3 CONTENTS 2 WIRE SYSTEM  General features  4 Entrance panel range  6 Handset range  8 Catalogue (entrance panels)  11 Composition tables (entrance panels)  25 Catalogue (handsets)  30 Catalogue (system accessories)  39 AUDIO AND VIDEO KITS  45 DESIGN SOFTWARE & TECHNICAL SUPPORT  53 TECHNICAL DATA  54 DIMENSIONAL DATA  88 NUMERIC INDEX  99 2  WIRE  DOOR  ENTR Y  SY STEM  CA T ALOGUE  -  C ONTENT S

4 2 WIRE SYSTEM  General features YOUR JOB IS EASIER The 2-WIRE system is easy to use.  Thanks to the polarity  insensitive 2-wire wiring used in each part of the  system, connection is simple, quick, and error-proof.  There will be no more mistakes, and therefore no need  to waste time in subsequent adjustments. HIGH PERFORMANCES Thanks to the 2-WIRE technology, it is possible to install  with the same ease any type of systems, from those in  single villas, to those for whole groups of apartment  blocks.  Also, thanks to the possibility of using the  existing cables, it represents the ideal solution when  refurbishment existing systems. The villa The apartment The group of apartment blocks The group of houses 600 metres Entrance panel Farthest handset 600  3900 Apartments 3900 Apartment videoentrance panels 15 Handsetsper apartment 39 Risers with indepedentsound mode 96 Video entrancepanels THE SYSTEM MAY INCLUDE:

5 5 5 2  WIRE  DOOR  ENTR Y  SY STEM  CA T ALOGUE  -  GENERAL  FEA TURES MAXIMUM VERSATILITY The 2-WIRE system has been  conceived to ensure a high level of  versatility, to meet the needs of each  and every customer.   The 2-WIRE technology enables  installing a door entry system  already preset for future conversion  into a video system, and is ideal  when a mixed audio/video system  is required, to meet the needs of  individual residents.  The system  also offers a wide range of entrance  panels and handsets, to meet all  the needs of the customer: from the  basic door entry system functions,  to the more advanced ones, to the  integration with MY HOME home  automation applications, or look  integration with BTicino residential  series. INTEGRATION WITH IP TECHNOLOGY IP and 2-WIRE technologies may be  integrated, for the realisation of large  projects.  Thanks to the dedicated LAN  network, IP technology offers high  system performances: long distances,  multichannel operation, switchboard  software and centralised alarm  notification. IP to 2 WIRE interface Switchboard software

6 SFERA MONOBLOC The versatility of SFERA combined with the  steel or brass monolithic front cover, for  prestigious small and medium size solutions. Entrance panel range 2 WIRE SYSTEM VERSATILITY SFERA MODULAR The solution for every installation  need: from the single villa, to the  large residential complex.

7 7 7 2  WIRE  DOOR  ENTR Y  SY STEM  CA T ALOGUE  -  GENERAL  FEA TURES EXCLUSIVITY AND LUXURY AXOLUTE OUTDOOR The luxury and refinement of AXOLUTE,   also outside the building. It’s the ideal  solution for large prestigious complexes. VILLA SOLUTION LINEA 2000 METAL Elegant and strong, enhanced by the zamak  finish, it’s the ideal solution for the villa. LINEA 2000 The basic solution in a smaller size, for  one-family or two-family homes. SFERA VANDAL-RESISTANT It’s the entrance panel with a rigorous  shape, emphasized by the vandal- resistant stainless steel front cover.  Equipped with digital call, it’s ideal  for large groups of apartment blocks.  VANDAL RESISTANT

8 Handset range 2 WIRE SYSTEM TECHNOLOGY AND INTEGRATION AXOLUTE  MULTIMEDIA TOUCH SCREEN Large 10” touch display for control and  display of video door entry system and MY  HOME functions.  PERFECT INTEGRATION WITH RESIDENTIAL LINES AND THE MY HOME FUNCTIONS The video handset has been conceived as an integral part of the residential series and home control terminal.   Available in two versions: VIDEO DISPLAY and VIDEO STATION. VIDEO DISPLAY The VIDEO DISPLAY terminal is  characterised by its compact size.  With handsfree technology, it’s  flush mounted using the same  procedure used for a light point.  Available in AXOLUTE versions. VIDEO STATION The wall mounted handsfree solution  featuring a large display. Available in  two versions. VIDEO STATION Nighter & Whice  feature an exclusive and elegant  design, where glass is the main  element.  AXOLUTE VIDEO STATION has instead  been conceived for integration with  the AXOLUTE residential series.

9 9 9 2  WIRE  DOOR  ENTR Y  SY STEM  CA T ALOGUE  -  GENERAL  FEA TURES TECHNOLOGY AND COMFORT TRADITIONAL POLYX RANGE Handsfree range with a modern  and minimalist design, well  suited to every style of home:  the range extends from the basic  audio and video versions to the  advanced version, which offers the  management of video door entry  system memory and of the MY HOME  functions. POLYX is the first video door entry  system range designed following  PIVOT The traditional range with a receiver  for every installation requirement:  wall mounted, flush mounted, and  table-top versions. SWING A range characterised by a classic  and elegant design. The B/W basic  video version has been conceived  as the perfect standard specification  solution.   The range is completed by the audio  and colour video version.  SPRINT AUDIO The audio receiver meeting the  standard specifications. the “for all” design criteria: multi-sensor notifications and accurate  ergonomic design are the distinguishing traits of POLYX.

10

11 1 11 1 2  WIRE  DOOR  ENTR Y  SY STEM  CA T A L OGUE  -  CA T A L OGUE CONTENTS 2 WIRE CATALOGUE - ENTRANCE PANELS AXOLUTE outdoor  12 SFERA function modules  13 SFERA vandal-resistant  15 SFERA modular  17 SFERA monobloc covers  21 LINEA 2000 METAL  23 LINEA 2000  24 COMPOSITION TABLES  25

12 339313 349140 339313 FLUSH MOUNTED BOX WITH TEARING PROTECTION ELECTRONIC MODULE SURROUND PLATE + FRAME TRANSPONDER KEYS AND PROGRAMMER  Item Description 339313  3 module flush mounted steel box with tearing protection. The SFERA 3 module flush mounted box, item 331130, may also be used in alternative Item Description 349140   outdoor AXOLUTE electronic module. Device also suitable for use in IP systems. It’s fitted with capacitive soft touch control backlit keypad, motorised colour camera (which swivelling operation can be controlled from the preset handsets), colour display with home page that can be fully customised by the installer, and transponder reader for the release of the door lock, which may also be activated using a numeric code for residents. Module to be finished with flush mounted box, item 339313, and surround plate, item 339213 (steel). TiAxoluteOutdoor and TiContacts programming software, residents’ address book creation, and configuration supplied. By locally installing a permanent cable with RJ45 socket (T568B type cross connection), it is possible to update the residents address book and the configuration, without removing the pushbutton panel. The device meets the following characteristics: Protection index IP54, protection index against mechanical impact IK07 Item Description 339213  3-module surround plate + frame in steel finish. Anti-tamper assembly/disassembly safety key supplied Item Description 348200   black transponder key  348201   red transponder key  348202  green transponder key  348203  blue transponder key  348204   orange transponder key  348205   grey transponder key  348206   yellow transponder key  348402   table-top transponder key programmer  339213 348402 348402 348200 348204 348201 348205 348202 348206 348203 2 WIRE SYSTEM AXOLUTE outdoor entrance panels Flush mounted digital call video entrance panel available in STAINLESS STEEL finish. Protection index: IP54. Protection index against mechanical impact: IK07 349140

13 1 13 3 2  WIRE  DOOR  ENTR Y  SY STEM  CA T A L OGUE  -  CA T A L OGUE 2 WIRE SYSTEM SFERA function modules 342640 342200 342240 WARNING: assembly note: flush mounted boxes, wall mounted enclosures, rainshield, front cover, and surround plates are the same as for 2-WIRE SFERA entrance panels (refer to the specific section in the catalogue) Item Description 342170  digital speaker module with two call pushbuttons and a pushbutton to control the staircase light relay actuator. The connections to the system are made by wiring the removable clamp supplied; also the nameplates are lit up by 8 green LED. A closing card is supplied to be inserted in the last pushbutton module.  Item Description 342630  digital alphanumeric call + speaker module. Can send the call to an handset by scrolling the residents’ names or codes on a display using the dedicated keys. Combines the functions of digital speaker module and alphanumeric keypad in one single device. The module can save up to 2000 residents’ names and surnames associating them to the apartment SCS address. 500 names can be saved when the option of coupling a message with them is selected. If only the residents’ codes are saved, the capacity extends to 5000 codes NOTE: for the programming use a PC with TICALL software installed (can be  downloaded free from the www.bticino.it site) and the interfaces item 335919  (RS-232) – item 3559 (USB), or the infrared remote control item 392123 Item Description 342640  extra alphanumeric keypad to be used together with module Item 342630. It can call the resident directly (by typing the programmed code) and access the door lock release function (by typing the secret code). It is supplied with multi-cable and connector for connection to the speaker module Item Description 342200  digital nameplate module which can be used to enter the street number or any other information. Can be used to enter a caption in entrance panels with numeric call module item 342610 Item Description 342240  digital pushbutton module with 4 call pushbuttons. The connections to the system are made using the multi-cable supplied; also the nameplates are illuminated by 12 green LED SPEAKER MODULE DIGITAL CALL SPEAKER MODULE WITH GRAPHIC DISPLAY ADDITIONAL ALPHANUMERIC KEYPAD MODULE NAMEPLATE MODULE  PUSHBUTTON MODULE  342170 342630

14 Item Description 342610  the numeric call module can make calls from the entrance panel to handsets by just keying in the number corresponding to the handset required. In practice it works like making a telephone call on a normal telephone. The correspondence between the numbers and the user names is found from a phone book by the side of the module and made up of nameplate modules Item 342200. From one to four numbers may be keyed in to make the call, as programmed by the installer. The module can also activate the electric door lock by means of a secret code number. The module is supplied with a multicable for the connection to the speaker module Item Description 342600  module which can send the call choosing the name of the audio handset in a list which is shown on a display. It can also release the door locks by typing a code. The module is supplied with a multicable for the connection to the phone module Item Description 332650  code-lock module that can be used both in analogue and digital systems. This module opens and closes two relays by keying in two code numbers Item Description 346220  accessory which can be installed in the camera module when there are several video entrance panels in series Item Description 342510  camera module with IR lighting for night views. The lens viewing angle can be adjusted horizontally and vertically by ±20° in the installation phase Item Description 342550  camera module with lighting with white LED for night views. The lens viewing angle can be adjusted horizontally (± 20°) and vertically (±15°) during installation NUMERIC DIGITAL CALL MODULE ALPHANUMERIC DIGITAL CALL MODULE CODE-LOCK MODULE ACCESSORY FOR CAMERA MODULES SWIVEL B/W CAMERA MODULE SWIVEL COLOUR CAMERA MODULE 332650 342600 342510 346220 342610 342550 2 WIRE SYSTEM SFERA function modules

15 1 15 5 2  WIRE  DOOR  ENTR Y  SY STEM  CA T A L OGUE  -  CA T A L OGUE Item Description 333714  pushbutton panel consisting of galvanized sheet metal flush mounted box, module holder, and front cover in 316L stainless steel with bright finish. It must be fitted with digital call speaker module with graphic display, item 342630 .  The display screen is made of scratch-resistant polycarbonate glass  (5 mm thick)  The three pushbuttons (diam. 16 mm) are made of 316L stainless steel  Item Description 333914  pushbutton panel consisting of galvanized sheet metal flush mounted box, module holder, and front cover in 316L stainless steel with bright finish. It must be fitted with digital call speaker module with graphic display + camera module, (items 342630 + 342510/342550).  The display screen is made of scratch-resistant polycarbonate glass  (5 mm thick)  The three pushbuttons (diam. 16 mm) are made of 316L stainless steel AUDIO PUSHBUTTON PANEL VIDEO PUSHBUTTON PANEL 333714 333914 342630 342510 b/w342550 colour 342630 2 WIRE SYSTEM SFERA vandal-resistant front covers 342630 342630 Item Description 333915  pushbutton panel consisting of galvanized sheet metal flush mounted box, module holder, and front cover in 316L stainless steel with bright finish. It must be fitted with digital call speaker module with graphic display + camera module, (items 342630 + 342510/342550).  The display screen is made of scratch-resistant polycarbonate glass  (5 mm thick)  The three pushbuttons (diam. 16 mm) are made of 316L stainless steel. Includes an additional alpha-numeric keypad. VIDEO PUSHBUTTON PANEL 333915 342510 b/w342550 colour 342630 342630 333915 included with 333915

16 2 WIRE SYSTEM SFERA vandal-resistant front covers 3 EXAMPLE OF VIDEO MODULARITY - SFERA VANDAL-RESISTANT  3 3 3 vandal-resistant front cover(video) display glass digital call module with graphic display module-holder frame 2 metal flush  mounted box 1 camera  module call forward key address book scroll key (up) address book scroll key (down) 1 1 2 2 2 va d nd l al res i is t ta t nt f fro t nt cover d d di d d di w w w m m fr fr fr c c ca m m m a a a a ad a c c ca

17 1 17 7 2  WIRE  DOOR  ENTR Y  SY STEM  CA T A L OGUE  -  CA T A L OGUE 331130 331431 A B A B 331331 A B C C C FLUSH MOUNTED BOX + FRAME     Dimensions (mm) Item Modules  A  B  C 331110 1  117  123  45 331120 2  117  214  45 331130 3  117  306  45 WALL MOUNTED ENCLOSURE WITH RAINSHIELD       Dimensions (mm) Item  Modules  No. of columns  A  B  C 331311 1  1  155  160  92 331321 2  1  155  255  92 331331 3  1  155  360  92 331341 4  2  290  255  92 331361 6  2  290  360  92 331391 9  3  430  360  92 RAINSHIELD (OPTIONAL)       Dimensions (mm) Item  Modules  No. of columns  A  B  C 331411 1  1  151  151  50 331421 2  1  151  242  50 331431 3  1  151  334  50 331441 4  2  290  242  50 331461 6  2  290  334  50 331491 9  3  430  334  50 342510B/W camera module 342550colour camera module 342630speaker module with grafic display for  A/V systems 342600alphanumeric call  module 342510 3422404 key module 3424808 key module 342170speaker module + 2 keysfor audio/video systems 342350speaker module + 4 keysfor audio/video systems 342560speaker module + 2 keyswith colour camera for A/V system 342170 342350 342610 numeric keypad module for direct call 342640additional alphanumeric keypad module for speaker module 342630 342200nameplate module 342200 332650code lock module(it controls 2 relays with numeric code) 342560 Digital call or pushbutton audio and video entrance panels, for flush mounted or wall mounted installation, available in zamak monobloc and modular version. Guaranteed protection from rain and water sprays 342600 342630 SFERA modular entrance panels - mechanics and function modules 2 WIRE SYSTEM

