10A plug top, 3 pin flat,10mm entry hole for 15A heavy duty cord (CL, GY) 10 100/8 10A plug top, 3 pin flat, figure 8 wire (BL, WE) 10 100R 10A plug top, 3 pin, round earth, flat active & neutral (BL, CL, GY, WE) 10 100/2R 10A plug top, 3 pin, flat earth, round active & neutral (CL, GY, WE) 10 100L15 15A plug top, 3 pin flat (CL, GY, WE) Pack Cat No. Low profile side entry with 45˚ cord entry and screwed clamp terminals, 240V a.c. 10 106/1 10A plug top, 3 pin flat. (BL, GY, WE) 10 106/2 10A plug top, 3 pin flat, accepts 15A heavy duty flexible cord. (WE) 10 106/3 15A plug top, 3 pin flat (BL, WE) 10 106/4 20A plug top, 3 pin flat (WE, GY) 10 106/5 25A plug top, 3 pin, L-shaped earth, flat active & neutral (WE) 10 106/6 10A plug top, 3 pin, round earth, flat active & neutral (WE) 10 106/7 10A plug top, 3 pin, flat earth, round active & neutral (WE) 10 106/8 32A plug top, 3 pin, U-shaped earth, flat active & neutral (WE) Plugs, Bases & Sockets  Plug bases Plug tops 90 106/1 100L 37

S 8 95 Section 8 Pack Cat No. 4 pin plug surface bases, 240V a.c. 10 33 10A 4 pin plug base with looping terminal. 50mm mounting centres. 69 x 69 x 46mm. (WE) 10 33B Snap-on base plate for Cat. No. 33 range. 58mm mounting centres. 114 x 70mm. (CL) 10 34B Snap-on base plate for Cat. No. 34 range. 91mm mounting centres. 150 x 70mm (CL) Pack Cat No. Plug base and plate assembliesMounting centres: 95mm. Suits standard mounting accssoiries. Can be mounted horizontally or vertically. Size: 114 x 70mm. 10 38/1 10A, Cat. No. 38 plug base on plate (BL. RED, WE) 10 38/115 15A, Cat. No. 38/15 plug base on plate (WE) 10 38/1R 10A, Cat. No. 38R plug base on plate (WE, RED) 10 38/120 20A, Cat. No. 38/20 plug base on plate (WE) 10 38/12R 10A, Cat. No. 38/2R plug base on plate (WE) 1 38/1PL Plate only suit 38 series (WE) Pack Cat No. Plug bases for panel or flush mounting, 240V a.c.Supplied as base mechanism plus front plate. Size: 38mm dia x 25mm deep. Minimum order quantities may apply - please check prior to ordering 10 38 10A plug base, 3 pin flat, suits panel thickness of 2.5mm (BL, MG, WE) 10 38A0 10A plug base, 3 pin flat, suits panel thickness of 1.0mm (BL, WE) 10 38A1 10A plug base, 3 pin flat, suits panel thickness of 1.2mm (BL, WE) 10 38A2 10A plug base, 3 pin flat, suits panel thickness of 1.5mm (WE) 10 38A3 10A plug base, 3 pin flat, suits panel thickness of 1.6mm (BL, WE) 10 38A4 10A plug base, 3 pin flat, suits panel thickness of 2.0mm (WE) 10 38A5 10A plug base, 3 pin flat, suits panel thickness of 2.2mm (WE) 10 38R 10A plug base, 3 pin, round earth, flat active & neutral, suits panel thickness of 2.5mm (WE) Plugs, Bases & Sockets  Pack Cat No. 3 pin plug surface bases, low profile, 240V a.c. 10 35 10A surface base, 3 pin flat (BR, BL, WE) 10 38/2R 10A plug base, 3 pin, flat earth, round active & neutral, suits panel thickness of 2.5mm (WE) 10 38/15 15A plug base, 3 pin flat, suits panel thickness of 2.5mm (BL, WE) 10 38/20 20A plug base, 3 pin flat, suits panel thickness of 2.5mm (WE) 10 38/25 25A plug base, 2 pin flat with L earth pin, suits panel thickness of 2.5mm (WE) Pack Cat No. Double Plug bases, surface, 240V a.c.Mounting centres: 84mm. Size 111mm dia x 69mm high. 5 37/2 10A double plug base (base included) Available in Clear (CL) and Black (BL) 5 37/215 15A double plug base (base included) Available in Clear (CL) 37/2 35 38/15 38/1 33 NEW