18 SFERA entrance panels - Modular front covers and surround plates - pushbutton call PUSHBUTTON CALL 34246..speaker module with  A/V camera 33248..8 keys 33265..alphanumeric call 34247..speaker module with A/V camera + 1 key 33220..nameplate 34248..speaker module with A/V camera + 2 keys 33220 34246 34247 34248 33265 33210...speaker module 342240 342240 332650 342280 342280 342200 342510 342550 342170 342170 342170 342560 342560 342560 33212...speaker module + 2 keys 33223...3 keys 33224...4 keys 33246...6 keys 33211...speaker module + 1 key 332 0 332 332 2 33223 33224 33295...blankto cover unused  electronic modules 33291...blanking module for  covering holes (presetting)  33251...camera 33123...3 modules (vertical) 33 23 1 Allmetal 2 White 3 Alugray Replace the dots in the code with the corresponding finish number AVAILABLE FINISHES MODULAR SURROUND PLATES 342170 342170 342170 342560 342560 342560 342240 342240 342280 342280 342200 342510 342550 3 332650 2 WIRE SYSTEM Modular surround plates and audio and video front covers, available in ALLMETAL, WHITE and ALUGRAY finish 33121...1 module 33122...2 modules (vertical) Code lock To open the entrance door by entering previously saved numeric codes. 33234...speaker module + 4 keys 342350 342350 33248

19 1 19 9 2  WIRE  DOOR  ENTR Y  SY STEM  CA T A L OGUE  -  CA T A L OGUE SFERA entrance panels - digital call 342510 342510 342550 342550 33251...camera 33251...camera 342510 342510 342550 342550 In case of high number of apartments (normally more than 20-30 apartments) the traditional entrance panel may pose space problems.In this case, it will be possible to replace the traditional pushbutton call system with a digital call system operating in two different ways: - with a direct code: the apartment is called by simply entering  the number of the desired resident on a numeric keypad.   - using an address book: the visitor calls the apartment by  selecting the resident’s name from an address book displayed, as for mobile phones The SFERA modular range is equipped with modules allowing one or both types of digital calls.  It can be used to make the call by selecting the resident’s name from the address book. The direct code call function is possible by combining the speaker module item 342630 with the additional alphanumeric keypad, item 342640. It is recommended that the module is installed side by side with one or more nameplate modules (342200+33220.) to obtain the correspondence between the numbers and the names of the residents. SPEAKER MODULE WITH GRAPHIC DISPLAY - 342630 SPEAKER MODULE WITH GRAPHIC DISPLAY AND ADDITIONAL KEYPAD 342630 + 342640 342630 342630 33266...speaker module with grafic display 33266...speaker module withgrafic display 33266 33266 (Optional) (Optional) + + + p 342630 g p y 342 630 33267..additionl  alphanumeric call  33267 342640 342640 342630 342630 2 WIRE SYSTEM

20 SFERA entrance panels - Modular front covers and surround plates - digital call 2 WIRE SYSTEM 342510 342510 342550 342550 33251...camera 33251...camera 342510 342510 342550 342550 It can be used to call from the address book, using a direct code. It enables the user to release the door lock (entrance) using a code. It is recommended that the module is installed side by side with one or more nameplate modules (342200+3322..) to obtain the correspondence between the numbers and the names of the residents. It can be used to call by using a direct code. It enables the user to release the door lock (entrance) using a code.   ALPHANUMERIC CALL MODULE - 342600 NUMERIC CALL MODULE - 342610 (Optional) (Optional) 33210...speaker module 33210...speaker module 342170 342170 33210 332 0 342170 342170 33260..alphanumeric call 33265..numeric call 33260 33265 342600 342610 342610 + + + + 342600 33251

21 2 2 21 1 2  WIRE  DOOR  ENTR Y  SY STEM  CA T A L OGUE  -  CA T A L OGUE SFERA monobloc front covers - pushbutton call Code lock 3331242 keys speaker moduleor speaker module with grafic display 333614code lock 3331141 key speaker module 333104speaker module+10 keys 333614 332650 333184speaker module+ 8 keys 333844speaker module+ camera +4 keys 33320412 keys 333164speaker module + 6 keys 333144speaker module + 4 keys 333824speaker module +  camera + 2 keys  333814speaker module +  camera + 1 key 3332848 keys 342170 342170 342170 342240 342170 342170 3 42170 3 42170 3 342170 3 332650 342240 342240 342240 342240 342240 342240 42240 34 42240 3 342240 3 342240 3 42240 34 42240 3 342240 3 342510342550 342170 342240 42240 3 342510 3 42170 3 342510342550 342510342550 342170 342170 42510 3 342510 3 42170 34 342170 3 342170 342170 42170 34 42170 34 342240 342240 342240 342240 42240 34 42240 34 342240 3 342240 3 Monobloc zamak audio and video front covers available in ALLSTEEL To open the entrance door by entering previously saved numeric codes.   ALPHANUMERIC CALL 32650 3 333864speaker module+ camera + 6 keys 342510342550 342170 342240 42240 34 42510 3 42170 34 3336 332650 2 WIRE SYSTEM

22 SFERA entrance panels - Monobloc front covers - digital call 2 WIRE SYSTEM In case of high number of apartments (normally more than 20-30 apartments) the traditional entrance panel may pose space problems.Also SFERA monobloc can be used to make digital calls, in alternative to the traditional pushbutton calls.  Using the speaker module with display, it is possible to make calls by selecting the name of the desired resident from the address book displayed. It enables making the call by selecting the desired resident from an address book that can be displayed on the display, and/or by entering the direct code. It enables the user to release the door lock (entrance) using a code.  SPEAKER MODULE WITH GRAFIC DISPLAY - 342630 ALPHANUMERIC CALL MODULE - 342600 333934fonico + camera +alphanumeric keypad 333934 342510342550 342170 342600 342510 342170 333724speaker module +  numeric / alphanumeric call 342170 342170 342600 333824speaker module+ camera+2 keys  342510342550 342510 342630 342630 333124 342600 342600 342630 342630

23 2 2 23 3 2  WIRE  DOOR  ENTR Y  SY STEM  CA T A L OGUE  -  CA T A L OGUE WALL MOUNTED VIDEO ENTRANCE PANELS Item Description 342981  2-WIRE video pushbutton panel with black and white camera and one call pushbutton. With white LEDs for illumination of the viewing field in low light conditions. Communication status audible - light signals for: call active, system busy, door lock release. Wall mounted installation. Zamak front cover. Nameplate lit by blue LED. Protection index against mechanical impact: IK07 342982  same as item 342981, but with 2 call pushbuttons 342991  2-WIRE video pushbutton panel with colour camera and one call pushbutton. With white LEDs for illumination of the viewing field in low light conditions. Communication status audible - light signals for: call active, system busy, door lock release. Wall mounted installation. Zamak front cover. Nameplate lit by blue LED. Protection index against mechanical impact: IK07 342992  same as item 342991, but with 2 call pushbuttons 2 WIRE SYSTEM LINEA 2000 METAL entrance panels Audio and video entrance panels for one-family and two family systems for wall mounted, gate post, or flush mounted installation. Protection index against mechanical impact: IK10 (audio EP) – IK07 (video EP) 342971 342972 WALL MOUNTED AUDIO ENTRANCE PANELS Item Description 342971  2-WIRE audio pushbutton panel with one call pushbutton for wall mounted installation. Zamak front cover. Nameplate lit by blue LED. Protection index against mechanical impact: IK10 342972  same as item 342971, but with 2 call pushbuttons 342981 b/w 342982 b/w 342991 colour 342992 colour

24 342911 Audio and video entrance panels for one-family and two family systems for wall mounted or gate post installation. LINEA 2000 AUDIO ENTRANCE PANELS Item Description 342911  2-WIRE audio pushbutton panel with one call pushbutton for wall mounted installation. Aluminium front cover. Nameplate lit by green LED  342921  same as item 342911, but with 2 call pushbuttons 342921 342951 b/w LINEA 2000 VIDEO ENTRANCE PANELS Item Description 342951  2-WIRE video pushbutton panel with black and white camera and one call pushbutton. Wall mounted installation. Aluminium front cover.Nameplate lit by green LED 342961  same as item 342951, but with 2 call pushbuttons 342961 b/w 2 WIRE SYSTEM LINEA 2000 entrance panels

25 2 2 25 5 2  WIRE  DOOR  ENTR Y  SY STEM  CA T A L OGUE  -  CA T A L OGUE 1. Allmetal 2.  Whit e KEY P AD  C OL OUR   R ANGE Replac e the dots in the  code with the number  co rr esponding t o  the  desir ed c olour 3.  Alug ra y W ARNING Add t o the syst em c omposition an y c onfigur at ors needed For pushbutt on panels with mor e than 26 calls see the  “2- WIRE  TECHNIC AL GUIDE” 2  WIRE  ENTRANCE  P ANELS  -  A UDIO  SFERA  MODULAR C omposition table with speaker module 342170 or 342150  No . of c alls   331110  331120  331130  33121.  33122.  33123.  342170  (p . supp . 346000)    342240  33210. 33211.  33212. 33223. 33224.  33291.                1  1    1      1     1        2  1    1      1       1        3    1     1   1  1  1    1     4    1     1   1  1  1      1    5    1     1   1  1   1     1    6    1     1   1  1     1    1    7      1      1  1 2 1      1  1    8      1      1  1 2 1        2    9      1     1  1  2   1      2    10      1     1  1  2      1  2    11    2       2    1 3 1      1  2    12    2      2   1  3  1      2    13    2      2   1  3  1  1     2    14    2      2   1  3  1   1  2    15      2       2  1 4 1      1  3 1   16      2      2  1  4  1       4  1 BO X  +  FR AME SURROUND  PL A TES SPEAKER   MODULE MODUL AR  FRONT  C O VERS PUSHBUT TON   MODULE    Allo w f or it em 346902 f or the c onnection o f the modules in dif fer ent fr ames.

26  No . of c alls   331120  331130  33122.  33123.  342550 (colori)  342170  342240  33251.  33210.  33211.  33212.  33223.  33224.  33291.            342510 (b/n)   1  1   1   1  1   1   1          2  1   1   1  1   1     1        3    1    1 1 1  1  1  1      1      4    1    1 1 1  1  1  1        1    5   1   1  1  1  1  1   1      1    6   1   1  1  1  1  1     1    1    7  2     2    1  1  2 1 1      1  1    8  2     2   1  1  2  1  1      2    9  2     2   1  1  2  1   1      2    10  2     2   1  1  2  1     1    2    11    2     2  1  1  3 1 1      1  2 1   12    2     2  1  1  3 1 1        3 1   13    2     2  1  1  3  1   1     3  1   14    2     2  1  1  3 1      1    3 1   15    2     3  1  1  4 1 1      1  3    16    2     3 1 1  4  1  1        4  BO X  +  FR AME SURROUND  PL A TES SPEAKER   MODULE VIDEO   MODULE MODUL AR  FRONT  C O VERS KEY P AD   MODULE 2  WIRE  ENTRANCE  P ANELS  -  VIDEO  SFERA  MODULAR C omposition table with speaker module 342170 and camera module 342550 c olour or 342510 B/W    Allo w f or it em 346902 f or the c onnection o f the modules in dif fer ent fr ames. Replac e the dots in the  code with the number  co rr esponding t o  the  desir ed c olour W ARNING Add t o the syst em c omposition an y c onfigur at ors needed For pushbutt on panels with mor e than 26 calls see the  “2- WIRE  TECHNIC AL GUIDE” 1. Allmetal 2.  Whit e KEY P AD  C OL OUR   R ANGE 3.  Alug ra y

27 2 2 27 7 2  WIRE  DOOR  ENTR Y  SY STEM  CA T A L OGUE  -  CA T A L OGUE 2  WIRE  ENTRANCE  P ANELS  -  VIDEO  SFERA  MODULAR C omposition table with audio/video module 342560  No . of   calls    331110  331120  331130  33121. 33122. 33123.  342560  342240  342480  34246. 34247. 34248. 33223. 33224.  33246. 33248. 1   1  1    1     1       1   2  1    1     1         1         3   1    1   1  1    1    1       4   1    1   1  1    1      1      5   1    1   1  1     1    1      6   1    1   1    1  1         1    7   1    1   1    1  1          1   8   1    1   1    1  1          1   9   1    1   1    1     1      1   10   1    1   1    1     1      1   11     1     1  1    2  1       1  1   12     1     1  1    2  1       1  1   13     1     1  1    2  1       1  1   14     1     1  1    2  1       1  1   15     1     1  1    2  1         2   16     1     1  1    2  1         2   17     1    1  1    2     1      2   18     1    1  1    2     1      2   19   2    2   1    3  1         1  2   20   2    2   1    3  1         1  2   21   2    2   1    3  1         1  2   22   2    2   1    3  1         1  2   23   2    2   1    3  1          3   24   2    2   1    3  1          3   25   2    2   1    3     1      3   26   2    2   1    3     1      3 BO X  +  FR AME    W ARNING Add t o the syst em c omposition an y c onfigur at ors needed For pushbutt on panels with mor e than 26 calls see the  “2- WIRE  TECHNIC AL GUIDE” SURROUND  PL A TES 1. Allmetal 2.  Whit e KEY P AD  C OL OUR  R ANGE Replac e the dots in the c ode with   the number c orr esponding t o the  desir ed c olour KEY S  MODULE A UDIO / VIDEO   MODULE MODUL AR  FRONT  C O VERS 3.  Alug ra y

28 W ARNING Add t o the syst em c omposition an y c onfigur at ors needed For pushbutt on panels with mor e than 26 calls see the  “2- WIRE  TECHNIC AL GUIDE” 2  WIRE  ENTRANCE  P ANELS  -  A UDIO  SFERA  MONOBL OC C omposition table with speaker module 342170 or 342150  No . of c alls   331110  331120  331130  342170   (supply 346000)   342240  333114 333124  333144 333164  333184  333104  333284  333204          1  1     1   1     2  1     1    1              3    1    1  1      1          4    1   1  1      1           5    1    1  1        1        6    1   1  1       1          7      1 1 2          1        8      1 1 2          1        9      1  1  2          1      10      1 1 2            1     11    2     1  3      1        1   12    2     1  3      1        1   13    2     1  3        1      1   14    2     1  3        1      1    15      2   1  5        1      1   16      2   1  5        1      1 BO X  +  FR AME SPEAKER   MODULE MONOBL OC  FRONT  C O VERS PUSHBUT TON   MODULE    Allo w f or it em 346902 f or the c onnection o f the modules in dif fer ent fr ames.

29 2 2 29 9 2  WIRE  DOOR  ENTR Y  SY STEM  CA T A L OGUE  -  CA T A L OGUE 2  WIRE  ENTRANCE  P ANELS  -  VIDEO  SFERA  MONOBL OC C omposition table with speaker module 342170 and camera module 342550 c olour or 342510 B/W  No . of  calls  331120 331130  342550  (colour)  342170 342240 333814 333824 333844  333864  333284  333204        342510  (b/w)    1  1   1  1  1     2  1   1  1    1         3   1  1  1  1    1        4   1  1  1  1    1       5    1  1  1  1        1     6    1  1  1  1        1      7  2     1  1 2 1        1    8  2     1  1 2 1        1    9  2     1  1 2 1        1    10  2     1  1  2  1     1   11    2   1  1  4      1      1  12    2   1  1  4      1      1  13    2   1  1  4      1      1  14    2   1  1  4      1      1  15    2   1  1  4      1      1  16    2   1  1  4      1      1 BO X  +  FR AME C AMER A   MODULE   PUSHBUT T ON   MODULE SPEAKER   MODULE MONOBL OC  FRONT  C O VERS    Allo w f or it em 346902 f or the c onnection o f the modules in dif fer ent fr ames. W ARNING Add t o the syst em c omposition an y c onfigur at ors needed For pushbut ton panels with mor e than 26 c alls see the “2 -WIRE TE CHNIC AL GUIDE”

30 CONTENTS 2 WIRE CATALOGUE - HANDSETS AXOLUTE Multimedia Touch Screen  31 AXOLUTE Nighter & Whice Video Station  32 AXOLUTE Video Station  32 AXOLUTE Video Display  33 POLYX audio and video  34 PIVOT audio and video  35 SWING audio and video  37 SPRINT audio  38 Video Switchboard  38 Software Switchboard  38 300

31 3 3 31 1 2  WIRE  DOOR  ENTR Y  SY STEM  CA T A L OGUE  -  CA T A L OGUE Item Description HD4690  advanced touch screen handset with 10” 16/9 LCD display for wall mounted installation.  Axolute white finish. In addition to the video door entry system and video monitoring systems functions, it also becomes - when integrated with a MY HOME home automation system - the actual control terminal for the whole house. Thanks to the OSD icon menu, customisable using the PC, it is possible to control and monitor all the MY HOME home automation functions. It gives the possibility of displaying videos and photos through the USB ports and SD CARD included. When connected to a LAN network, it provides access to RSS services. To be completed with the appropriate surround plate HC4690  same as item HD4690 - Tech AXOLUTE HS4690  same as item HD4690 - Anthracite AXOLUTE Item Description HA4690XC  surround plate in satin-finished aluminiumHA4690VBB  white surround plateHA4690LTK  Teak surround plateHA4690VNB  Nighter surround plateHA4690VSW  Whice surround plate MULTIMEDIA TOUCH SCREEN SURROUND PLATES FOR MULTIMEDIA TOUCH SCREEN Multimedia Touch Screen Finishing surround plate supplied with Touch Screen HS4690 Multimedia Touch Screen assembly Surround plate HA4690VSW HA4690VSW HA4690LTK HA4690XC HA4690VNB HS4690 HD4690 HC4690 HA4690VBB SURROUND PLATE RANGE Finishinng surround plate suppli F Finishin 2 WIRE SYSTEM AXOLUTE Multimedia Touch Screen handset NEW

32 2 WIRE SYSTEM AXOLUTE VIDEO STATION handsets 349320 349321 NIGHTER AND WHICE AXOLUTE VIDEO STATION Item Description 349320          2-WIRE handsfree video handset for wall mounted installation in Nighter  finish. With 8” colour LCD display, backlit capacitive keypad with soft touch controls and PC customisable OSD navigation icon menu for the management of the following MY HOME applications: video door entry system, temperature control, sound system, automation (scenarios) and anti-intrusion and multimediality. In systems integrated with the sound system, the VIDEO STATION behaves as an amplifier, enabling playback of all audio/video sources connected to the system. Keys available: navigation, auto-switch on, door lock release, staircase lights, mute, handsfree/pager connection, and call exclusion.  LED signalling for: call exclusion, door status, and connection.  Firmware update/programming USB port.  It can be integrated with MY HOME, also in combination with the Multimedia interface, item 3465 - (in this case, allow for a local video door entry system power supply). Suitable for wall mounted installation using the special bracket (supplied as standard). It can be configured using physical configurators or the TiNighterandWhiceStation programming and configuration software (supplied as standard)   349321          same as item 349320 - white 349310 349210 349211 349212 VIDEO STATION  Item Description 349310          2-WIRE handsfree video handset for wall mounted installation.   With 5.6” colour LCD display with PC customisable OSD navigation icon menu for the management of the following MY HOME applications: video door entry system, temperature control, sound system, automation (scenarios) and anti-intrusion. In systems integrated with the sound system, the VIDEO STATION behaves as an amplifier, enabling playback of all audio/video sources connected to the system. Keys included: navigation, auto-switch on, door lock release, mute function, handsfree/pager connection, and call exclusion. LED signalling for: call exclusion, door status, and connection. Firmware update/programming USB port. Suitable for wall mounted installation using the special bracket (supplied as standard). It can be configured using physical configurators or the TiAxoluteStation programming and configuration software (supplied as standard). To be completed with surround plate 349210              surround plate in satin-finished aluminium349211              Kristall glass surround plate349212              Teak surround plate NEW

33 3 3 33 3 2  WIRE  DOOR  ENTR Y  SY STEM  CA T A L OGUE  -  CA T A L OGUE 2 WIRE SYSTEM AXOLUTE VIDEO DISPLAY handsets 349311 349312 VIDEO DISPLAY Item Description 349311         2-WIRE handsfree video handset for flush mounted installation - white  Axolute. With 2.5” colour LCD display with PC customisable OSD navigation icon menu for the management of the following MY HOME applications: video door entry system, temperature control, sound system, automation (scenarios) and anti-intrusion. Keys included: navigation, auto-switch on, door lock release, handsfree connection. LED signalling for: call exclusion, door status, and connection. Firmware update/programming USB port. Suitable for flush mounted installation using item 506 boxes. To be completed with finishing plate (all those suitable for item 506E of the AXOLUTE series). It can be configured using physical configurators or the TiAxoluteDisplay programming and configuration software (supplied as standard). 3349312             same as item 349311 - Anthracite AXOLUTE 349319 Item Description 349319  AXOLUTE VIDEO DISPLAY video handset table-top base. It can be connected to the system using the cable item 336813 and an 8 pole socket (item 349413, item 349414, item 349415). To be completed with the rectangular front cover plates for item 506E of the AXOLUTE civil series VIDEO DISPLAY TABLE-TOP BASE SYS TEM C OMPONENE TS RECTANGULAR COVER PLATES brushed aluminium HA4826XC brushed anthracite HA4826XS brushed titanium HA4826NX white Limoges HA4826BG red China HA4826RC green Sèvres HA4826VS blue Meissen HA4826BM brushed chrome HA4826CR brushed bronze HA4826BR brushed mercury HA4826AZ silver mat HA4826SA ashwood HA4826LFR teak HA4826LTK wenge HA4826LWE black glass HA4826VNN blue glass HA4826VZS mirror glass HA4826VSA kristall glass HA4826VKA slate HA4826RLV Carrara marble HA4826RMC ELLIPTIC COVER PLATES Axolute aluminium HB4826XC Axolute anthracite HB4826XS solid black HB4826NR liquid white HB4826DB liquid ivory HB4826DA liquid blue HB4826DZ liquid orange HB4826DR liquid green HB4826DV shiny gold HB4826OR light titanium HB4826TC silver mat HB4826SA gold mat HB4826OS maple HB4826LAE cherrywood HB4826LCA walnut HB4826LNC Dusk HB4826CDK Sandstone HB4826CSD shiny Alessi stainl. steel HB4826AXL brushed Alessi stainl. steel HB4826AXS sand leather HB4826SLC coffee leather HB4826SLS AXOLUTE VIDEO DISPLAY cover plates RectangularHA4826... EllipticHB4826...

34 2 WIRE SYSTEM POLYX audio and video handsets 344082 POLYX AUDIO Item Description 344082  wall mounted 2-WIRE handsfree audio handset. Performs all the traditional door entry system functions. Keys available: entrance panel/cycling activation, door lock release, staircase light switching on, and 4 programmable keys, which operation is defined during the configuration procedure. Configuration through physical connection of the configurators. Wall fixing bracket supplied. Specific audible and visual signals mean that it is also suitable for use by disabled people POLYX VIDEO Item Description 344192  wall mounted 2-WIRE handsfree video handset with 3.5” colour LCD display. Performs all the traditional video door entry system functions. Keys available: entrance panel/cycling activation, door lock release, staircase light switching on, and 4 programmable keys, which operation is defined during the configuration procedure. Configuration through physical connection of the configurators. Wall fixing bracket supplied. Specific audible and visual signals mean that it is also suitable for use by disabled people 344182  same as item 344192 but with integrated inductive teleloop module 344192 344163 POLYX MEMORY DISPLAY AND TELELOOP MODULE Item Description 344163         wall mounted installation 2-WIRE handsfree video handset with audio  and video memory. With 3.5” colour LCD display with PC customisable OSD navigation icon menu for the management of the following MY HOME applications: video door entry system, temperature control, sound system, scenarios and anti-intrusion. With video door entry system answering machine with call memory function. LED signalling for: call exclusion, door status, connection with entrance panel, and answering machine status. Suitable for wall mounted installation using the special bracket (supplied as standard). Configuration using the physical configurators or the TiPolyxMemoryDisplay software supplied as standard with the product    344182 NEW

35 3 3 35 5 2  WIRE  DOOR  ENTR Y  SY STEM  CA T A L OGUE  -  CA T A L OGUE 2 WIRE SYSTEM PIVOT audio and video handsets PIVOT AUDIO AND VIDEO HANDSET Item Description 344032  2-WIRE audio handset for wall, table-top and flush mounted installation (using the appropriate MULTIBOX accessories). Keys available: door lock release, staircase light switching on, and generic actuation. Bell volume adjustable on 3 levels: high, medium and disabled (this condition is signalled by a flashing red LED). With conversation secrecy function. White. Wall fixing bracket supplied. It can be fitted with a 4 key module, item 346812 344102  2-WIRE video handset with black and white 4” flat monitor. Wall, table-top, and flush mounted installation (using the appropriate MULTIBOX accessories). Keys available: entrance panel/cycling activation, door lock release, staircase light switching on, and generic actuation. Bell volume adjustable on 3 levels: high, medium and disabled (this condition is signalled by a flashing red LED). With conversation secrecy function. White. Wall fixing bracket supplied. It can be fitted with a 4 key module, item 346812 344122  2-WIRE video handset with colour 4” TFT monitor. all, table-top, and flush mounted installation (using the appropriate MULTIBOX accessories). Keys available: entrance panel/cycling activation, door lock release, staircase light switching on, and generic actuation. Bell volume adjustable on 3 levels: high, medium and disabled (this condition is signalled by a flashing red LED). With conversation secrecy function. White. Wall fixing bracket supplied. It can be fitted with a 4 key module, item 346812 344032 344102344122 PIVOT HANDSET ACCESSORIES Item Description 346812  additional 4 key module (optional) for PIVOT audio and video handsets. It gives the possibility of controlling and performing additional functions, such as: activation of lights, door locks, and scenarios, intercom calls, direct activation of the entrance panels. It requires configuration using physical configurators. White 337102    PIVOT handset table-top installation support. It can also be used for tilted wall mounted installation. White 337122  PIVOT video handset table-top installation support. It can also be used for tilted wall mounted installation. White 336982     LIGHT series 8-pole socket for table-top installation of PIVOT handsets. White 337102 337122 346812 336982 344102344122

36 2 WIRE SYSTEM MULTIBOX accessories for PIVOT handsets MULTIBOX INSTALLATION OF THE AUDIO HANDSET Item Description 16101  flush mounted box 16101LT  installation kit with white lateral surround plates 16122  no. 4 white fixing supports 344032  PIVOT audio handset MULTIBOX INSTALLATION OF THE VIDEO HANDSET Item Description 16103  flush mounted box 16103LT  installation kit with white lateral surround plates 16121  no. 4 white fixing supports 16122  no. 4 white fixing supports 344102  b/w PIVOT video handset  344122  colour PIVOT video handset 16101 16101LT 16122 344032 Audio handset Video handset 16 16 1 344032 16103 16 16103LT 1 16121 1 16122 22 344102344122 344 102

37 3 3 37 7 2  WIRE  DOOR  ENTR Y  SY STEM  CA T A L OGUE  -  CA T A L OGUE 2 WIRE SYSTEM SWING audio and video handsets SWING AUDIO AND VIDEO HANDSETS Item Description 344704  2-WIRE audio handset for wall mounted installation. With door lock release key and 4 programmable keys (0-1-2-3), which operating mode is set through appropriate configuration procedure. The volume of the bell can be adjusted, or the bell may be disabled. Conversation secrecy function, office function, and door lock release (signalling through appropriate LED). White. Wall fixing bracket supplied 344832  2-WIRE basic video handset with black and white 4” monitor. Wall mounted installation. With the following keys for the video door entry system functions: door lock release, entrance panel/ camera cycling activation, staircase light switching on, and intercom. The volume of the bell can be adjusted, or the bell may be disabled. Call secrecy function and door status function also available. Wall fixing bracket supplied 344824  2-WIRE video handset with colour 4” TFT monitor. With door lock release key and 4 programmable keys (0-1-2-3), which operating mode is set through appropriate configuration procedure. The volume of the bell can be adjusted, or the bell may be disabled. Conversation secrecy function, office function, and door lock release (signalling through appropriate LED). White. Wall fixing bracket supplied 344832 (BASIC B/W monitor) 344824 (colour monitor) 344704 NEW