S 8 96 Pack Cat No. BC cord grip, 240V. Colour codes: BL (Black), WE (White) 10 333 Lampholder, cord grip, supplied with long skirt, (Cat. No. 333SK) (BL, WE) Lampholders Section 8 Plugs, Bases & Sockets  Pack Cat No. 240V. a.c. To suit B22 bayonet cap lamps. Supplied with long skirt, (Cat. No. 333SK).  Battenholder, 4 terminals 10 360 Adjustable angle battenholder, 4 large terminals. 64mm dia base. 50mm mounting centres. (WE) 5 360/W1 Adjustable angle battenholder, IP23. 4 terminals. Integral anchor plugs. 50mm mounting centres. (WE) 10 366 Battenholder, 4 terminals, standard 68mm dia base. 50mm mounting centres. (WE) 10 366S Safety battenholder, 4 terminals, standard 68mm diameter base. 50mm mounting centres. (WE) 10 366Y Battenholder, 4 terminals, integral fix-fast anchor plugs,standard 68mm dia base. 50mm mounting centres. (WE) 10 366LY Battenholder, 4 terminals, separate fix-fast anchor plugs, standard 68mm dia base. 50mm mounting centres. (WE) 10 368 Battenholder, 4 terminals, 90mm  dia base. 50mm mounting centres. (WE) 10 368/1 Battenholder, 4 terminals, 90mm  dia base. 70mm mounting centres. (WE) Battenholders Pack Cat No. Elbow plug socket 10 39 10A elbow plug socket Pack Cat No. Latching cover ceiling roses, 240V a.c.  10 80 Ceiling rose, 4 way connection. Easily wired with connectors supplied. 68mm dia x 44mm high. (WE) Screw-on cover ceiling roses, 240V a.c.Size: 65mm dia x 37mm high. 10 84 Ceiling rose 10A, 4 plate x 2 post per plate (BL, BR, WE) Large screw-on cover type, 240V a.c.Size: 92mm dia x 36mm high. 10 78 Ceiling rose 10A, 4 plate x 2 posts per plate (WE) Ceiling roses Pack Cat No. Flexible PVC cover with safety skirt, cord locking nut and screwed clamp terminals, 240V a.c.Colour codes: BL (Black), Cl (Clear), GY (Grey), WE (White). 10 7P 10A extension socket, 3 pin flat, 8mm entry hole (BL. CL, GY, WE) 10 7P15 10A extension socket, 3 pin flat, 10mm entry hole (CL, GY, WE) Extension sockets 7P 39 8084 366 333

S 8 97 Section 8 Pack Cat No. Switched lampholders - tapered cap - top cable entry240V a.c. Double pole push bar switch with red dot indication. Supplied with long skirt, (Cat. No. 333SK). 10 310 Switched lampholder with 1/2 inch brass thread with nipple (WE) 10 310/10 Switched lampholder with 10mm thread (1.0mm pitch) (WE) Plugs, Bases & Sockets  Pack Cat No. Tapered cap - top cable entrySupplied with long skirt, (Cat. No. 333SK) 10 359/10 Lampholder with 10 mm thread (1.0 mm pitch) (WE) Pack Cat No. Festoon lampholdersMounting centres: 50mm. 3A, 240V a.c.. BC with side entry cable, wire piercing connections. Overall height 65mm. 10 303/1F Lampholder with fanged screw-on cap & long skirt, (Cat. No. 333SK) (BL) 10 WS303/1R Lampholder with round screw-on cap & rubber skirt for weatherproofing (BL) 10 WS303/1F Lampholder with fanged screw-on cap & rubber skirt for weatherproofing (BL) Pack Cat No. Lampholder skirts 10 333SK Lampholder skirt (long), 37 mm (WE) Lampholder accessories 359/10 310 303/1F 333SK