38 2 WIRE SYSTEM SPRINT audio handsets SPRINT HANDSETS Item Description 344212  2-WIRE audio handset (WITH the possibility of fitting with accessories) for audio systems and mixed audio/video systems. Wall mounted or table-top installation (using the 337242 support). With door lock release key and auxiliary functions key. Preset for call to the floor function. It can be accessorised with additional keys and call exclusion card 346800. Bell volume adjustable on 3 levels. White 344212 Item Description 346310  switchboard for 2-WIRE audio and video systems. Access to various services (video door entry system functions, door lock and/or stair light management, and monitoring of apartment alarms) directly from the keyboard, or using the intuitive menu icons. The switchboard is supplied with built-in table top support and has a 7” colour LCD display, receiver and handsfree, dedicated keys for the main functions, and configurable keys. Programming can be performed directly from the device, or using a PC with the software (supplied as standard) 336982              8-way socket for switchboard table top installation – LIGHT finish336813  AMP – RJ cable for switchboard table top installation SWITCHBOARD 346310 Colour video switchboard Software switchboard SOFTWARE SWITCHBOARD Item Description   346300  switchboard software for the management of audio and  video door entry system calls. The software (Windows operating system compatible) can be installed on any desktop or laptop PC, and gives the possibility of receiving, managing and transferring the calls from the entrance panel and the handset. It implements home video monitoring, with cyclical display of the cameras, night and day functions, and the possibility of displaying the alarms in the various apartments.   - Supported operating systems:  Microsoft Windows XP Service Pack 2 and Windows Vista.  - Software required: NET Framework 3.5 or higher.     - Must be integrated to the 2 wire system using the IP interface 574039.     346300 NEW

39 3 3 39 9 2  WIRE  DOOR  ENTR Y  SY STEM  CA T A L OGUE  -  CA T A L OGUE CONTENTS 2 WIRE CATALOGUE - SYSTEM ACCESSORIES Power supplies  40 Video mixers  40 PABX 40 System interfaces  41 Interfaces with other BTicino systems  41 DIN actuators  41 BASIC housing devices  42 Wiring accessories  42 Universal speaker unit & expansion module  43 Cable 43 Configurators 43 Melodic bells and extra bells  44 2-WIRE outdoor and indoor cameras  44

40 2 WIRE SYSTEM DIN auxiliary devices 63435 ¬ POWER SUPPLIES Item Description 63435  2-WIRE audio and video system power supply with 8 DIN modular housing. Power supply 230 Vac @ 50-60 Hz. On the output it supplies 27 Vdc continuous low voltage, with a maximum current of 1.2 A. It’s electronically protected (without fuses) against short circuit and overload.  It’s a SELV double insulation safety device 346030  mini power supply with integrated video adapter for small 2-WIRE video systems (intercom). 2 DIN modular housing. Power supply  230 Vac @ 50-60 Hz. On the output it supplies 27 Vdc continuous low voltage, with a maximum current of 600 mA. It’s protected  on the PRI side (with fuses) against short circuit and overload. It’s a SELV double insulation safety device 63442  additional power supply used for the local power supply of preset handsets and entrance panels. 2 DIN modular housing. Power supply  230 Vac @ 50-60 Hz. On the output it supplies 27 Vdc continuous low voltage, with a maximum current of 600 mA. It’s protected  on the PRI side (with fuses) against short circuit and overload. It’s a SELV double insulation safety device SELV 346030 ¬ SELV 63442 ¬ SELV 573998 03584 63434 VIDEO MIXERS Item Description 63434  video adapter with 2 DIN modular housing. For connecting 3 BUS to the system. It is therefore possible to install systems with 2 video entrance panels and 1 riser, as well as systems with one video entrance panel and 2 risers. The device must be used with system power supply, item 63435 573998  audio/video node with 2 DIN modular housing preset with 4 input clamps and 4 output clamps. It can be used for connecting up to 4 source device posts (entrance panels or cameras) on the input and up to 4 2-wire video risers on the output. The device must be used with system power supply item 63435. It must be used in alternative to the audio/video adapter, item 63434 03584  multichannel matrix with 10 DIN modular housing. Preset for the connection of video door entry system entrance panels, cameras and sound system sources on the input, and entrance panels and amplifiers on the output. Four inputs are for entrance panels/cameras, and 4 for sound system sources. It enables to create multichannel sound system. The device must be used with system power supply item 63435. Within the systems, it replaces the video adapter, item 63434, and the audio/video node, item 573998 PABX Item Description 345829  Dual line PABX for 2-wire system. 8 extension output with integrated  MYHOME function capabilities. Multi channel line system with remote MYHOME function control. PLTI  Telephone line protection module for PABX PLT1 345829 63434 COMING SOON

41 4 4 41 1 2  WIRE  DOOR  ENTR Y  SY STEM  CA T A L OGUE  -  CA T A L OGUE 63438 63439 SYSTEM INTERFACES Item Description 63438  apartment interface in 4 DIN modular housing. It can be used to interface to a 2-wire riser a dedicated apartment video door entry system with local video monitoring system, sound system, and MY HOME applications control. The device must be configured using physical configurators 63439  system expansion interface with modular 4 DIN housing. It enables doubling of the length of the entrance panel - handset line, to create independent audio risers, and to expand the range or functions of the apartment system. The device must be configured using physical configurators INTERFACES WITH OTHER BTICINO SYSTEMS Item Description 574039  2-WIRE - IP interface with 10 DIN modular housing. Thanks to the creation of an IP backbone with 2-wire risers, it gives the possibility of installing very large mixed 2-wire/IP systems with a high number of devices. The device must be configured using physical configurators, or the software supplied 574039 63431 63433 346260 346260 DIN ACTUATORS Item Description 63431  relay actuator with 4 DIN modular housing. it can be used for switching the lights on, opening the gates, repeating calls on bells (MOD=Sylvania), or for controlling other devices using the video handsets. The device must be configured using physical configurators 63433  door lock relay actuator with 2 DIN modular housing. For the power supply and activation of an electrical door lock. The device must be configured using physical configurators 346260  timed door lock relay actuator with 4 DIN modular housing. It can be used for switching the lights on, opening gates, or manage electromagnetic door locks, timed door opening, and door lock status (with NC contact). The device must be configured using physical configurators 2 WIRE SYSTEM DIN auxiliary devices 63 39 63433

42 2 WIRE SYSTEM System accessories 63432 574038 346833 BASIC HOUSING DEVICES   Item Description 63432  4-output floor shunt. For installing 2-wire video door entry systems with star wiring distribution. The device automatically adapts the video signal. Thanks to its compact sizes, it can also be fitted inside a flush mounted box   346833  call to the floor interface. By connecting traditional pushbuttons, the following functions will be possible: general call to the floor, addressed call to the floor, staircase lights on, and door lock release (specific actuator needed), and association of the video image to the call to the floor. The device must be configured using physical configurators 574038  interface for the conversion of the coaxial signal into a 2-WIRE BUS signal. It can be used to connect to the BUS of the 2-wire video door entry system a camera with coaxial video output powered at 12 Vdc, with maximum absorption 150 mA and 1 Vpp video output (75 Ω). The device must be configured using physical configurators 346870 346870 346903 WIRING ACCESSORIES Item Description 346870  2-WIRE video amplifier. In video systems wired using non-twisted wires, where the distance between the entrance panels and the handset exceeds 50 metres, it enables increasing such distance to up to 100 metres   346903  accessory for the connection of SFERA pushbutton panels with more than 26 calls. To be fitted on the back of the SFERA speaker module, in the appropriate socket 346902  cable for the connection of SFERA pushbutton modules arranged on several columns 346250  gate opening relay module to be used with LINEA 2000, LINEA 2000 METAL, MINISFERA AND SFERA pushbutton panels (only audio/video module 342560). It can be used to release door locks (NOT managed through the BUS) from the entrance panel 346907  adaptor cable for AUDIO/VIDEO SFERA module, length 40 cm 336813  cable (RJ45/8 poles) for table top connection of video handsets  F442  TV SCS modulator with 6 DIN modular housing. For displaying on the home television set the images from the 2-WIRE video door entry system. 22 selectable S band channels 03589  line terminator. To be used to terminate the riser or apartment line, when the last installed device is not fitted with line closing micro switch 346902 346250 03589 F442 63432

43 4 4 43 3 2  WIRE  DOOR  ENTR Y  SY STEM  CA T A L OGUE  -  CA T A L OGUE Item Description 346991  The universal speaker unit can be used to install the 2-WIRE audio system in new or refurbished systems, where pushbutton panels of other manufacturers are present or required (mail boxes, patterned brass, compact sheet metal units, etc.),  preset for a traditional speaker module (e.g. 2659N). The universal speaker unit has a contact base for the connection of 8 call keys; for systems with a higher number of keys (up to 56 when using the 63435 power supply) one or more key expansion modules must be used (1 every 8 keys) 346992  expansion module for connecting more than 8 call keys to item 346991 - max. 6 modules (56 calls max.) with power supply 63435. 346991 346992 UNIVERSAL SPEAKER UNIT AND EXPANSION MODULE 573999 26145 SYSTEM CABLE Item Description   573999  specific cable for video door system applications with 2 twisted conductors. It can be installed in underground piping, in accordance with CEI 20-13 and CEI 20-14 standards. It ensures the best performance in video systems (higher distance between EP and Handset when compared with other cables). 200 m coil CONFIGURATORS  (10 PIECE PACK) Item Description 49200  configurator  0 49201  configurator  1 49202  configurator  2 49203  configurator  3 49204  configurator  4 49205  configurator  5 49206  configurator  6 49207  configurator  7 49208  configurator  8 49209  configurator  9 CONFIGURATOR KIT Item Description 26145  configurator kit consisting of:  - 10 pieces for each type of configurator from 0 to 9  - 2 blue removable 8-clamp connectors  - 2 green removable 2-clamp connectors  - 1 configurator connection tool  - 1 plastic screwdriver 2 WIRE SYSTEM System accessories

44 336993 2 WIRE SYSTEM System accessories 346982 336910 MELODIC BELLS EXTRA BELLS Item Description   346982  2-WIRE melodic bell with LIGHT look (white). It’s used to repeat the     video door entry system call in several rooms. Wall mounted installation     using the accessories and front cover plates of the LIGHT residential    series  346983  same as item 346982 - LIVING 346984  same as item  346982 - LIGHT TECH Item Description   336992  LIGHT extra bell (white). It’s used to repeat the video door entry system     call in several rooms. Wall mounted installation using the accessories     and front cover plates of the LIGHT residential series 336993  same as item 336992 - LIVING 336994  same as item 336992 - LIGHT TECH 336910  extra bell with neutral look.  It’s used to repeat the video door entry     system call in several rooms. Wall mounted installation or installation     inside round box (with fixing clips) 346984 346983 336992 336994 391659391669 391658391668 391657391667 573986 2 WIRE INDOOR CAMERAS Item Description 391658  flush mounted colour camera in LIGHT finish. 3.7 mm fixed optics,  1/3” CCD, 380 horizontal lines resolution. With microphone.  The device must be configured using physical configurators 391659  same as item 391658 -  LIGHT TECH 391657  same as item 391658 -  LIVING 391668  flush mounted b/w camera in LIGHT finish. 3.7 mm fixed optics,  1/3” CCD, 380 horizontal lines resolution. With microphone. The device must be configured using physical configurators 391669  same as item  391668 - LIGHT TECH 391667  same as item 391668 - LIVING 2 WIRE OUTDOOR CAMERA Item Description   573986  compact colour camera with IP 65 housing, fixed 6 mm optics,  1/3” CMOS, 330 horizontal lines resolution. The device must be configured using physical configurators

45 4 4 45 5 2  WIRE  DOOR  ENTR Y  SY STEM  CA T A L OGUE  -  CA T A L OGUE CONTENTS 2 WIRE SYSTEM - AUDIO AND VIDEO KIT  POLYX MEMORY DISPLAY handsfree colour video kit  - LINEA 2000 METAL  47 POLYX VIDEO handsfree colour video kit  - LINEA 2000 METAL  47 SWING - SFERA modular colour video kit  49 SWING - LINEA 2000 METAL colour video kit  49 SWING BASE - SFERA B/W audio/video kit  50 SWING BASE - LINEA 2000 B/W video kit  50 POLYX - LINEA 2000 METAL audio kit  51 SWING - SFERA modular audio kit  51 SWING - LINEA 2000 METAL audio kit  52 2 WIRE SYSTEM - ANALOGUE KIT SPRINT - LINEA 2000 audio kit  52 SOFTWARE & TECHNICAL SUPPORT YouDiagram Software  53 Technical Support  53

46 2 WIRE SYSTEM Audio and video kit The kit is the most economical  and practical solution for creating  one-family and two-family 2-wire or  analog audio and video door entry  systems for the residential and small  service sector.  With a single reference code, the kit  includes all the items required for the  creation of a system: power supply,  entrance panel, handset, and any  wiring accessories. The kit includes a manual with all the  technical information required for  the installation, the connection, the  putting into operation of the system,  as well as an explanation of all the  system features, and expansion  possibilities. The combinations between entrance  panels and handsets and the type  of installation (surface or flush  mounted), meet all installation  requirements. 46 The 2-WIRE kits are fully expandable  and are suitable for all installation  requirements.  They are fully  compatible with the 2-WIRE range of  devices (outdoor pushbutton panels,  audio handsets, video handsets,  system accessories, and indoor or  outdoor cameras), ensuring the  possibility of expansion without  limitations.

47 4 4 47 7 2  WIRE  DOOR  ENTR Y  SY STEM  CA T A L OGUE  -  CA T A L OGUE Handsfree colour video kit  POLYX VIDEO HANDSFREE KIT - LINEA 2000 METAL WALL MOUNTED INSTALLATION Item Description   368911  one-family handsfree video (colour) kit with POLYX VIDEO handset and LINEA 2000 pushbutton panel. 2-WIRE technology. Devices suitable for wall mounted installation. The pushbutton panel has an IK10 protection index against mechanical impact Composition   Item  368911  LINEA 2000 METAL pushbutton panel     342991 1      1 call pushbutton POLYX VIDEO video handset    344192 1    Power supply     346000 1  Video adapter    346830 1  Door lock relay accessory    346250  1                2 WIRE SYSTEM (3.5” colour display) Handsfree colour video kit with memory POLYX MEMORY DISPLAY HANDSFREE KIT -  LINEA 2000 METAL WALL MOUNTED INSTALLATION Item Description   369411  one-family handsfree kit with call memory and colour video display consisting of POLYX MEMORY DISPLAY video handset and LINEA 2000 METAL pushbutton panel. The video handset has an icon menu for the control of video door entry functions and MY HOME automation functions. 2-WIRE technology. Devices suitable for wall mounted installation. The pushbutton panel has an IK10 protection index against mechanical impact Composition   Item  369411  LINEA 2000 METAL pushbutton panel    342991 1      1 call pushbutton POLYX MEMORY DISPLAY   344163 1      video handset  Power supply     346000 1  Video adapter    346830 1    Door lock relay accessory    346250  1            (3.5” colour display) NEW NEW

48 Colour video monitoring system kit with memory 2 WIRE SYSTEM The 344163 POLYX MEMORY DISPLAY video handset includes a call memory function. It is possible to record voice and images of entrance panel calls. It is also possible to record an audio message to play back on the entrance panel following an unanswered call. The video door entry system message can be recorded in 2 ways:  PICTURES: the message includes a picture of the visitor  and the recorded audio message (160 messages max)  VIDEO: the message includes a video feed (duration 16  seconds) and the recorded audio message (18 messages max) Each message is given a progressive number, which will be displayed on the video handset screen, together with the date and time information EXAMPLE OF EXPANDABILITY WITH TWO ENTRANCE PANELS AND TWO 2-WIRE OUTDOOR CAMERAS Video handset Entrance panel 1 Entrance panel 2 Audio/video node Power supply Camera 1 Camera 2 2 2 2 2 2

49 4 4 49 9 2  WIRE  DOOR  ENTR Y  SY STEM  CA T A L OGUE  -  CA T A L OGUE The 2-WIRE BASE SYSTEM video kits are the basis for the  creation of black&white or colour video systems in small  residential units.   The kit contains all the necessary materials for the  installation which can then be easily expanded using the  products in the 2-WIRE BTicino range (entrance panels,  handsets, video handsets, and system accessories). SWING – SFERA MODULAR EXPANDABLE VIDEO KIT Item Description   369111  one-family expandable video kit with SWING colour video handset and SFERA A/V pushbutton panel. The video handset is suitable for wall mounted installation. The pushbutton panel is suitable for flush mounted installation. 2-WIRE technology Composition   Item  369111  SFERA flush mounted box , 2 modules            331120  1                          SFERA speaker module  342170   1                Colour SFERA camera module                 342550  1                        Allmetal speaker module front cover, 1 pb.                  332111   1    Allmetal camera front cover                                332511  1           Allmetal  2 modules surround plate               331221  1      SWING colour video handset                344824  1      Power supply               346000  1       Video adapter  346830  1  BASE SYSTEM video kit 2 WIRE SYSTEM (4” colour display) SWING VIDEO KIT - LINEA 2000 METAL  Item Description   367511  one-family video (colour) kit with SWING BASE video handset and LINEA 2000 pushbutton panel. 2-WIRE technology. Devices suitable for wall mounted installation. The pushbutton panel has an IK10 protection index against mechanical impact Composition   Item  367511  LINEA 2000 METAL pushbutton panel   342991 1      1 call pushbutton SWING colour video handset     344824 1    Power supply     346000 1  Video adapter    346830 1    Door lock relay accessory    346250 1    (4” colour display)

50 SWING BASE VIDEO KIT - LINEA 2000  Item Description   365411  one-family video (black & white) kit with SWING BASE video handset and LINEA 2000 pushbutton panel. 2-WIRE technology. Devices suitable for wall mounted installation. Composition   Item  365411  LINEA 2000 pushbutton panel   342951 1      1 call pushbutton BASE SWING video handset     344832 1    Power supply     346000 1  Video adapter    346830 1    Door lock relay accessory    346250 1    B/W and colour video kit (4” B/W display) 2 WIRE SYSTEM SWING BASE - SFERA AUDIO/VIDEO EXPANDABLE VIDEO KIT Item Description   366311  expandable video kit with SWING BASE video handset and SFERA A/V pushbutton panel. The video handset is suitable for wall mounted installation. The pushbutton panel is suitable for flush mounted installation. 2-WIRE technology Composition   Item  Quantity SFERA flush mounted box, 1 module       331110                    1                              SFERA audio/video module with                           342560                    1             colour camera Allmetal front cover, 1 key  342471 1  Allmetal SFERA surround plate                       331211                    1                     SWING BASE video handset with                    344832                    1                                   b/w monitor   Video adapter                                346830                    1          Power supply                                     346000                    1      (4” B/W display) NEW NEW

51 5 5 51 1 2  WIRE  DOOR  ENTR Y  SY STEM  CA T A L OGUE  -  CA T A L OGUE POLYX AUDIO KIT - LINEA 2000 METAL Item Description   369211  one-family kit with POLYX audio handset and LINEA 2000 METAL pushbutton panel. 2-WIRE technology. Devices suitable for wall mounted installation. The pushbutton panel has an IK10 protection index against mechanical impact. POLYX audio has LED call visualisation Composition   Item  369211  LINEA 2000 METAL pushbutton panel   342971 1      1 call pushbutton POLYX audio                                  344082                 1           Power supply                                  346000                 1                                                                                                               Audio kit 2 WIRE SYSTEM SWING AUDIO KIT - MODULAR SFERA Item Description   367211  one-family kit with SWING handset and SFERA modular pushbutton panel in Allmetal finish. 2-WIRE technology. Handset suitable for wall mounted installation. Pushbutton panel suitable for flush mounted installation Composition   Item  367211  Box + frame, 1 module  331110 1  speaker module front cover   332111 1      1 Allmetal pushbutton Surround plate                          331211                 1           1 Allmetal module            2-WIRE speaker module                       342170            1                                                                                                                     SWING handset                       344704              1                                  Power supply                     346000               1                                                                            NEW

52 Audio kit 2 WIRE SYSTEM SPRINT AUDIO KIT - LINEA 2000 Item Description   363811  one-family kit with SPRINT audio handset and LINEA 2000 pushbutton panel in analogue technology. Handset and pushbutton panel are suitable for wall mounted installation. Additional internal handset is 331550 Composition   Item  363811  SPRINT handset  -  1                                                                                                                       SPRINT handset                       -             1                                  Power supply                     336842               1  Additional audio handset                           331550                  Suitable only for 363811 kit        SWING AUDIO KIT - LINEA 2000 METAL Item Description   368111  one-family kit with SWING handset and LINEA 2000 METAL pushbutton panel. 2-WIRE technology. Devices suitable for wall mounted installation. The pushbutton panel has an IK10 protection index against mechanical impact Composition   Item  368111  LINEA 2000 METAL pushbutton panel   342971 1      1 call pushbutton SWING handset                                   344704                 1           Power supply                                  346000                 1                                                                                                               Analogue kit Entance panel and handset is specific for this kit only

53 5 5 53 3 2  WIRE  DOOR  ENTR Y  SY STEM  CA T A L OGUE  -  CA T A L OGUE YouDiagram Quotation Software SOFTWARE & TECHNICAL SUPPORT Quotation Software 1st Phase 2nd Phase List of Materials Specifications Wiring Diagram in CAD 3rd Phase Analysing Communication Troubleshooting Software TECHNICAL SUPPORT For general inquiries contact 1300 369 777  For specific troubleshooting please contact the Door Entry System Technical Support Team through the call centre SCS Log Wiring Diagram in PDF Technical Support

54 CONTENTS 54 2 WIRE CATALOGUE - TECHNICAL DATA  Residential Installations  55 System functions  63 System composition  68 Configuration 73 The wiring  76 Installation 78 System performance  79

55 5 5 55 5 2  WIRE  DOOR  ENTR Y  SY STEM  CA T ALOGUE  -  TECHNICAL  DA T A Example 1 - Villa Whice Video Station  Nighter Video Station   Audio/video node Power supply Entrance panel ONE-FAMILY VIDEO DOOR-ENTRY SYSTEM WITH INTERCOM BETWEEN VIDEO HANDSETS l RESIDENTIAL INSTALLATIONS

56 BUS BUS BUS BUS BUS BUS 2  1 BUS S C S O U T 1 O U T 2 O U T3 O U T 4 I N 1 I N2 IN 3 I N 4 OUT IN 349321 349321 349320 349320 349320 N = –= 5 P = –M = – N = –= 1 P = –M = – N = –= 4 P = –M = – N = –= 3 P = –M = – ITEM DESCRIPTION QUANTITY 34299157399863455349320349321S Entrance panelAudio/video nodePower supplyNighter Video Station  Whice Video Station  Electrical door lock 111321 ON OFF OFF OFF OFF 573998 63435 342991 LIVING ROOM ROOM 2 RECEPTION ROOM KITCHEN ROOM 1 N = –= 2 P = –M = – 230 Vac P = –= – N = –T = –S = 9 S

57 5 5 57 7 2  WIRE  DOOR  ENTR Y  SY STEM  CA T ALOGUE  -  TECHNICAL  DA T A Example 2 - Villa Whice Video Station  Nighter Video Station   Entrance panel Outdoor camera Polyx Memory Display Audio/video node Power supply ONE-FAMILY VIDEO DOOR-ENTRY SYSTEM WITH OUTDOOR CAMERAS Outdoor pp y RESIDENTIAL INSTALLATIONS

58 ITEM DESCRIPTION QUANTITY 34299157398657399863435349320349321344163S Entrance panelOutdoor cameraAudio/video nodePower supplyVideo Station NighterWhice Video Station Polyx Memory DisplayElectrical door lock 12112211 Max. 5 handsetsMax. 200 metres between the entrance panel and the last handset S = Electric door lock 18 V 4 A impulsive 250 mA holding current NOTE 1: We recommend that the video handsets are configured using the software supplied with the productNOTA 2: The answering machine function is available only using the 344163 video handset, and can only be activated on 1 video handset (the one configured with N=1) OFF OFF BUS BUS BUS BUS BUS BUS 2  1 BUS S C S OUT 1 OUT 2 O U T 3 OU T 4 I N 1 I N 2 IN 3 I N 4 OUT IN N = –= 1 P = –M = – N = –= 2 P = –M = – N = –= 5 P = –M = – N = –= 4 P = –M = – N = –= 3 P = –M = – BUS 2 1 S C S OU T1 O UT 2 O U T 3 OU T 4 IN 1 I N 2 IN 3 IN 4 OUT IN ON OFF OFF BUS N = –= 1 P = –M = – ON BUS N = –= 2 P = –M = – OFF BUS N = –= 5 P = –M = – OFF 349321 349321 OFF BUS N = –= 4 P = –M = – 349321 OFF BUS N = –= 3 P = –M = – 349321 344163 349320 349320 573998 63435 342991 573986 573986 P = –= – N = –= – T = –S = 9 P = –= 1 N = –Z = –M = –A = –PL = – P = –= 2 N = –Z = –M = –A = –PL = – LINVING ROOM ROOM 2 RECEPTION ROOM KITCHEN ROOM 1 S 230 V

59 5 5 59 9 2  WIRE  DOOR  ENTR Y  SY STEM  CA T ALOGUE  -  TECHNICAL  DA T A Example 3 - Apartment Outdoor camera Polyx Memory Display Audio/video node Power supply Indoor camera Axolute Video display  Apartment interface APARTMENT WITH DEDICATED ENTRANCE PANEL AND PRIVATE CAMERAS RESIDENTIAL INSTALLATIONS l d d l

60 BUS 2  1 SC S OUT 1 OUT 2 O UT3 OUT 4 I N 1 I N2 IN 3 IN 4 OUT IN BUS BUS ON OUT IN ON OFF BUS BUS BUS BUS ITEM DESCRIPTION QUANTITY 3429915739865739526343557399863438344163349312S L2000 Entrance panel Outdoor cameraAxolute indoor cameraPower supplyAudio/video nodeApartment interfacePolyx memory displayEteris Video Display Electrical door lock 111111411 NOTE 1: We recommend that the video handsets are configured using the software supplied with the productNOTE 2: Configure the entrance panels and the apartment cameras starting from (P=1)NOTE 3: The audio/video answering machine can only be activated on one 344163 video handset (the one configured with N=-1)  Max 5 video handsets, 1 apartment EP and 2 apartment cameras OFF ON OFF ON OFF N = –= 5 P = 1M = – N = –= 4 P = 1M = – N = –= 3 P = 1M = – P = –= 3 N = –Z = –M = –A = –PL = – N = –= 1 P = 1M = – N = –= 2 P = 1M = – N = –= 5 M = 3 P = –= 2 N = –Z = –M = –A = –PL = – P = –= 1 N = –T = –S = 9 344163 349312 344163 344163 344163 63435 573998 63438 342991 573952 573986 BUILDING RISER APARTMENT EXTENSION 230 Vac ON S BUILDING RISER

61 6 6 61 1 2  WIRE  DOOR  ENTR Y  SY STEM  CA T ALOGUE  -  TECHNICAL  DA T A Example 4 - Complexes of small houses  MULTI-FAMILY SYSTEM WITH SINGLE INDEPENDENT DWELLINGS AND AT LEAST ONE COMMON ACCESS POINT Apartment interface Entrance panel Audio/video node Power supply A i f RESIDENTIAL INSTALLATIONS

62 ITEM DESCRIPTION QUANTITY 3491403392133393135739986343563438S346260 Axolute entrance panel Front cover plateFlush mounted boxAudio/video nodePower supplyApartment interfaceElectrical door lockDoor lock actuator 111111 - 9911 Max 99 apartment interfaces and 1 apartment complex entrance panelMax 50 metres between entrance panel and audio/video node BUS ON OUT IN ON OFF BUS SCS BUS 2  1 ON OUT IN ON OFF ON OUT IN ON OFF BUS ON OUT IN ON OFF BUS BUS SCS TMP C NO/S+ NC PL RC SCS BUS 2  1 SCS TMP C NO/S+ NC PL RC 573998 63435 346260 OFF OFF OFF ON BUS ON OUT IN ON OFF OFF BUS ON OUT IN ON OFF ON BUS ON OUT IN ON OFF OFF ON OUT IN ON OFF BUS OFF 63438 63438 63438 63438 349140 N = 3= 5 M = 3 N = 9= 9 M = 3 N = –= 1 M = 3 N = 2= 6 M = 3 SMALL HOUSE 35 SMALL HOUSE 99 SMALL HOUSE 1 SMALL HOUSE 26 Inside of the apartment –   see previous diagram Inside of the apartment –   see previous diagram Inside of the apartment –   see previous diagram Inside of the apartment –   see previous diagram P = –= – T = –M = – JMPJMP S P = –= – S = – The EP must be configured and programmed using the software supplied with the product max. 50 m 230 Vac

63 6 6 63 3 2  WIRE  DOOR  ENTR Y  SY STEM  CA T ALOGUE  -  TECHNICAL  DA T A System functions THE CALL Pressing the call pushbutton on the  entrance panel, the system generates  a signal that is only recognised by the  video handsets the call is addressed  to (the call will have to be answered  within 30 seconds from the moment  the pushbutton is pressed). Each VIDEO handset is configured in  a unique specific way. When the call  is received, the video handset rings  and the monitor switches on. Press the    pushbutton to  establish the communication  (maximum duration of the  communication is 1 minute) with the  entrance panel. Press   again to  stop the communication and switch  the monitor off. CONVERSATION SECRECY During the conversation between  the entrance panel and the video  handsets, all external panels and  handsets that are not involved in  the conversation are temporarily  excluded in order to guarantee  the privacy of video door entry  conversations.  When calling from an  entrance panel that is temporarily  excluded, a time-out tone will be  heard, to indicate that the extension  line is momentarily busy. SIMULTANEOUS SWITCHING ON With video handsets, simultaneous  switching on of the monitor is also  possible: upon arrival of the call, all  handsets ring and the monitors of all  video handsets switch on. When the  call is answered, only the monitor of  the video handset communicating with  the entrance panel will remain on.  In order to set this function, all the  video handsets but one must be  powered locally using an additional  power supply, item 346020. call The handset rings and the monitor switches on communication The conversation  cannot be heard Apartment 1 Apartment 2 call All the handsets, on the same call, ring and switch on the monitor. TECHNICAL DATA

64 DOOR LOCK PUSHBUTTON The video handsets are fitted with a  door lock pushbutton. Pressing this  pushbutton will open of one of the  door locks of the system. With the system at rest, the pressure  of the pushbutton will cause the  opening of the door lock of the  entrance panel associated with the  handset during the P configuration of  the handset itself.  On the other hand,  if the pushbutton is pressed during  the call, the door lock associated to  the entrance panel making the call  will be opened. THE STAIRCASE LIGHT FUNCTION The video handsets are equipped  with an icons menu. This function activates a relay for the  timed switching on of lights and the  opening of the gate. The function can be performed by  installing the actuator item 63431,  appropriately configured. SELF-SWITCHING ON  PUSHBUTTON By pressing the self-switching on  pushbutton while the videohandset  is at rest, a connection will be  established with the  entrance panel  associated with the handset during  the P configuration of the handset  itself. Pressing repeatedly on the self- switching on pushbutton, will scroll  through the various entrance panels  and the cameras connected to the  system. call CLAK Pressing the door lock key will open the gate associated with the handset. The staircase light function will switch on the system lights connected to a special actuator Each time the self-switching on key is pressed  the images displayed change.

65 6 6 65 5 2  WIRE  DOOR  ENTR Y  SY STEM  CA T ALOGUE  -  TECHNICAL  DA T A System functions MASTER-SLAVE FUNCTION For multi-family installations the  MASTER-SLAVE function is available:  when the call is received, all the  apartment handsets ring, but only  the monitor of the video handset  configured as master comes on.  When the auto-switching on key of  a SLAVE is pressed, the monitor of  the MASTER handset turns off, while  the monitor of the SLAVE itself turns  on (without necessarily establishing  communication with the entrance  panel).  If the connection key    of a SLAVE is pressed, the MASTER  monitor turns off and communication  with the audio-video entrance panel  is established. call When a call is received, the MASTER comes on, while the SLAVE  will only ring. Master Slave INTERCOM The system offers an intercom  function, with up to 3 minutes  communications between  videohandsets: From different apartments Within the same apartment  If the apartment has an apartment  interface - item 63438 - or is a  one- family apartment, each  videohandset of the apartment can  be called individually. The INTERCOM  connection can be established at  the same time as other external  connections.  The INTERCOM  connection can be simultaneous to  other connections external to the  apartment.  If the apartment does not  have an apartment interface - item  63438 - any apartment handset can  call all other apartment handsets.   The INTERCOM connection will not  occur at the same time as external  connections.  Any call received by an  EP, even to any other apartment, will  terminate the INTERCOM connection. INTERCOMcall Apartment 1 Apartment 2 Item 63438 apartment interface enables the INTERCOM function between the devices within the one apartment and the various apartments APARTMENT 2 APARTMENT 1 R T AR PA A A P A A A P 2 2 2 TECHNICAL DATA

66 VIDEO DOOR ENTRY SYSTEM  ANSWERING MACHINE FUNCTION Function available only using the  POLYX MEMORY DISPLAY video  handset, item 344163. It is possible  to record voice and images of a call  from an entrance panel. It is also possible to record an audio  message to play back on the entrance  panel following an unanswered call.  The video door entry system message  can be recorded in 2 ways: STILLS: the message includes  a picture of the visitor and the  recorded audio message (160  messages max). VIDEOS: the message includes a  video feed (duration 16 seconds)  and the recorded audio message  (18 messages max).  Each message will be given a  progressive number, which will be  displayed on the video handset,  together with the date and time  information. Playback of sounds and images recorded by the answering machine Answering machine active We are currently out..... MESSAGGE 1MESSAGGE 2MESSAGGE 3

67 6 6 67 7 2  WIRE  DOOR  ENTR Y  SY STEM  CA T ALOGUE  -  TECHNICAL  DA T A System functions PAGER FUNCTION IN SYSTEMS  INTEGRATED WITH SOUND  SYSTEM By pressing the conversation  pushbutton   on the video  handsets, it is possible to broadcast  a message through all the  loudspeakers of the sound system.  The involved video handsets must be  powered locally.  From the video handset menu it  is possible to control and display  the functions of the sound system  through the icons of the menu itself. NOTE: function possible by configuring the video  handsets using the software supplied with the  product. Dinner  is served! SCENARIO CONTROL FUNCTION  IN SYSTEMS INTEGRATED WITH  AUTOMATION SYSTEM From the video handsets, it is possible  to recall the scenarios saved in the  03551 scenarios. NOTE: function possible by configuring the video  handsets using the software supplied with the  product. UP ON SUPERVISION FUNCTION IN  SYSTEMS INTEGRATED WITH THE  TEMPERATURE CONTROL SYSTEM From the video handset menu, it is  possible to display the status of the  temperature control system. Using the appropriate icons it is  possible, for example, to change the  temperature parameters, and display  the status of the probes. NOTE: function possible by configuring the video  handsets using the software supplied with the  product. 20.5 °C 22.5 (+2) 18.5°C KITCHEN + – + – A off TECHNICAL DATA

68 System composition The system is classed as SELV (Safety  Extra – Low Voltage) due to the fact  that it is powered by non grounded  safety double insulation independent  power supplies with a max. voltage  of 25 Vac (effective) or 60Vdc non- inverted voltage.  In addition, all BTicino devices are  double insulated.   BASIC ELEMENTS OF THE VIDEO  SYSTEM In order to install a system it is  necessary to purchase, in addition to  the entrance panel and the handset,  also the 63434 video adapter, or the  573998 audio/video node, and the  63432 floor shunt with the function  of distributing the video signal. A maximum of 3 connections are allowed on the video adapter. Handsets Entrance panel Handsets Connection of 2 entrance panels and a riser for the handsets Connection of 1 entrance panel and 2 risers for the handsets ( ) If either an interface is connected to the entrance panel, only one connection on the TK BUS terminal of the video adapter is possible. ( ) Entrance panels VIDEO ADAPTER The video adapter is used to connect  entrance panels and handsets to a 2  wire video system A maximum of 3 connections are  allowed on the video adapter. Video entrance panel Video adapter Power supply Video handset VIDEO ADAPTER 2 2 Entrance panels Handsets Power supply 63435 The conformity to SELV classification  is only guaranteed only subject to  FULL COMPLIANCE with current  installation regulations and with the  GENERAL RULES FOR INSTALLATION  relating to each single device and  cable, making up the installation. BUS PI BUS TK PS BUS PI BUS TK PS BUS PI BUS TK PS BUS PI BUS TK PS TECHNICAL DATA

69 6 6 69 9 2  WIRE  DOOR  ENTR Y  SY STEM  CA T ALOGUE  -  TECHNICAL  DA T A Video entrance panel Power supply Power supply Video handset AUDIO/VIDEO NODE OR VIDEO MATRIX The 573998 audio/video node and  the 03584 video matrix must be used  in alternative to the video adapter  when more than 2 entrance panels  must be installed in the system, or  when more than 2 risers are needed.   The use of the audio/video node  or the video matrix is however  recommended, to allow for future  MY HOME integrations, system  expansions, and/or addition of  cameras. Allow for one output of the audio/ video node, or the video matrix, for  each video door entry system video  handset with table-top installation. AUDIO/VIDEO NODE To the entrance panels/cameras To the handsets FLOOR SHUNT When creating video systems, the  use of the floor shunt, item 63432  is recommended. This will provide  important savings on the cable to  be used.  This is particularly suitable  for multi-family systems, when more  than one living unit on the same floor  or in multi-family systems, where  max. distance between the entrance  panel and all handsets is needed. The  Floor shunt enables star connection  of up to 4 apartments with a max.  of 3 handsets for Apartment (max.  1 handset per output, if set in  simultaneous switching on). One output of the audio/video node  should be dedicated to each table- mounted video handset installed. FLOOR SHUNT Apartment 1 Apartment 2 Apartment 3 Apartment 4 2 wire riser Riser For each output: max. 3 video handsets or bells in the same apartmentmax. 1 video handset in simultaneous switching onmax. 1 table-mounted video handset 2 Audio/video node 2 w 2 w 2 w w w i i ire ris Ris Ris Ris er er er ART. 63432

70 System composition SYSTEM EXPANSION MODULE  63439 IN MOD = 0 (SYSTEM EXPANSION MODE) To be used for system expansion, in  order to: Regenerate the video signal and have  a further 200 m available after the  interface (using the 573999 cable) Increase the number of devices  connected to the BUS  Use a max. of 3 modules, configured  using the MOD = 0 in cascade. As far as the system composition,  distances and topology are  concerned, within the system 1  section, the system expansion  module item 63439 must be  considered as a handset. On the  other side, within the system 2  section it should be considered as an  entrance panel.  MOD = 0 2 2 2 2 2 2 ON OUT IN ON OFF S C S SC S 2 SC S 2 2 2 2 2 SC S ON OUT IN ON OFF ON OUT IN ON OFF ON OUT IN ON OFF ON OUT IN ON OFF Entrance panel 573998 63435 63439 573998 63435 200 m 200 m Entrance panel 63439 63439 63439 63439 max. 1 item 63439with MOD = 0 for each output 573998 63435 573998 63435 The IN clamp of the system expansion modules configured with Mod = 0 must be connected to a dedicated output of the 573998 audio/video node or the 63432 floor shunt (as a handset with local power supply). System 1 section System 2 section TECHNICAL DATA

71 7 7 71 1 2  WIRE  DOOR  ENTR Y  SY STEM  CA T ALOGUE  -  TECHNICAL  DA T A MOD = 5 SYSTEM EXPANSION MODULE  ITEM 63439 IN MOD = 5 (INDEPENDENT RISER MODE) This is used in buildings to have  risers with riser entrance panels  and independent audio and video  functions. 2 SC S 2 2 2 2 SC S 2 2 2 ON OUT IN ON OFF ON OUT IN ON OFF SC S ON The building entrance panel must be  made with alphanumeric or numeric call module Entrance panel Riser entrance panel Riser 1 Riser 2 Riser 1 system section (with independent audio) Riser 2 system section (with independent audio) 63435 573998 63435 573998 63439 63439 63435 Riser entrance  panel Common system section 573998 In the common system section, for the purpose of system composition, distances and layout, the system expansion modules  must be treated as a handsets. On the other hand, in the riser system sections they must be treated as entrance panels.

72 System composition APARTMENT INTERFACE   ITEM 63438 This is used to have an apartment  system independent from the  building. In this way, the apartment  system can have private cameras  and entrance panels and can be  integrated with all the MY HOME  applications. As far as the system composition,  distances and topology are  concerned, within the building  system, the interface item 63438  must be treated as a handset. On  the other side, within the apartment  system, it should be treated as an  entrance panel configured with P = 0. 2 2 SC S 2 2 2 2 ON OUT IN ON OFF SC S 2 Entrance panel Apartment system section Handset 63438 63435 63435 573998 Apartment camera Apartment entrance panel Apartment block system section 573998 For the completion of the system, any type of cable  can be used (including existing cables). Maximum  performance and distances are achieved using the  573999 cable. TECHNICAL DATA

73 7 7 73 3 2  WIRE  DOOR  ENTR Y  SY STEM  CA T ALOGUE  -  TECHNICAL  DA T A Configuration To configure means to program the  system. This occurs assigning an  identification and operational mode  number to the devices.  This operation is made inserting  in the appropriate seats some  configurators (numbered from 0  to 9), using a clamp provided with  the power supply or contained in  the case of the configurators or  using the configuration software  (recommended). A seat is left empty corresponds to  the configuration of a zero. In the system exist two different  numerations to identify respectively  the entrance panels (EP) and the  handsets. The numeration of the EP (0-96) is  generally identified by P, while the  address of the handsets (0-99) is  identified by N. On the EP, in addition to the P  address it is necessary to configure  also the N address relating to the  handset from which we would start  to call. On the handsets in addition to the N  address, it is necessary to configure  in P the EP associated to the same  handset, or the entrance panel  on which the door lock and auto- switching ON controls work when the  handset is switched OFF. Example of configured system and its operation Do or lock and aut o-swit ching ON  contr ols in pause fr om apar tment 25 Do or lock and aut o-swit ching ON  contr ols in pause fr om apar tment 1 Call apar tment  Call apar tment 25 Apartment 1 Apartment 25 co n co n tr o tr o ls ls  in in  pau pau se se  fr o fr o ma m a par par tme tme nt nt  1 1 Doo r l oc k an d aut o-swit ch in g O N   co ntr ols in  pau se  fr om a par tment 25 pp Ca l Ca l la l a par par tme tme nt nt  Ca l Ca l Ca l la la l a par par par tme tme tme nt nt nt  25 25 25 Should occur the need to modify the configuration of a device, it is necessary, in addition to change the configurators, take off the power supply to the whole system, wait 1 minute, and then provide voltage again. For each device exist also particular configurations which will be detailed in the product technical sheet. The configurators can be purchased in a case I 26145 or individually 1 2 3 4 5 6 7 8 9 0 S L A 49201 49202 49203 49204 49205 49206 49207 49208 49209 49200 49218 0-9 P = –= – S = – P = –= 1 S = – N = –= 1 P = – N = 2= 5 P = 1 TECHNICAL DATA

74 Configuration SYSTEM EXPANSION MODULE  ITEM 63439 The system expansion module can be  configured in 2 different ways: (the addresses in M with MOD = 0  and MOD = 5 do not conflict with  each other) MOD =  0 for system expansion M  =  specific progressive number for interface Entrance panel 573998 63439 63439 63439 63439 Entrance panel 63439 63439 Video handset Video handset 2 2 2 ON ON OFF ON ON OFF ON ON OFF ON ON OFF ON ON OFF ON ON OFF MOD = 0M = 2 MOD = 0M = 1 MOD = 0M = 1 MOD = 0M = 2 MOD = 0M = 3 MOD = 0M = 4 TECHNICAL DATA

75 7 7 75 5 2  WIRE  DOOR  ENTR Y  SY STEM  CA T ALOGUE  -  TECHNICAL  DA T A APARTMENT INTERFACE 63438 The apartment interface is configured  as a normal handset. The interface  must be configured in a specific  unique way. No other handset can  be configured in N using the same  address, in the same system or on the  same riser with independent audio.  The factory device is configured with  M = 3. Correct configuration Wrong configuration SYSTEM 2 WIRE BUS SYSTEM 63438 63438 WIR E B E 2 WIRE BUS SYSTEM SYSTEM 2 2 2 2 2 2 MOD = 5 for independent audio risers M = specific progressive number indicating the riser number For the common entrance panel, the handsets have address M (riser number) x 100 + N (handset for the riser). Es. Handset N = 20 of the riser 12 for the common EP = 12 x 100 + 20 = 1220 Common entrance panel 63439 63439 63439 63 634 6 39 634 6 39 INDEPENDENT 2 WIRE RISER I IN INDEPENDENT2 2 2  WIR WIR WIR E E RIS RIS ER ER ER R R E E RIS RIS E E INDEPENDENT 2 WIRE RISER I IN INDEPENDENT2 2  2 WIR WIR E E RIS RIS S ER ER INDEPENDENT 2 WIRE RISER I IN INDEPENDENT2 2 2  WIR WIR WIR E E E RIS RIS RIS ER ER ER RE RISE 2 2 2 ON INT EXT ON OFF ON INT EXT ON OFF ON ON OFF ON ON OFF ON ON OFF MOD = 5M = 1 MOD = 5M = 2 MOD = 5M = 39 N = 7 N = 6 N = 5 N = 5 N = 5 N = 6

76 The wiring SYSTEM WIRING The systems can also be wired in 2  modes: in-out wiring STAR wiring with floor shunt  63432 (RECOMMENDED). IN-OUT WIRING IN-OUT wiring is connected directly  on the terminal of the appliances  which are connected to the system. Each riser must be terminated by  positioning the micro switch of the  last handset to ON. IN-OUT wiring is particularly  indicated for one and two-family  systems and for vertical or horizontal  multi-family systems (with the homes  in rows). STAR WIRING The star wiring is made connecting  the individual apartment to an  output of the floor distribution block  Item 63432.  Each line must be terminated by  positioning the micro switch of the  last appliance to ON. STAR wiring is particularly suitable  for multi-family systems, when more  than one living unit on the same floor  or in multi-family systems, where  max. distance between the entrance  panel and all handsets is needed.  On each output of the shunt it will be  possible to connect up to 3 handsets  maximum.   An output of the floor distribution  block must be dedicated to  each handset with simultaneous  switching on or table-top base  installation. Apartment 1 STAR wiring ON Apartment 2 ON Apartment 3 ON Apartment 4 ON IN-OUT wiring 2 WIRE BUS Apartment  n ON Apartment 2 OFF Apartment 3 OFF Apartment 4 OFF ON Apartment 5 ON Apartment 6 ON Apartment 7 ON Apartment 8 63432 63432 Handsets BUS 2 WIRE BUS TECHNICAL DATA

77 7 7 77 7 2  WIRE  DOOR  ENTR Y  SY STEM  CA T ALOGUE  -  TECHNICAL  DA T A COMBINED WIRING Both wiring methods described  previously can be used together, for  the realization of more articulated  systems. The combined wiring (IN-OUT  and Star) allows to execute wiring  systems in order to satisfy the  greatest quantity of requests. Floor distribution blocks outputs  can be used to connect a single  device or to generate an apartment  line (on which max. 3 devices can  be connected, without using the  apartment interface item 63438). To the Bus handset can be connected  in IN-OUT floor distribution blocks or  handsets.  The assignation of the handsets  to the apartments occurs through  configuration (for further information  see technical sheets for the individual  devices). Video entrance panel Video entrance panel V 200 m ON OFF OFF ON OFF Floor shunt 63432 Apartment n ON Apartment 3 OFF ON OFF OFF ON ON ON OFF OFF ON ON Apartment 2 Apartment 1 Entrance panel BUS 2 2 2 2 2 2

78 Installation of entrance panels, handsets and interfaces HEIGHT OF THE HANDSET When installing the handsets, including  standard or video handsets, it is  recommended that the devices are  positioned at a height of 160 – 165 cm  (top edge). Note: recommended installation heights, unless  otherwise required by local regulations. 160 – 165 cm INTERFACES ITEM 63438 AND   63439 The interfaces item 63438  (apartment interface) and item  63439 (system expansion module)  cannot be installed in a manhole. For  their installation, a sealed electric  cabin with DIN rail must be used (DIN  switchboard). HEIGHT OF THE ENTRANCE PANEL When installing the Entrance  panel, it is recommended that the  pushbutton panel is installed at a  height of 160 – 165 cm (top edge). The camera must not be installed in  front of  light sources, or in places  where the subject being filmed is in  the shadow.  If this condition cannot be respected,  the picture will not have much  contrast in the darker areas. This  is because the brightness is self- regulated on the lighter part of the  picture. To solve these problems change the  camera installation height, normally   160 – 165 cm, to a height of 180 cm  and direct the lens downwards to  improve the quality of the shots. In scarcely lit areas, the installation  of an additional light source is  recommended. NOOOOO 160 – 165 cm ON INT ON OF F ON ON OF F ON INT ON OF F ON ON ON OF OF FF TECHNICAL DATA

79 7 7 79 9 2  WIRE  DOOR  ENTR Y  SY STEM  CA T ALOGUE  -  TECHNICAL  DA T A System performance The following information provides  general parameters on the maximum  distances that can be achieved, and  the features of the cables to be used.   The type of system considered is a  single family system or system below  an apartment interface. Note: in systems with apartment interfaces only (in/out connection) the distance of   LINE C to be taken into account is 200 m (with Legrand cable 573999) ( ) Max. variable distance. MAXIMUM DISTANCE LINE A ENTRANCE PANEL  - FURTHEST HANDSET Cable sec tion mm 2 2 normal cables   0.2 mm 2 573999 twist ed t elephone  pair 0.28 mm 2 one pair of the   multi-pair da ta cable ,   item C9881U/5E 5 HANDSETS in/out  50 m 200 m 140 m 140 m 5 one-fam HANDSETS/OUTDOOR EP 50 m 200 m 100 m 70 m 5 one-fam HANDSETS/EP with local power supply 50 m 200 m 140 m 170 m MAXIMUM DISTANCE LINE C POWER SUPPLY – FURTHEST HANDSET Cable sec tion mm 2 2 normal cables   0.2 mm 2 573999 twist ed t elephone  pair 0.28 mm 2 one pair of the   multi-pair da ta cable ,   item  C9881U/5E 5 HANDSETS in/out  50 m 110 m 70 m 50 m 5 HANDSETS (with shunts) 50 m 110 m 70 m 50 m MAXIMUM DISTANCE LINE B ENTRANCE PANEL – POWER SUPPLY Cable sec tion mm 2 2 normal cables   0.2 mm 2 573999 twist ed t elephone  pair 0.28 mm 2 one pair of the   multi-pair da ta cable ,   item  C9881U/5E 2 pushbuttons 50 m 200 m 115 m 90 m OUTDOOR EP 20 m 50 m 30 m 20 m Entrance panel with local power supply 50 m 200 m 140 m 120 MAXIMUM DISTANCE LINE D ENTRANCE PANEL – DOOR LOCK Cable sec tion mm 2 0.28 Le gr and SCS cable -  item 573999 1 S+ S- clamps 30 m 50 m 100 m 573998 LINE B 63435 63434 63438 63439 LINE D Door lock Entrance panel Furthest video handset 63438 63439 Ent Ent Ent ran ran ran ce ce ce pan pan pan el el el Ent ra LINE C LINE A 63435 BUS PI BUS TK PS O WARNING: For installation solutions or types other than those shown,  the distances and the current absorptions can be calculated using the You  Diagram software (which can be downloaded free of charge from the  website www.professionisti.BTicino.it – technical service – software and  diagrams).  Also refer to the specific technical documentation   (2 WIRE system Technical Guide). ON ON OFF ON ON OFF ON INT EXT ON OFF ON INT EXT ON OFF MOD = 0 MOD = 5 e MOD = 0 MOD = 5 e TECHNICAL DATA

80 SYSTEM WITH APARTMENT  INTERFACE AND SYSTEM  EXPANSION MODULE Up to 3 interfaces, items 63438  and 63439 may be installed in  cascade. Cascade interfaces are  those “crossed” by an audio/video  connection (Entrance panel –  HANDSET) or (HANDSET – HANDSET,  e.g.  INTERCOM). Only 2 of these  interfaces (selected by the user)  retransmit the signal for 200 metres. The maximum distance between  EP and the furthest handset is 600  metres. Each LINE (EP – INTERFACE),  (INTERFACE – INTERFACE) and  (INTERFACE – H) must be 200 metres  maximum (with Legrand cable  573999). The IN end cap of the system  expansion module configured with  M=0 MUST be wired and considered  as a H with local power supply. It must also be connected to an  output of the Audio/video node  573998, or the Floor shunt 63432. System performance max. 200 m max. 200 m Video entrance panel Audio/video connection between the entrance panel and the video handset  (3 passages maximum) = OK 63438 max. 200 m 2 2 2 2 63439 max. 200 m ON INT EXT ON OFF 2 2 2 2 2 2 2 2 ON ON OFF 63439 ON ON OFF TECHNICAL DATA

81 8 8 81 1 2  WIRE  DOOR  ENTR Y  SY STEM  CA T ALOGUE  -  TECHNICAL  DA T A CONNECTION OF 16 AUDIO /VIDEO ENTRANCE PANELS OR CAMERAS BUS 2  1 SC S O U T 1 OU T 2 O U T3 OU T 4 I N1 I N 2 I N3 IN4 OUT IN SC S OU T1 OU T 2 O U T3 OU T 4 IN1 I N2 IN3 IN4 OUT IN SC S OUT1 OUT 2 O UT3 OUT 4 IN1 I N 2 IN3 IN4 OUT IN SC S OU T1 OU T 2 O UT 3 OU T 4 IN1 I N2 I N3 I N4 OUT IN SC S O UT 1 O UT 2 O UT 3 O U T 4 I N1 I N 2 I N3 I N4 OUT IN Video door entry system/apartment interface risers 4 entrance panels or cameras 4 entrance panels or cameras 4 entrance panels or cameras 4 entrance panels or cameras 03589 03589 03589 03589 573998 573998 573998 573998 573998 63435

82 One-family system with 1 EP  and 5 intercommunicating video handsets ITEM DESCRIPTION 3429913441636343163435573998LEPPSS1 Linea 2000 Metal EPPolyx Memory Display video handsetStaircase light actuator (optional)Power supplyAudio/video nodeStaircase lightEntrance panelDoor lock release pushbutton (optional)Electric door lock 18V 4A impulsive 250mA holding current BUS BUS BUS BUS BUS BUS 2  1 SC S OU T1 OU T 2 O UT3 OUT 4 IN1 I N 2 IN3 IN4 OUT IN BUS PL S+ S- PS S1 NC NO C L 2 1 4 3 6 5 8 7 Configure the handsets starting from N = 1Configure and insert the Jumpers with the system SWITCHED OFF. Also every time the configuration is modified the power supply to the system must be switched off and on again, waiting about 1 minute.The intercom function is operating even with a lack of entrance panel connection.We recommend that the video handsets are configured using the software supplied with the product. A A A A    Use of the actuator is necessary for the staircase light  service or generic actuations. B B B B   For the Entrance Panel, all the pushbutton panels of the 2  wire range can be used C C C C   Move the micro switch of the last video or audio handset  at the end of the line to the ON position D D D D   Fit a “9” configurator to be inserted in S on the  speaker module for the general call; do not insert any configurator in N. E E E E   The audio video answering machine can only be used on  1 video handset (the one configured with N=1) Electric distribution board or My Home Flatwall ON OFF OFF N = –= 3 P = –M = – N = –= 2 P = –M = – N = –= 1 P = –M = – OFF OFF N = –= 5 P = –M = – N = –= 4 P = –M = – 344163 344163 344163 342991 573998 63435 230 Vac 63431 A A A A E E E E DEVICE 3 DEVICE 2 DEVICE 1 DEVICE 5 DEVICE 4 B B B B P = –= – N = –= – T = –S = 9 9 9 9 D D D D 344163 344163 230 Vac  WARNING EP C C C C

83 8 8 83 3 2  WIRE  DOOR  ENTR Y  SY STEM  CA T ALOGUE  -  TECHNICAL  DA T A Two-family systems with 1 EP,  3 handsets per home and intercom between apartments Configure and insert the Jumpers with the system SWITCHED OFF. Also every time the configuration is modified the power supply to the system must be switched off and on again, waiting about 1 minute.It is possible to install a maximum of 3 video handsets for apartment.We recommend that the video handsets are configured using the software supplied with the productConfigure Master and Slave devices using the software When a call is received, the MASTER rings and switches on, while the SLAVE will only ring. If the call is answered from a SLAVE unit, the master unit switches off again, while the monitor of the SLAVE from where the call is answered comes on." A A A A   Move the micro switch at the back of the last video or  audio handset at the end of the line to the ON position B B B B   For the Entrance Panel, all the pushbutton panels of the 2  wire range can be used. C C C C   The audio video answering machine can only be used on  1 video handset (the MASTER video handset) ITEM DESCRIPTION 34299234416363435573998EPPSS1 Two-family Linea 2000 Metal entrance panelPolyx Memory Display video handsetPower supplyAudio/video nodeEntrance panel (main)Door lock release pushbutton (optional)Electric door lock 18V 4A impulsive 250mA holding current BUS BUS BUS BUS BUS BUS 2  1 S C S O U T 1 OU T 2 O U T3 O U T 4 IN1 I N 2 IN3 IN4 OUT IN BUS PL S+ S- PS S1 BUS Electric distribution board or My Home Flatwall  WARNING N = –= 1 P = –M = – ON 344163 N = –= 1 P = –M = – 344163 C C C C A A A A C C C C N = –= 1 P = –M = – N = –= 2 P = –M = – N = –= 2 P = –M = – N = –= 2 P = –M = – 344163 344163 344163 344163 OFF OFF OFF OFF 573998 63435 230 Vac 342992 P = –= – N = –= 1 T = –S = – B B B B A A A A ON EP MASTER MASTER SLAVE SLAVE SLAVE SLAVE HOME 2 HOME 1

84 One-family system with 2 EP and 2 outdoor cameras BUS PL S+ S- PS S1 BUS 2  1 SC S OUT1 OUT 2 O UT 3 OUT 4 IN1 I N2 IN3 IN4 OUT IN BUS BUS BUS PL S+ S- PS1 S2 ITEM DESCRIPTION 34299134932157398663435573998PE-PE1PS-PS1S1-S2Cam.1-Cam.2 Linea 2000 Metal entrance panel Whice Axolute Video Station 2 wire outdoor cameraPower supplyAudio/video nodeEntrance panel Door lock release pushbutton (optional)Electric door lock 18V 4A impulsive 250mA holding current2 wire outdoor camera  WARNING Configure and insert the Jumpers with the system SWITCHED OFF. Also every time the configuration is modified the power supply to the system must be switched off and on again, waiting about 1 minute.We recommend that the video handsets are configured using the software supplied with the product.End with the micro switch of the last line/riser handset in the ON position.    A A A A  For the Entrance Panel, all the pushbutton panels of the  2 wire range can be used.    B B B B  Fit a “9” configurator to be inserted in S on the Entrance  panel to make a general call. 349321 349321 230 Vac 573998 63435 342991 342991 573986 573986 P = –= – N = –= 1 T = –S = 9 9 9 9 B B B B P = –= 1 N = –= 1 T = –S = 9 9 9 9 B B B B P = –= 2 N = –Z = –M = –A = –PL = – P = –= 3 N = –Z = –M = –A = –PL = – N = –= 2 P = –M = – N = –= 1 P = –M = – BUS PI  (5 handsets max.) Electric distribution board or  My Home Flatwall EP EP1 Cam.1 Cam. 2 A A A A A A A A DEVICE 2 DEVICE 1 OFF                                OFF

85 8 8 85 5 2  WIRE  DOOR  ENTR Y  SY STEM  CA T ALOGUE  -  TECHNICAL  DA T A S C S O UT 1 O U T 2 O U T 3 OU T 4 I N1 I N 2 I N3 I N4 OUT IN BUS BUS BUS BUS BUS BUS 2  1 BUS PL S+ S- PS S1 1 2 PRI 1- 2 346020 PRI:  220 – 240 V~   175 – 165 mA  47/63  Hz SCS: 27 Vdc 600  mA 1 2 PRI 1- 2 346020 PRI:  220 – 240 V~   175 – 165 mA  47/63  Hz SCS: 27 Vdc 600  mA 1 2 PRI 1- 2 346020 PRI:  220 – 240 V~   175 – 165 mA  47/63  Hz SCS: 27 Vdc 600  mA 1 2 PRI 1- 2 346020 PRI: 220  –  240  V~    175 – 165 mA  47/63  Hz SCS: 27 Vdc 600  mA 1 2 PRI 1- 2 346020 PRI: 220  –  240  V~    175 – 165 mA  47/63  Hz SCS: 27 Vdc 600  mA NC NO C L 2 1 4 3 6 5 8 7 One-family system with 5 video handsets in simultaneous switching on ITEM DESCRIPTION 342991 3441636343534602057399863431PSS1 Flush mounted Linea 2000 Metal entrance panelPolyx Memory Display video handsetSystem power supplyAdditional power supply Audio/video node Staircase light actuator (optional)Door lock release pushbutton panelElectrical door lock Configure the handsets starting from N = 1Configure and insert the Jumpers with the system SWITCHED OFF. Also every time the configuration is modified the power supply to the system must be switched off and on again, waiting about 1 minute.We recommend that the video handsets are configured using the software supplied with the product     Use of the actuator is necessary for the staircase light  service or generic actuations.    For the Entrance Panel, all the pushbutton panels of the 2  wire range can be used.    Move to ON the microswitch, on the Video handset or  audio handset, which ends the line.     Fit a “9” configurator to be inserted in S on the  speaker module for the general call; do not insert any configurator in N.     The audio video answering machine can only be used on  1 video handset item 344163  WARNING ON N = –= 5 P = –M = – 346020 344163 230 Vac 573998 63435 342991 EP P = –= – N = –= – T = –S = 9 9 9 9 D D D D 63431 B B B B ON N = –= 4 P = –M = – 346020 344163 ON N = –= 3 P = –M = – 346020 344163 230 Vac 230 Vac 230 Vac ON N = –= 2 P = –M = – 346020 344163 230 Vac OFF                                N = –= 1 P = –M = – 346020 344163 230 Vac 230 Vac

86 OFF One-family system with max. 16 cameras  or entrance panels BUS 2  1 BUS BUS PL S+ S- PS S1 D D D D BUS 2  1 OFF BUS B B B B N = –= 1 P = –M = – 349320 To other handsets / apartment interfaces To other handsets / apartment interfaces 230 Vac 573998 573998 63435 3499 P = –= – N = –= 1 T = –S = 9 342991 573986 573986 573986 P = –= 1 N = –Z = –M = –A = –PL = – P = –= 2 N = –Z = –M = –A = –PL = – P = –= 3 N = –Z = –M = –A = –PL = – C C C C PE Cam.1 Cam.2 ITEM DESCRIPTION 0358934932057399863435342991573986EPPSS1Cam1-Cam3Cam4-Cam7 Line terminatorAxolute Video Station NighterAudio/video nodePower supplyLinea 2000 Metal EP2 wire outdoor cameraEntrance panelDoor lock release pushbutton (optional) Electrical door lockOutdoor cameraIndoor camera Cam.3 A A A A DEVICE 1

87 8 8 87 7 2  WIRE  DOOR  ENTR Y  SY STEM  CA T ALOGUE  -  TECHNICAL  DA T A P = –= 4 N = –Z = –M = –A = –PL = – P = –= 5 N = –Z = –M = –A = –PL = – P = –= 6 N = –Z = –M = –A = –PL = – P = OFF= 7 N = –Z = –M = –A = –PL = – 573998 573998 573998 03589 03589 03589 Cam. 4 To other entrance panels or other common cameras(configured with P= 8 – P= 11)   To other entrance panels or other common cameras(configured with P= 12 – P= 15)   When the nodes are used in cascade, the distances of the various lines are halved.   For the Entrance Panel, all the pushbutton panels of the 2  wire range can be used.   All the advanced  video handsets of the 2 wire range may  be installed.   Only use one output for each node and allow for a  terminator item 03589 to be connected to the SCS clamp   Configure advanced handsets using a PC and Software  supplied.   By entering OFF in the first seats of the P configurators,  the microphone of the 2 wire cameras is excluded (this function is only possible for cameras 0 to 9. The microphone cannot be excluded on the other cameras).   WARNING Cam. 5 Cam. 6 Cam. 7 COLOUR INDOOR CAMERAS AVAILABLE IN THE FOLLOWING FINISHES: 391658391659391657 LIGHTLIGHT TECHLIVING PL PL PL = = = – PL L L = = = – PL PL PL = = = – PL = = = –

88 CONTENTS 88 2 WIRE CATALOGUE - DIMENSIONAL DATA  Entrance panels  89 Handsets 93 Accessory devices in BASIC housing  96 Accessory devices in DIN housing  96 Melodic and extra bells  98 Indoor cameras (flush mounted)  98 Outdoor camera  98

89 8 8 89 9 2  WIRE  DOOR  ENTR Y  SY STEM  CA T ALOGUE  -  DIMENSIONAL  DA T A 139 27.5 339213Steel surround plate.  Protrusion from the wall: 11 mm NOTE: dimensions in mm 104 300 50 84 253 35.5 339313 349140 AXOLUTE OUTDOOR entrance panels DIMENSIONAL DATA FLUSH MOUNTED BOX SURROUND PLATES + FRAME ELECTRONIC MODULE 330

90 NOTE: dimensions in mm SFERA entrance panels FLUSH MOUNTED BOXES MODULAR SFERA WALL MOUNTED ENCLOSURES SFERA ALL FUNCTION MODULES SFERA MODULAR RAINSHIELDS SFERA MODULAR SURROUND PLATES DIMENSIONS IN mm Item A    B C 331110 117 123  45331120 117 214  45331130 117 306  45 DIMENSIONS IN mm Item A   B  C 331411 151  151  50331421 151  242  50331431 151  334  50331441 290  242  50331461 290  334  50331491 430  334  50 A A A C C A B B B B C C DIMENSIONS IN mm Item A   B C 331311 150  154  92331321 150  245  92331331 150  337  92331341 289  245  92331361 289  337  92331391 428  337  92 DIMENSIONS IN mm Item A   B 331211 140  142331221 140  233331231 140  325331821 125  233331831 125  325 100 89 DIMENSIONAL DATA

91 9 9 91 1 2  WIRE  DOOR  ENTR Y  SY STEM  CA T ALOGUE  -  DIMENSIONAL  DA T A SFERA entrance panels DIMENSIONAL DATA MONOBLOC SFERA FRONT COVERS VANDAL-RESISTANT SFERA A A B B DIMENSIONS IN mm No. of modules A   B   1 140  142 2 140  233 3 140  325 DIMENSIONS IN mm Item A    B   C 333915 150 401.5 5 DIMENSIONS IN mm Item A    B   C 333714 150 198 4 Video and keypad pushbutton panels Audio pushbutton panels A A A C C C B B B NOTE: dimensions in mm DIMENSIONS IN mm Item A    B   C 333914 40  284 4 Video pushbutton panels

92 LINEA 2000 entrance panels DIMENSIONAL DATA AUDIO AND VIDEO PUSHBUTTON PANELS 176 98 31 342951342961 342911342921 NOTE: dimensions in mm LINEA 2000 METAL entrance panels WALL AUDIO AND VIDEO PUSHBUTTON PANELS 106 35 185 342991342992 342981342982 342971342972

93 9 9 93 3 2  WIRE  DOOR  ENTR Y  SY STEM  CA T ALOGUE  -  DIMENSIONAL  DA T A AXOLUTE handsets MULTIMEDIA TOUCH SCREEN VIDEO STATION NIGHTER AND WHICE VIDEO STATION 349210 - 349211 - 349212 349310 349320349321 HD4690 - HC4690 - HS4690 154 251 10 226 305 161 256 36 305 230 OK C 25 NOTE: dimensions in mm 305 17 228 DIMENSIONAL DATA

94 AXOLUTE handsets POLYX handsets DIMENSIONAL DATA AXOLUTE VIDEO DISPLAY TABLE-TOP BASE POLYX AUDIO POLYX VIDEO - POLYX MEMORY DISPLAY For AXOLUTE VIDEO DISPLAY 10.5 118 127 127 130 9.5 30.2 349311349312 349319 124.5 168 128 151 30 30 NOTE: dimensions in mm 344082 344192344182344163

95 9 9 95 5 2  WIRE  DOOR  ENTR Y  SY STEM  CA T ALOGUE  -  DIMENSIONAL  DA T A PIVOT handsets PIVOT AUDIO AND VIDEO HANDSET MULTIBOX FLUSH MOUNTED BOXES  NOTE: dimensions in mm 70 68,5 68.5 210 210 210 Item Internal  External    dimensions (mm)  dimensions (mm) 16101 84x218x69  110x243x7016103 224x218x69  250x243x70 344032 344102344122 DIMENSIONAL DATA

96 SWING handsets SPRINT handsets Devices in BASIC housing DIMENSIONAL DATA 321 3210 SWING AUDIO AND VIDEO HANDSETS SPRINT AUDIO HANDSETS COAX INTERFACE - 2 WIRES FLOOR CALL INTERFACE VIDEO SHUNT - 2 WIRES 90 101 56 210 215 215 56 56 216 PZ N PZ N 40 40 40 18 18 18 40 40 40 344704 574038 346833 63432 344832344824 344212 NOTE: dimensions in mm

97 9 9 97 7 2  WIRE  DOOR  ENTR Y  SY STEM  CA T ALOGUE  -  DIMENSIONAL  DA T A UNIVERSAL SPEAKER MODULE LINE AMPLIFIER 90 B C 35 15 26 55 52 Item  Dimensions (mm)    No. of DIN modules   A B  C 63435 90  140  61  863442 105  35 30 2  346030  105  35 30 2  63431 90 72 61 4 63433 105  35 30 2  346260  105  70 30 4 63434 105  35 30 2 63438 90 72 30 463439 90 72 30 4574039 90  175  60  10 573998 90  105  30  6 03584 90  175  30  10 F442 90 105 30 6  DIN RAIL DEVICES A NOTE: dimensions in mm 346991 346870 Devices in BASIC housing DIMENSIONAL DATA

98 Bells and cameras DIMENSIONAL DATA MELODIC BELLS EXTRA BELLS 43 65 38 100 43 43 48 43 39 48 346982346983346984 391657391658391659 391670 391667391668391669 336992336993336994 FLUSH MOUNTED INDOOR CAMERAS OUTDOOR CAMERA LIVING, LIGHT, LIGHT TECH and AXOLUTE cameras

99 9 9 99 9 2  WIRE  DOOR  ENTR Y  SY STEM  CA T ALOGUE  -  NUMERIC  INDEX NUMERIC INDEX     Item  Catalogue page  Dimensional data page     Item  Catalogue page  Dimensional data page 03584 40  97 26145 43  - 49200 43  - 49201 43  - 49202 43  - 49203 43  - 49204 43  - 49205 43  - 49206 43  - 49207 43  - 49208 43  - 49209 43  - 63431 41  97 63432 42  96 63433 41  97 63434 40  97 63435 40  97 63438 41  97 63439 41  97 63442 40  97 331110 50  90 331120 49  90 331130 17  90 331311 17  90 331321 17  90 331331 17  90 331341 17  90 331361 17  90 331391 17  90 331411 17  90 331421 17  90 331431 17  90 331441 17  90 331461 17  90 331491 17  90 332650 14  - 333714 15  91 333914 15  91 333915 15  91 336842 52  - 336910 44  - 336982 35  - 336992 44  98 336993 44  98 336994 44  98 337102 35  - 337122 35  - 337242 38  - 339213 12  89 339313 12  89 342150 17  - 342170 13  - 342200 13  - 342240 13  - 342350 17  -  342480 17  - 342510   14  - 342550 14  - 342560 17  - 342600 14  - 342610 14  -  342630 13  - 342640 13  - 342911 24  92 342921 24  92 342951 24  92 342961 24  92 342971 23  92 342972 23  92 342981 23  92 342982 23  92 342991 23  92 342992 23  92 344032 35  95 344082 34  94 344102 35  95 344122 35  95  344163 34  94 344182 34  94 344192 34  94 344212 38  96 344704 37  96
